Mitsubishi Mirage (2012 – present) – fuse box diagram

Posted on by admin

Mitsubishi Mirage (2012 – present) – fuse box diagram

Year of production: 2012, 2013, 2014, 2015, 2016, 2017, 2018

Instrument panel fuse panel

Mitsubish Mirage - fuse box diagram - instrument panel
Mitsubish Mirage – fuse box diagram – instrument panel
No.
 Function/component
 A
1 Tail light (left) 7.5
2 Cigarette lighter 15
3 Ignition coil 10
4 Starter motor 7.5
5 Not used –
6 Not used –
7 Tail light (right) 7.5
8 Outside rearview mirrors 7.5
9 Engine control unit 7.5
10 Control unit 7.5
11 Rear fog light 10
12 Door lock 15
13 Interior light (Dome light) 15
14 Rear window wiper 15
15 Gauges 7.5
16 Relay 7.5
17 Heated seats 20
18 Option 10
19 Heated outside rearview mirrors 7.5
20 Windshield wiper 20
21 Back-up light 7.5
22 Defogger 30
23 Heater 30
24 Not used –
25 Radio 10
26 Electronic controlled unit 15

Engine compartment fuse box (location)

Mitsubish Mirage - fuse box diagram - engine compartment - location
Mitsubish Mirage – fuse box diagram – engine compartment – location

Engine compartment fuse box (A)

Mitsubish Mirage - fuse box diagram - engine compartment - box A
Mitsubish Mirage – fuse box diagram – engine compartment – box A
No.
 Function/component
 A
SBF1 Radiator fan motor 40
SBF2 Anti-lock braking system 30
SBF3 Ignition switch 40
SBF4 Power window control 40
BF1 DC-DC (P/T) 30
BF2 DC-DC (AUDIO) 30
FI Headlight (low beam) (left) 10
F2 Headlight (low beam) (right) 10
F3 Headlight (high beam) (left) 10
F4 Headlight (high beam) (right) 10
F5 Horn 10
F6 Front fog lights 15
F7 Daytime running lights 10
F8 Not used –
F9 Not used –
F10 Battery current sensor 7.5
F11 Not used –
F12 Stop lights (Brake lights) 15
F13 Ignition coil 7.5
F14 Engine control 7.5
F15 Alternator 7.5
F16 Hazard warning flasher 10
F17 Automatic transaxle 15
F18 Air conditioning 10
F19 ETV 15
F20 Starter 7.5
F21 CVT oil/pump 15
F22 Fuel pump 15
F23 Engine 20
F24 Automatic transaxle 7.5
#1 Spare fuse 20
#2 Spare fuse 30

Engine compartment fuse box (B)

Mitsubish Mirage - fuse box diagram - engine compartment - box B
Mitsubish Mirage – fuse box diagram – engine compartment – box B
No.
 Function/component
 A
SBF1 PTC heater 40
SBF2 PTC heater 40
SBF3 PTC heater 40

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Mitsubishi Outlander (2012 – present) – fuse box diagram

Posted on by admin

Mitsubishi Outlander (2012 – present) – fuse box diagram

Year of production: 2012, 2013, 2014, 2015, 2016, 2017, 2018

Instrument panel fuse panel

Mitsubish Outlander - fuse box diagram - instrument panel
Mitsubish Outlander – fuse box diagram – instrument panel

A – Main fuse block
B – Sub fuse block

Mitsubish Outlander - fuse box diagram - instrument panel
Mitsubish Outlander – fuse box diagram – instrument panel
No.
 Function/component
 A
1 Power window control 30
2 Defogger 30
3 Heater 30
4 Windshield wipers 30
5 Door locks 20
6 Rear fog light 10
7 12 V power outlet 15
8 Rear window wiper 15
9 Sunroof 20
10 Ignition switch 10
11 Option 10
12 Hazard warning flasher 15
13 4-wheel drive system 10
14 Stop lights (Brake lights) 15
15 Gauges 10
16 SRS airbag 7.5
17 Radio 15
18 Control unit relay 7.5
19 Interior lights (Room lights) 15
20 Back-up lights 7.5
21 Heated outside rearview minors 7.5
22 Outside rearview minors 10
23 Cigarette lighter/ 12 V power outlet 15
24 Charge 7.5
25 Power seat 30
26 Heated seats 30

Engine compartment fuse box

Mitsubish Outlander - fuse box diagram - engine compartment
Mitsubish Outlander – fuse box diagram – engine compartment
No.
 Function/component
 A
SBF1 Air conditioning condenser fan motor 30
SBF2 Starter 30
SBF3 Air conditioning condenser fan motor 30
SBF4 Radiator fan motor 40
SBF5 Anti-lock braking system 40
SBF6 VLC 40
SBF7 Anti-lock braking system 30
BF1 Power liftgate 30
BF2 Audio system amplifier 30
BF3 IOD 30
BF4 Diesel 30
F1 Automatic transaxle 20
F2 Wiper de-icer 15
F3 Not used –
F4 Daytime running lights 10
F5 Front fog lights 15
F6 Air conditioner 10
F7 Headlight washer 20
F8 Security horn 20
F9 Horn 10
F10 ETV 15
F11 Alternator 7.5
F12 Engine 7.5
F13 ENG/POWER 20
Fuel line heater 25
F14 Fuel pump 15
F15 Ignition coil 10
F16 ENG/POWER 10
F17 Headlight (high beam) (left) 10
F18 Headlight (high beam) (right) 10
F19 Head light (low beam) (left) (LED) 20
F20 Head light (low beam) (right) (LED) 20
F21 Head light (low beam) (left) (Halogen) 10
F22 Head light (low beam) (right) (Halogen) 10
F23 Battery current sensor 7.5

