Volkswagen EOS (2006 – 2008) – fuse and relay box diagram
Year of production: 2006, 2007, 2008
The Volkswagen Eos coupé-cabriolet was manufactured from 2006 to 2016. This article provides fuse box diagrams for the Volkswagen Eos models from 2006 to 2008. You will also find details on the location of the fuse panels inside the vehicle and information about the fuse and relay assignments (fuse layout).
Instrument Panel Fuse Box (Fuse Panel -SC-)
Fuse Box Location
Volkswagen EOS (2006 – 2008) – fuse and relay box location – passenger compartment
Fuse Box Diagram
Volkswagen EOS (2006 – 2008) – fuse and relay box diagram – passenger compartment
Assignment of the fuses in the instrument panel
№
Amps
Function/Component
F1
10A
16-Pin Connector
Data Link Connector Fuel Pump (FP) Control Module
Engine Control Module (ECM)
F2
5A
Anti-Slip Control Switch
ASR/ESP Button
Brake Pedal Position Sensor
ABS Control Module
F3
10A
Airbag Control Module
F4
5A
Tire Pressure Monitoring Button
High Pressure Sensor
Oil Level Thermal Sensor
Driver’s Heated Seat Control Module
Front Passenger’s Heated Seat Control Module
Climatronic Control Module
F5
5A
Headlamp Adjuster
Headlamp Range/Cornering Lamp Control Module
Left Headlamp Beam Adjustment Motor
Right Headlamp Beam Adjustment Motor
F6
5A
Instrument Cluster Control Module
Power Steering Control Module
Data Bus On Board Diagnostic Interface
Selector Lever Sensors Control Module
F7
5A
Operating Electronics and Telephone Control Module
Automatic Day/Night Interior Mirror
F8
5A
Towing Recognition Control Module
F9
–
Not used
F10
7.5A
Garage Door Opener Control Module
F11
10A
Right Headlamp Power Output Stage
F12
10A
Driver’s Door Control Module
Front Passenger’s Door Control Module
F13
10A
Light Switch
16-Pin Connector – Data Link Connector
F14
–
Not used
F15
7.5A
Vehicle Electrical System Control Module
F16
10A
Heater/Heat Output Switch
Climatronic Control Module
A/C Control Module
Auxiliary Engine Coolant Heating RF Receiver
F17
5A
Magnetic Field Sensor for Compass
Rain/Light Recognition Sensor
Antenna Selection Control Module
F18
5A
Parking Aid Control Module
Selector Lever Sensors Control Module
F19
7.5A
Door Closing Assist Control Module
F20
–
Not used
F21
–
Not used
F22
40A
Fresh Air Blower
F23
30A
Driver’s Door Control Module
Front Passenger’s Door Control Module
F24
15A
Cigarette Lighter
F25
25
Heated Rear Window
A/C Control Module
Heater/Heat Output Switch
Fresh Air Blower Series Resistor With Fuse
F26
20A
12V Socket (luggage compartment)
F27
15A
Fuel Pump (FP) Control Module
Transfer Fuel Pump (FP)
Fuel Pump (FP) Relay
F28
–
Not used
F29
10A
Mass Air Flow (MAF) Sensor
Engine Control Module (ECM) (BVY)
F30
10A
Cylinder 1-4 Fuel Injector (BLF)
F31
20A
Brake System Vacuum Pump
F32
30A
Left Rear Door Control Module
Right Rear Door Control Module
F33
–
Not used
F34
15A
Driver’s Seat Lumbar Support Adjustment Switch
Airbag Energy Reserve
Volkswagen EOS (2006 – 2008) – fuse and relay box location – engine compartment
Fuse Box Diagram (Version 1, Low)
Volkswagen EOS (2006 – 2008) – fuse and relay box diagram – engine compartment (version 1, low)
Assignment of the fuses in the engine compartment (Version 1, Low)
№
Amps
Function/Component
F1
20A
From January 2006 to May 2006: Comfort System Central Control Module
F2
5A
From January 2006 to May 2008: Steering Column Electronic Systems Control Module
F3
5A
Vehicle Electrical System Control Module
F4
20A/30A
ABS Control Module
F5
15A
Direct Shift Gearbox (DSG) Mechatronic
F6
5A
Instrument Cluster Control Module
Steering Column Electronic Systems Control Module (from May 2008)
F7
15A/40A
From January 2006 to May 2006: Special Purpose Vehicle Control Module
From May 2008: Power Supply Relay 2 (terminal 15)
F8
15A
Radio/Navigation Display Control Module
TV/Radio/Navigation Display/Control Module
Radio
Digital Satellite Radio Tuner
F9
5A
Telephone Transceiver
F10
5A/10A
Motronic Engine Control Module (ECM) Power Supply Relay (only models with gasoline engine, not for engine code BLF)
