Dodge RAM 3500  (1994 – 1997) – fuse and relay box diagram

Dodge RAM 3500  (1994 – 1997) – fuse and relay box diagram

Year of production: 1994, 1995, 1996, 1997



The Dodge Ram 3500 (1994–1997) is a heavy-duty truck from Dodge’s second generation of Ram pickups, renowned for its strength, durability, and impressive towing and payload capacity. The 1994 redesign marked a revolutionary shift for Dodge, with the introduction of the iconic big-rig-inspired design and a focus on making the Ram 3500 a go-to vehicle for those in need of serious power. This generation of the Ram 3500 was popular among contractors, farmers, and others needing a truck that could handle the most demanding tasks.



Passenger Compartment Fuse Box

Fuse Box Location

The fuse panel is located behind the cover on the driver’s side of the instrument panel.

Dodge RAM 1500 (1994 - 1997) - fuse and relay location - passenger compartment
Dodge RAM 3500 (1994 – 1997) – fuse and relay location – passenger compartment



Fuse Box Diagram

Dodge RAM 1500 (1994 - 1997) - fuse and relay diagram - passenger compartment
Dodge RAM 3500 (1994 – 1997) – fuse and relay diagram – passenger compartment



Assignment of fuses in the passenger compartment (1994-1997)

No.
A
Protected Component
1 20 ’96-’97: Power Outlet
2  –
3  –
4  –
5 20 Cigar Lighter, Power Outlet (’94-’95)
6 15 ’94-’95: Turn Signal Flasher
20 ’96-’97: Turn Signal Flasher
7 10 ’94-’95: Radio
15 ’96-’97: Radio
8 20 Intermittent Wiper Control Module, Remote Keyless Entry (’96-’97), Intermittent Wiper Switch, Windshield Wiper Motor, A/C Clutch (Diesel (’94-’95))
9 10 Fuel Pump Relay, A/C Compressor Clutch Relay, Automatic Shutdown Relay, Transmission Overdrive Solenoid, EGR Solenoid, Powertrain Control Module (PCM), Ignition Module, High Pressure Fuel Shut-Off Solenoid Relay (CNG Models Only), EGR Solenoid (CNG Models Only), Fuel Shutdown Solenoid, Heated Intake Air System Relays, Diagnostic Connector, Automatic Shut Down Relay, Duty Cycle EVAP/Purge Solenoid
10 2 ’94-’95: Vehicle Speed Control
11 10 Overdrive Switch, Buzzer Module, Overhead Console
12 15 Airbag Diagnostic Module, Instrument Cluster, Message Center, Diesel Wait-To-Start and Water-In Fuel Lamps.
13 5 Illumination, Fog Lamp Switch, Overdrive Switch, Instrument Cluster, A/C Heater Control, Overhead Console, Radio
14 20 ’94-’95: RWAL and ABS Module
20 ’96-’97: Control Anti-Lock Brake, ABS Pump Motor Relay, ABS Warning Lamp Relay, Vacuum Sensor
15 15 Automatic Day/Night Mirror, Back-up Lights (Park/Neutral Position Switch (A/T), Back-Up Lamp Switch (M/T), Daytime Running Lamps
16 15 Airbag Diagnostic Module
17 15 Ignition Off Draw, Clock Memory, Underhood Lamp, Power Mirror Switch, Time Delay Relay, Buzzer Module, Data Link Connector, Radio Choke Relay, Glove Box Lamp Switch, Radio
18 15 ’94-’95: Parking Lamps
15 ’96-’97: Headlamp Switch, Radio, Overhead Console, Fog Lamp Relay
19 20 Power Door Locks
20 15 Stop Lamps, Controller Anti-Lock Brake (’96-’97)
21  –
22 30 Blower Motor
CB1 30 Circuit Breaker: Power Windows
CB2 30 Circuit Breaker: Power Seats
Relay
R1 Time Delay
R2 Hazard Warning Flasher
R3 Turn Signal Flasher

Engine Compartment Fuse Box

Fuse Box Location

The fuse box is near the battery.

Dodge RAM 1500 (1994 - 1997) - fuse and relay location - engine compartment
Dodge RAM 3500 (1994 – 1997) – fuse and relay location – engine compartment



Fuse Box Diagram

’94-’95:

Dodge RAM 1500 (1994 - 1995) - fuse and relay diagram - engine compartment
Dodge RAM 3500 (1994 – 1995) – fuse and relay diagram – engine compartment



’96-’97:

Dodge RAM 1500 (1996 - 1997) - fuse and relay diagram - engine compartment
Dodge RAM 3500 (1996 – 1997) – fuse and relay diagram – engine compartment



Assignment of fuses and relay in the engine compartment (1994-1997)

No.
A
Protected Component
1 50 Power Distribution Center, Fuse Block
2 40 Fuse Block, Ignition Switch, Ignition Starter Motor Relay
3 40 Ignition Switch, Fuse Block
4 30 Automatic Shut Down Relay, Oxygen Sensors, Powertrain Control Module (PCM), Fuel Injectors, Ignition Coils, EGR Control Module
5 20 ’94-’95: Fuel Pump
40 ’96-’97: ABS Pump Motor Relay, Hydraulic Control Unit, Controller Anti-Lock Brake & Rear Wheel Anti-Lock Valve
6 30 ’94-’95: Trailer Lamps
40 ’96-’97: Daytime Running Lamp Module, Fuse Block, Headlamp Switch, Headlamp Dimmer Switch
7 40 ’94-’95: Stop/Headlamp
’96-’97: Electronic Brake Provision, Trailer Tow Relay, Trailer Toe Connector
8 40 ’94-’95: ABS Pump
20 ’96-’97: Fuel Pump Relay, Transmission Control Relay, Powertrain Control Module, Fuel Pump Module, Transmission Solenoid Assembly
9 15 ’96-’97: Fog Lamp Relay, Fog Lamp Switch
10 20 A/C Compressor Clutch, Horn Relay
11 15 ’94-’95: Hazard Warning Flasher
20 ’96-’97: Hazard Warning Flasher
12 120 Generator
Relay
R1 Anti-Lock Brake System / Dual Tank 3
R2 Starter
R3 ’94-’95: ABS Warning Light
’96-’97: Automatic Shut Down
R4 Fuel Pump
R5 ’94-’95: Trailer Lamps
’96-’97: Fog Lamp (No.1) / Dual Tank 1
R6 ’94-’95: Horn
’96-’97: Fog Lamp (No.2) / Dual Tank 2
R7 ’94-’95: Air Conditioning Clutch
’96-’97: ABS Warning Light
R8 ’94-’95: Automatic Shut Down
’96-’97: Trailer
R9 ’96-’97: Horn
R10 ’96-’97: Air Conditioning Clutch
R11 ’96-’97: Transmission Control

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Dodge RAM 2500  (1994 – 1997) – fuse and relay box diagram

Dodge RAM 2500  (1994 – 1997) – fuse and relay box diagram

Year of production: 1994, 1995, 1996, 1997



The Dodge Ram 2500 (1994–1997) was part of the second generation of Dodge Ram trucks, which saw a complete redesign in 1994. This generation brought Dodge back into the spotlight in the truck market due to its bold new styling and heavy-duty performance. The Ram 2500 was positioned between the lighter-duty Ram 1500 and the heavy-duty Ram 3500, making it a popular choice for buyers who needed a capable work truck with substantial towing and payload capacity.



Passenger Compartment Fuse Box

Fuse Box Location

The fuse panel is located behind the cover on the driver’s side of the instrument panel.