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Land Rover Range (P38A; 1994 – 2002) – fuse box diagram

Posted on by admin

Land Rover Range (P38A; 1994 – 2002) – fuse box diagram

Year of production: 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002

Right hand seat fuse box

Land Rover Range P38A - fuse box diagram - right hand seat fuse box
Land Rover Range P38A – fuse box diagram – right hand seat fuse box
No.
 A
 Function/component
1 10 Instrument pack, Clock, Radio, Centre console switch pack
2 30 RH rear window, LH/RH seat heater
3 5 EAT ECU – Battery supply
4 30 Transfer box ECU – Battery supply
5 – Spare
6 10 Rear view mirror dip, Spare 1 ignition, Sun visor illumination.
Up to 99MY: EAT ECU Ignition supply, Transfer box ECU ignition supply
7 10 Up to 99MY: Airbag
From 99MY: EAT ECU Ignition supply, Transfer box ECU ignition supply
8 30 Car phone, radio, front cigar lighter, HEVAC.
Up to 99MY: Aerial amplifier
9 20 LH/RH front ICE amplifier, LH/RH door Battery 2
10 30 RH seat Battery 1, RH seat battery 2, RH seat lumbar, Rear cushion battery 1, Fore/aft adjustment battery 1, Front cushion battery 2, backrest battery 2, headrest battery 2
11 – Spare (When spare fuse of at least 5 Amps is inserted, transfer box moves to neutral position)
12 30 Heated rear window, LH rear window
13 20 Shift interlock solenoid, Sunroof
Up to 99MY: Key inhibit solenoid
14 30 LH/RH rear central door locking, Fuel flap release, trailer battery supply
15 20 LH/RH rear ICE amplifiers, Courtesy/Load space lamps, ICE subwoofer RH rear courtesy lamp, RF remote receiver, Tail door central door locking, Rear wiper
16 30 Spare
17 10 Brake switch feed
Up to 99MY: HEVAC ignition signal, Air suspension switches
18 30 6th outstation battery supply (not fitted)
19 – Spare
20 30 LH seat battery 1, LH seat battery 2, LH seat lumbar, Rear cushion battery 1, Fore/aft adjustment battery 1, Backrest battery 2, Front cushion battery 2, Headrest battery 2
21 – Spare
22 30 LH door battery 1 (front window only), RH door battery 2 (front window only)

Engine compartment fuse box

Land Rover Range P38A - fuse box diagram - engine compartment
Land Rover Range P38A – fuse box diagram – engine compartment
No.
 A
 Function/component
1 60 *
2 50 Spare
3 40 ABS pump
4 60 *
5 60 *
23 10 Airbag SRS
24 5 ABS
25 20 Front wiper system, headlight washers
26 20 Engine management system (EMS)
27 10 Air conditioning compressor
28 30 Ignition coils – petrol engines
15 Cooling fan – diesel engines
29 10 Air suspension
30 30 Heated front screen
31 30 Air-conditioning
32 30 Heated front screen
33 5 Diagnostics, battery back-up sounder
34 30 Heater blower
35 10 Air conditioning, air suspension
36 30 Air-conditioning
37 30 Engine management system (EMS)
38 30 ABS
39 20 Fuel pump
40 40 Starter motor, air suspension
41 20 Horn
42 10 Heating & ventilation, key inhibit
43 30 Heater blower
44 30 Engine management system (EMS)

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Fiat Uno – fuse box diagram

Posted on by admin

Fiat Uno – fuse box diagram

Year of production:

Fuse box

Fiat Uno - fuse box diagram
Fiat Uno – fuse box diagram
No.
 A
 Circuit protected
1 7.5 Left front parking, right rear tail lamp, cigar lighter illumination, heater control and clock, digital clock illumination
2 7.5 Right front parking lamp and left rear tail lamp, instrument panel illumination and rear number plate lamp
3 10 Left-hand headlamp (main beam)
4 10 Right-hand headlamp (main beam)
5 25 Engine cooling fan and horn (Comfort)
6 10 Courtesy lamps, cigar lighter, radio power feed, disc pad sensors, economy gauge (ES models)
7 10 Left-hand dipped headlamp, rear foglamps
8 10 Right-hand dipped headlamp
9 20 Heated tailgate glass
10 10 Stop lamps, direction indicator lamps, instrument panel warning lamps, tachometer economy gauge, check control system
11 20 Heater booster fan, digital clock map reading lamp
12 20 Windscreen wiper and washer, rear screen wiper/washer, check system panel illumination
13 10 Front fog lights
14 20 Spare (Comfort), Horn (Super)
15 10 Hazard warning lamps
16 – Spare
17 – Spare
18 – Spare
19 – Spare
Supplementary fuses at side of main fuse block
Fuses (903, 999, 1116, 1299/1301 and 1301 cc Turbo ie)
A 20 Front fog lamps
B 30 Cooling fan (Turbo ie models)
C 10 Fuel injector cooling fan (Turbo ie models)
D 30 Electric windows
E 10 Fuel pump (Turbo ie models)
Fuses (later 903, 999, 1108, 1372 ie and 1372 cc Turbo ie)
A 30 Electric windows
B 25 Central locking (where fitted)
C 10 Injector cooling fan (where fitted)
D 20 Headlamp washers (where fitted)
E 20 Foglamp and warning lamp
F – Spare
G 10 Fuel pump (fuel injection models)
– 10 Heated Lambda sensor
Supplementary fuses on steering column relay bracket
– 10 Antiskid monitor circuit (where fitted)
– 25 Antiskid supply circuit (where fitted)

Auxiliary fuses and relays on 1301 cc Turbo ie models

Fiat Uno - fuse box diagram - auxiliary fuse and relay
Fiat Uno – fuse box diagram – auxiliary fuse and relay
No.
 Circuit protected
1 Horn relay
2 Heated rear screen relay
3 Foglamps relay
4 Radiator fan relay
5 Electric windows relay
Fiat Uno - fuse box diagram - auxiliary fuse
Fiat Uno – fuse box diagram – auxiliary fuse
Fiat Uno - fuse box diagram - auxiliary fuse
Fiat Uno – fuse box diagram – auxiliary fuse

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market..

