KIA Cadenza (VG; 2011 – 2016) – fuse box diagram

Posted on by admin

KIA Cadenza (VG; 2011 – 2016) – fuse box diagram

Year of production: 2011, 2012, 2013, 2014, 2015, 2016

Instrument panel fuse panel (2011)

KIA Cadenza - fuse box diagram - instrument panel
KIA Cadenza – fuse box diagram – instrument panel
No. A Fuse Circuit Protected
F1 10 – –
F2 10 ROOM LP ICM Relay Box (Room Lamp Auto Cut Relay)
F3 10 WIPER 2 IPM (Washer Switch), Multifunction Switch (Wiper) Washer Motor
F4 25 PDM 1 PDM
F5 10 PDM 3 PDM, Smart Key Control Module
F6 15 A/BAG SRS Control Module
F7 25 P/WDW LH Driver Safety Power Window Module Rear Door Mood Lamp LH Driver Door Mood Lamp, Rear Power Window Switch LH
F8 25 P/WDW RH Passenger Door Module .Passenger Door Mood Lamp Rear Door Mood Lamp RH, Rear Power Window Switch RH
F9 10 CURTAIN Driver/Passenger Door Module, Rear Curtain Module
F10 20 S/H EATER FRT Driver/Passenger CCS Control Module Driver/Passenger Seat Warmer Module
F11 20 – –
F12 10 PDM 2 FOB Holder, PDM, Smart Key Control Module Start Stop Button Switch
F13 10 MODULE 2 ATM Shift Lever Illumination, Instrument Cluster Multifunction Switch (Remote Control) Tilt & Telescopic Module, Head Lamp Leveling Device Actuator LH/RH, Auto Head Lamp Leveling Device Module IMS Control Module, Head Lamp Leveling Device Switch Front CCS Switch, Front Seat Warmer Switch Driver/Passenger CCS Control Module Driver/Passenger Seat Warmer Module Rear Seat Warmer Module LH/RH, Rear Seat Warmer Switch Driver/Passenger Door Module, Electro Chromic Mirror LDWS Camera Module, Room Lamp (Deluxe Type)
F14 10 A/BAG IND Instrument Cluster (Air Bag IND.)
F15 10 MODULE 3 ABS Control Module, ESP Control Module, ESP Off Switch Yaw Rate Sensor, Steering Angle Sensor
F16 20 IG 1 E/R Fuse & Relay Box (Fuse – F10, F11, F12)
F17 20 SUNROOF Panorama Sunroof
F18 20 DR LOCK Driver Door Module
F19 15 ECS ICM Relay Box (Rear Fog Lamp Relay)
F20 10 AUDIO 2 Audio, Audio Monitor, Amp, Overhead Console Lamp Switch PDM, Smart Key Control Module
F21 15 POWER OUTLET 2 Console Power Outlet
F22 15 POWER OUTLET 1 (Not Used)
F23 15 C/LIGHTER Front Cigarette Lighter
F24 25 AMP Amp
F25 10 TRUNK Trunk Lid Relay, Trunk Main Switch, Trunk Lid Motor Fuel Filler Door Switch
F26 20 S/H EATER RR Rear Seat Warmer Module LH/RH
F27 10 POWERCONNECTOR MEMORY Driver/Passenger Foot Lamp, Data Link Connector Auto Light & Photo Sensor, Instrument Cluster (MICOM, IND.) Rear Curtain Module, Door Warning Switch Garnish Lamp LH/RH/Center, Tilt & Telescopic Module A/C Control Module, Loom Lamp (Deluxe Type) Driver/Passenger Door Scuff Lamp, IMS Control Module Driver/Passenger Door Lamp, Driver/Passenger Door Module RF Receiver, Trunk Room Lamp
F28 15 POWERCONNECTOR AUDIO 1 Audio, Audio Monitor
F29 10 MODULE 1 PDM, Rear Curtain Module, Rain Sensor Panorama Sunroof, ICM Relay Box (Head Lamp Washer Relay)
F30 10 – –
F31 25 WIPER 1 Front Wiper Motor, Multifunction Switch (Wiper) E/R Fuse & Relay Box (RLY. 11. RLY. 12)
F32 15 HTD HANDLE Steering Wheel Heated
F33 20 P/SEAT PASS Passenger Manual Switch
F34 30 P/SEAT DRI Driver Lumbar Support Switch, Driver Cushion Extension Switch Driver Manual Switch, IMS Control Module
F35 15 P/HANDLE Key Solenoid, Tilt & Telescopic Module, Sport Mode Switch
F36 10 A/CON A/C Control Module, Ionizer, E/R Fuse & Relay Box (RLY. 14)
F37 10 HTD MRR Driver/Passenger Power Outside Mirror, A/C Control Module
F38 10 START [W/O Smart Key] Ignition Switch, Burglar Alarm Relay E/R Fuse & Relay Box (RLY. 3-G4KE, RLY 6-G6DC) [With Smart Key] PDM, E/R Fuse & Relay Box (RLY 6)

