Jeep Cherokee KK (2008 – 2013) – fuse box diagram

Posted on by admin

Jeep Cherokee KK (2008 – 2013) – fuse box diagram

Year of production: 2008, 2009, 2010, 2011, 2012, 2013

Fuse box

Jeep Cherokee (KK) - fuse box diagram
Jeep Cherokee (KK) – fuse box diagram
No. A Description
J1 –  –
J2 30 Transfer Case Module
J3 40 Rear Door Module
J4 25 Driver Door Node
J5 25 Passenger Door Node
J6 40 ABS (Pump)
J7 30 ABS (Valve)
J8 40 Power Seats
J9 40 Partial Zero Emission Vehicle (PZEV), Flex Fuel
J10 30 Headlamp Wash Relay, Manifold Tuning Valve
J11 30 Sway Bar, Thatcham Lock-Unlock, Power Sliding Door Module
J13 60 Ignition Off Draw (IOD) – Main
J14 40 Rear Window Defogger
J15 30 Rear Blower
J17 40 Starter Solenoid
J18 20 Powertrain Control Module (PCM), Transmission Control Relay
J19 60 Radiator Fan
J20 30 Front Wiper
J21 20 Front Washer, Rear Washer
J22 25 Sunroof Module

1 15 Stop Lamp Switch, Center High-Mounted Stop Light (CHMSL)
2 20 Trailer Lighting
3 20 Front/Rear Axle Locker Relay
4 10 Trailer Tow
5 25 Power Inverter
6 20 Power Outlet No.1, Rain Sensor, Trailer Tow
7 20 Power Outlet No.2 (BATT/ACC SELECT)
8 20 Front Heated Seat
9 20 Rear Heated Seat
10 15 Hands-Free Module, Universal Garage Door Opener, Vanity Lamp
11 10 Automatic Temperature Control (ATC)
12 30 Radio, Amplifier
13 20 Cabin Compartment Node, Wireless Control Module, Multi-function Control Switch
14 20 Trailer Tow (BUX)
15 20 Multi-function Control Switch, Cabin Compartment Node, Steering Column Control Module, Rear View Mirror, Tire Pressure Monitor, IR Sensor, Transfer Case Module
16 10 Occupant Restraint Controller (ORC)
17 15 Left Front Park Lamp, Side Marker Lamps, Left Tail Lamp, Running Lamps, License Lamps
18 15 Right Front Park Lamp, Side Marker Lamps, Right Tail Lamp, Running Lamps
19 25 Auto Shut Down (ASD No.1 and No.2)
20 15 Interior Lighting, Steering Wheel Switches, Switch Bank, Electronic Vehicle Information Center (EVIC)
21 20 Auto Shut Down (ASD No,3)
22 10 Right Horn
23 10 Left Horn
24 25 Rear Wiper
25 20 Fuel Pump
26 10 Power Window Switch, Driver Window Switch
27 10 Ignition Switch Feed, Wireless Module, Steering Column Lock
28 10 Powertrain Control Module
29 10 Occupant Classification Module (OCM)
30 15 Rear Wiper Module, Diagnostic Connector
31 20 Backup Lamps
32 10 Occupant Restraint Controller (ORC)
33 10 Powertrain Control Module
34 10 Park Assist Module, Heating – Ventilation & Air Conditioning (HVAC) Module, Compass Module
35 10 Heated Mirrors
36 20 Power Outlet No.3
37 10 ABS, Electronic Stability Control, Stop Lamp Switch
38 25 Door & Liftgate Lock/Unlock Motors
Circuit Breaker
CB1 25 Power Seat
Relay
R1 Ignition (Run/Accessory)
R2 Ignition (Run)
R3 Starter
R4 Ignition (Run-Start)
R5 Transmission Control Module (TCM)
R6 Rear Window Defogger
R7  –
R8  –
R9  –
R10 Automatic Shutdown
R11 Radiator Fan Control

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Jeep Liberty KK (2008 – 2013) – fuse box diagram

Posted on by admin

Jeep Liberty KK (2008 – 2013) – fuse box diagram

Year of production: 2008, 2009, 2010, 2011, 2012, 2013

Fuse box

Jeep Liberty (KK) - fuse box diagram
Jeep Liberty (KK) – fuse box diagram
No. A Description
J1 –  –
J2 30 Transfer Case Module
J3 40 Rear Door Module
J4 25 Driver Door Node
J5 25 Passenger Door Node
J6 40 ABS (Pump)
J7 30 ABS (Valve)
J8 40 Power Seats
J9 40 Partial Zero Emission Vehicle (PZEV), Flex Fuel
J10 30 Headlamp Wash Relay, Manifold Tuning Valve
J11 30 Sway Bar, Thatcham Lock-Unlock, Power Sliding Door Module
J13 60 Ignition Off Draw (IOD) – Main
J14 40 Rear Window Defogger
J15 30 Rear Blower
J17 40 Starter Solenoid
J18 20 Powertrain Control Module (PCM), Transmission Control Relay
J19 60 Radiator Fan
J20 30 Front Wiper
J21 20 Front Washer, Rear Washer
J22 25 Sunroof Module

1 15 Stop Lamp Switch, Center High-Mounted Stop Light (CHMSL)
2 20 Trailer Lighting
3 20 Front/Rear Axle Locker Relay
4 10 Trailer Tow
5 25 Power Inverter
6 20 Power Outlet No.1, Rain Sensor, Trailer Tow
7 20 Power Outlet No.2 (BATT/ACC SELECT)
8 20 Front Heated Seat
9 20 Rear Heated Seat
10 15 Hands-Free Module, Universal Garage Door Opener, Vanity Lamp
11 10 Automatic Temperature Control (ATC)
12 30 Radio, Amplifier
13 20 Cabin Compartment Node, Wireless Control Module, Multi-function Control Switch
14 20 Trailer Tow (BUX)
15 20 Multi-function Control Switch, Cabin Compartment Node, Steering Column Control Module, Rear View Mirror, Tire Pressure Monitor, IR Sensor, Transfer Case Module
16 10 Occupant Restraint Controller (ORC)
17 15 Left Front Park Lamp, Side Marker Lamps, Left Tail Lamp, Running Lamps, License Lamps
18 15 Right Front Park Lamp, Side Marker Lamps, Right Tail Lamp, Running Lamps
19 25 Auto Shut Down (ASD No.1 and No.2)
20 15 Interior Lighting, Steering Wheel Switches, Switch Bank, Electronic Vehicle Information Center (EVIC)
21 20 Auto Shut Down (ASD No,3)
22 10 Right Horn
23 10 Left Horn
24 25 Rear Wiper
25 20 Fuel Pump
26 10 Power Window Switch, Driver Window Switch
27 10 Ignition Switch Feed, Wireless Module, Steering Column Lock
28 10 Powertrain Control Module
29 10 Occupant Classification Module (OCM)
30 15 Rear Wiper Module, Diagnostic Connector
31 20 Backup Lamps
32 10 Occupant Restraint Controller (ORC)
33 10 Powertrain Control Module
34 10 Park Assist Module, Heating – Ventilation & Air Conditioning (HVAC) Module, Compass Module
35 10 Heated Mirrors
36 20 Power Outlet No.3
37 10 ABS, Electronic Stability Control, Stop Lamp Switch
38 25 Door & Liftgate Lock/Unlock Motors
Circuit Breaker
CB1 25 Power Seat
Relay
R1 Ignition (Run/Accessory)
R2 Ignition (Run)
R3 Starter
R4 Ignition (Run-Start)
R5 Transmission Control Module (TCM)
R6 Rear Window Defogger
R7  –
R8  –
R9  –
R10 Automatic Shutdown
R11 Radiator Fan Control