Vauxhall Omega B (1994 – 2003) – fuse box diagram

Posted on by admin

Vauxhall Omega B (1994 – 2003) – fuse box diagram

Year of production: 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003

Fuse box

Vauxhall Omega B - fuse box diagram
Vauxhall Omega B – fuse box diagram
Vauxhall Omega B - fuse box diagram
Vauxhall Omega B – fuse box diagram
No.
 Function/component
 A
1 Electric windows 30
2 Brake lamps, hazard warning lights, information display 15
3 Windscreen wipers, rear window wiper, windscreen wash system 30
4 Cooling fan 15
5 Adjustable front seats, position memory, clamp 30: continuous trailer current 30
6 Radio, infotainment system 20
7 Check control, engine oil level, courtesy lamp 10
8 Daytime running lights 10
9 Automatic transmission, reversing lamps 10
10 Heated diesel fuel filter 30
11 Heated exterior mirrors 10
12 Instruments, electronic air conditioning system, Hazard warning lights, central locking system, Vauxhall alarm system information display, radio, infotainment system 20
13 Adjustable exterior mirrors, electric windows, sun roof, central locking system 10
14 Power steering, Vauxhali alarm system, cigarette lighter, rear window blind, air conditioning system, heated front seats, heated wiper jets 30
15 Reversing lamps, level control system, Vauxhall alarm system, seat and mirror setting, information display, heated seats, control indicators, instruments, instrument illumination, windscreen wipers, cooling fan, headlamp range adjustment 20
16 Fog lamps 20
17 Horn 20
18 Fuel pump 20
19 ABS, TC, ESP 10
20 Heated seats, central locking system, rear window blind 20
21 Main beam (left) 10
22 Dipped beam (left), headlamp range adjustment 15
23 Parking and tail lamps (left) 10
24 Coolant heating 20
25 Sun roof 20
26 Numberplate lamp, automatic transmission, head lamp wash system 10
27 Level control, accessory socket 20
28 Fog tail lamps 10
29 Cooling fan, heated seats, courtesy lamp, airbags 10
30 Parking and tail lamps (right) 10
31 Dipped beam (right), head lamp range adjustment 15
32 Main beam (right) 10
33 Electronic air conditioning system 30
34 Rear window, cooling fan 40
35 Window lifter 30

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market..

Opel Omega B (1994 – 2003) – fuse box diagram

Posted on by admin

Opel Omega B (1994 – 2003) – fuse box diagram

Year of production: 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003

Fuse box

Opel Omega B - fuse box diagram
Opel Omega B – fuse box diagram
Opel Omega B - fuse box diagram
Opel Omega B – fuse box diagram
No.
 Function/component
 A
1 Electric windows 30
2 Brake lamps, hazard warning lights, information display 15
3 Windscreen wipers, rear window wiper, windscreen wash system 30
4 Cooling fan 15
5 Adjustable front seats, position memory, clamp 30: continuous trailer current 30
6 Radio, infotainment system 20
7 Check control, engine oil level, courtesy lamp 10
8 Daytime running lights 10
9 Automatic transmission, reversing lamps 10
10 Heated diesel fuel filter 30
11 Heated exterior mirrors 10
12 Instruments, electronic air conditioning system, Hazard warning lights, central locking system, Vauxhall alarm system information display, radio, infotainment system 20
13 Adjustable exterior mirrors, electric windows, sun roof, central locking system 10
14 Power steering, Vauxhali alarm system, cigarette lighter, rear window blind, air conditioning system, heated front seats, heated wiper jets 30
15 Reversing lamps, level control system, Vauxhall alarm system, seat and mirror setting, information display, heated seats, control indicators, instruments, instrument illumination, windscreen wipers, cooling fan, headlamp range adjustment 20
16 Fog lamps 20
17 Horn 20
18 Fuel pump 20
19 ABS, TC, ESP 10
20 Heated seats, central locking system, rear window blind 20
21 Main beam (left) 10
22 Dipped beam (left), headlamp range adjustment 15
23 Parking and tail lamps (left) 10
24 Coolant heating 20
25 Sun roof 20
26 Numberplate lamp, automatic transmission, head lamp wash system 10
27 Level control, accessory socket 20
28 Fog tail lamps 10
29 Cooling fan, heated seats, courtesy lamp, airbags 10
30 Parking and tail lamps (right) 10
31 Dipped beam (right), head lamp range adjustment 15
32 Main beam (right) 10
33 Electronic air conditioning system 30
34 Rear window, cooling fan 40
35 Window lifter 30

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market..