Dodge RAM 1500 (1994 - 1997) - fuse and relay location - passenger compartment
Dodge RAM 2500 (1994 – 1997) – fuse and relay location – passenger compartment



Fuse Box Diagram

Dodge RAM 1500 (1994 - 1997) - fuse and relay diagram - passenger compartment
Dodge RAM 2500 (1994 – 1997) – fuse and relay diagram – passenger compartment



Assignment of fuses in the passenger compartment (1994-1997)

No.
A
Protected Component
1 20 ’96-’97: Power Outlet
2  –
3  –
4  –
5 20 Cigar Lighter, Power Outlet (’94-’95)
6 15 ’94-’95: Turn Signal Flasher
20 ’96-’97: Turn Signal Flasher
7 10 ’94-’95: Radio
15 ’96-’97: Radio
8 20 Intermittent Wiper Control Module, Remote Keyless Entry (’96-’97), Intermittent Wiper Switch, Windshield Wiper Motor, A/C Clutch (Diesel (’94-’95))
9 10 Fuel Pump Relay, A/C Compressor Clutch Relay, Automatic Shutdown Relay, Transmission Overdrive Solenoid, EGR Solenoid, Powertrain Control Module (PCM), Ignition Module, High Pressure Fuel Shut-Off Solenoid Relay (CNG Models Only), EGR Solenoid (CNG Models Only), Fuel Shutdown Solenoid, Heated Intake Air System Relays, Diagnostic Connector, Automatic Shut Down Relay, Duty Cycle EVAP/Purge Solenoid
10 2 ’94-’95: Vehicle Speed Control
11 10 Overdrive Switch, Buzzer Module, Overhead Console
12 15 Airbag Diagnostic Module, Instrument Cluster, Message Center, Diesel Wait-To-Start and Water-In Fuel Lamps.
13 5 Illumination, Fog Lamp Switch, Overdrive Switch, Instrument Cluster, A/C Heater Control, Overhead Console, Radio
14 20 ’94-’95: RWAL and ABS Module
20 ’96-’97: Control Anti-Lock Brake, ABS Pump Motor Relay, ABS Warning Lamp Relay, Vacuum Sensor
15 15 Automatic Day/Night Mirror, Back-up Lights (Park/Neutral Position Switch (A/T), Back-Up Lamp Switch (M/T), Daytime Running Lamps
16 15 Airbag Diagnostic Module
17 15 Ignition Off Draw, Clock Memory, Underhood Lamp, Power Mirror Switch, Time Delay Relay, Buzzer Module, Data Link Connector, Radio Choke Relay, Glove Box Lamp Switch, Radio
18 15 ’94-’95: Parking Lamps
15 ’96-’97: Headlamp Switch, Radio, Overhead Console, Fog Lamp Relay
19 20 Power Door Locks
20 15 Stop Lamps, Controller Anti-Lock Brake (’96-’97)
21  –
22 30 Blower Motor
CB1 30 Circuit Breaker: Power Windows
CB2 30 Circuit Breaker: Power Seats
Relay
R1 Time Delay
R2 Hazard Warning Flasher
R3 Turn Signal Flasher

Engine Compartment Fuse Box

Fuse Box Location

The fuse box is near the battery.

Dodge RAM 1500 (1994 - 1997) - fuse and relay location - engine compartment
Dodge RAM 2500 (1994 – 1997) – fuse and relay location – engine compartment



Fuse Box Diagram

’94-’95:

Dodge RAM 1500 (1994 - 1995) - fuse and relay diagram - engine compartment
Dodge RAM 2500 (1994 – 1995) – fuse and relay diagram – engine compartment



’96-’97:

Dodge RAM 1500 (1996 - 1997) - fuse and relay diagram - engine compartment
Dodge RAM 2500 (1996 – 1997) – fuse and relay diagram – engine compartment



Assignment of fuses and relay in the engine compartment (1994-1997)

No.
A
Protected Component
1 50 Power Distribution Center, Fuse Block
2 40 Fuse Block, Ignition Switch, Ignition Starter Motor Relay
3 40 Ignition Switch, Fuse Block
4 30 Automatic Shut Down Relay, Oxygen Sensors, Powertrain Control Module (PCM), Fuel Injectors, Ignition Coils, EGR Control Module
5 20 ’94-’95: Fuel Pump
40 ’96-’97: ABS Pump Motor Relay, Hydraulic Control Unit, Controller Anti-Lock Brake & Rear Wheel Anti-Lock Valve
6 30 ’94-’95: Trailer Lamps
40 ’96-’97: Daytime Running Lamp Module, Fuse Block, Headlamp Switch, Headlamp Dimmer Switch
7 40 ’94-’95: Stop/Headlamp
’96-’97: Electronic Brake Provision, Trailer Tow Relay, Trailer Toe Connector
8 40 ’94-’95: ABS Pump
20 ’96-’97: Fuel Pump Relay, Transmission Control Relay, Powertrain Control Module, Fuel Pump Module, Transmission Solenoid Assembly
9 15 ’96-’97: Fog Lamp Relay, Fog Lamp Switch
10 20 A/C Compressor Clutch, Horn Relay
11 15 ’94-’95: Hazard Warning Flasher
20 ’96-’97: Hazard Warning Flasher
12 120 Generator
Relay
R1 Anti-Lock Brake System / Dual Tank 3
R2 Starter
R3 ’94-’95: ABS Warning Light
’96-’97: Automatic Shut Down
R4 Fuel Pump
R5 ’94-’95: Trailer Lamps
’96-’97: Fog Lamp (No.1) / Dual Tank 1
R6 ’94-’95: Horn
’96-’97: Fog Lamp (No.2) / Dual Tank 2
R7 ’94-’95: Air Conditioning Clutch
’96-’97: ABS Warning Light
R8 ’94-’95: Automatic Shut Down
’96-’97: Trailer
R9 ’96-’97: Horn
R10 ’96-’97: Air Conditioning Clutch
R11 ’96-’97: Transmission Control

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Dodge Neon (1994 – 1999) – fuse and relay box diagram

Dodge Neon (1994 – 1999) – fuse and relay box diagram

Year of production: 1994, 1995, 1996, 1997, 1998, 1999



The Dodge Neon was a compact car produced by Chrysler Corporation under the Dodge brand, from 1994 to 2005. Known for its affordability, sporty handling, and peppy performance, it was one of the more exciting economy cars of its era.



First Generation (1994–1999), Second Generation (2000–2005), Dodge Neon SRT-4 (2003–2005)



Passenger Compartment Fuse Box

Fuse box location

The fuse panel is located behind the cover on the driver’s side of the dashboard.

Dodge Neon (1994 - 1999) - fuse and relay location - passenger compartment
Dodge Neon (1994 – 1999) – fuse and relay location – passenger compartment



Fuse box Diagram

Dodge Neon (1994 - 1999) - fuse and relay diagram - passenger compartment
Dodge Neon (1994 – 1999) – fuse and relay diagram – passenger compartment