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Jeep Grand Cherokee WK2 (2011 – 2013) – fuse box diagram

Posted on by admin

Jeep Grand Cherokee WK2 (2011 – 2013) – fuse box diagram

Year of production: 2011, 2012, 2013

Fuse box

Jeep Grand Cherokee WK2 - fuse box diagram
Jeep Grand Cherokee WK2 – fuse box diagram
No. A Description
J1 40 Air Suspension
J2 30 Power Liftgate Module
J3 30 Trailer Tow
J4 25 Driver Door Node
J5 25 Passenger Door Node
J6 40 ABS (Pump)
J7 30 ABS (Valve)
J8 40 Power Seats
J9 30 E-Brake
J10 30 Headlamp Wash Relay
J11 30 Drive Train Control Module
J13 60 Streaming Video Module, Video System 3 Module, Video System 2 Module, Display, DVD
J14 20 Trailer Tow Lamps, Park Lamps
J15 30 Rear Window Defroster
J17 40 Starter Solenoid
J18 20 Powertrain Control Module (PCM), Transmission Control Relay
J19 60 Radiator Fan
J20 30 Front Wiper
J21 20 Front Washer, Rear Washer
J22 25 Sunroof Module

1 15 Stop Lamp Switch, Center High-Mounted Stop Light (CHMSL)
2 20 Electronic Limit Slip Differential, Air Suspension
3 20 Liftgate Unlock, Daytime Running Light Relay
4 –  –
5 25 115V AC Power Inverter
6 20 Power Outlet No.1, Rain Sensor
7 20 Power Outlet No.2 (Switchable)
8 20 Front Heated Seat, Heated Steering Wheel
9 20 Rear Heated Seat
10 20 Hands-Free Module, Universal Garage Door Opener, Vanity Lamp
11 10 Heating, Ventilation & Air Conditioning (Climate Control System)
12 30 Radio, Amplifier
13 20 Main #2 Instrument Cluster, Wireless Control Module, ITM, Siren, Multifunction Switch (Steering Control Module)
14 20 Back Up Camera
15 20 Power Seat Module, Adaptive Cruise Control, Audio Telematics, Daytime Running Lights Relay, Air Suspension Module, Instrument Cluster
16 10 Occupant Restraint Controller (ORC)
17 –  –
18 –  –
19 25 Auto Shut Down (ASD No.1 and No.2)
20 15 Instrument Cluster Interior Lighting Feed, Switch Steering Wheel, Switch Bank, Steering Control Module (Temperature/Compass Display)
21 20 Auto Shut Down (ASD No,3)
22 10 Right Horn
23 10 Left Horn
24 25 Rear Wiper
25 20 Fuel Pump Motor Output, Diesel Lift Pump
26 –  –
27 10 Ignition Switch, Wireless Control Module, Keyless Entry Module
28 10 Powertrain Control Module (PCM), Transmission Control Module (TCM)
29 10 Tire Pressure Monitoring System
30 15 Diagnostic Connector
31 –  –
32 10 Occupant Restraint Controller (ORC)
33 10 Powertrain Control Module (PCM), Transmission Control Module (TCM)
34 10 Park Assist Module, Climate Control System Module, IR Sensor, Compass Module
35 15 LH Rear Parklamps
36 20 Power Outlet No.3
37 10 ABS, Electronic Stability Control, Stop Lamp Switch Sensor
38 25 Door & Liftgate Lock/Unlock Motors
Circuit Breaker
CB1 25 Power Windows, Power Vent Window
Relay
R1 Ignition (Run/Accessory)
R2 Ignition (Run)
R3 Starter
R4 Ignition (Run-Start)
R5 Powertrain Control Module (PCM)/Transmission Control Module (TCM)
R6 Trailer Tow Lamps/Park Lamps
R7 Diesel: Fuel Pump
R8  –
R9 Electrical Back Light (EBL)
R10 Automatic Shutdown
R11 Radiator Fan (Low Speed)

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Jeep Grand Cherokee WK2 (2014 – 2019) – fuse box diagram

Posted on by admin

Jeep Grand Cherokee WK2 (2014 – 2019) – fuse box diagram

Year of production: 2014, 2015, 2016, 2017, 2018, 2019

Engine compartment fuse box (power distribution center)

The Power Distribution Center is located in the engine compartment near the battery.