Mercedes-Benz w203 C-Class (2000 – 2007) – fuse box diagram

Posted on by admin

Mercedes-Benz w203 C-Class (2000 – 2007) – fuse box diagram

Year of production: 2001, 2001, 2002, 2003, 2004, 2005, 2006, 2007

Luggage compartment fuse box

Mercedes-Benz C-Class w203 - fuse box diagram - luggage compartment
Mercedes-Benz C-Class w203 – fuse box diagram – luggage compartment
No.
 Circuit protected
 A
1 Front passenger front seat adjustment control unit with memory
Front passenger partially-electric seat adjustment switch		 30
2 Driver front seat adjustment control unit with memory
Driver partially-electric seat adjustment switch		 30
3 Dome lamp
Right luggage compartment lamp
Left luggage compartment lamp
STH radio remote control receiver		 7.5
TV tuner (up to 29.2.04)
TV tuner (MOST) (as of 1.4.04)		 20
4 Fuel pump relay (N10/2kA) 20
5 Valid for engine 112.961 (up to 31.3.04): Charge air cooler circulation pump
Valid without engine 112.961: Backup relay 2		 20
6 Spare 25
7 Backup relay 1 7.5
8 Amplifier module, window antenna
Alarm signal horn (H3) ATA [EDW] inclination sensor		 7,5
9 Overhead control panel control unit 25
10 Heated rear window 40
11 Spare 20
12 Interior socket
Valid for model 203.0 USA version (up to 31.3.04): Power outlet		 15
13 Multicontour seat pneumatic pump
Voice control system control unit
Rear dome lamp
Rear dome lamp PTS warning indicator
PTS control unit
Japan version: VICS+ETC voltage supply separation point.		 5
14 Tailgate wiper motor 15
15 Fuel filler cap polarity change relay 1
Fuel filler cap polarity change relay 2		 10
16 Voice control system control unit 20
17 Trailer recognition control unit 20
18 Trailer hitch socket (13-pin) 20
19 Multicontour seat pneumatic pump 20
20 Rear window roller blind relay
Valid for model 203.2/7 USA version: Power outlet		 15
Relay
A Fuel pump relay
B Relay 2, terminal 15R
C Reserve relay 2
D Reserve relay 1
E Rear window defroster relay
F Relay 1, terminal 15R
G Filler cap relay, polarity reverser 1
H Filler cap relay, polarity reverser 2

The instrument panel fuse panel

Mercedes-Benz C-Class w203 - fuse box diagram - instrument panel
Mercedes-Benz C-Class w203 – fuse box diagram – instrument panel
No.
 Circuit protected
 A
21 Left front door control unit 30
22 Right front door control unit 30
23 Up to 30.11.04: Central gateway control unit 15
24 CD player with changer (in glove compartment) 7.5
25 Upper control panel control unit 30
26 Sound amplifier 25
27 Driver-side front seat adjustment control unit, with memory
Special vehicle multifunction control unit (SVMCU [MSS])		 30
28 Spare 30
29 Driver-side front seat adjustment control unit, with memory
Driver-side front seat adjustment control unit, with memory
Special vehicle multifunction control unit		 30
30 Heating systems recirculation unit 40
31    EIS [EZS] control unit
Electric steering lock control unit		 20
32 Left rear door control unit 30
33 Right rear door control unit 30
34 Cell phone separation point
up to 31.5.01:
Telephone and TELE AID transmitter/receiver, D2B
Telephone transmitter and receiver unit, D2B
Telephone interface
E-net compensator
up to 31.5.01, Japan version: E-call control unit		 7.5
up to 31.3.04: Front passenger front seat adjustment control unit with memory
as of 1.4.04: Passenger-side front seat adjustment control unit with memory
up to 31.5.03, Taxi: Special vehicle multifunction control unit
as of 1.6.03, Taxi: Special vehicle multifunction control unit
as of 1.6.01, Police: Special vehicle multifunction control unit		 15
as of 1.4.04: Front passenger front seat adjustment control unit with memory
as of 1.4.04, Taxi: Special vehicle multifunction control unit		 30
35 up to 31.3.04: STH heater unit 30
as of 1.4.04: STH heater unit 20
36 up to 31.3.04, Police: Interior socket 30
Valid for engine (612.990) (up to 29.2.04): Charge air cooler circulation pump
as of 1.4.04, Japan version: Audio gateway control unit		 15
Universal Portable CTEL Interface (UPCI [UHI]) control unit 7.5
37 Charge air cooler circulation pump
up to 29.2.04: Brake booster vacuum pump control unit		 25
38 up to 29.2.04:Passenger-side front seat adjustment control unit with memory
as of 1.4.04, Police:Special vehicle multifunction control unit (SVMCU [MSS])		 30
39 Spare 30
40 Passenger-side front seat adjustment control unit with memory
Universal Portable CTEL Interface (UPCI [UHI]) control unit
Cell phone separation point
Telephone interface
E-net compensator
as of 1.6.01, MB standard telephone: Telephone transmitter and receiver unit, D2B
as of 1.6.01, TELE AID: Telephone and TELE AID transmitter/receiver, D2B
as of 1.6.01, Canadian vehicles: Via the trunk lid/FFS [RBA] separation point the trunk lid emergency release switch and the rear SAM control unit with fuse and relay module
USA version: Via the trunk lid/FFS [RBA] separation point the trunk lid emergency release switch and the rear SAM control unit with fuse and relay module
as of 1.4.04, Japan version: E-call control unit		 7.5
up to 31.5.01: Special vehicle multifunction control unit 30
41 HEAT control and operating unit
up to 31.5.01:
AAC [KLA] control and operating unit
Comfort AAC [kLa] control and operating unit		 7,5
as of 1.6.01:
AAC [KLA] control and operating unit
Comfort AAC [KLA] control and operating unit		 15
42 Instrument cluster 7.5