Assignment of fuses in the passenger compartment

No.
A
Circuit Protected
1 15 Cigar Lighter/Power Outlet
2 15 Headlamp Switch (Park Lamp, Tail Lamp, License Lamp, Radio, Front Fog Lamp Switch, Remote Keyless Entry Module (’98-’99))
3 20 Door Lock Switch, Remote Keyless Entry Module (’98-’99), Immobilizer (’98-’99)
4 10 Fog Lamp Switch
5 10 ’95-’97: A/C Cycling Switch, Back-Up Lamp (Back-Up Lamp Switch M/T), Park/Neutral Position Switch (A/T), Rear Window Defogger Switch
10 ’98-’99 (LHD): Airbag Control Module
10 ’98-’99 (RHD): A/C Cycling Switch, Back-Up Lamp (Back-Up Lamp Switch M/T), Park/Neutral Position Switch (A/T), Rear Window Defogger Switch, High Speed Warning Module
6 10 Turn Signal/Hazard
7 25 A/C Heater Blower Motor
8 10 ’95-’97: Airbag Control Module
10 ’98-’99 (LHD): A/C Cycling Switch, Back-Up Lamp (Back-Up Lamp Switch M/T), Park/Neutral Position Switch (A/T), Rear Window Defogger Switch, High Speed Warning Module
10 ’98-’99 (RHD): Airbag Control Module
9 4 ’95-’97: Instrument Cluster, Radio, Ash Receiver Lamp, Rear Window Defogger Switch, “PRNDL” Lamp, Rear Fog Lamp Switch, A/C Heater Control Switch, Headlamp Leveling Switch
10 ’98-’99 (LHD): Airbag Control Module
4 ’98-’99 (RHD): Instrument Cluster, Radio, Ash Receiver Lamp, Rear Window Defogger Switch, “PRNDL” Lamp, Rear Fog Lamp Switch, A/C Heater Control Switch, Headlamp Leveling Switch
10 15 Powertrain Control Module, Air Conditioner Compressor Clutch Relay, ABS, Vapor Canister Leak Detector, Torque Converter Clutch Solenooid (A/T), Duty Cycle EVAP/Purge Solenoid, ABS Relay Box, EGR Transducer Solenoid, ABS Warning Lamp Relay
11 5 Instrument Cluster, Daytime Running Lamp Module (’98-’99), Remote Keyless Entry Module (’98-’99), Immobilizer (’98-’99)
12 10 ’95-’97: Airbag Control Module
4 ’98-’99 (LHD): Instrument Cluster, Radio, Ash Receiver Lamp, Rear Window Defogger Switch, “PRNDL” Lamp, Rear Fog Lamp Switch, A/C Heater Control Switch, Headlamp Leveling Switch
10 ’98-’99 (RHD): Airbag Control Module
13  –
14 20 Sunroof
15 20 Wiper Motor, Wiper/Washer Switch, Intermittent Wiper/Washer Switch, Cigar Lighter Relay
16 10 Radio
17 10 Left Headlamp, Left/Right Headlamp Leveling Motor
18 10 Right Headlamp
19  –
20  –
Circuit Breaker
CB1 30 Power Window, Power Window
CB2  –
Relay
R1 ’98-’99 (LHD): Time Delay
R2 ’95-’97: Cigar Lighter
’98-’99 (LHD): Combination Flasher
’98-’99 (RHD): Cigar Lighter
R3 ’95-’97: Combination Flasher
’98-’99 (LHD): Time Out
’98-’99 (RHD): Combination Flasher



Engine Compartment Fuse Box

Fuse box location

Dodge Neon (1994 - 1999) - fuse and relay location - engine compartment
Dodge Neon (1994 – 1999) – fuse and relay location – engine compartment



Fuse box diagram

Dodge Neon (1994 - 1999) - fuse and relay diagram - engine compartment
Dodge Neon (1994 – 1999) – fuse and relay diagram – engine compartment



Assignment of fuses and relay in the engine compartment

No.
A
Protected Component
2 40 Ignition Switch (Fuse (Passenger Compartment): “5”, “6”, “7”, “8”, “CB1”)
3 40 Headlamp Switch, Fuse (Passenger Compartment): “1”, “3”, “4”
5 30 Solid State Fan Relay (Radiator Fan)
8 30 Rear Window Defogger
10 40 ABS Relay Box
11 30 Starter Relay, Ignition Switch (Clutch Pedal Position Switch (M/T), Fuse (Passenger Compartment): “10”, “11”, “12”, “14”, “15”, “16”)
13 10 Dome Lamp, Trunk Lamp, Underhood Lamp, Instrument Cluster, Radio, Glove Box Lamp, Map/Reading Lamp, Visor/Vanity Lamp, Power Mirror Switch, High Speed Warning Module (’98-’99), Time Delay Relay (’98-’99), Time Out Relay (’98-’99)
16 20 Fog Lamp Relay, Rear Fog Lamp Switch
18 10 ’95-’97: Air Conditioner Compressor Clutch Relay
20 ’98-’99: Air Conditioner Compressor Clutch Relay, ABS
20 10 Turn Signal/Hazard
21 20 Fuel Pump Relay, Auto Shut Down Relay (Fuel Injectors, Ignition Coil Pack, Powertrain Control Module, Generator, Data Link Connector, Oxygen Sensors, Capacitor, Noise Suppressor)
23 15 Horn Relay
25 15 Stop Lamp Switch
Relay
R1  –
R2 Fuel Pump
R3 Auto Shut Down
R4 Horn
R5 Fog Lamp
R6 ABS Warning Lamp
R7 Air Conditioner Compressor Clutch
R8 Starter

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Alfa Romeo 164 (1988 – 1997) – fuse box diagram

Alfa Romeo 164 (1988 – 1997) – fuse box diagram

Year of production: 1988, 1989, 1990, 1991, 1992, 1992, 1993, 1994, 1995, 1996, 1997



Alfa Romeo 164 is a business class car manufactured by Alfa Romeo. Produced from 1987 to 1998 in the sedan body. This material is suitable for cars produced in 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997 for finding and replacing fuses and relays on Alfa Romeo 164 cars. We will also show the fuse box diagrams and their locations, as well as the purpose of their elements.

Passenger compartment

Fuse box location

Fuse and relay box is locate under the dashboard

Alfa Romeo 164 (1988 - 1997) - fuse box location - passenger compartment
Alfa Romeo 164 (1988 – 1997) – fuse box location – passenger compartment

Fuse box diagram

Alfa Romeo 164 (1988 - 1997) - fuse box diagram - passenger compartment
Alfa Romeo 164 (1988 – 1997) – fuse box diagram – passenger compartment
Relays A Description
A Headlamp high beam relay
B Headlamp low beam relay
C Turn Signal / Hazard Relay
D Front / Rear Lamp Relays
E Interior lamp relay
F Front power window relay
G Rear power window relay
H Seat heater / sunroof relay
1 10 LH side lamp, LH tail lamp, license plate lamp, cigarette lighter lamp
2 10 LH lamp, RH lamp, Tailgate lamp, instrument cluster illumination, vanity mirror lamp
3 20 Heated door mirrors, heated rear window, heated windscreen, cigarette lighter – front
4 30 Power window regulator – front left
5 30 Power window regulator – front right
6 10 Interior lamp
7 10 Low beam headlamp – LH
8 10 Low beam headlamp – right
9 20 Sunroof, seat heater
10 10 Cluster illumination rheostat, A / C relay, A / C compressor clutch relay
11 30 Power window regulator – rear right
12 30 Power window regulator – rear left
13 10 High beam headlamp – LH
14 10 High beam headlamp – right
15 10 Direction indicators, front / rear lamps
16 20 Reversing lights, windshield wiper
17 15 Fog lights-front
18 10 Stop lights
19 20 Headlamp washer, hazard warning lights
20 30 Power seat
21 10 Cooling fan motor relay, glow plug relay, fuel heater relay, cruise control
22 10 Rear fog lamps
23 15 Central locking
24 10 Cigar lighter , rear
25 75 “+” battery
26 10 Power supply circuit
27 30 Fuel filler flap / cover
28 3 A / C compressor magnetic clutch
29 75 Anti-theft system
The fuse number 24, 10A, is responsible for the cigarette lighter.



Engine compartment

Fuse and relay boxes

There are several small boxes with relays and fuses under the hood.

Alfa Romeo 164 (1988 - 1997) - fuse box diagram - engine compartment
Alfa Romeo 164 (1988 – 1997) – fuse box diagram – engine compartment



Alfa Romeo 164 (1988 - 1997) - fuse box diagram - engine compartment
Alfa Romeo 164 (1988 – 1997) – fuse box diagram – engine compartment
No. A Description
1 Common relay
2 Relay of fuel pump
3 Relay of device of the variable valve timing system
4 Relay 2 of the electronic engine color unit
1 15 Fuel pump
2 3 Electronic engine control unit
3 75 Oxygen sensor
Alfa Romeo 164 (1988 - 1997) - fuse box diagram - engine compartment
Alfa Romeo 164 (1988 – 1997) – fuse box diagram – engine compartment

Luggage compartment fuse box

Alfa Romeo 164 (1988 - 1997) - fuse box diagram - luggage compartment
Alfa Romeo 164 (1988 – 1997) – fuse box diagram – luggage compartment
Description
Suspension control relay
Heated rear window relay
Rear seat motor relay
10A Anti-thef system
3A Anti-thef alarm horn
10A Phone
40A Heated rear window

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Chrysler Neon (1994 – 1999) – fuse and relay box diagram

Chrysler Neon (1994 – 1999) – fuse and relay box diagram

Year of production: 1994, 1995, 1996, 1997, 1998, 1999



The Chrysler Neon, also known as the Dodge Neon in some markets, was a compact car produced by Chrysler Corporation from 1994 to 2005. It was initially marketed under both the Dodge and Plymouth brands in North America and as the Chrysler Neon in international markets.