Jeep Grand Cherokee WK2 - fuse box diagram - engine compartment
Jeep Grand Cherokee WK2 – fuse box diagram – engine compartment
No. A Description
1 –  –
2 –  –
3 60 Radiator Fan
4 –  –
5 40 Compressor for Air Suspension
6 40 Anti-lock Brakes/Electronic Stability Control (Pump)
7 30 ’16-’19: Starter Solenoid
40 ’14-’15: Starter Solenoid
8 40 Diesel (’14-’15): Emission sensors
9 30 Diesel: Fuel Heater, Brake Vacuum Pump (’16-’19)
30 Gasoline (’16-’19): Brake Vacuum Pump
10 40 Body Control Module (BCM) (Exterior Lighting No.2)
11 30 Trailer Tow Electric Brake
12 40 Body Control Module (BCM) (Power Locks)
13 40 Blower Motor Front
14 40 Body Control Module (BCM) (Exterior Lighting No.1)
15 40 ’18-’19: LTR (Low Temperature Radiator) Engine Cooling Pump
16 –  –
17 30 Headlamp Washer
18 –  –
19 20 ’16-’19: Headrest Solenoid
20 30 Passenger Door Module
21 –  –
22 20 Engine Control Module
23 30 Body Control Module (BCM) (Interior Lights No.1)
24 30 Driver Door Module
25 30 Front Wipers
26 30 Anti-lock Brakes/Stability Control Module (Valves)
27 –  –
28 20 Trailer Tow Backup Lights
29 20 Trailer Tow Parking Lights
30 30 Trailer Tow Receptacle, Trailer Tow (Separate E-Brake), Trailer Tow (BUX)
31 –  –
32 30 Drive Train Control Module
33 –  –
34 30 Electronic Limited Slip Differential Module
35 30 Sunroof, Sunroof Shade Motor
36 30 Rear Window Defroster
37 25 ’15-’19: Rear Blower Motor
30 ’14: Rear Blower Motor
38 30 Power Inverter 115V AC
39 30 Power Liftgate
40 10 Daytime Running Lights, Headlamp Leveling
41 –  –
42 20 Horn
43 –  –
44 10 Diagnostic Connector
45 5 ’18-’19: Cyber Security Gateway
46 10 ’14-’15: Tire Pressure Monitor
47 –  –
48 –  –
49 10 Integrated Central Stack, Climate Control
50 20 Air Suspension Module, Electronic Limited Slip Differentials
51 15 ’15-’19: Keyless Ignition Node Module, Radio Frequency Hub Module, Steering Column Lock
10 ’14: Keyless Ignition Node Module, Radio Frequency Hub Module, Steering Column Lock
52 5 ’14-: Intelligent Battery Sensor
53 20 Trailer Tow – Left Turn/Stop Lights
54 –  –
55 –  –
56 15 Diesel: Additional Content
57 20 ’16-’19: NOX Sensor
15 ’14: Transmission Control Module
15 ’14-’15: HID Headlamps LH
58 15 ’16-’19: HID Headlamps LH
59 10 Diesel: Purging Pump
60 15 Transmission Control Module
61 10 Diesel (’15-’19): Transmission Control Module, PM Sensor
62 10 Air Conditioning Clutch
63 20 Gasoline: Ignition Coils, Short Runner Valve Actuator
20 Diesel: Urea Heater
64 25 Fuel Injectors, Powertrain Control Module (PCM)
65 –  –
66 10 Sunroof Motor, Sunroof Shade, Passenger Window Switches, Rain Sensor, Inside Rearview Mirror, Charging USB Port, Dedicated Short Range Communications (DSRC), DTV
67 15 CD/DVD/Bluetooth Hands-free Module, Left/Right Seatback Video Screen Module, UCI Port, USB Charging Port
68 20 Rear Wiper Motor
69 15 ’15-’19: Spotlight Feed
70 20 Fuel Pump Motor
71 30 Audio Amplifier, ANCM
72 10 ’16-’19: Powertrain Control Module (PCM)
73 15 HID Headlamp RH
74 20 ’14-’15: Brake Vacuum Pump
75 10 ’16-’19: Dual Batt Control
76 10 Anti-lock Brakes/Electronic Stability Control
77 10 Drivetrain Control Module, Electronic Limited Slip Differential Module
78 10 Engine Control Module, Electric Power Steering
79 –  –
80 10 Universal Garage Door Opener, Compass, Anti-Intrusion Module
81 20 Trailer Tow Right Turn/Stop Lights
82 10 Steering Column Control Module, Cruise Control, DTV
83 10 Fuel Door Switch
84 15 Switch Bank, Instrument Cluster
85 10 Airbag Module
86 10 Airbag Module
87 10 Air Suspension Control Module, Trailer Tow Module, Steering Column Control Module
88 15 Instrument Panel Cluster, Security Gateway (SGW), Integrated Trailer Brake Module (ITBM)
89 –  –
90 20 Power Outlet (Rear Seats)
91
92 10 Rear Console Lamp
93 20 Cigar Lighter
94 10 Shifter, Transfer Case Module
95 10 Rear Camera, Park ASsist Module, License Lamp, Rear Blind Spot Sensors
96 10 Rear Seat Heater Switch, Flashlamp Charger
97 20 ’15-’19: Rear Heated Seats, Heated Steering Wheel
25 ’14: Rear Heated Seats, Heated Steering Wheel
98 20 ’15-’19: Front Heated Seats, Ventilated Seats
25 ’14: Front Heated Seats, Ventilated Seats
99 10 Climate Control, Driver Assistance Systems Module, Dedicated Short Range Communications (DSRC), Adaptive Cruise Control Module, HALF
100 10 Active Damping Control Module
101 15 Electrochromatic Mirror, Smart High Beams, In Car Temperature Sensor, Humidity Sensor
102 –  –
103 10 Cabin Heater (Diesel), Rear HVAC
104 20 Power Outlets (Instrument Panel, Center Console, Rear Cargo)
Circuit Breaker
CB1 25 Power Window, Power Door Lock
CB2 25 Driver Power Seat, Memory Seat Module
CB3 25 Passenger Power Seat
Relay
R1 Radiator Fan (Low Speed)
R2 Radiator Fan (High Speed)
R3 Air Suspension
R4 Selective Catalytic Reduction (SCR)
R5 Auto Shut Down (Powertrain Control Module)
R6 Ignition (Run/Accessory No.1)
R7 Starter
R8 Ignition (Run/Start)
R9 Fuel Heater (No.1)
Air Pump (No.2)
R10 EBL
R11  –
R12 Ignition (Run/Only No.2)
R13 Frame Heater
R14 Ignition (Run/Accessory No.2)
R15 Ignition (Run/Only No.1)
R16 Blower Motor

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Jeep Gladiator (JT) – (2018 – 2024) – fuse box diagram

Posted on by admin

Jeep Gladiator (JT) – (2018 – 2024) – fuse box diagram

Year of production: 2018, 2019, 2020, 2021, 2022

Engine Compartment Fuse Box

Gasoline:

Jeep Gladiator JT - fuse box diagram - engine compartment (gasoline)
Jeep Gladiator JT – fuse box diagram – engine compartment (gasoline)

Diesel:

Jeep Gladiator JT - fuse box diagram - engine compartment (diesel)
Jeep Gladiator JT – fuse box diagram – engine compartment (diesel)
Jeep Gladiator JT - fuse box diagram - engine compartment
Jeep Gladiator JT – fuse box diagram – engine compartment
No.
 A
 Circuit Protected
1 5 PHEV: HV Electric Coolant Heater Enable
2 40 except PHEV: Starter
3 5 Intelligent Battery Sensor (IBS)
4 20 Fuel Pump Motor, Fuel Pump Control Module (FPCM)
25 6.4L Hemi V8 (’18-’23): Fuel Pump
5 5 Security Gateway
6 15 PHEV: Battery Pack Control Module (BPCM)
7 15 Wrangler: Low Temp Radiator Cooling Pump (LTR)
15 PHEV: PECP-2
8 15 ZF 8HP75: Transmission Control Module (TCM)
9 5 PHEV: Integrated Dual Charging Module (IDCM)
10 15 Key Ignition Node (KIN), Radio Frequency Hub (RF HUB), Electric Steering Column Lock (ESCL)
11 10 UCI Port (USB & AUX)
12 25 HiFi Amplifier
13 10 PHEV: Power Inverter Module (PIM) – Redundant Main Power Supply
14 10 PHEV: Power Inverter Module (PIM) – Main Power Supply
15 15 Instrument Panel Cluster (IPC), Switch Bank-Heavy Duty Electrical Pkg
16 –  –
17 40 PHEV: Transmission Oil Pump
18 10 Air Conditioning Clutch
19 5 PHEV: Charge Port Indicator
20 30 Interior Lights – Central Body Controller (CBC)
21 20 Wrangler: Rear Wiper
22 10 Engine Control Module (ECM)/Powertrain Control Module (PCM), Motor Generator Unit (MGU – Wrangler), Power Pack Unit (PPU – Wrangler), Power Inverter Module (PIM – PHEV)
23 10 except PHEV: Engine Control Module (ECM)/Powertrain Control Module (PCM)
24 30 ’23-: Passenger’s Power Seat
25 10 Module Shift By Wire
26 40 Exterior Lights No.1 – Central Body Controller (CBC)
27 30 Front Wipers
28 40 Power Locks – Central Body Controller (CBC)
29 40 Exterior Lights No.2 – Central Body Controller (CBC)
30 30 ’23-: Power Step/Slider
31 10 Data Link Connector (DLC)
32 10 Occupant Classification Module (OCM), Driver Presence Detection Module (DPDM), Heating Ventilation Air Conditioning (HVAC) Module, Steering Column Lock (SCL)
33 10 ParkTronics System (PTS), Airbag Disable Lamps, Infrared Camera Module (IRCM)
34 10 Electronic Stability Control (ESC), Electric Hydraulic Power Steering (EHPS), Smart Bar Control Module (SBCM)
35 30 except PHEV: Brake Vacuum Pump
36 30 Electric Brake Module (Trailer Tow)
37 30 Trailer Tow Connector (7W)
38 20 Engine Control Module (ECM)
39 15 3.6L (Wrangler MHEV): Mild Hybrid Motor Generator Unit (MGU) Coolant Pump
40 15 DriveTrain Control Module (DTCM), Axle Lock (FT/RR)
41 15 Instrument Cluster (IC), Security GateWay (SGW)
42 10 with Stop/Start: Power Control Relay Control Feed (except PHEV)
43 20 Wrangler: Power Outlet – Batt (Cargo) (You can select to switch the Cargo Power Outlet from F43 battery fed power to this position F45 which is fed when the ignition in ON)
44 10 InfraRed Camera (IRCAM) – Heaters
45 20 Wrangler: Power Outlet – Ignition (Cargo)
46 10 Headlamp Switch, Auto Headlamp Leveling Module, Headlamp Leveling Motors
47 10 PHEV: Quiet Vehicle Pedestrian Module (QVPM)
48 –  –
49 10 Occupant Restraint Controller (ORC)
50 10 Heavy Duty (HD) Aссessory
51 10 Wrangler: Digital TV (DSRC), USB, InSide RearView Mirror (ISRVM), Compass Module (CSGM), Inverter 400W (PHEV), Engine Control Module (ECM – PHEV), Power Inverter Module (PIM – PHEV)
10 Gladiator: Humidity Light Rain Sensor (HLRS), Inverter 400W, USB, InSide RearView Mirror (ISRVM), Compass Module (CSGM), Digital TV (DTV)
52 20 Cigarette Lighter
53 10 Gladiator, PHEV: Wireless Speaker
54 –  –
55 10 Wrangler (’22-): Central Vision Processing Module (CVPM)
10 Gladiator: Central Vision Processing Module (CVPM) or Parktronics Module
56 10 In Car Temperature Sensor, PTC Heater Coil (’20- (except PHEV))
57 20 Front Driver Heated Seat
58 20 Front Passenger Heated Seat
59 30 ’23-: Driver Power Seat
60 15 Heated Steering – Comfort Steering Wheel Module (CSWM)
61 10 Left Blind Spot Sensor (LBSS), Right Blind Spot Sensor (RBSS), Central ADAS Decision Module (CADM Lo (’23-))
62 10 ’22-: Exhaust Solenoid (except PHEV)
63 10 Occupant Restraint Controller (ORC)
64 –  –
65 50 Gladiator, PHEV: Power Inverter 400W
66 40 Front Blower Motor (HVAC)
67 15 PHEV: BCP – Lo Temp Active Pump
68 – –
69 5 Wrangler (’18-’23): Motor Generator Unit (MGU), Belt Starter Generator (BSG)
10 ’23-: KIN / RF Hub
70 25 Gasoline: Injectors, Ignition Coils
25 Diesel: Glow Plug Module
71 10 PHEV: Battery Coolant Heater
72 10 HD ELEC ACC PKG
73 20 Wrangler: Power Top (LT)
74 20 Wrangler: Power Top (RT)
75 10 Wrangler (’18-’23): Belt Starter Generator (BSG), Power Pack Unit – Battery Pack Control Module & Auxiliary Power Module (PPUBPCM & APM)
5 PHEV: Battery Charge Indicator, Switch Bank PHEV Mode
76 20 Gasoline: Engine Control Module (ECM)
20 Diesel: Powertrain Control Module (PCM)
77 10 Heated Mirrors
78 10 Wrangler: Computer, Intrusion Module, Siren, Intrusion Sensor
79 20 Smart Bar Control Module
80 15 Powertrain Control Module (PCM), Block Shift Solenoid No.1 & No.2 (Wrangler – ’22-), ELCM Module (PHEV), Fuel Tank Isolation Solenoid (PHEV)
10 Wrangler (’22-’23): Vapor Blocking Valve (BSG)
81 30 Rear Window Defogger (EBL)
82 30 Diesel: Fuel Heater
83 60 Diesel: Glow Plug
50 PHEV: ESC-ECU & Valves
84 30 Diesel: Urea Heater Control Unit
20 PHEV: Power Inverter Module (PIM) – High Side Drive Power
85 10 ’18-’23: PM Sensor
15 PHEV: PECP – Lo Temp Passive Pump
86 30 Wrangler (’18-’23): Brake Vacuum Pump No.2
87 10 ’18-’23: Purging Pump Supply
15 PHEV: AHP – High Temp Auxiliary Pump
88 20 ’18-’23: NOx Sensor No.1 & No.2
89 10 Steering Column Control Module (SCCM), Cruise Control, Digital TV (DTV), Electronic Vehicle Information Center (EVIC (’22-)), Airbag Disable Lamp (’20-)
90 20 Parking Lamp (Trailer Tow)
91 20 Horn
92 40 Heavy Duty (HD) Accessory No.2
93 40 Heavy Duty (HD) Accessory No.1
94 10 ’18-’21: Tire Pressure Monitor (TPM), RF Hub System (CORAX)
10 ’23-: Red Dual USB Port
95 –  –
96 10 Power Mirror Switch
97 20 Radio, Telematic Box Module (TBM)
98 10 Off Road, Switch Bank (Heavy Duty Electrical)
99 –  –
100 30 except PHEV: Electronic Stability Control (ESC) Control Unit & Valves
101 30 DriveTrain Control Module (DTCM)
102 15 ’18-’23: Dual USB Port
15 ’23-: TBM2 / DCSD Mod
103 15 Heavy Duty (HD) Accessory No.3
104 15 ’18-’23: PPU Cool Pump
15 ’23-: Power Seat Lumbar Switch (Driver & Passenger)
105 10 Integrated Center Stack (ICS), Heat Ventilation Air Conditioning (HVAC), ETC (’23-)
106 40 ’18-’22: Electronic Stability Control (ESC) Pump Motor
50 ’22-: Electronic Stability Control (ESC) Pump Motor
107 20 Left Stop & Turn Lamps (Trailer Tow)
108 15 Heavy Duty (HD) Accessory No.4
109 20 Right Stop & Turn Lamps (Trailer Tow)
110 30 Power Inverter 150W
111 20 Backup Lamps (Trailer Tow)
Relay
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R11
R12
R13
R14
R15
R16
R17
R18
R19
R20
R21