Engine compartment fuse box

Mercedes-Benz C-Class w203 - fuse box diagram - engine compartment
Mercedes-Benz C-Class w203 – fuse box diagram – engine compartment
No.
 Circuit protected
 A
43a Fanfare horn relay 15
43b Fanfare horn relay 15
44 Telephone and TELE AID transmitter/ receiver, D2B
Telephone transmitter and receiver unit, D2B
Cell phone separation point		 5
45 Restraint systems control unit 7.5
46 Wiper ON/OFF relay
Wiper speed 1 and 2 relay		 40
47 Glove compartment illumination with switch
Front cigar lighter (with illumination)		 15
48 Valid for engine 612.990 (up to 31.3.04): Brake booster vacuum pump control unit
Valid for engine 112 and engine 113: Circuit 15 connector sleeve (fused)
Valid for engine 646, USA version (up to 31.3.04): Circuit 30 connector sleeve
Valid for engine 646 (as of 1.4.04): O2 sensor upstream of TWC [kAt] connector		 15
49 Restraint systems control unit 7.5
50 Light switch module
Valid for engine 612.990
Glow output stage (up to 31.3.04)
Hot film mass air flow sensor (1.4.04 up to 30.11.04)		 5
51 AAC with integrated control additional fan motor
Instrument cluster
Valid for code (581) comfort automatic air conditioning:
C-AAC [K-KLA] multifunction sensor
C-AAC [K-KLA] sun sensor (4 in total)
Left front lamp unit
Right front lamp unit
Valid for AMG vehicles: Charge air cooler circulation pump
Valid for model 203.0 (up to 31.7.01): SPS [PML] control unit		 7.5
52 Starter 15
53 Valid for diesel engines:
   Starter relay
Rear SAM control unit with fuse and relay module
Valid for engine 611/612/642/646: CDI control unit		 25
Valid for gasoline engines:
Starter relay
Rear SAM control unit with fuse and relay module
Valid for engine 111/271/272: ME-SFI [ME] control unit
Valid for engine 112/113:
ME-SFI [ME] control unit
Circuit 87M1e connector sleeve		 15
54 Valid for engine 271.940:
ME-SFI [ME] control unit
Purge control valve (USA version)
Activated charcoal canister shutoff valve
Valid for engine 271.942: NOX (nitrogen oxides) control unit
Valid for engine 642/646: CDI control unit
Valid for engine 642/646: Circuit 30 connector sleeve		 15
Valid for engines 611/612: CDI control unit
Valid for engine 611/612 (up to 30.11.04): Vent line heater element		 7,5
55 Steering angle sensor
Distronic: DTR control unit
Valid for transmission 722:
ETC [EGS] control unit (up to 31.5.04)
Electronic selector lever module control unit
Electric controller unit (VGS)
Valid for transmission 716:
Gear recognition switch
Automated manual transmission control unit		 7.5
56 ESP and BAS control unit
Stop light switch		 5
57 Steering angle sensor (up to 31.5.02)
EIS [EZS] control unit
Steering column module (as of 1.6.02)
Valid for engine 112/113: ME-SFI [ME] control unit		 5
58 Valid for transmission 716: SEQ hydraulic pump 40
59 ESP and BAS control unit 50
60 ESP and BAS control unit 40
61 Valid for transmission 716: Automated manual transmission control unit 15
62 Data link connector
Light switch module
Stop light switch		 5
63 Light switch module 5
64 Radio
Radio and navigation unit
COMAND operating, display and control unit		 10
65 Valid for engine 112/113: Electric air pump 40
Relay
I Fanfare horn system relay
K Terminal 87 relay, chassis
L Wiper speed 1 and 2 relay
M Terminal 15R relay
N SEQ [ASG] pump control relay (with Sequentronic automated manual transmission (ASG))
O Air pump relay (engines 112, 113, 271 only)
P Terminal 15 relay
Q Wiper ON/OFF relay
R Terminal 87 relay, engine
S Starter relay

Front prefuse box

Mercedes-Benz C-Class w203 - fuse box diagram - front prefuse box
Mercedes-Benz C-Class w203 – fuse box diagram – front prefuse box
No.
 Circuit protected
 A
1 Interior fuse box 125
2 Rear SAM control unit with fuse and relay module 200
3 Additional fuse holder l, spare wheel well 125
4 Front SAM control unit with fuse and relay module 200
5 Engine and AC electric suction fan with integrated control
Valid for diesel engines: Glow output stage		 125
6 Front SAM control unit with fuse and relay module 60

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Citroen C4 (2010 – present) – fuse box diagram

Posted on by admin

Citroen C4 (2010 – present) – fuse box diagram

Year of production: 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023

The instrument panel fuse panel

Citroen C4 - fuse box diagram - instrument panel
Citroen C4 – fuse box diagram – instrument panel
Citroen C4 - fuse box diagram - instrument panel
Citroen C4 – fuse box diagram – instrument panel
No.
 A
 Description
R1 – Not used
R2 – 12 V socket in boot
F3 20 Parking lamps, trailer hazard warning lamps
F4 20 Interior lighting, trailer interface
F5 30 Front one-touch electric windows
F6 30 Rear one-touch electric windows
F11 20 12 V trailer socket
F12 30 Panoramic sunroof blind
F13 30 Hi-Fi amplifier
F22 20 Trailer signalling
F8 3 Alarm siren, alarm ECU
F13 10 Cigar lighter
F14 10 12V socket in boot
F16 3 Lighting for the large multifunctional storage unit, rear map reading lamps, glove box illumination
F17 3 Sun visor illumination, front map reading lamps
F28 15 Audio system, radio (after-market)
F30 20 Rear wiper
F32 10 Hi-Fi amplifier
F36 15 Rear 12 V socket
F37 – Not used
F38 – Not used
F39 – Not used
F40 – Not used

Engine compartment fuse box

Citroen C4 - fuse box diagram - engine compartment
Citroen C4 – fuse box diagram – engine compartment
No.
 A
 Description
F19 30 Windscreen wipers slow/fast speed
F20 15 Front and rear screenwash pump
F21 20 Headlamp wash pump
F22 15 Horn
F23 15 Right-hand main beam headlamp
F24 15 Left-hand main beam headlamp
F27 5 Left-hand dipped headlamp
F28 5 Right-hand dipped headlamp

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market..