First Generation (1994–1999), Second Generation (2000–2005), Dodge Neon SRT-4 (2003–2005)



Passenger Compartment Fuse Box

Fuse box location

The fuse panel is located behind the cover on the driver’s side of the dashboard.

Chrysler Neon (1994 - 1999) - fuse and relay location - passenger compartment
Chrysler Neon (1994 – 1999) – fuse and relay location – passenger compartment



Fuse box Diagram

Chrysler Neon (1994 - 1999) - fuse and relay diagram - passenger compartment
Chrysler Neon (1994 – 1999) – fuse and relay diagram – passenger compartment



Assignment of fuses in the passenger compartment

No.
A
Circuit Protected
1 15 Cigar Lighter/Power Outlet
2 15 Headlamp Switch (Park Lamp, Tail Lamp, License Lamp, Radio, Front Fog Lamp Switch, Remote Keyless Entry Module (’98-’99))
3 20 Door Lock Switch, Remote Keyless Entry Module (’98-’99), Immobilizer (’98-’99)
4 10 Fog Lamp Switch
5 10 ’95-’97: A/C Cycling Switch, Back-Up Lamp (Back-Up Lamp Switch M/T), Park/Neutral Position Switch (A/T), Rear Window Defogger Switch
10 ’98-’99 (LHD): Airbag Control Module
10 ’98-’99 (RHD): A/C Cycling Switch, Back-Up Lamp (Back-Up Lamp Switch M/T), Park/Neutral Position Switch (A/T), Rear Window Defogger Switch, High Speed Warning Module
6 10 Turn Signal/Hazard
7 25 A/C Heater Blower Motor
8 10 ’95-’97: Airbag Control Module
10 ’98-’99 (LHD): A/C Cycling Switch, Back-Up Lamp (Back-Up Lamp Switch M/T), Park/Neutral Position Switch (A/T), Rear Window Defogger Switch, High Speed Warning Module
10 ’98-’99 (RHD): Airbag Control Module
9 4 ’95-’97: Instrument Cluster, Radio, Ash Receiver Lamp, Rear Window Defogger Switch, “PRNDL” Lamp, Rear Fog Lamp Switch, A/C Heater Control Switch, Headlamp Leveling Switch
10 ’98-’99 (LHD): Airbag Control Module
4 ’98-’99 (RHD): Instrument Cluster, Radio, Ash Receiver Lamp, Rear Window Defogger Switch, “PRNDL” Lamp, Rear Fog Lamp Switch, A/C Heater Control Switch, Headlamp Leveling Switch
10 15 Powertrain Control Module, Air Conditioner Compressor Clutch Relay, ABS, Vapor Canister Leak Detector, Torque Converter Clutch Solenooid (A/T), Duty Cycle EVAP/Purge Solenoid, ABS Relay Box, EGR Transducer Solenoid, ABS Warning Lamp Relay
11 5 Instrument Cluster, Daytime Running Lamp Module (’98-’99), Remote Keyless Entry Module (’98-’99), Immobilizer (’98-’99)
12 10 ’95-’97: Airbag Control Module
4 ’98-’99 (LHD): Instrument Cluster, Radio, Ash Receiver Lamp, Rear Window Defogger Switch, “PRNDL” Lamp, Rear Fog Lamp Switch, A/C Heater Control Switch, Headlamp Leveling Switch
10 ’98-’99 (RHD): Airbag Control Module
13  –
14 20 Sunroof
15 20 Wiper Motor, Wiper/Washer Switch, Intermittent Wiper/Washer Switch, Cigar Lighter Relay
16 10 Radio
17 10 Left Headlamp, Left/Right Headlamp Leveling Motor
18 10 Right Headlamp
19  –
20  –
Circuit Breaker
CB1 30 Power Window, Power Window
CB2  –
Relay
R1 ’98-’99 (LHD): Time Delay
R2 ’95-’97: Cigar Lighter
’98-’99 (LHD): Combination Flasher
’98-’99 (RHD): Cigar Lighter
R3 ’95-’97: Combination Flasher
’98-’99 (LHD): Time Out
’98-’99 (RHD): Combination Flasher



Engine Compartment Fuse Box

Fuse box location

Chrysler Neon (1994 - 1999) - fuse and relay location - engine compartment
Chrysler Neon (1994 – 1999) – fuse and relay location – engine compartment



Fuse box diagram

Chrysler Neon (1994 - 1999) - fuse and relay diagram - engine compartment
Chrysler Neon (1994 – 1999) – fuse and relay diagram – engine compartment



Assignment of fuses and relay in the engine compartment

No.
A
Protected Component
2 40 Ignition Switch (Fuse (Passenger Compartment): “5”, “6”, “7”, “8”, “CB1”)
3 40 Headlamp Switch, Fuse (Passenger Compartment): “1”, “3”, “4”
5 30 Solid State Fan Relay (Radiator Fan)
8 30 Rear Window Defogger
10 40 ABS Relay Box
11 30 Starter Relay, Ignition Switch (Clutch Pedal Position Switch (M/T), Fuse (Passenger Compartment): “10”, “11”, “12”, “14”, “15”, “16”)
13 10 Dome Lamp, Trunk Lamp, Underhood Lamp, Instrument Cluster, Radio, Glove Box Lamp, Map/Reading Lamp, Visor/Vanity Lamp, Power Mirror Switch, High Speed Warning Module (’98-’99), Time Delay Relay (’98-’99), Time Out Relay (’98-’99)
16 20 Fog Lamp Relay, Rear Fog Lamp Switch
18 10 ’95-’97: Air Conditioner Compressor Clutch Relay
20 ’98-’99: Air Conditioner Compressor Clutch Relay, ABS
20 10 Turn Signal/Hazard
21 20 Fuel Pump Relay, Auto Shut Down Relay (Fuel Injectors, Ignition Coil Pack, Powertrain Control Module, Generator, Data Link Connector, Oxygen Sensors, Capacitor, Noise Suppressor)
23 15 Horn Relay
25 15 Stop Lamp Switch
Relay
R1  –
R2 Fuel Pump
R3 Auto Shut Down
R4 Horn
R5 Fog Lamp
R6 ABS Warning Lamp
R7 Air Conditioner Compressor Clutch
R8 Starter

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Chrysler Cirrus (1995 – 2000) – fuse and relay box diagram

Chrysler Cirrus (1995 – 2000) – fuse and relay box diagram

Year of production: 1995, 1996, 1997, 1998, 1999, 2000



The Chrysler Cirrus is a mid-size sedan that was produced by Chrysler from 1995 to 2000. Part of Chrysler’s “Cloud Car” series, the Cirrus shared its platform with the Dodge Stratus and Plymouth Breeze, with each model offering slightly different features and trim levels. The Cirrus was designed to offer a balance of style, performance, and comfort in the competitive mid-size sedan market of the 1990s.

The Chrysler Cirrus was a stylish, comfortable, and reasonably well-equipped sedan for its time. It offered a good blend of power (particularly with the V6 engine), a smooth ride, and modern design cues. While it is no longer in production, the Cirrus remains a memorable part of Chrysler’s history in the mid-size sedan segment.