Instrument panel fuse panel (2012-2016)

KIA Cadenza - fuse box diagram - instrument panel
KIA Cadenza – fuse box diagram – instrument panel
No. A Circuit Protected
F1 10 Tilt & Telescopic Module, Instrument cluster, ATM Shift Lever Indicator, Driver/Passenger Seat Warmer Module, Rear Seat Warmer Module LH/RH, IMS Control Module, Rear Parking Assist Sensor LH/RH, Rear Parking Assist Sensor LH/RH (Center), AMP, Console Switch, Front Parking Assist Sensor LH/RH (Center), Driver/Passenger Door Module, LDWS Camera Module, Electro Chromic Mirror, Room Lamp, MTS Module, Driver/Passenger CCS Control Module, Head Lamp Leveling Device Switch, Auto Head Lamp Leveling Device Module, Front Parking Assist Sensor LH/RH, Multipurpos Check Connector, A/C Control Module, Adaptive Front Lighting Module, Head Lamp LH/RH Head Lamp Leveling Device Actuator LH/RH
F2 10 Smart Key Control Module
F3 10 Driver Power Outside Mirror, Passenger Power Outside Mirror, A/C Control Module
F4 10 Auto Light & Photo Sensor, Data Link Connector, Driver/Passenger Foot Lamp, Instrument Cluster, Analog Clock, Rear Curtain Module, A/C Control Module, Room Lamp, Driver/Passenger Door Module, Tire Pressure Monitoring Module
F5 15 MTS Module, Audio, A/V & Navigation Head Unit, Front Monitor
F6 10 –
F7 15 RF Receiver
F8 15 ICM Relay Box (Rear Fog Lamp Relay)
F9 10 –
F10 15 –
F11 20 Driver/Passenger Seat Warmer Module, Driver/Passenger CCS Control Module, Haptic Seat Unit
F12 10 Instrument Cluster
F13 15 Clock Spring
F14 10 Rear Curtain Module, Driver/Passenger Door Module
F15 20 Passenger Manual Switch
F16 25 AMP
F17 25 Passenger Safety Power Window Module, Rear Power Window Switch RH
F18 25 Driver Safety Power Window Module, Rear Power Window Switch LH
F19 15 SRS Control Module
F20 10 Ionizer, A/C Control Module, E/R Fuse & Relay Box (RLY. 14)
F21 10 Smart Key Control Module, Rear Audio Switch, AMP, Front Monitor, Overhead Console Lamp Switch, MTS Module, Audio, IPS Control Module, A/V & Navigation Head Unit, Analog clock, Camera Control Module, A/C Control Module
F22 10 Driver/Passenger Vanity Lamp Switch, Glove Box Lamp, Overhead Console Lamp Switch, Driver/Passenger Door Scuff Lamp, Driver/Passenger Door Lamp, Trunk Room Lamp
F23 20 Panorama Sunroof
F24 10 Fuel Filler Door Switch, Trunk Lid Relay
F25 20 Rear Seat Warmer Module LH/RH
F26 10 ESP Control Module, ABS Control Module, Electric Parking Brake Module, Steerinq Anqle Sensor, Crash Pad Switch, Console Switch, Haptic Seat Unit,
F27 10 Blind Spot Detection LH/RH, Smart Cruise Control Radar
F28 15 Console Power Outlet
F29 25 Smart Key Control Module
F30 10 Key Solenoid, Tilt & Telescopic Module, Sport Mode Switch
F31 10 Stop Lamp Switch, Start Stop Button Switch
F32 20 Driver Door Module
F33 20 E/R Fuse & Relay Box (F12 15A, F11 10A, F10 10A)
F34 25 E/R Fuse & Relay Box (RLY. 11, RLY.12), Front Wiper Motor, Multifunction Switch
F35 10 Front Cigarette Lighter
F36 10 Transaxle Range Switch, PCM