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Jeep Wrangler (JL) – (2018 – 2024) – fuse box diagram

Posted on by admin

Jeep Wrangler (JL) – (2018 – 2024) – fuse box diagram

Year of production: 2018, 2019, 2020, 2021, 2022

Engine Compartment Fuse Box

Gasoline:

Jeep Wrangler JL - fuse box diagram - engine compartment (gasoline)
Jeep Wrangler JL – fuse box diagram – engine compartment (gasoline)

Diesel:

Jeep Wrangler JL - fuse box diagram - engine compartment (diesel)
Jeep Wrangler JL – fuse box diagram – engine compartment (diesel)



Jeep Wrangler JL - fuse box diagram - engine compartment
Jeep Wrangler JL – fuse box diagram – engine compartment
No.
 A
 Circuit Protected
1 5 PHEV: HV Electric Coolant Heater Enable
2 40 except PHEV: Starter
3 5 Intelligent Battery Sensor (IBS)
4 20 Fuel Pump Motor, Fuel Pump Control Module (FPCM)
25 6.4L Hemi V8 (’18-’23): Fuel Pump
5 5 Security Gateway
6 15 PHEV: Battery Pack Control Module (BPCM)
7 15 Wrangler: Low Temp Radiator Cooling Pump (LTR)
15 PHEV: PECP-2
8 15 ZF 8HP75: Transmission Control Module (TCM)
9 5 PHEV: Integrated Dual Charging Module (IDCM)
10 15 Key Ignition Node (KIN), Radio Frequency Hub (RF HUB), Electric Steering Column Lock (ESCL)
11 10 UCI Port (USB & AUX)
12 25 HiFi Amplifier
13 10 PHEV: Power Inverter Module (PIM) – Redundant Main Power Supply
14 10 PHEV: Power Inverter Module (PIM) – Main Power Supply
15 15 Instrument Panel Cluster (IPC), Switch Bank-Heavy Duty Electrical Pkg
16 –  –
17 40 PHEV: Transmission Oil Pump
18 10 Air Conditioning Clutch
19 5 PHEV: Charge Port Indicator
20 30 Interior Lights – Central Body Controller (CBC)
21 20 Wrangler: Rear Wiper
22 10 Engine Control Module (ECM)/Powertrain Control Module (PCM), Motor Generator Unit (MGU – Wrangler), Power Pack Unit (PPU – Wrangler), Power Inverter Module (PIM – PHEV)
23 10 except PHEV: Engine Control Module (ECM)/Powertrain Control Module (PCM)
24 30 ’23-: Passenger’s Power Seat
25 10 Module Shift By Wire
26 40 Exterior Lights No.1 – Central Body Controller (CBC)
27 30 Front Wipers
28 40 Power Locks – Central Body Controller (CBC)
29 40 Exterior Lights No.2 – Central Body Controller (CBC)
30 30 ’23-: Power Step/Slider
31 10 Data Link Connector (DLC)
32 10 Occupant Classification Module (OCM), Driver Presence Detection Module (DPDM), Heating Ventilation Air Conditioning (HVAC) Module, Steering Column Lock (SCL)
33 10 ParkTronics System (PTS), Airbag Disable Lamps, Infrared Camera Module (IRCM)
34 10 Electronic Stability Control (ESC), Electric Hydraulic Power Steering (EHPS), Smart Bar Control Module (SBCM)
35 30 except PHEV: Brake Vacuum Pump
36 30 Electric Brake Module (Trailer Tow)
37 30 Trailer Tow Connector (7W)
38 20 Engine Control Module (ECM)
39 15 3.6L (Wrangler MHEV): Mild Hybrid Motor Generator Unit (MGU) Coolant Pump
40 15 DriveTrain Control Module (DTCM), Axle Lock (FT/RR)
41 15 Instrument Cluster (IC), Security GateWay (SGW)
42 10 with Stop/Start: Power Control Relay Control Feed (except PHEV)
43 20 Wrangler: Power Outlet – Batt (Cargo) (You can select to switch the Cargo Power Outlet from F43 battery fed power to this position F45 which is fed when the ignition in ON)
44 10 InfraRed Camera (IRCAM) – Heaters
45 20 Wrangler: Power Outlet – Ignition (Cargo)
46 10 Headlamp Switch, Auto Headlamp Leveling Module, Headlamp Leveling Motors
47 10 PHEV: Quiet Vehicle Pedestrian Module (QVPM)
48 –  –
49 10 Occupant Restraint Controller (ORC)
50 10 Heavy Duty (HD) Aссessory
51 10 Wrangler: Digital TV (DSRC), USB, InSide RearView Mirror (ISRVM), Compass Module (CSGM), Inverter 400W (PHEV), Engine Control Module (ECM – PHEV), Power Inverter Module (PIM – PHEV)
10 Gladiator: Humidity Light Rain Sensor (HLRS), Inverter 400W, USB, InSide RearView Mirror (ISRVM), Compass Module (CSGM), Digital TV (DTV)
52 20 Cigarette Lighter
53 10 Gladiator, PHEV: Wireless Speaker
54 –  –
55 10 Wrangler (’22-): Central Vision Processing Module (CVPM)
10 Gladiator: Central Vision Processing Module (CVPM) or Parktronics Module
56 10 In Car Temperature Sensor, PTC Heater Coil (’20- (except PHEV))
57 20 Front Driver Heated Seat
58 20 Front Passenger Heated Seat
59 30 ’23-: Driver Power Seat
60 15 Heated Steering – Comfort Steering Wheel Module (CSWM)
61 10 Left Blind Spot Sensor (LBSS), Right Blind Spot Sensor (RBSS), Central ADAS Decision Module (CADM Lo (’23-))
62 10 ’22-: Exhaust Solenoid (except PHEV)
63 10 Occupant Restraint Controller (ORC)
64 –  –
65 50 Gladiator, PHEV: Power Inverter 400W
66 40 Front Blower Motor (HVAC)
67 15 PHEV: BCP – Lo Temp Active Pump
68 – –
69 5 Wrangler (’18-’23): Motor Generator Unit (MGU), Belt Starter Generator (BSG)
10 ’23-: KIN / RF Hub
70 25 Gasoline: Injectors, Ignition Coils
25 Diesel: Glow Plug Module
71 10 PHEV: Battery Coolant Heater
72 10 HD ELEC ACC PKG
73 20 Wrangler: Power Top (LT)
74 20 Wrangler: Power Top (RT)
75 10 Wrangler (’18-’23): Belt Starter Generator (BSG), Power Pack Unit – Battery Pack Control Module & Auxiliary Power Module (PPUBPCM & APM)
5 PHEV: Battery Charge Indicator, Switch Bank PHEV Mode
76 20 Gasoline: Engine Control Module (ECM)
20 Diesel: Powertrain Control Module (PCM)
77 10 Heated Mirrors
78 10 Wrangler: Computer, Intrusion Module, Siren, Intrusion Sensor
79 20 Smart Bar Control Module
80 15 Powertrain Control Module (PCM), Block Shift Solenoid No.1 & No.2 (Wrangler – ’22-), ELCM Module (PHEV), Fuel Tank Isolation Solenoid (PHEV)
10 Wrangler (’22-’23): Vapor Blocking Valve (BSG)
81 30 Rear Window Defogger (EBL)
82 30 Diesel: Fuel Heater
83 60 Diesel: Glow Plug
50 PHEV: ESC-ECU & Valves
84 30 Diesel: Urea Heater Control Unit
20 PHEV: Power Inverter Module (PIM) – High Side Drive Power
85 10 ’18-’23: PM Sensor
15 PHEV: PECP – Lo Temp Passive Pump
86 30 Wrangler (’18-’23): Brake Vacuum Pump No.2
87 10 ’18-’23: Purging Pump Supply
15 PHEV: AHP – High Temp Auxiliary Pump
88 20 ’18-’23: NOx Sensor No.1 & No.2
89 10 Steering Column Control Module (SCCM), Cruise Control, Digital TV (DTV), Electronic Vehicle Information Center (EVIC (’22-)), Airbag Disable Lamp (’20-)
90 20 Parking Lamp (Trailer Tow)
91 20 Horn
92 40 Heavy Duty (HD) Accessory No.2
93 40 Heavy Duty (HD) Accessory No.1
94 10 ’18-’21: Tire Pressure Monitor (TPM), RF Hub System (CORAX)
10 ’23-: Red Dual USB Port
95 –  –
96 10 Power Mirror Switch
97 20 Radio, Telematic Box Module (TBM)
98 10 Off Road, Switch Bank (Heavy Duty Electrical)
99 –  –
100 30 except PHEV: Electronic Stability Control (ESC) Control Unit & Valves
101 30 DriveTrain Control Module (DTCM)
102 15 ’18-’23: Dual USB Port
15 ’23-: TBM2 / DCSD Mod
103 15 Heavy Duty (HD) Accessory No.3
104 15 ’18-’23: PPU Cool Pump
15 ’23-: Power Seat Lumbar Switch (Driver & Passenger)
105 10 Integrated Center Stack (ICS), Heat Ventilation Air Conditioning (HVAC), ETC (’23-)
106 40 ’18-’22: Electronic Stability Control (ESC) Pump Motor
50 ’22-: Electronic Stability Control (ESC) Pump Motor
107 20 Left Stop & Turn Lamps (Trailer Tow)
108 15 Heavy Duty (HD) Accessory No.4
109 20 Right Stop & Turn Lamps (Trailer Tow)
110 30 Power Inverter 150W
111 20 Backup Lamps (Trailer Tow)
Relay
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R11
R12
R13
R14
R15
R16
R17
R18
R19
R20
R21