Mercedes-Benz ML-Class W164 (2005 – 2011) – fuse box diagram

Posted on by admin

Mercedes-Benz ML-Class W164 (2005 – 2011) – fuse box diagram

Year of production: 2005, 2006, 2007, 2008, 2009, 2010, 2011

Luggage compartment fuse box

Up to 31.05.2006

Mercedes-Benz ML w164 - fuse box diagram - luggage compartment
Mercedes-Benz ML w164 – fuse box diagram – luggage compartment

As of 01.06.2006

Mercedes-Benz ML w164 - fuse box diagram - luggage compartment
Mercedes-Benz ML w164 – fuse box diagram – luggage compartment
No.
 Description
 A
20 Up to 2008: Roof antenna module
As of 2009: Interference suppression filter for radio antenna
As of 2009: Microphone array control unit (Japanese version)		 5
21 RCP [HBF] control unit 5
22 PTS control unit
STH radio remote control receiver		 5
23 DVD player
Rear audio control unit
Portable CTEL separation point (Japanese version)
E-net compensator
Bluetooth module
Universal Portable CTEL Interface (UPCI [UHI]) control unit (Japanese version)		 10
24 Right front reversible emergency tensioning retractor 40
25 COMAND operating, display and control unit 15
26 Right front door control unit 25
27 Passenger-side front seat adjustment control unit with memory
Front passenger seat adjustment comfort relay		 30
28 Driver-side front seat adjustment control unit, with memory
Driver seat adjustment comfort relay		 30
29 Left front reversible emergency tensioning retractor 40
30 As of 2009: Folding rear bench seat control unit
Valid for engine 156:
Left fuel pump control unit
Right fuel pump control unit
Valid for model 164.195 (ML 450 Hybrid): Fuel pump control unit circuit 30 connector sleeve		 40
31 HS [SIH], seat ventilation and steering wheel heater control unit 10
32 AIRmatic control unit 15
33 KEYLESS-GO control unit 25
34 Left front door control unit 25
35 Amplifier for sound system
As of 2009: Subwoofer amplifier		 30
36 Emergency call system control unit 10
37 Backup camera power supply module (Japanese version)
Backup camera control unit (Japanese version)		 5
38 Digital TV tuner
Up to 2008: Audio gateway control unit (Japanese version)
As of 2009: TV combination tuner (analog/digital) (Japanese version)
Valid for model 164.195 (ML 450 Hybrid): High voltage battery module		 10
39 Tire pressure monitor [RDK] control unit
Up to 2008: SDAR control unit (USA version)
As of 2009: High definition tuner control unit
As of 2009: Digital Audio Broadcasting control unit
As of 2009: External navigation separation point (South Korea version)		 7.5
40 Up to 2008: Rear-end door closing control unit 40
As of 2009: Rear-end door closing control unit 30
41 Overhead control panel control unit 25
42 Up to 2008: SR motor
As of 2009: Overhead control panel control unit		 25
43 As of 2009; Valid for engine 272, 273: Fuel pump control unit
Up to 31.05.2006: Tailgate wiper motor
As of 01.06.2006: Not assigned		 20
44 Up to 31.05.2006: Left 2nd seat row socket
Up to 31.05.2006: Right 2nd seat row socket
As of 01.06.2006: Not assigned
As of 2009: Front interior socket (USA)
As of 2009: 115V socket		 20
45 Cargo area connector box
Up to 2008: Front interior socket
As of 2009: Right 2nd seat row socket		 20
46 Front cigar lighter with ashtray illumination  15
47 Valid for model 164.195 (ML 450 Hybrid): High voltage battery coolant pump
As of 2009: Left front illuminated door sill molding
As of 2009: Right front illuminated door sill molding		 10
48 As of 2009: Rear axle differential lock control unit
As of 2009; Valid for engine 642.820: AdBlue® supply relay
As of 1.7.09; Valid for model 164.195 or model 164.1 with engine 272 or model 164.8 with engine 642 or 273: Pyrotechnical separator		 5
49 Heated rear window 30
50 Up to 31.05.2006: Tailgate wiper motor 10
As of 01.06.2006: Tailgate wiper motor 15
51 Activated charcoal canister shutoff valve 5
52 Up to 31.5.09: Left front reversible emergency tensioning retractor
Up to 31.5.09: Right front reversible emergency tensioning retractor
As of 2009: Rear axle differential lock control unit		 5
53 AIRmatic control unit
Valid for engine 156:
Left fuel pump control unit
Right fuel pump control unit
Valid for engine 272, 273: Fuel pump control unit
As of 2009: Transfer case control unit		 5
54 Headlamp range adjustment control unit
Front SAM control unit		 5
55 Instrument cluster
Rotary light switch		 7.5
56 Up to 31.05.2006: Data link connector
Valid for engine 642.820: AdBlue® control unit
Valid for model 164.195: Fuel pump control unit		 5
57 Up to 2008: Fuel pump with fuel gauge sensor
Valid without engine 156: Fuel pump		 20
58 Datalink connector
Central gateway control unit		 7.5
59 As of 2009: Driver NECK-PRO head restraint solenoid
As of 2009: Front passenger NECK-PRO head restraint solenoid		 7.5
60 Glove compartment illumination with switch
Engine compartment fuse and relay box
Rear SAM control unit
Cell phone separation point
VICS+ETC voltage supply separation point (Japan version)
Multicontour seat pneumatic pump (as of 2009)
External navigation separation point (South Korea)
Electrical connection, Blind-Spot-Monitoring interior rear bumper (as of 1.8.10)
Emergency call system control unit (USA)		 5
61 Up to 2008:
Restraint systems control unit
Right front seat contacting strip		 10
As of 2009:
Restraint systems control unit
Right front seat contacting strip		 7.5
62 Front passenger seat adjustment switch 30
63 Driver lumbar support regulator control unit
Front passenger lumbar support regulator control unit
Driver seat adjustment switch		 30
64 Spare –
65 Spare –
66 As of 2009: Multicontour seat pneumatic pump 30
67 Rear air conditioning blower motor 25
68 Up to 2008: Left 2nd row seat heated cushion
Up to 2008: Right 2nd row seat heated cushion
As of 2009: HS [SIH], seat ventilation and steering wheel heater control unit		 25
69 As of 2009: Rear axle differential lock control unit 30
70 Trailer hitch socket (13-pin) (as of 2009)
Trailer hitch socket (7-pin)		 20
Trailer hitch socket (13-pin) (up to 2008) 15
71 Electric brake control separation point 30
72 Trailer hitch socket (13-pin) 15
Relay
K Up to 31.05.2006: Terminal 15R power outlet relay, with power-down
As of 01.06.2006: Circuit 15R seat adjustment
As of 2009: Relay, circuit 15R sockets (with K power-down) (power supply of electric seat adjustment)
L Terminal 30X
M Heated rear window relay
N Circuit 15 relay / terminal 87FW
O Fuel pump relay
P Rear wiper relay
R Circuit R relay115R
S Reserve 1 (changer) (power supply for front socket)
T As of 01.06.2006Circuit 30, socket for 2nd seat row and load compartment
As of 2009: Reserve 2 (normally open contact) (power supply for center and rear sockets)
U As of 01.06.2006Circuit 30, trailer
V As of 01.06.2006 –