Engine Control Module (ECM)
Transmission Control Module (TCM) (From January 2006 to May 2006: )
F11
20A
Auxiliary Heater Control Module
F12
5A
Data Bus On Board Diagnostic Interface
F13
30A/25A/15A
Engine Control Module (ECM)
F14
20A
Ignition Coil
Ignition Coil 1-4 with Power Output Stage
F15
10A/5A
Heated Oxygen Sensor (HO2S) (BVY)
Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) (BVY)
Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) (BVY)
Oxygen Sensor (O2S) 3 Behind Three Way Catalytic Converter (TWC) (BVY)
Fuel Pump (FP) Relay
Automatic Glow Time Control Module
From January 2006 to May 2008:
Map Controlled Engine Cooling Thermostat
Coolant Fan Control (FC) Control Module
EGR Vacuum Regulator Solenoid Valve
Evaporative Emission (EVAP) Canister Purge Regulator Valve 1
Intake Manifold Tuning (IMT) Valve
Camshaft Adjustment Valve 1
Intake Manifold Runner Control (IMRC) Valve
Ignition Coil Power Output StageFrom May 2008: Coolant Fan Control (FC) Control Module
F25
40A
From January 2006 to May 2008: Vehicle Electrical System Control Module (T11b/1) Terminal 30 – R
From May 2008: ABS Control Module
F26
40A
Vehicle Electrical System Control Module (T11 c/1) Terminal 30 – L
F27
40A/50A
Automatic Glow Time Control Module
F28
40A
From January 2006 to May 2008: Power Supply Relay 2 (terminal 15)
From May 2008: Convertible Top Control Module
F29
50A
From May 2006:
Convertible Top Control Module (From May 2006 to May 2008)
Left Rear Door Control Module
Right Rear Door Control Module
F30
50A
Load Reduction Relay
Fuse 7 (on fuse panel C)
Fuse 8 (on fuse panel C)
Fuse 28 (on fuse panel C)
Fuse 35 (on fuse panel C)
SA1
150A/200A
Generator (GEN) (90A/120A)
Generator (GEN) (140A)
SA2
80A
Power Steering Control Module
Electro-mechanical Power Steering Motor
SA3
50A/80A
Coolant Fan Control (FC) Control Module
Coolant Fan
Coolant Fan 2
SA4
40A
Special equipment
SA5
80A/100A
Fuse 43 (on fuse panel C)
Fuse 45 (on fuse panel C)
Fuse 28 (on fuse panel C)
Fuse 22 (on fuse panel C)
Fuse 18 (on fuse panel C)
Fuse 19 (on fuse panel C)
Fuse 12 (on fuse panel C)
Fuse Panel C
508
–
Terminal 30 feed
SA6
80A/100A
Auxiliary Air Heater Control Module
Auxiliary Air Heater Heating Element
SA7
50A/40A/30A
From January 2006 to May 2006:
Trailer
Handicapped equipmentFrom May 2006 to May 2008:
Convertible Top Control Module
Convertible Top Hydraulic Pump
A1
Motronic Engine Control Module (ECM) Power Supply Relay
A2
Secondary Air Injection (AIR) Pump Relay
Connection bridge, Automatic Glow Time Control Module, Glow Plug 1-4
Fuse Box Diagram (Version 2, High)
Volkswagen EOS (2006 – 2008) – fuse and relay box diagram – engine compartment (version 2, high)
Assignment of the fuses in the engine compartment (Version 2, High)
№
Amps
Function/Component
F1
30A
From January 2006 to May 2006: ABS Control Module
F2
30A
ABS Control Module (valves)
F3
20A
Comfort System Central Control Module
Transmission Control Module (TCM)
F4
5A
Vehicle Electrical System Control Module (measuring cable)
Oxygen Sensor (O2S) Heater 1 (behind Three Way Catalytic Converter (TWC)
F13
15A
Direct Shift Gearbox (DSG) Mechatronic
F14
–
Not used
F15
10A
Coolant Pump
F16
5A
From January 2006 to May 2006: ABS Control Module
From May 2006: Steering Column Electronic Systems Control Module
F17
5A
Instrument Cluster Control Module
F18
30A
Amplifier
F19
15A
Radio
Radio/Navigation Display Control Module
F20
5A
From January 2006 to May 2006: Radio/Navigation Display Control Module
From May 2006: Telephone Transceiver
F21
–
Not used
F22
–
Not used
F23
10A
Engine Control Module (ECM)
F24
5A
Data Bus On Board Diagnostic Interface
F25
–
Not used
F26
–
Not used
F27
–
Not used
F28
25A
Engine Control Module (ECM)
F29
5A
Auxiliary Engine Coolant (EC) Pump Relay
F30
20A
Auxiliary Heater Control Module
F31
30A
Windshield Wiper Motor
F32
–
Not used
F33
–
Not used
F34
–
Not used
F35
–
Not used
F36
–
Not used
F37
–
Not used
F38
10A
Coolant Fan Control (FC) Control Module