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Jeep Cherokee XJ (1997 – 2001) – fuse box diagram

Posted on by admin

Jeep Cherokee XJ (1997 – 2001) – fuse box diagram

Year of production: 1997, 1998, 1999, 2000, 2001

Passenger Compartment Fuse Box

It is located behind the lid under the glove compartment.

Jeep Cherokee XJ - fuse box diagram - passenger compartment fuse box
Jeep Cherokee XJ – fuse box diagram – passenger compartment fuse box
No.
 A
 Circuit Protected
1 25 Power Outlet
2 25 Cigar Lighter
3 10 Left Headlamp (High Beam), Fog Lamp Relay No.1
4 10 Left Headlamp (Low Beam), Leveling Motor
5 10 Right Headlamp (Low Beam), Leveling Motor, Headlamp Leveling Switch, Daytime Running Lamp Module
6 5 Instrument Cluster, Radio, Rear Wiper/Washer Switch, A/C Heater Control or Heater Control, Rear Window Defogger Switch, Extended Idle Switch, Front Fog Lamp Switch, Rear Fog Lamp Switch, Transmission Range Indicator Illumination (PRNDL), Transfer Case Switch Illumination
7 10 Left Tail Lamp, Left Front Park Lamp, Left Side Marker Lamp, Trailer Tow Connector, License Lamp, Front Fog Lamp Relay No.1 (’98-’01), Front Fog Lamp Switch, Fog Lamp Relay
8 – Not Used
9 10 Instrument Cluster, Overhead Console, Sentry Key Immobilizer Module, Message Center/Tell Tale Module (Diesel), Headlamp Delay Module, Compass
10 15 1999-2001:  Back-Up Lamp, Back-Up Lamp Switch (M/T), Transmission Range Sensor (A/T), Daytime Running Lamp Module, EVAP/Purge Solenoid (Gasoline), Radiator Fan Relay, Air Conditioner Compressor Clutch Relay, Oxygen Sensor Downstream Relay (Gasoline), Oxygen Sensor Upstream Relay (Gasoline)
11 20 Gasoline 1997-1998: Automatic Shut Down Relay, Radiator Fan Relay, Fuel Pump Relay, Air Conditioner Compressor Clutch Relay, Back-Up Lamp (Back-Up Lamp Switch (M/T), Transmission Range Sensor (A/T)), Transmission Control Module, Duty Cycle EVAP/Purge Solenoid, EVAP Leak Detection Pump, Daytime Running Lamp Module, Torque Converter Solenoid, Park/Neutral Position Switch;

Gasoline 1999-2001): Powertrain Control Module, Transmission Control Module, Automatic Shut Down Relay, Fuel Pump Relay;

Diesel 1997-1998: Powertrain Control Module, Back-Up Lamp Switch, Fuel Heater Relay, MSA Controller;

Diesel 1999-2001:  Engine Control Module, Fuel Heater Relay
12 10 Combination Flasher, Rear Window Defogger Relay
13 – Not Used
14 10 Heated Mirror
15 25 Passenger Door Module (Power Window/Door Lock)
16 10 Right Headlamp (High Beam)
17 15 Radio
18 10 1998-2001:  Driver Door Module, Power Mirror Switch (’99-’01), Heated Seat Switch (’99-’01), Heated Seat Relay (’99-’01), Rear Fog Lamp Relay (’99-’01)
19 10 Starter Relay, Clutch Interlock Switch (M/T)
20 10 or 15 1997: Trailer Tow Connector, Trailer Tow Left Turn Relay, Trailer Tow Right Turn Relay (10A);

1998-2001:  Trailer Tow Connector, Trailer Tow Left Turn Relay, Trailer Tow Right Turn Relay (15A)
21 15 Horn Relay
22 20 Rear Wiper/Washer Switch
23 10 Right Tail Lamp, Right Front Park Lamp, Right Side Marker Lamp
24 – Not Used
25 15 Blower Motor Relay, Blend Door Actuator, Brake Transmission Shift Interlock Solenoid, Extended Idle Switch, A/C Heater Control or Heater Control, ABS Relay, ABS
26 10 Airbag Control Module
27 10 Airbag Control Module
Circuit Breakers
28 25 or 30 1997-1998: Driver/Passenger Door Module (Power Window, Door Lock) (30A);