Engine compartment fuse box

Mercedes-Benz ML w164 - fuse box diagram - engine compartment
Mercedes-Benz ML w164 – fuse box diagram – engine compartment
No.
 Description
 A
100 Wiper motor 30
101 AAC with integrated control additional fan motor
Valid for engine 156: Terminal 87 M3e connector sleeve
Valid for engine 156, 272, 273: Purge control valve
Valid for engines 272, 273:
Circuit 87 M1e connector sleeve
Suction-type fan control unit
Valid for engine 629:
CDI control unit
Circuit 30 connector sleeve
Suction fan control unit
Valid for model 164.195:
ME-SFI [ME] control unit
Engine compartment/engine connector
Valid for engine 642 except 642.820:
CDI control unit
O2 sensor upstream of CAT
Suction fan control unit
Valid for engine 642.820: O2 sensor upstream of CAT		 15
102 Valid for engine 642.820 up to 31.7.10: Recirculation pump for transmission oil cooler
Valid for engine 156: Engine coolant circulation pump
 15
Valid for model 164.195:
Recirculation pump for transmission oil cooler
Low temperature coolant pump		 10
103 Circuit 87 M1e connector sleeve
CDI control unit
Up to 2008; Valid for engines 113, 272, 273: ME-SFI [ME] control unit		 25
Valid for model 164.195: ME-SFI [ME] control unit
Valid for engine 272, 273:ME-SFI [ME] control unit		 20
104 Valid for engine 156, 272, 273: Terminal 87M2e connector sleeve
Valid for engine 629: Terminal 87 connector sleeve
Valid for engine 642.820: Terminal 87 D2 connector sleeve
Valid for engine 642 except 642.820: CDI control unit
Valid for model 164.195:
Interior and engine wiring harness connector
Engine compartment fuse and relay box
Valid for engine 113: ME control unit		 15
105 Valid for engine 156, 272, 273:
ME-SFI [ME] control unit
Circuit 87 M1 i connector sleeve
Valid for engine 629: CDI control unit
Valid for engine 642.820:
CDI control unit
Fuel pump relay
Valid for engine 642 except 642.820:
CDI control unit
Fuel pump relay (as of 2009)
Starter (up to 2008)
Valid for model 164.195: Interior and engine wiring harness connector
Valid for engine 113: Circuit 15 connector sleeve, fused		 15
106 Spare –
107 Valid for engine 156, 272 and 273: Electric air pump
Valid for model 164.195: Engine compartment/engine connector		 40
108 AIRMATIC compressor unit 40
109 ESP control unit
Valid for model 164.195: Regenerative braking system control unit		 25
110 Alarm signal siren 10
111 Intelligent servo module for DIRECT SELECT 30
112 Left front lamp unit
Right front lamp unit		 7.5
113 Left fanfare horn
Right fanfare horn		 15
114 Up to 2008: –
As of 2009: Front SAM control unit
Valid for engine 629: CDI control unit		 5
115 ESP control unit
Valid for model 164.195: Regenerative braking system control unit		 5
116 Electric controller unit (VGS)
Valid for model 164.195: Hybrid vehicle fully integrated transmission control controller unit		 7.5
117 DTR controller unit 7.5
118 Valid for engine 156, 272, 273: ME-SFI [ME] control unit
Valid for engine 629, 642: CDI control unit		 5
119 Valid for engine 642.820: CDI control unit 5
120 Valid for engine 156, 272, 273:
ME-SFI [ME] control unit
Engine circuit 87 relay
Valid for engine 113: ME-SFI [ME] control unit
Valid for engine 629: CDI control unit
Valid for engine 629, 642: Engine circuit 87 relay		 10
121 STH heater unit
Valid for model 164.195: Fuse and relay box 2, engine compartment		 20
122 Valid for engine 156, 272, 273, 629, 642: Starter
Valid for engine 113, 272, 273: ME-SFI [ME] control unit		 25
123 Valid for engine 642: Fuel filter condensation sensor with heating element
Valid for engine 629, 642 as of 1.9.08: Fuel filter condensation sensor with heating element		 20
124 Valid for model 164.120/122/822/825 as of 1.6.09, Model 164.121/124/125/824: Electrohydraulic power steering
Valid for model 164.195:
Electrohydraulic power steering
Electric refrigerant compressor control unit		 7.5
125 Valid for model 164.195: Power electronics control unit 7.5
Relay
A Wiper level relay 1/2
B Wiper ON / OFF
C Valid for engine 642: Additional circulation pump for transmission oil cooling
Valid for engine 156: Engine coolant circulation pump
D Terminal 87 engine
E Secondary air injection pump
F Fanfare horn
G Air suspension compressor
H Circuit 15
I Starter