Passenger Compartment Fuse Box

Fuse Box Location

Chrysler Cirrus (1995 - 2000) - fuse and relay location - passenger compartment
Chrysler Cirrus (1995 – 2000) – fuse and relay location – passenger compartment



Fuse Box Diagram

Chrysler Cirrus (1995 - 2000) - fuse and relay diagram - passenger compartment
Chrysler Cirrus (1995 – 2000) – fuse and relay diagram – passenger compartment



Assignment of fuses in the instrument panel

No.
A
Protected Component
1 30 Blower Motor
2 20 Convertible: Right Headlamp (High Beam), Daytime Running Lamp Module
10 Right Headlamp (High Beam), Daytime Running Lamp Module
3 20 Convertible: Left Headlamp (High Beam)
10 Left Headlamp (High Beam)
4 15 Back-Up Lamp (Back-Up Lamp Switch (M/T), Transmission Range Sensor (A/T)), Power Top Relay (Convertible), Daytime Running Lamp Module, Power Door Lock Switch, Power Mirror Switch, Automatic Day/Night Mirror, Steering Proportional Steering Module
5 10 Dome Lamp, Data Link Connector, Power Antenna, Overhead Map Lamp, Trunk Lamp, Traveler, Body Control Module, Radio, Glove Box Lamp, Visor/Vanity Lamp, Universal Garage Door Opener, Automatic Day/Night Mirror, Illuminated Entry Relay, Courtesy Lamp, Power Door Lock Switch, Door Arm/Disarm Switch, Key-In Halo Lanp, Sunroof Control Module
6 10 Heated Mirror, A/C Heater Control
7 20 ’98-’00: Instrument Cluster, Headlamp Switch
15 ’95-’97: Headlamp Switch
8 20 Cigar Lighter/Power Outlet, Horn Relay
9 15 Body Control Module
10 20 Rear Fog Lamp Switch, Daytime Running Lamp Module
11 10 Body Control Module, Instrument Cluster, Autostick Switch, Transmission Control Module
12 10 Left Headlamp (Low Beam), Daytime Running Lamp Module
13 20 Right Headlamp (Low Beam), Front Fog Lamp Switch
14 10 Radio
15 10 Combination Flasher, Seat Belt Control Module (Convertible), Intermittent Wiper Relay, Wiper (High/Low) Relay, Rear Window Defogger Relay
16 10 Airbag Control Module
17 10 Airbag Control Module
Circuit Breaker
18 20 Power Seat Switch, Decklid Release Relay
19 20 Power Window, Master Power Window Switch, Window Timer Module, Sunroof Control module
Relay
R1 Headlamp Delay
R2 Horn
R3 Rear Window Defogger



Engine Compartment Fuse Box

Fuse Box Location

Chrysler Cirrus (1995 - 2000) - fuse and relay location - engine compartment
Chrysler Cirrus (1995 – 2000) – fuse and relay location – engine compartment



Fuse Box Diagram

Chrysler Cirrus (1995 - 2000) - fuse and relay diagram - engine compartment
Chrysler Cirrus (1995 – 2000) – fuse and relay diagram – engine compartment



Assignment of fuses in the engine compartment

No.
A
Protected Component
1 10 Oxygen Sensor Downstream
2 20 ABS
3 20 Transmission Control Module, Transmission Control Relay
4 20 Stop Lamp Switch, Fuse (Passenger Compartment): “5”
5 20 Automatic Shut Down Relay (Fuel Injectors, Ignition Coil Pack (2.0L and 2.4L), Noise Suppressor (2.0L and 2.4L), Generator, Oxygen Sensor Upstream, Distributor (2.5L) EGR Solenoid, Fuse: “1”), Powertrain Control Module
6 20 Combination Flasher, Sentry Key Immobilizer Module
7 10 Ignition Switch (Fuse (Passenger Compartment): “11”)
8 20 Starter Relay, Fuel Pump Relay, Ignition Switch (Body Control Module, Clutch Interlock Switch (M/T), Transmission Control Module (EATX), Fuse (Passenger Compartment): “14”, “15”, “17”, Fuse (Engine Compartment): “9”, “10”)
9 10 Air Conditioner Compressor Clutch Relay, Radiator Fan (High Speed) Relay, Radiator Fan (Low Speed) Relay, Fuel Pump Module, Instrument Cluster, Sentry Key Immobilizer Module, Brake Shift Interlock Solenoid
10 10 Fuel Pump Relay, Powertrain Control Module, ABS
11 20 Convertible: Seat Belt Control Module
12 40 Rear Window Defogger Relay
13 40 ABS
14 40 Fuse (Passenger Compartment): “7”, “8”
15 40 Headlamp Switch, Headlamp Delay Relay (Body Control Module, Headlamp Switch, Fuse (Passenger Compartment): “12”, “13”), Fuse (Passenger Compartment): “9”, “10””18″
16 40 Ignition Switch (Fuse (Passenger Compartment): “1”, “4”, “16”, “19”)
17 40 Convertible: Power Top Up/Down Relays
18 40 Intermittent Wiper Relay (Wiper (High/Low) Relay)
19 40 Air Conditioner Compressor Clutch Relay, Radiator Fan (High Speed) Relay, Radiator Fan (Low Speed) Relay
Relay
R1 Radiator Fan (High Speed)
R2 Automatic Shut Down
R3 Radiator Fan (Low Speed)
R4 Starter
R5  –
R6 Air Conditioner Compressor Clutch
R7 Convertible: Power Tow
R8 Intermittent Wiper
R9 Wiper (High/Low)
R10 Fuel Pump
R11 Transmission Control
R12  –

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Volkswagen Golf 3(1991 – 1997) – fuse box diagram

Volkswagen Golf mk3 (1991 – 1997) – fuse box diagram

Year of production: 19991, 1992, 1993, 1994, 1995, 1996, 1997



The 3rd generation Volkswagen Golf compact car was produced in 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001 and 2002 with gasoline and diesel engines. Delivered worldwide in various body styles: convertible, sedan, station wagon and hatchback. In this article you will find a designation of the fuse and relay boxes diagram of the 3rd generation Volkswagen Golf.

Passenger compartment

Fuse box location

It is located at the bottom of the dashboard on the driver’s side, behind the protective cover. To remove it, press the buttons – latches.

Volkswagen Golf 3 - fuse box location - passenger compartment
Volkswagen Golf 3 – fuse box location – passenger compartment

Fuse box diagram

Volkswagen Golf 3 - fuse box location - passenger compartment
Volkswagen Golf 3 – fuse box location – passenger compartment

A
Circuits protected
1 10 Headlight, low beam, left
2 10 Headlight, low beam, right
3 10 Instrument and number plate lighting
4 15 Rear window wiper and washer system, sliding/tilting roof
5 15 Windscreen wiper, windscreen and rear window washer, electric heated windscreen washer jets
6 20 Fresh air blower, A/C
6 30 Blower, air conditioner
7 10 Tail lights, right
8 10 Tail lights, left
9 15 Rear window defogger
9 20 Rear window heating, mirror heating
10 15 Fog lights, rear fog light
11 10 Headlight, high beam, left. main beam warning lamp
12 10 Headlight, high beam, right
13 10 Horn, radiator fan (run-on)
14 10 Back-up fights
14 15 Reversing lights, electric outside mirrors, seat heating, elec. windows, air conditioner cruise control system
15 10 Engine electronics, coolant circulation run-on pump, (six cylinder engine)
16 15 Warning lamps, glove box light, cassette storage box light, power sunroof, front map/reading light
17 10 Emergency flashers
18 20 Fuel pump (FP), heated oxygen sensor (H02S) control module
19 30 Coolant fan, A/С relay
20 10 Brake lights, cruise control system (trigger contacts on brake and clutch pedals)
21 15 Interior and luggage compartment lights, clock, cigarette lighter, central locking, multi-function indicator
22 10 Cigarette fighter, radio, luggage compartment