Camshaft Adjustment Valve 1
F39
5A
From January 2006 to May 2006: Brake Pedal Position Sensor
From May 2006: Clutch Position Sensor
F40
20A
Ignition Coil 1-4 with Power Output Stage
F41
–
Not used
F42
5A
From January 2006 to May 2006: Engine Component Power Supply Relay
F43
30A
From January 2006 to May 2006: Ignition Coil 1-6 with Power Output Stage
F44
–
Not used
F45
–
Not used
F46
–
Not used
F47
40A
Vehicle Electrical System Control Module
F48
40A
Vehicle Electrical System Control Module
F49
40A
Power Supply Relay 2 (terminal 15)
F50
–
Not used
F51
40A
From January 2006 to May 2006: Secondary Air Injection (AIR) Pump Relay
F52
40A
Load Reduction Relay
F53
–
Not used
F54
40A
Driver’s Power Seat Adjustment Circuit Breaker 1
Sunroof Circuit Breaker
SA1
150A/200A
Generator (GEN) (90A/120A)
Generator (GEN)
SA2
80 A
Power Steering Control Module
Electro-mechanical Power Steering Motor
SA3
50A
Coolant Fan Control (FC) Control Module
Coolant Fan
Coolant Fan 2
SA4
40A
Preheating Coolant, High Heat Output Relay
SA5
80A
Fuse 17 (on fuse panel C)
Fuse 16 (on fuse panel C)
Fuse 15 (on fuse panel C)
Fuse 14 (on fuse panel C)
Fuse 13 (on fuse panel C)
Fuse 12 (on fuse panel C)
Fuse Panel C
508
–
Terminal 30 feed (battery in engine compartment)
SA6
80A
Auxiliary Air Heater Control Module
Auxiliary Air Heater Heating Element
SA7
40A
Convertible Top Hydraulic Pump
A1
Motronic Engine Control Module (ECM) Power Supply Relay
A2
Auxiliary Engine Coolant (EC) Pump Relay
A3
–
A4
Engine Component Power Supply Relay
WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
Cigar lighter (power outlet) fuses in the Mitsubishi Galant are the fuses #9 (Power outlet), and #16 (Cigarette lighter) in the Passenger compartment fuse box.
WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
The fuses are located behind a cover on the driver’s side of the dash panel. To open the fuse cover in the dash panel, open the driver’s side door, pull the top of the cover out, then pivot downwards.
This fuse box is located on the passenger side of the engine compartment near the battery. To remove the cover, press the catch on the side of the fuse box towards the engine and release the two tabs at the opposite side.
The Holden Captiva / Captiva 7 (CG, pre-facelift) is a compact crossover SUV that was manufactured between 2006 and 2011. This article provides fuse box diagrams for the 2006, 2007, 2008, 2009, and 2010 models of the Holden Captiva. It also includes details about the location of the fuse panels within the vehicle and outlines the function and layout of each fuse and relay.
Passenger Compartment Fuse Box
Fuse Box Location
The fuses are located on the left-hand side of the driver’s side footwell. To open the fuse cover, pull the top of the cover outward.
Assignment of the fuses in the passenger compartment
№
Amps
Allocation
1
10A
Front mirror
2
20A
Door lock
3
Spare
4
15A
Front door lock
5
15A
BCM (VB6)
6
20A
APO 1 (Additional power outlet 1)
7
20A
Cigar lighter
8
20A
APO 2 (Additional power outlet 2)
9
15A
BCM (VB3)
10
20A
Heat/mat
11
20A
Passenger power window
12
15A
TCM
13
15A
Audio
14
20A
Driver’s power window
15
15A
Engine
16
15A
BCM (VB4)
17
10A
XBCM
18
15A
BCM (VB5)
19
10A
2006-2007: Trailer
20
10A
2006-2007: RR CLS
21
10A
2006-2007: PKLP-RH
22
Relay ACC/RAP
23
10A
Lift glass
24
15A
Air conditioning
25
10A
Air conditioning
26
Relay run/crank
27
15A
OSRVM HT
28
20A
BCM (VB2)
29
10A
2006-2007: SSPS
30
15A
BCM (VB7)
31
10A
Clock
32
10A
Instrument cluster
33
2A
Ignition switch
34
10A
BCM (VB1)
35
10A
Ignition 1
36
10A
Rear defrost
37
10A
2006-2007: CTD Horn
38
10A
Airbag
39
10A
Airbag
40
2A
2006-2007: WHL S/W
41
10A
Front washer
Engine Compartment Fuse Box
Fuse Box Location
This fuse box is located on the passenger side of the engine compartment, it contains circuit fuses, main fuses and relays. To remove the cover, press the catch on the side of the fuse box toward the engine and release the two tabs at the opposite side.