Battery compartment prefuse box

Mercedes-Benz ML w164 - fuse box diagram - battery compartment-prefuse
Mercedes-Benz ML w164 – fuse box diagram – battery compartment-prefuse
No.
 Description
 A
78 up to 30.6.09: PTC heater booster 100
up to 2008; as of 1.7.09: PTC heater booster 150
79 Rear SAM control unit 60
80 Rear SAM control unit 60
81 Valid for engine 642.820: AdBlue® relay supply 40
Valid as of 1.7.09 without engine 642.820: Engine compartment fuse and relay box
Valid for model 164.195: Vacuum pump relay (+)
Up to 2008: –		 150
82 Load compartment fuse and relay box 100
83 Weight Sensing System (WSS) control unit 5
84 Restraint systems control unit 10
85 As of 2009: DC/AC converter control unit (115 V socket) 25
Up to 2008: Intelligent servo module for DIRECT SELECT 30
86 Cockpit fuse box 30
87 Transfer case control unit 30
Valid for model 164.195:Fuse and relay box 2, engine compartment 15
88 Front SAM control unit 70
89 Front SAM control unit 70
90 Front SAM control unit 70
91 As of 2009: AC air recirculation unit
Up to 2008: Blower regulator		 40

Front prefuse

Mercedes-Benz ML w164 - fuse box diagram - front prefuse
Mercedes-Benz ML w164 – fuse box diagram – front prefuse
No.
 Description
 A
4 Spare –
5 Valid for model 164.195 (ML 450 Hybrid): Regenerative braking system control unit 40
6 ESP control unit 40
Valid for model 164.195 (ML 450 Hybrid): Electrohydraulic power steering 80
7 AAC with integrated control additional fan motor 100
8 up to 2008: Engine compartment fuse and relay box 150
as of 2009: Engine compartment fuse and relay box 100

Fuse box in passenger compartment

Mercedes-Benz ML w164 - fuse box diagram - passenger compartment
Mercedes-Benz ML w164 – fuse box diagram – passenger compartment
No.
 Description
 A
10 Booster blower electronic blower controller 10
11 Instrument cluster 5
12 AAC [KLA] control and operating unit
Comfort AAC [KLA] control and operating unit		 15
13 Steering column module Upper control panel control unit 5
14 EIS [EZS] control unit 7.5
15 Electronic compass
Media interface control unit		 5
16 Spare –
17 Spare –
18 Spare –

AdBlue® fuse block

Mercedes-Benz ML w164 - fuse box diagram - AdBlue fuse block
Mercedes-Benz ML w164 – fuse box diagram – AdBlue fuse block
No.
 Description
 A
A AdBlue® control unit 15
B AdBlue® control unit 20
C AdBlue® control unit 7.5
D Spare –

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

KIA Avella (1994 – 2000)- fuse box diagram

Posted on by admin

KIA Avella (1994 – 2000) – fuse box diagram

Year of production: 1994, 1995, 1996, 1997, 1998, 1999, 2000

Instrument panel fuse panel

KIA Avella - fuse box diagram - instrument panel
KIA Avella – fuse box diagram – instrument panel
Fuse
 A
 Protected Component
ACC 15 Cigar lighter, Stereo
ENGINE 10 Cooling fan relay, Main relay
METER 15 Meter warning lamp (Rear defroster, Engine, Charge, oil pressure), Rear defroster relay, TWS unit, Back lamp, Flasher unit, Meter set (Fuel, Tacho, Turn indicator), Turn signal lamp
Rr. DEFROSTER 20 Rear defroster
REAR WIPER 15 Rear wiper and washer, Blower motor unit
WIPER 20 Front wiper and washer, A/C switch, A/C relay, ADD fan relay
BLOWER 30 Blower motor
ROOM 10 TWS unit, Powertrain control module, Room lamp, Stereo, Back-up
HAZARD 15 Flasher and hazard lamp
STOP 15 Cargo lamp, Horn relay, Horn, Stop lamp
TAIL 15 Turn signal lamp, Front side marker lamp, Illumination, License lamp, Tail lamp, Front park lamp

Engine compartment fuse box

KIA Avella - fuse box diagram - engine compartment
KIA Avella – fuse box diagram – engine compartment
Fuse
 A
 Protected Component
EGI INJ. 30 EGI system
HEAD 30 Headlamp
C.FAN 30 Cooling fan motor,  ADD fan motor, Magnetic clutch
MAIN 80 Hazard lamp, Cargo lamp, Horn, Stop lamp, Powertrain control module, TNS relay, Illumination (Panel, A/C switch, A/T indicator, Rear defroster switch), License lamp, Tail lamp, Front side marker lamp, Cigar lighter, Stereo, Cooling fan relay, Main relay, Ignition coil, Rear defroster relay, Meter warning lamp (Rear defroster, Engine, Fuel, Tacho, Temp, Brake, Charge, Oil pressure), Back lamp, Flasher uni, Turn signal lamp, Rear defroster, Rear wiper and washer, Blower motor relay, Front wiper and washer, TWS unit, Interior lamp

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