Relay


Circuits protected
1 Air conditioner relay
2 Rear window wiper / washer relay
3 Relay, electronic engine control unit
4 Relay for main ignition circuits
5
6 Relay – turn signal interrupter
7 Headlight washer control unit
8 Relay for intermittent operation of the windshield wiper / washer
9 Seat belt not fastened indicator relay 1995
10 Fog lamp relay
11 Horn relay
12 Fuel pump relay
13 Intake manifold heater relay
14
15 Pump relay ABS
16 Reversing light relay (Ecomatic)
17 Headlamp High Beam Relay (Ecomatic)
18 Low beam relay (Ecomatic)
19 Fuse 30A – air conditioning, Climatronic 2.0 / 2.8 (1993)
20 Start inhibit switch relay
21 Oxygen sensor relay
22 Seat Belt Not Fastened Indicator Relay (1995)
23 Vacuum pump relay (Ecomatic)
24 Thermal fuse (20A) – Power windows

Additional fuses (in separate holders, above the relays)


A
Circuits protected
1 30 Fuse for ABS motor relay
2 30 Fuse for ABS main relay
3 10 Fuse for normal air conditioner
4 30 Fuse for fresh air blower on Climatronic
5 5 Fuse for Climatronic
6 20 Automatic fuse for electric windows
7 15 Trailer perma nent +

Additional fuses (in the engine compartment on the bulkhead above the brake servo)

On vehicles with diesel engines, the glow plug power supply circuit is protected by a high power fuse in the form of a fusible link.

Volkswagen Golf 3 - fuse box location - engine compartment
Volkswagen Golf 3 – fuse box location – engine compartment

A
Circuits protected
1 50 Diesel glow plugs

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Volkswagen Transporter (T4; 1990 – 2003) – fuse box diagram

Volkswagen Transporter (T4; 1990 – 2003) – fuse box diagram

Year of production: 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003



Volkswagen Transporter T4  – represents the 4th generation of the legendary Transporter series. This model was produced in 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002 and 2003 with diesel and gasoline engines with different wheelbases: short and long, and with different roof height. Also on the T4, Volkswagen continued its lineup of luxury Caravelle, California and Multivan models. In this article, we will show the location of all electronic control sides and a detailed designation of the purpose of fuses and relays Volkswagen T4 with box diagrams in which they are located.



Locations

Volkswagen Transporter T4 (1990 - 2003) - fuse box location
Volkswagen Transporter T4 (1990 – 2003) – fuse box location



1 Air conditioning control unit 1 – with automatic temperature control – in the heater control panel, front
2 Air conditioning control unit 2 – with automatic temperature control – in the heater control panel, rear – central pillar
3 Evaporator Fan Control Unit (A / C) – With Rear A / C – Behind Right Rear Trim Panel
4 Air conditioning / heater fan motor control unit 1 – with automatic temperature control – front – fan unit
5 Air conditioning / heater blower motor control unit 2- with automatic temperature control – rear- bottom of the body, in the center
6 Aerial amplifier – behind the dash, passenger side
7 Alternator resistor – near additional relays – CV / AUF, with alternator 150A / automatic transmission / automatic temperature control – behind the central part of the dashboard
8 Additional battery – under the driver’s seat
9 Accumulator battery
10 Central locking signal control unit – behind the dashboard
11 Cruise control unit (with throttle motor) – cruise control is controlled by the ECM
12 Electronic cruise control module (without throttle motor) – behind dash, passenger side
13 Diagnostic connector (DLC) – instrument panel, driver’s side
14 Diagnostic unit – 05/99 (except for AAC / ABL / AET / AES / AJA) – in the instrument cluster
15 Cooling Fan Motor Relay – Behind Left Headlight
16 Cooling Fan Motor 1/2 Resistor – Behind Left Headlight
17 Coolant heater control unit (with additional coolant heater – D3W / B4W / D4W) – in the heater – underbody, in the center
18 Coolant heater control unit (with optional coolant heater – B7W / D7W) – behind the dash, passenger side
19 Engine oil pressure warning buzzer – in instrument cluster control unit
21 Fuse / relay box, instrument cluster 1
22 Fuse / relay box 2, dash – under dash fuse / relay box 1
23 Fuse / relay box, dash 3 – above dash fuse / relay box 1
24 Fuse / relay box, dash 4 – behind dash, center
25 Fuse / Relay Box, Driver’s Seat – Under Seat
26 Fuse / Relay Box, Engine Compartment – Battery Powered
27 Additional fuse (5A / 7.5A / 10A) – in the back of the audio system unit
28 Additional fuse (10A) – at the rear of the navigation system control unit
29 Headlights not switched off warning buzzer – in the instrument cluster control unit
30 Heater blower motor resistor – manual temperature control – blower unit, front
31 Horn 1/2 – behind the front bumper
32 Immobilizer control unit – behind the instrument cluster
33 Immobilizer ring antenna – near the ignition switch
34 Turn signal relay, alarm relay – in the alarm switch
35 Instrument Cluster Control Module / Digital Multifunction Display – In Instrument Cluster
36 Outside temperature sensor – behind the front bumper
37 Driver’s seat heating control unit – in the seat heating switch
38 Passenger seat heating control unit – in the seat heating switch
39 SRS control unit – under the dash, center
40 Sunroof electric control unit
41 Theme control unit – in the display of the navigation system
42 Telephone interface control unit – behind the instrument cluster
43 Electronic gearbox control unit – near the engine control unit
44 Vehicle speed sensor – gearbox



Passenger compartment

Fuse box location

The main fuse and relay box is located under the dash on the driver’s side.

Fuse box diagram

Version 1

Volkswagen Transporter T4 (1990 - 2003) - fuse box diagram - passenger compartment (version 1)
Volkswagen Transporter T4 (1990 – 2003) – fuse box diagram – passenger compartment (version 1)

A
Description
1 10 Left Headlight Low Beam
2 10 Right Headlight Low Beam
3 10 Instrument & License Lights
4 15 Rear Window Wiper/Washer, Heated Front Seats
5 15 Windshield Wiper/Washer, Rear Window Washer, Heated Washer Jets
6 30 A/C, Fresh Air Fan
7 10 Right Tail Light & Side Marker Light, Engine Compartment Lamp
8 10 Left Taillight & Side Marker Light
9 20 Rear Window & Mirror Heater
10 15 Fog Lamps
11 10 Left Headlight High Beam & High Beam Indicator
12 10 Right Headlight High Beam
13 10 Horn, Radiator Cooling Fan
14 10 Backup Lights, Electric Mirrors, Heated Front Seats, Windshield Washer Jets, Cruise Control, Power Roof
15 10 Engine Electronics
16 15 Warning/Indicator Lights, Multi-Function Indicator, Glove Box Light, ABS
17 10 Turn Signals
18 20 Fuel Pump
19 30 A/C, Radiator Cooling Fan
20 10 Brake Lights
21 15 Dome & Luggage Lamps, Clock, Radio, Central Locking System, Multi-Function Indicator, Vanity Mirror, OBD Diagnostic
22 10 Cigarette Lighter
Relay
1 A/C Control Module Relay
2 Rear Window Wiper/Washer Relay
3 ECM Power Supply Relay
4 Load Reduction Relay
5 Open
6 Emergency Flasher Relay
7 Headlight Washer Relay
8 Washer/Wiper Intermittent Relay
9 Seat Belt Warning Relay
10 Fog Lamp/Parking Lamp Relay
11 Dual Horn Relay
12 Fuel Pump Relay
13 Heater Control Module Relay
14 Coolant Pump After-Run Relay
15 Open
16 Open
17 Open
18 Roof Ventilator Fan (Fuse)
19 Heater Air Blower Relay
20 Starter Interlock/Back-up Light Relay
21 5 Back-up Lights, Cruise Control
22 20 A/C (Second Evaporator)
23 Rear Window Defroster/Heated Mirror Relay
24 20 Power Windows, Central Locking System
25 10 ABS System
26 15 Rear Window Defroster, Heated Mirrors
27 A/C Compressor Clutch Relay