J160 – Circulation pump relay2)
J708 – Residual heat relay2)
R149 – Remote control receiver for auxiliary coolant heater2)
U18 – 12 V socket 21)
U20 – 12 V socket 41)
3
15
202)
U5 – 12 V socket
U19 – 12 V socket 3
4
20
J162 – Heater control unit
5
20
U18 – 12 V socket 22)
U19 – 12 V socket 42)
J807 – Relay for power sockets1)
6
15
J518 – Entry and start authorisation control unit3)
J708 – Residual heat relay1)
7
5
T16b – Diagnostic connection
J515 – Aerial selection control unit
G397 – Rain and light detector sensor
8
25
307)
V – Windscreen wiper motor
9
15
J519 – Onboard supply control unit (windscreen wiper pump)
10
25
307)
J388 – Rear left door control unit (window regulator)
11
15
J386 – Driver door control unit (central locking)
J388 – Rear left door control unit (central locking)
12
10
J519 – Onboard supply control unit (interior light)
13
–
Not assigned
14
25
307)
J386 – Driver door control unit (window regulator)
15
15
J393 – Convenience system central control unit (right tail light cluster)
16
20
J519 – Onboard supply control unit (fanfare)
17
30
J519 – Onboard supply control unit (left light)
18
20
257)
J39 – Headlight washer system relay
19
–
Not assigned
20
30
J519 – Onboard supply control unit (battery 1)
21
–
Not assigned
22
30
J647 – Axle differential lock control unit
J605 – Rear lid control unit
23
10
J647 – Axle differential lock control unit
24
5
J502 – Tyre pressure monitor control unit
25
15
J352 – Steering column and belt height adjustment control unit
26
10
F36 – Clutch pedal switch
J… – Engine control units
J234 – Airbag control unit
J285 – Control unit in dash panel insert
J519 – Onboard supply control unit
K145 – Front passenger side airbag deactivated warning lamp
N378 – Driver seat belt inertia reel magnet
N379 – Front passenger side seat inertia reel magnet
27
5
E183 – Interior monitoring switch
W11 – Rear left reading light
W12 – Rear right reading light
W14 – Front passenger side illuminated vanity mirror
W20 – Driver side illuminated vanity mirror
W51 – Rear lid light
28
–
Not assigned
29
–
Not assigned
30
–
Not assigned
31
–
Not assigned
32
–
Not assigned
33
15
J527 – Steering column electronics control unit
34
5
G273 – Interior monitoring sensor
G384 – Vehicle inclination sender
J285 – Control unit in dash panel insert2)
35
30
J519 – Onboard supply control unit
36
30
E470 – Driver seat adjustment operating unit
37
–
Not assigned
38
–
Not assigned
39
5A
J9 – Heated rear window relay
J32 – Air conditioning system relay
J329 – Terminal 15 voltage supply relay
J755 – Transport mode relay
J807 – Relay for power sockets1)
40
5
J285 – Control unit in dash panel insert
41
15
J518 – Entry and start authorisation control unit
42
30
J245 – Sliding sunroof adjustment control unit
43
–
Not assigned
44
30
E470 – Driver seat adjustment operating unit
J136 – Seat and steering column adjustment control unit with memory
J810 – Driver seat adjustment control unit
45
25
J786 – Heated rear seats control unit
46
–
Not assigned
47
10
J647 – Axle differential lock control unit
48
5
J769 – Lane change assist control unit
J770 – Lane change assist control unit 2
49
5
J236 – Servotronic control unit
50
10
G266 – Oil level and oil temperature sender
N79 – Crankcase breather heater element4)
51
5
T16b – Diagnostic connection
F321 – Parking brake contact switch
G238 – Air quality sensor
G550 – Sensor for automatic distance control
J755 – Transport mode relay
52
30
157)
V12 – Rear window wiper motor
53
5
E1 – Light switch
J527 – Steering column electronics control unit
J393 – Convenience system central control unit
54
10
E102 – Headlight range control regulator5)
J667 – Power output module for left headlight6)
V48 – Left headlight range control motor5)
V49 – Right headlight range control motor5)
55
15
J486 – Fresh air blower relay for 2nd speed
56
40
J32 – Air conditioning system relay
J309 – Solar cell isolation relay
J486 – Fresh air blower relay, 2nd speed
SB55 – Fuse 55 on fuse holder B
V305 – Motor for front Bitron blower regulation
57
40
V306 – Motor for rear Bitron blower regulation8)
J403 – Adaptive suspension compressor relay7)
1) Only one battery onboard supply
2) Only auxiliary battery and two battery onboard supply
3) Only V10 TDI
4) Only models with engine codes BHK, BHL
5) Only models with halogen headlights
6) Only models with cornering light
7) From November 2007
8) Up to November 2007
Fuse assignment in fuse box, right-side dash panel
Assignment of the fuses in the right-side of the dash panel.
No.