1999-2001:  Driver/Passenger Door Module (Power Window, Door Lock) (25A)
29 25 or 30 1997-1998: Power Seat (30A);

1999-2001:  Power Seat, Heated Seat Relay (25A)
30 20 Front Wiper Motor, Front Wiper/Washer Switch
Relays
R1 Not Used
R2 Cigar Lighter
R3 Horn
R4 Rear Window Defogger

Engine Compartment Fuse Box (Gasoline)

‘00-’01:

Jeep Cherokee XJ - fuse box diagram - engine compartment fuse box (gasoline)
Jeep Cherokee XJ – fuse box diagram – engine compartment fuse box (gasoline)

’97-’99:

Jeep Cherokee XJ - fuse box diagram - engine compartment fuse box (gasoline)
Jeep Cherokee XJ – fuse box diagram – engine compartment fuse box (gasoline)
No.
 A
 Circuit Protected
1 – Not Used
2 40 Ignition Switch (Cigar Lighter Relay, Fuse (Passenger Compartment): “8”, “9”, “10”, “11”, “17”, “18”, “27”, “28”, “30”))
3 40 Ignition Switch (Fuse (Passenger Compartment): “12”, “19”, “22”, “24”, “25”, “26”))
4 40 or 50 1997: Fuse (Passenger Compartment): “1”, “2”, “15”, “20”, “21”, “29” (40A);

1998-2001:  Fuse (Passenger Compartment): “1”, “2”, “15”, “20”, “21”, “29” (50A)
5 40 Radiator Fan Relay
6 40 Blower Motor Relay
7 30 Headlamp Switch, Headlamp Delay Module, Daytime Running Lamp Module
8 30 2000-2001:  Automatic Shut Down Relay
9 20 Air Conditioner Compressor Clutch Relay, Fuse (Engine Compartment): “27” (2000-2001), “26” (1997-1999)
10 20 or 30 1997-1998: Starter Relay, Rear Window Defogger Relay, Fuse (Passenger Compartment): “13” (30A);

1999-2001:  Starter Relay (20A)
11 30 1998-2001:  Rear Window Defogger Relay, Fuse (Passenger Compartment): “13”
12 40 ABS
13 20 ABS
14 – Not Used
15 – Not Used
16 15 Dome Lamp, Cargo Lamp, Instrument Cluster, Courtesy Lamp, Radio, Transmission Control Module, Underhood Lamp, Visor/Vanity Lamp, Overhead Console, Remote Keyless Entry Module, Glove Box Lamp, Compass, Left Front Power Lock/Window Switch (1997 LHD), Right Front Power Lock/Window Switch (1997 LHD)
17 20 1997-1999: Headlamp Switch, Data Link Connector, Rear Fog Lamp Relay (1997), Power Antenna Relay (1998-1999);

2000-2001:  Oxygen Sensor Downstream Relay, Oxygen Sensor Upstream Relay
18 15 2000-2001:  Fuel Injectors, Coil Rail, Coil Capacitor
19 20 or 25 1997-1999: Automatic Shut Down Relay (25A)

2000-2001:  Headlamp Switch, Data Link Connector, Power Antenna Relay (20A)
20 15 Combination Flasher
21 15 or 20 1997-1999: Fuel Injectors, Ignition Coil, Powertrain Control Module (20A)

2000-2001:  Powertrain Control Module (15A)
22 15 Fuel Pump Relay, Powertrain Control Module
23 15 Stop Lamp Switch
24 15 1997-1999:  Oxygen Sensor Downstream, Oxygen Sensor Upstream
25 15 Fog Lamp Relay №2 (1998-2001), Fog Lamp Relay (1997-1999)
26 20 Power Amplifier
27 10 Sentry Key Immobilizer Module
Relays
R1 Air Conditioner Compressor Clutch
R2 1997-1999: Fog Lamp;
1998-2001: Fog Lamp No.1
R3 1998-2001: Fog Lamp No.2
R4 ABS
R5 1997-1999: Radiator Fan;
2000-2001: Fuel Pump
R6 1997-1999:  Automatic Shut Down;
2000-2001: Starter
R7 1997-1999:  Starter;
2000-2001: Oxygen Sensor Upstream
R8 1997-1999: Fuel Pump;
2000-2001: Oxygen Sensor Downstream
R9 2000-2001: Radiator Fan
R10 2000-2001:  Automatic Shut Down



Fuse Box Diagram (Diesel)

Jeep Cherokee XJ - fuse box diagram - engine compartment fuse box (diesel)
Jeep Cherokee XJ – fuse box diagram – engine compartment fuse box (diesel)
No.
 A
 Circuit Protected
1 – Not Used
2 50 Glow Plug Relay
3 50 Glow Plug Relay
4 30 1997-1998: Diesel Power Relay (Fuel Pump Module, Powertrain Control Module, Generator, Fuse (Engine Compartment): “21”), Fuse (Engine Compartment): “24”;

1999-2001:  Automatic Shut Down Relay (Engine Control Module, Fuel Injection Pump, Powertrain Control Module, Radiator Fan Relay, Air Conditioner Compressor Clutch Relay), Fuse (Engine Compartment): “24”
5 40 Ignition Switch (Cigar Lighter Relay, Fuse (Passenger Compartment): “8”, “9”, “10”, “11”, “17”, “18”, “27”, “28”, “30”))
6 30 Fuel Heater Relay
7 20 or 30 1997-1998: Starter Relay, Rear Window Defogger Relay, Fuse (Passenger Compartment): “13” (30A);

1999-2001:  Starter Relay (20A)
8 30 Headlamp Switch, Headlamp Delay Module
9 50 Fuse (Passenger Compartment): “1”, “2”, “15”, “20”, “21”, “29”
10 40 Ignition Relay (Fuse (Passenger Compartment): “12”, “19”, “22”, “24”, “25”, “26”))
11 40 Blower Motor Relay
12 40 ABS
13 40 Radiator Fan Relay (1998-2001)
14 20 ABS
15 30 Rear Window Defogger Relay, Fuse (Passenger Compartment): “13” (1999-2001)
16 15 Dome Lamp, Cargo Lamp, Instrument Cluster, Courtesy Lamp, Radio, Transmission Control Module, Underhood Lamp/Mercury Switch, Visor/Vanity Lamp, Overhead Console, Remote Keyless Entry Module, Glove Box Lamp, Compass, Left Front Power Lock/Window Switch (1997 LHD), Right Front Power Lock/Window Switch (1997 LHD)
17 – Not Used
18 – Not Used
19 15 Stop Lamp Switch
20 20 Air Conditioner Compressor Clutch Relay, Fuse (Engine Compartment): “27”
21 20 1997-1998: Glow Plug Relay, Mass Air Flow Sensor, Fuel Pump Module, Electronic Vacuum Modulator, Air Conditioner Compressor Clutch Relay