Version 2

Fuse box diagram (main box)

Volkswagen Transporter T4 (1990 - 2003) - fuse box diagram - passenger compartment (version 2)
Volkswagen Transporter T4 (1990 – 2003) – fuse box diagram – passenger compartment (version 2)

A
Description
Relay assignment
1 (105) Heater blower motor relay – rear (ventilation)
2 (174) Rear window wiper / washer relay
3 (30/109) Engine management relay
4 (18) Ignition auxiliary circuits relay 1
5 Reserve
6 (22/21) Emergency ventilation relay (with repeaters for direction indicators on the roof)
7 (95) Headlight washer pump relay
8 (99) Relay for intermittent operation of the windshield wiper / washer
9 (36) Headlamps warning buzzer
10 (53) Fog lamp relay
11 (53) Horn relay
12 (167) Fuel pump relay
Fuse
1 10 Left headlight – low beam, headlight range control
2 10 Right headlight – low beam, headlight range control
3 10 License plate lamps
4 15 Rear window wiper / washer, auxiliary ignition circuit relay 2, additional equipment
5 15 Windshield wiper / washer, heaters for windshield washer nozzles (05/01)
6 30 Air conditioning system, heater fan motor
7 10 Front right side / rear right side lamps
8 10 Lamps front left / rear left
9 20 Heated rear window, heated outside mirror
10 15 Fog lights
11 10 Left headlamp-high beam
12 10 RH headlamp-high beam
13 10 Sound signal
14 10 ABS system (with ESP), automatic transmission control system, additional equipment, central locking, cruise control system, power windows, power rear-view mirrors on the doors, reverse light (s)
15 10 Engine management system, crankcase ventilation heater, cruise control system, vehicle speed sensor
16 15 ABS indicator, glove box illumination lamp, turn signals, immobilizer, instrument cluster
17 10 Additional heater
18 20 Engine management system, fuel pump
19 30 A/C, Radiator Cooling Fan
20 10 Stop lights
21 15 Audio system, diagnostic connector (DLC), interior lamps, navigation system

Additional Fuse box

It is located under the main block.

Volkswagen Transporter T4 (1990 - 2003) - fuse box diagram - additional fuse box
Volkswagen Transporter T4 (1990 – 2003) – fuse box diagram – additional fuse box

A
Description
1 15 Accessory power connector
2 15 Trailer electrical connector
3 10 Roof identification light
4 20 Additional heater (AC V / AH Y / AJT / AU F)
5 10 Anti-lock braking system (ABS)
6 FOR Phone
7 15 Taxi
8 10 Roof fan
9 15 Audio system, instrument cluster
10 15 Central locking
11 15 Heated seats
12 30 Heated door mirrors, heated rear window
13 FOR PHONE (ACV / AH Y / AJT / AU F)
14 30 Air conditioning system – manual automatic temperature control
15 20 Additional heater



Additional relay box 1

Located at the top of the main unit.

Relay box diagram

Volkswagen Transporter T4 (1990 - 2003) - fuse box diagram - additional relay box no. 1
Volkswagen Transporter T4 (1990 – 2003) – fuse box diagram – additional relay box no. 1

  Description
1 (53) Coolant pump relay
2 (125) Idle speed control (AM) relay
3 (137) Glow plug control unit (ABL)
4 (53) Ignition auxiliary circuits relay 2 (some models)
5 (53) Ignition auxiliary circuits relay 2 (AES, with air conditioning)
F1 30 Power window fuse
F2 15 Engine control unit
F3 15 Actuator

Additional relay box 2

It is located behind the dashboard in the center.

Fuse box diagram

Volkswagen Transporter T4 (1990 - 2003) - fuse box diagram - additional relay box no. 2
Volkswagen Transporter T4 (1990 – 2003) – fuse box diagram – additional relay box no. 2

 Description
1 (106) Auxiliary heater relay
2 Audio / Telephone Speaker Switch Relay
3 (53) (53) Heater blower motor relay – rear (warm air)
4 (114) Heater blower motor relay – automatic temperature control
5 (152) Heater radiator coolant valve relay (rear heater)
6 (38) Air intake changeover actuator relay (A / C / heater)
7 (53) Alternator relay (AES, with 150A alternator)
8 (53) Alternator relay (ACV / AUF, with alternator 150A / automatic / automatic temperature control)
9 (175) Start inhibit switch relay / reversing lamp relay
10 (87) Wheel hub connection control unit



Another unit can be located under the driver’s seat. The following items may be located there: (214/426) Relay for additional battery, (403) Relay for additional heater, (30A) Additional liquid heating system, (5A) Sockets , etc.



Engine compartment

Fuse box location

This unit is located on the cover in front of the battery.

Fuse box diagram

Volkswagen Transporter T4 (1990 - 2003) - fuse box diagram - engine compartment
Volkswagen Transporter T4 (1990 – 2003) – fuse box diagram – engine compartment




 Description
1 60A Glow plug relay
2 50A Cooling fan motor
3 50A Cooling fan motor
4 50A Anti-lock braking system (ABS)
5 110A/150A/175A Generator
6 30A System of maintaining exchange rate stability
7 30A Anti-lock braking system (with ESP)
8 5A System of maintaining exchange rate stabilit

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Alfa Romeo 155 (1992 – 1998) – fuse box diagram

Alfa Romeo 155 (1992 – 1998) – fuse box diagram

Year of production: 1992, 1993, 1994, 1995, 1996, 1997, 1998



Alfa Romeo 155 is a mid-size sedan produced in 1992, 1993, 1994, 1995, 1996, 1997 and 1998. In this article, we will show a designation of fuses and relays Alfa Romeo 155 with box diagrams and their locations. Note the cigarette lighter fuse.

Passenger Compartment Fuse Panel

Version 1

The fuse and relay box is located in the passenger compartment on the left.

Alfa Romeo 155 (1992 - 1998) - fuse box diagram - passenger compartment (version 1)
Alfa Romeo 155 (1992 – 1998) – fuse box diagram – passenger compartment (version 1)
No. Circuit protected
Daytime running light relay I
Headlight washer relay (black)
Suspension relay (brown)
Tailgate/Trunk Compartment Release Relay (Red)
Daytime running light relay II
Coolant fan motor Relay (White)
Sunroof Motor Relay (White)
20 Washing/wiping the headlights
30 Suspension adjustment
30 Boot release
25 Electric windows
25 Electric windows
25 Electric windows
10 ABS

Version 2

Alfa Romeo 155 (1992 - 1998) - fuse box diagram - passenger compartment (version 2)
Alfa Romeo 155 (1992 – 1998) – fuse box diagram – passenger compartment (version 2)
Fuse A Circuit protected
1 10 Hazard warning lights
2 20 Horns, Cigar lighters, Stoplights, Boot release, Radio
3 20 Windscreen wipers
4 20 Roof light timer
5 10 Control lighting, Rear left and front right sidelights, RH numberptale light
6 10 Control lighting, Rear right and front left sidelights, LH numberptale light
7 10 RH dipped beam headlight
8 10 LH dipped beam headlight
9 10 RH main beam headlight
10 10 LH main-beam headlight (+ warning lamp)
11 7,5 Rear foglamp (+ warning lamp)
12 30 Heated rear window (+ warning lamp), Door mirror defrosters
13 20 Heating/air conditioning fan, Seat warming, Rear and front power windows, Radio
14 20 Engine cooling fan (6V)
25 Electric fan for radiator cooling
15 10 Dashboard, Check Panel, Windscreen washers, Headlight washers, Reversing lights, Controlled damping suspension solenoid valves, Air conditioning compressor control, Engine electric fan control
16 7,5 Interior lights, Clock, Air conditioning control unit
17 7,5 Direction indicators, Door mirror adjustment, Controlled damping suspension
18 20 Door locks
19 20 Front foglamps (+ warning lamp)
Relay
N11 Door locking control unit
N13 Hazard warning lights and direction indicators intermittence
N14 Electronic windscreen wiper intermittence
I2 Heated rear window relay
I3 Horn relay
I17 Fog-light relay
I25 Rear fog light relay
I35 Key-operated supply relay
I49 Dipped beam headlight
I50 Main beam headlight
I64 Sidelights relay

Auxiliary Fusebox

Alfa Romeo 155 (1992 - 1998) - fuse box diagram - auxiliary fuse box
Alfa Romeo 155 (1992 – 1998) – fuse box diagram – auxiliary fuse box
A Color Circuit protected
20 Black Headlight washer intermittence
25 Brown Passenger side power window
10 Red ABS
25 Blue Rear power windows
30 Green Electric seat adjustment
30 Red Boot release
20 Brown Controlled damping suspension
30 White Sunroof
Black Timer for headlight washer
Green Relay for radiator fan (only for TS model)

Engine compartment

There are usually two fuses and relay boxes. The first is located near the headlight and radiator cap under the protective casing.