А
Function/component
1
15
202)
J345 – Trailer detector control unit
2
5
J446 – Parking aid control unit
3
15
J345 – Trailer detector control unit
4
5
J412 – Mobile telephone operating electronics control unit
5
15
252)
J345 – Trailer detector control unit
6
30
J104 – ABS control unit
7
5
J646 – Transfer box control unit
8
30
J519 – Onboard supply control unit (right light)
9
10
Individualisation
R190 – Satellite digital radio tuner1)
10
5
J772 – Reversing camera system control unit
R78 – TV tuner
11
20
J503 – Control unit with display for radio and navigation system
R – Radio
R – Preparation for radio and navigation system with TV (models for Japan)
12
30
R12 – Amplifier
13
–
Not assigned
14
15
J393 – Convenience system central control unit
15
25
303)
J389 – Rear right door control unit (window regulator)
16
10
53)
W3 – Luggage compartment light
17
–
Not assigned
18
30
J9 – Heated rear window relay
19
–
Not assigned
20
30
U13 – AC/DC converter with socket 12 V – 230 V
U27 – AC/DC converter with socket 12 V – 115 V1)
21
10
F266 – Bonnet contact switch
22
25
J774 – Heated front seats control unit
23
10
J255 – Climatronic control unit
24
30
E471 – Front passenger seat adjustment operating unit
J521 – Front passenger seat adjustment with memory control unit
25
5
E265 – Rear Climatronic operating and display unit
J301 – Air conditioning system control unit
26
–
Not assigned
27
15
J197 – Adaptive suspension control unit
28
–
Not assigned
29
10
53)
J217 – Automatic gearbox control unit
30
20
J714 – Power latching system relay
31
15
J393 – Convenience system central control unit
32
10
J387 – Front passenger door control unit (central locking)
J389 – Rear right door control unit (central locking)
33
15
Individualisation
34
25
303)
J387 – Front passenger side door control unit (window regulator)
35
30
E471 – Front passenger seat adjustment operating unit
36
5
J603 – Vehicle position recognition control unit
J702 – Roof display unit
37
–
Not assigned
38
10
J104 – ABS control unit
39
5
J410 – Heated windscreen relay for left side
J411 – Heated windscreen relay for right side
J745 – Cornering light and headlight range control unit
Individualisation
40
10
J646 – Transfer box control unit
41
10
J345 – Trailer detector control unit
42
5
E284 – Garage door operating unit
J530 – Garage door operation control unit
43
5
F41 – Reversing switch
44
5
E94 – Heated driver seat regulator
E95 – Heated front passenger seat regulator
E128 – Heated rear left seat switch with regulator
E129 – Heated rear right seat switch with regulator
E281 – Operating unit to regulate suspension height
Z20 – Left washer jet heater element
Z21 – Right washer jet heater element
45
–
Not assigned
46
–
Not assigned
47
10
J668 – Power output module for right headlight
48
10
J197 – Adaptive suspension control unit
49
5
Y7 – Automatic anti-dazzle interior mirror
50
5
E256 – TCS and ESP button
51
15
J217 – Automatic gearbox control unit
52
5
F125 – Multifunction switch
F189 – Tiptronic switch
N380 – Selector lever lock for position P solenoid
53
30
J411 – Heated windscreen relay for right side
54
30
J410 – Heated windscreen relay for left side
55
–
Not assigned
56
40
J104 – ABS control unit
57
40
J646 – Transfer box control unit
1) Only American markets
2) From May 2008
3) From November 2007
Fuses and relay position assignment in pre-fuse box, under driver seat
Fuse box diagram
Volkswagen Touareg – fuse and relay box diagram – passenger compartment (pre-fuse, under driver seat)
Pre-fuse box (under driver seat).
No.
А
Function/component
SD1
150
Left fuse carrier
SD2
150
Right fuse carrier
SD3
60
Right fuse carrier
SD4
60
403)
J701 – Voltage supply relay 21)
V306 – Motor for rear Bitron blower regulation3)
SD5
60
403)
J329 – Terminal 15 voltage supply relay
SD6
–
Not assigned
SD7
250
J713 – Charger relay for second battery
SD8
1501)
602)
Left fuse carrier
J701 – Voltage supply relay 11)
SD9
5
J519 – Onboard supply control unit
SD10
10
53)
J519 – Onboard supply control unit1)
SD11
5
J519 – Onboard supply control unit1)
SD12
–
Not assigned
SD13
40
J403 – Adaptive suspension compressor relay
V306 – Motor for rear Bitron blower regulation1,3)
SD14
–
Not assigned
Relays
1
Battery master/isolator switch -E74-
2
Terminal 15 voltage supply relay -J329- (433)
3
Second battery charging circuit relay -J713-
1) Only V10 TDI
2) Only models with additional battery
3) From November 2007
Relay locations for E-box on left under dash panel near centre console
Fuse box diagram
Volkswagen Touareg – fuse and relay box diagram – passenger compartment (e-box; left-side under dashpanel)
Relay panel E-Box 1 (on left under dash panel near center console).
No.