Engine compartment fuse box

KIA Cadenza - fuse box diagram - engine compartment
KIA Cadenza – fuse box diagram – engine compartment
No. A Circuit Protected
F1 60 IPM (Fuse – F7/ F8/ F9/ F19, IPS Control – IPS’!/ IPS2/ IPS3/ IPS5/ IPS7)
F2 60 IPM (Fuse – F17/ F24/ F25/ F26/ F33/ F34)
F3 40 [W/O Smart Key] Ignition Switch, [With Smart Key] RLY. 1 (ACC Relay), RLY. 9 (IG1 Relay)
F4 40 ESP Control Module, ABS Control Module
F5 40 RLY 2 (Rear Defogger Relay)
F6 40 RLY 14 (Blower Relay)
F7 60 IPM (Fuse- F2/ F10, IPS Control – IPS 0/ IPS4/ TURN/ IPS6)
F8 80 Spare
F9 10 A/C Control Module
F10 10 RLY 8 (Back-up Lamp Relay), Stop Lamp Switch, Multipurpose Check Connector
F11 10 RLY 6 (Start2 Relay), Alternator (G6DC)
F12 10 PCM, Transaxle Range Switch
15 Transaxle Range Switch
F13 30 Spare
F14 30 [W/O Smart Key] Ignition Switch, RLY 3 (Startl Relay), [With Smart Key] RLY 3 (Startl Relay), RLY 10 (IG2 Relay)
F15 40 IPM (Fuse – F4/ F12/ F18/ F35, Power Connector – F27/ F28)
50 E/R Fuse & Relay Box (RLY. 4, RLY. 5)
F16 30 Electric Parking Brake Module
F17 40 EMS Box (Fuse – F35/ F36/ F37/ F38)
F18 30 ESP Control Module, ABS Control Module, Multipurpos Check Connector
F19 30 Electric Parking Brake Module
F20 10 IPM, RLY 11 (Wiper Relay), Front Wiper Motor
F21 10 A/V & Navigation Head Unit, Rear Curtain Module, Audio,Electro Chromic Mirror, Rear Combination Lamp(In) LH/RH,Front Monitor
F22 10 (Not Used)
F24 20 PCM (G4KE)
F25 15 Stop Lamp Switch
F26 20 RLY. 7 (Front Wiper Deicer Relay)
F27 20 Multipurpose Check Connector
10 Smart Cruise Control Radar
F28 30 MS Control Module, Driver Lumbar Support Switch, Driver Cushion Extension Switch, Driver Manual Switch
F29 40 RLY. 4 (Cooling Fan (Low) Relay), RLY 5 (Cooling Fan (High) Relay)
F30 20 Ignition Coil #1 /#2 /#3 /#4 (G4KE),
Iqnition Coil #1 /#2 /#3 /#4 /#5 /#6 (G6DC),
Condenser (G4KE),
Condenser #1 /#2 (G6DC)
F31 – Not used
F32 15 G4KE : Immobilizer Module, Camshaft Position Sensor #1 /#2, Crankshaft Position Sensor, Oil Control Valve #1 /#2, Canister Purge Control Solenoid Valve Variable Intake Manifold Valve,
G6DC : Immobilizer Module, PCM, Oxygen Sensor #1 /#2 /#3 /#4
F33 15 G4KE : Oxygen Sensor (Up)/(Down), RLY 5 (Cooling Fan (High) Relay)
G6DC : PCM, Oil Control Valve #1 /#2, Canister Purqe Control Solenoid Valve, Variable Intake Manifold Valve #1 /#2, RLY. 5 (Coolinq Fan (Hiqh) Relay)
F34 15 Injector #1/ #2/ #3/ #4 (G4KE),
Injector #1/ #2/ #3/ #4/ #5/ #6 (G6DC), PCM (G6DC), RLY. 16 (Fuel Pump Relay)
F35 20 RLY. 16 (Fuel Pump Relay)
F36 10 PCM, Alternator (G6DC)
F37 15 RLY. 13 (Burglar Alarm Horn Relay), RLY. 15 (Horn Relay)
F38 30 RLY. 17 (Engine Control Relay)
F39 25 Spare
F40 20 Spare
F41 15 Spare
F42 10 Spare
Relay
RLY.1 ACC Relay
RLY.2 Rear Defogger Relay
RLY.3 Startl Relay
RLY.4 Cooling Fan (Low) Relay
RLY.5 Cooling Fan (High) Relay
RLY.6 Start2 Relay
RLY.7 Front Wiper Deicer Relay
RLY.8 Back-up Lamp Relay
RLY.9 IG1 Relay
RLY.10 IG2 Relay
RLY.11 Wiper Relay
RLY.12 Rain Sensor Relay
RLY.13 Burglar Alarm Horn Relay
RLY.14 Blower Relay
RLY.15 Horn Relay
RLY.16 Fuel Pump Relay
RLY.17 Engine Control Relay

Main fuse

KIA Cadenza - fuse box diagram - main fuse
KIA Cadenza – fuse box diagram – main fuse

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