Fuse box no. 1

Alfa Romeo 155 (1992 - 1998) - fuse box diagram - engine compartment (fuse box no.1)
Alfa Romeo 155 (1992 – 1998) – fuse box diagram – engine compartment (fuse box no.1)
No. A Fuse component
F1 7,5 Fuel pump
F2 7,5 Lambda probe
F3 3 Engine control module
Relay
1 Engine Control Module 1 Relay
2 Timing relay
3 Fuel pump relay
4 Engine control module relay 2

Fuse box no. 2

The second one is near the ABS sensor above the brake cylinder.

Alfa Romeo 155 (1992 - 1998) - fuse box diagram - engine compartment (fuse box no.2)
Alfa Romeo 155 (1992 – 1998) – fuse box diagram – engine compartment (fuse box no.2)
No. A Fuse component
F1 30 A/C fan motor
F2 40 A/C cooling fan
F3 15 A/C compressor
Relay
1 A/C condenser fan motor relay
2 A/C condenser fan timer relay
3 A/C compressor clutch relay
4 Air conditioner relay



Fuse box no. 3

For V16 and 2.5 versions only, a third block has been added.

No. A Fuse component
F1 7,5 Lambda probe
F2 15 Motronic system
Relay
1 Engine Control Module I Relay
2 Fuel pump relay
3 Engine Control Module II Relay

1.8-2.0 TS Model

The following fuses are housed on a bracket located between the battery and the air-flow meter.

Alfa Romeo 155 (1992 - 1998) - fuse box diagram - engine compartment (1.8-2.0 TS Model)
Alfa Romeo 155 (1992 – 1998) – fuse box diagram – engine compartment (1.8-2.0 TS Model)
Number Circuit protected
1 Control unit power supply
2 Lambda probe (for vehicles equipped with catalytic converter)
3 Fuel pump
Relay
R1 Fuel pump relay
R2 Main relay
R3 Timing variator relay
R4 Relay for services

2.4 V6 model

The following fuses are located in a box located on the rear wall of the engine compartment next to the tank

Alfa Romeo 155 (1992 - 1998) - fuse box diagram - engine compartment (2.4 V6 model)
Alfa Romeo 155 (1992 – 1998) – fuse box diagram – engine compartment (2.4 V6 model)
Number Fuse component
1 Lambda probe (for vehicles equipped with catalytic converter)
2 Fuel pump
Relay
R1 Fuel pump relay
R2 Main relay
R3 Relay for services

Heating – ventilation system

The following fuses are housed in the rear left-hand part of the engine compartment next to the brake-clutch fluid reservoir.

Alfa Romeo 155 (1992 - 1998) - fuse box diagram - engine compartment (heating - ventilation system)
Alfa Romeo 155 (1992 – 1998) – fuse box diagram – engine compartment (heating – ventilation system)
No. A Fuse component
1 50 Heating-ventilatton system control unit
2 40 Engine cooling liquid radiator fan (only for 1.8 – 2.0 TS model

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Toyota Previa First Generation mk1 (XR10, XR20; 1990–1999) – fuse box diagram

Toyota Previa First Generation mk1 (XR10, XR20; 1990–1999) – fuse box diagram

Year of production: 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999

Instrument panel

Toyota Previa mk1 - fuse box - instrument panel
Toyota Previa mk1 – fuse box – instrument panel

Front compartment

Toyota Previa mk1 - fuse box - front compartment
Toyota Previa mk1 – fuse box – front compartment

Fuses (type A)

Fuse Ampere rating [A} Circuit
1 ST 7,5 Starter system
2 IGN 7,5 Charging system, discharge warning light, emission control system, multiport fuel injection system/sequential multiport fuel injection system, SRS airbag system
3 OBD 7,5 On-board diagnosis system
4 FOG 20 Front fog lights
5 T/M ACC 7,5 Automatic transmission shift indicator
6 TAIL 15 Tail lights, parking lights, side marker lights, license plate lights, instrument panel lights
7 HAZ-HORN 15 Emergency flashers, horns, turn signal lights
8 HEAD (LH) 15 (USA) Left-hand headlight
HEAD
(LH-L WR)
10 (Canada)
9 HEAD (RH) 15 (USA) Right-hand headlight
HEAD
(RH-L WR)
10 (Canada)
10 ENGINE 7,5 Charging system, emission control system
11 RADIO 7,5 Radio, cassette tape player, Compact Disc player
12 ST-A 7,5 Starter system
13 STOP 20 Stop lights, anti-lock brake system
14 DOME 15 Interior lights, luggage compartment light, clock, open door warning light, radio, cassette tape player, Compact Disc player
15 DEFOG 15 Rear window defogger
16 ECU-B 15 Anti-lock brake system, electronically controlled automatic transmission system
17 CIG 15 Cigarette lighter, digital clock display, power rear view mirrors, theft deterrent system, SRS airbag system, automatic transmission shift lock system
18 EFI 15 Multiport fuel injection system/sequential multiport fuel injection system
19 TURN 7,5 Turn signal lights
20 GAUGE 10 Gauges and meters, service reminder indicators and warning buzzers (except discharge and open door warning lights), back-up lights, automatic transmission overdrive system, rear window defogger, electric rear sun roof, power windows, power door lock system
21 FR-WIPER 30 Windshield wipers and washer
22 ENGINE OIL 15 Engine oil autofeed system
23 RR-WIPER 15 Rear window wiper and washer
24 A/C 15 Air conditioning cooling system, cool box
25 ECU-IG 15 Cruise control system, electronically controlled automatic transmission system, anti-lock brake system, theft deterrent system
26 FR-W ASHER 10 Windshield washer motor
27 HEAD (LH-UPR) 10 Left-hand headlight (Canada only)
28 HEAD (RH-UPR) 10 Right-hand headlight (Canada only)
29 ALT-S 7,5 Charging system
30 AM2 20 Charging system, discharge warning light, emission control system, multiport fuel injection system/ sequential multiport fuel injection system

Fuses (type B)

Fuse Ampere rating [A] Circuit
31 DOOR 30 Power door lock system, theft deterrent system
32 POWER 30 Electric rear sun roof, power windows

Fuses (type C)

Fuse Ampere rating [A] Circuit
33 ABS 60 Anti-lock brake system
34 ALT 100 “ABS”, “AM1”, “STOP”, “DEFOG”, “FOG”, “ECU-B”, “TAIL”, “A/C” and “RR A/C” fuses, and “FR-HTR” circuit breaker
35 AM1 50 “ENGINE”, “GAUGE”, “TURN”, “FR-WIPER”, “ECU-IG”, “A/C”, “RADIO”, “CIG”, “ST”, “POWER” and DOOR” fuses
36 MAIN 50 “HAZ-HORN”, “DOME”, “HEAD (LH)”, “HEAD (RH)” and “EFI” fuses

Circuit breaker

Fuse Ampere rating [A] Circuit
37 FR-HTR C/B 40 Air conditioning control system

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