Function/component
D1
Servotronic control unit -J236- (476)
D2
Power latching system relay -J714- (404)
D3
Adaptive suspension compressor relay -J403- (373)
D4
Power sockets relay -J807- (404)
D5
Air conditioning system relay -J32- (100) / (370) optional installation
D6
Fresh air blower relay, 2nd speed -J486- (404), only manually operated air conditioning system
D7
Heated rear window relay -J9- (53)
D8
Circulation pump relay -J160- (404), only VR6 with auxiliary heater
D9
Alternator cut-in relay -J442- (53)
E1
Solar cells isolation relay -J309- (79)
E2
Not assigned
E3
Heated windscreen relay for left side -J410- (53)
E4
Not assigned
E5
Voltage supply relay 2 -J710- (432), only V10 TDI
E6
Not assigned
E7
Headlight washer system relay -J39- (53)
E8
Residual heat relay -J708- (404)
E9
Heated windscreen relay for right side -J411- (53)
Relay carrier on E-box on right under dash panel, near right a-pillar (only right-hand drive)
Fuse box diagram
Volkswagen Tourareg – fuse and relay box diagram – relay carrier on E-box on right-side under dash panel, near right a-pillar (only right-hand drive)
Relay panel E-box 2 (on right under dash panel, near right a-pillar)
No.
Function/component
D1
Servotronic control unit -J236- (476)
D2
Power latching system relay -J714- (404)
D3
Adaptive suspension compressor relay -J403- (373)
D4
Power sockets relay -J807- (404)
D5
Air conditioning system relay -J32- (100) / (370) optional installation
D6
Fresh air blower relay, 2nd speed -J486- (404), only manually operated air conditioning system
D7
Heated rear window relay -J9- (53)
D8
Circulation pump relay -J160- (404), only VR6 with auxiliary heater
D9
Alternator cut-in relay -J442- (53)
E1
Solar cells isolation relay -J309- (79)
E2
Residual heat relay -J708- (404)
E3
Heated windscreen relay for left side -J410- (53)
E4
Voltage supply relay 2 -J710- (432), only V10 TDI
E5
Heated windscreen relay for right side -J411- (53)
Volkswagen Touareg – fuse and relay box diagram – engine compartment relay & fuse box (2.5 l (R5) TDI engine)
Assignment of the fuses in the Engine compartment (2.5L (R5) TDI engine)
No.
A
Function/component
1
60
J293 – Radiator fan control unit
2
30
J671 – Radiator fan control unit 21)
3
–
Not assigned
4
–
Not assigned
5
–
Not assigned
6
–
Not assigned
7
–
Not assigned
8
–
Not assigned
9
30
J623 – Engine control unit
10
10
G65 – High-pressure sender
J17 – Fuel pump relay
J255 – Climatronic control unit
J293 – Radiator fan control unit
J301 – Air conditioning system control unit
J445 – Fuel cooling pump relay
J496 – Additional coolant pump relay
J671 – Radiator fan control unit 2
N75 – Charge pressure control solenoid valve
N79 – Crankcase breather heater element
N280 – Air conditioner compressor regulating valve
N345 – Exhaust gas recirculation cooler changeover valve
11
–
Not assigned
12
10
J179 – Automatic glow period control unit
J496 – Additional coolant pump relay
J248 – Diesel direct injection system control unit
J623 – Engine control unit
10
10
G65 – High-pressure sender
J17 – Fuel pump relay
J179 – Automatic glow period control unit
J255 – Climatronic control unit
J293 – Radiator fan control unit
J301 – Air conditioning system control unit
J338 – Throttle valve module3)
J442 – Alternator cut-in relay2)
J445 – Fuel cooling pump relay
J496 – Additional coolant pump relay
J671 – Radiator fan control unit 2
J724 – Turbocharger 1 control unit
J865 – Control unit for charge air cooler bypass3)
N18 – Exhaust gas recirculation valve
N280 – Air conditioner compressor regulating valve
N345 – Exhaust gas recirculation cooler changeover valve
N381 – Exhaust gas recirculation cooler changeover valve 23)
N428 – Valve block 2 in front passenger side rear seat3)
V157 – Intake manifold flap motor
V275 – Intake manifold flap 2 motor
V400 – Pump for exhaust gas recirculation cooler3)
G65 – High-pressure sender
J17 – Fuel pump relay
J293 – Radiator fan control unit
J671 – Radiator fan control unit 2
N345 – Exhaust gas recirculation cooler changeover valve
N381 – Exhaust gas recirculation cooler changeover valve 2
V336 – Metering pump for post-injection in particulate filter for cylinder bank 12)
V337 – Metering pump for post-injection in particulate filter for cylinder bank 22)
11
15
F265 – Map-controlled engine cooling system thermostat
J255 – Climatronic control unit
J724 – Turbocharger 1 control unit
J725 – Turbocharger 2 control unit
N280 – Air conditioner compressor regulating valve
V135 – Particulate filter additive pump2)
V157 – Intake manifold flap motor
V275 – Intake manifold flap 2 motor
V280 – Turbocharger 1 control motor
V281 – Turbocharger 2 control motor
12
5
J179 – Automatic glow period control unit
J445 – Fuel cooling pump relay
J496 – Additional coolant pump relay
J703 – Glow period control unit 2
Volkswagen Touarge – fuse and relay box diagram – engine compartment relay & fuse box (3.6 l (V6) FSI engine)
Assignment of the fuses in the Engine compartment (3.6L (V6) FSI engine)
No.
A
Function/component
1
60
J293 – Radiator fan control unit
2
301)
J671 – Radiator fan control unit 2
V7 – Radiator fan
3
–
Not assigned
4
–
Not assigned
5
–
Not assigned
6
–
Not assigned
7
20
N70 – Ignition coil 1 with output stage
N127 – Ignition coil 2 with output stage
N291 – Ignition coil 3 with output stage
8
20
N292 – Ignition coil 4 with output stage
N323 – Ignition coil 5 with output stage
N324 – Ignition coil 6 with output stage
9
30
J623 – Engine control unit
10
10
G65 – High-pressure sender
J293 – Radiator fan control unit
J496 – Additional coolant pump relay
J671 – Radiator fan control unit 21)
V144 – Fuel system diagnostic pump
11
10
J255 – Climatronic control unit
J301 – Air conditioning system control unit
J442 – Alternator cut-in relay2)
N280 – Air conditioner compressor regulating valve
12
10
N80 – Activated charcoal filter system solenoid valve 1
N205 – Inlet camshaft control valve 1
N316 – Intake manifold flap valve
N318 – Exhaust camshaft control valve 1
13
25
J538 – Fuel pump control unit
14
15
N276 – Fuel pressure regulating valve
15
10
J623 – Engine control unit
J271 – Motronic current supply relay
J670 – Motronic current supply relay 2
Volkswagen Touareg – fuse and relay box diagram – Engine compartment relay & fuse box (4.2 l (V8) FSI engine)
Assignment of the fuses in the Engine compartment (4.2L (V8) FSI engine)
No.
A
Function/component
1
60
J671 – Radiator fan control unit 2
V177 – Radiator fan 2
2
601)
30
J293 – Radiator fan control unit
V7 – Radiator fan
3
40
J299 – Secondary air pump relay
V101 – Secondary air pump motor
4
–
Not assigned
5
–
Not assigned
6
–
Not assigned
7
20
N70 – Ignition coil 1 with output stage
N127 – Ignition coil 2 with output stage
N291 – Ignition coil 3 with output stage
N292 – Ignition coil 4 with output stage
N323 – Ignition coil 5 with output stage
N324 – Ignition coil 6 with output stage
N325 – Ignition coil 7 with output stage
N326 – Ignition coil 8 with output stage
8
–
Not assigned
9
30
J623 – Engine control unit
10
10
G70 – Air mass meter
G246 – Air mass meter 2
J299 – Secondary air pump relay
N80 – Activated charcoal filter solenoid valve 1
V144 – Fuel system diagnostic pump
11
–
Not assigned
12
20
F265 – Map-controlled engine cooling system thermostat
G65 – High-pressure sender
J151 – Continued coolant circulation relay
J255 – Climatronic control unit
J301 – Air conditioning system control unit
J293 – Radiator fan control unit
J442 – Alternator cut-in relay2)
J671 – Radiator fan control unit 2
N205 – Inlet camshaft control valve 1
N208 – Inlet camshaft control valve 2
N280 – Air conditioner compressor regulating valve
N318 – Exhaust camshaft control valve 1
N319 – Exhaust camshaft control valve 2
V157 – Intake manifold flap motor
V183 – Variable intake manifold motor
J623 – Engine control unit
J624 – Engine control unit 2
10
10
G65 – High-pressure sender
J255 – Climatronic control unit
J293 – Radiator fan control unit
J301 – Air conditioning system control unit
J442 – Alternator cut-in relay2)
J671 – Radiator fan control unit 2
V144 – Fuel system diagnostic pump
11
15
N80 – Activated charcoal filter solenoid valve 1
N205 – Inlet camshaft control valve 1
N208 – Inlet camshaft control valve 2
N280 – Air conditioner compressor regulating valve
N318 – Exhaust camshaft control valve 1
N319 – Exhaust camshaft control valve 2
12
5
J49 – Electric fuel pump 2 relay
J299 – Secondary air pump relay
J545 – Secondary air pump relay 2
J624 – Engine control unit 2
Toyota Highlander Hybrid (XU40; 2006 – 2007) – fuse and relay box diagram
Year of production: 2006, 2007
The 1st generation Toyota Highlander was produced in 2000, 2001, 2002, 2003, 2004, 2005, 2006 and 2007 with the U20 designation. In some countries it is known as Toyota Kluger V. In this publication we will show the locations of the electronic control units, describe in detail the fuses and relays of the Toyota Highlander 1 Kluger with box diagrams.
Engine compartment
Fuse Box Location
Toyota Highlander Hybrid – fuse and relay box location – engine compartment
Fuse Box №1 Diagram
Toyota Highlander Hybrid – fuse and relay box diagram – engine compartment (fuse box no.1)
Fuse Box №2 Diagram
Toyota Highlander Hybrid – fuse and relay box diagram – engine compartment (fuse box no.2)
Fuse Box №3 Diagram
Toyota Highlander Hybrid – fuse and relay box diagram – engine compartment (fuse box no.3)
Instrument panel
Fuse Box Location
Remove the lid to access.
Toyota Highlander Hybrid – fuse and relay box location – passenger compartment
Fuse Box Diagram
Toyota Highlander Hybrid – fuse and relay box diagram – passenger compartment
Fuses (type A)
Fuse
Ampere rating [A]
Circuit
1
ETCS
10
Hybrid system
2
DC/DC−S
10
Hybrid system
3
ABS NO.2
10
Electronically controlled brake system
4
ABS NO.1
10
Electronically controlled brake system
5
BATT FAN
15
Hybrid system
6
ABS NO.3
15
Electronically controlled brake system
7
OIL PUMP
10
Transmission fluid cooling system
8
ST
7,5
Hybrid system
9
RR HTR
15
Rear heater system
10
DRL
7,5
Daytime running light system
11
H−LP L LWR
15
Left−hand headlight (low beam)
12
H−LP L UPR
15
Left−hand headlight (high beam)
13
H−LP R UPR
15
Right−hand headlight (high beam)
14
PWR OUTLET NO.2
20
Power outlet (115 VAC)
15
TOWING
20
Trailer lights
16
HAZ
15
Turn signal lights, emergency flashers
17
SECURITY
15
Theft deterrent system
18
AM2 NO.1
30
“IGN”, “IG2” and “ST” fuses
19
MPX−B1
7,5
Electric power steering system
20
HORN
10
Horns
21
RADIO NO.1
25
Audio system
22
ECU−B NO.1
7,5
Theft deterrent system, air conditioning system, gauges and meters, electric moonroof, engine immobilizer system, multiplex communication system
23
DOME
10
Personal lights, interior lights, vanity lights, ignition switch light, wireless remote control system, gauges and meters, navigation system
24
DOOR NO.1
25
Power door lock system
25
A/F
25
Air/fuel control system
26
CRT
7,5
Rear seat entertainment system, navigation system screen
27
H−LP R LWR
15
Right−hand headlight (low beam)
28
INV W/P
15
Hybrid system
29
IGCT NO.5
10
Hybrid system
30
WATER PUMP
10
Air conditioning system
31
IGCT NO.4
10
Emission control system, transmission control system, air/ fuel control system
32
IGCT NO.3
10
Hybrid system, fuel pump
33
IGCT NO.2
10
Hybrid system
34
IGN
10
Meters and gauges, SRS airbag system, hybrid system, electronically controlled brake system, engine immobilizer system
35
RAD NO.2
7,5
Audio system, rear seat entertainment system, navigation system, air conditioning system, multiplex communication system
36
CIG
15
Cigarette lighter
37
P RR DOOR
20
Power windows
38
PWR OUTLET1
15
Power outlets (12 VDC)
39
FR FOG
20
Front fog lights
40
ECU−IG
10
Electronically controlled brake system, transmission control system, electric power steering system, theft deterrent system
41
WIPER
25
Windshield wipers
42
D RR DOOR
20
Power windows
43
D FR DOOR
25
Power windows, power door lock system, door courtesy light
44
S/ROOF
20
Electric moonroof
45
HEATER
10
Air conditioning system, rear heater system, rear window defogger, hybrid system
46
IG1
7,5
Hybrid system, power door lock system, multiplex communication system, airbag on−off indicator lights, turn signal lights, back−up lights, outside rear view mirror defoggers, auto anti−glare inside rear view mirror, power outlet (115 VAC), seat heaters, navigation system
47
RR WIP
15
Rear window wiper
48
STOP
20
Stop lights, high mounted stoplight, electronically controlled brake system, transmission control system, hybrid system
49
OBD
7,5
On−board diagnosis system
50
SEAT HTR
15
Seat heaters
51
IG2
15
Multiport fuel injection system/sequential fuel injection system, engine ignition system
Year of production: 2005, 2006, 2007, 2008, 2009, 2010, 2011
Alfa Romeo 159 (939 series) is a mid-size car, produced by the company since 2005 with sedan and station wagon bodies (SPORTWAGON). This material will be useful for the owner of cars produced in 2006, 2007, 2008, 2009, 2010, 2011 to find and replace fuses and relays on the Alfa Romeo 159 car. We will also show box diagrams with a description of the elements and their location.
Locations
Vehicle fuses are grouped into four blocks:
in the passenger compartment
on the positive terminal of the storage battery
in the engine compartment
in the trunk (usually on the left side).
Fuse box on the dashboard
Located behind a plastic cover on the front panel. To access, unscrew the required 2 screws and remove the protective cover.
Alfa Romeo 159 – fuse box – dashboard
Fuse box on the battery positive pole
To access the fuse box on the battery terminal, press in on the latches and remove the protective cover.
Alfa Romeo 159 – fuse box – battery positive pole
Fuse box near the battery
To access the fuse box next to the battery, you need to unscrew the screws.