1999-2001:  Fuel Injection Pump, Glow Plug Relay, EGR Solenoid
22 20 Power Amplifier
23 15 Combination Flasher
24 10 Powertrain Control Module
25 15 Fog Lamp Relay
26 20 Headlamp Switch, Data Link Connector, Power Antenna Relay (1998-2001), Rear Fog Lamp Relay (1997)
27 10 Sentry Key Immobilizer Module (1998-2001), Overhead Module (1997)
Relays
R1 Air Conditioner Compressor Clutch
R2 Fog Lamp (1997-1999)
R3 Fog Lamp (2000-2001)
R4 ABS
R5 Radiator Fan
R6 1997-1999: Diesel Power;
2000-2001:  Automatic Shut Down
R7 Starter
R8 Fuel Heater



WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Honda E (2023)- fuse box diagram

Posted on by admin

Honda E (2023)- fuse box diagram

Year of production: 2023

Fuse Box inside the Bonnet

Fuse box A

Located near the 12-volt battery.

Honda E - fuse box diagram - inside the bonnet (fuse box A)
Honda E – fuse box diagram – inside the bonnet (fuse box A)
No.
 A
 Protected Component
1 40 Fuse box sub
40 ESB
40 ABS/VSA FSR
30 REALY MODULE 1
30 IG MAIN 2
30 IG MAIN
150 MAIN FUSE
2 70 ESP
50 FUSE BOX MAIN 2
40 ABS/VSA MOTOR
60 COOLING FAN
50 FUSE BOX OPTION 2
30 REALY MODULE 2
3 40 R/BOX MAIN 1
30 FRONT DEICER RIGHT
— —
40 FUSE BOX OPTION 1
40 FUSE BOX MAIN 1
40 BLOWER MOTOR
4 60 POWER WINDOW MAIN 1
60 FUSE BOX MAIN 1
40 REAR DEFROSTER
30 FRONT DEICER LEFT
5 5 COOLING FAN CONTROL
6 30 WIPER
7 10 STOP LIGHTS
8 10 IGA
9 10 IGB
10 10 BACK UP P/P
11 10 DT ELECTRIC WATER PUMP 2
12 — —
13 10 HEAD LIGHT CONTROL LEFT
14 10 HEAD LIGHT CONTROL RIGHT
15 15 DT ELECRIC WATER PUMP
16 7,5 BATTERY SENSOR
17 7,5 IGMG ECU
18 10 BACK UP
19 15 AUDIO
20 15 WASHER
21 7,5 ES VLV1
22 7,5 ES VLV2
23 10 HORN
24 10 ES ELECTRIC COOLANT HEATER
25 10 ES ELECTRIC WATER PUMP
26 15 FRONT FOG LIGHT
27 10 CHARGE LID ACTUATOR



Fuse box B

Pull up the cover on the + terminal, then remove it while pulling out the tab as shown.

No.
 A
 Protected Component
175 BATTERY FUSE

Driver Side Interior Fuse Box

Fuse Box A

Located behind the instrument panel.

Honda E - fuse box diagram - driver side interior (fuse box A)
Honda E – fuse box diagram – driver side interior (fuse box A)
No.
 A
 Protected Component
1 — —
2 10 LEFT SIDE DOOR UNLOCK
3 10 RIGHT SIDE DOOR UNLOCK
4 10 ACC
5 — —
6 10 SRS
7 — —
8 7,5 P-ACT ECU
9 10 KEYLESS ACCESS
10 10 REAR FOG
11 10 LEFT SIDE DOOR LOCK
12 — —
13 10 RIGHT SIDE DOOR LOCK
14 10 OPTION
15 5 DAYTIME RUNNING LIGHT
16 — —
17 10 WIDE MOITOR
18 10 HAZARD
19 7,5 CENTER CAMERA MIRROR SYSTEM
20 10 QUIC CHARGEING SYSTEM
21 — —
22 — —
23 10 COMBO
24 10 IMG
25 7,5 SHIFTER
26 10 LEFT SIDE CAMERA MIRROR SYSTEM
27 10 RIGHT SIDE CAMERA MIRROR SYSTEM
28 7,5 ABS/VSA
29 7,5 ELECTRIC POWER PLANT
30 — —
31 10 REAR USB CHARGER
32 10 OPTION
33 — —
34 20 FRONT SEAT HEATERS
35 10 ACG
36 10 METER
37 10 OPTION
38 — —
39 — —
40 10 HEATED STEERING WHEEL
41 10 IGC
42 — —
43 7,5 AUDIO SUB
44 20 PREMIUM AMP
45 10 REAR WIPER
46 10 SRS
47 — —
48 10 A/C MAIN
49 20 DOOR LOCK
50 20 FRONT ACCESSORY SOCKET
51 — —
52 10 A/C ELECTRIC WATER PUMP
53 20 SUPER LOCK (not available on all models)
54 15 POUP DOOR OUTER HANDLE
55 — —

Fuse Box B

Located under the fuse box A.

Honda E - fuse box diagram - driver side interior (fuse box B)
Honda E – fuse box diagram – driver side interior (fuse box B)
No.
 A
 Protected Component
1 30 LEFT REAR POWER WINDOW
2 30 PASSENGER’S POWER WINDOW
3 30 RIGHT REAR POWER WINDOW
4 30 DRIVER’S POWER WINDOW



Rear Fuse Box

Located under the luggage area floor lid.

Honda E - fuse box diagram - rear fuse box
Honda E – fuse box diagram – rear fuse box
No.
 A
 Protected Component
1 20 EOP
2 30 P-ACT
3 — —
4 — —
5 — —

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Toyota RAV4  (SXA1; 1994 – 1997) – fuse box diagram

Posted on by admin

Toyota RAV4  (SXA1; 1994 – 1997) – fuse box diagram

Year of production: 1994, 1995, 1996, 1997

Engine Compartment

  1. Fuse Box
  2. Relay Box
  3. ABS Relay
  4. Fusible Link Block

Engine Compartment Fuse Box



No.
 Fuse
 A
 Circuit
1 – – –
2 – – –
3 H-LP (LH) 15 Left-hand headlight
4 H-LP (RH) 15 Right-hand headlight
5 – – –
6 – – –
7 SPARE 15 Spare fuse
8 SPARE 10 Spare fuse
9 ALT-S 5 Charging system
10 – – –
11 HAZ-HORN 15 Emergency flashers, horns
12 EFI 15 Multiport fuel injection system/sequential multiport fuel injection system
13 DOME 15 Personal lights, open door warning light, clock
14 AM2 20 Multiport fuel injection system/sequential multiport fuel injection system, charging system
15 CDS FAN 30 Electric cooling fan
16 RDI FAN 30 Electric cooling fan
17 – – –
18 MAIN No. 1 30 Starting system, headlights
19 ABS 60 -1997: Anti-lock brake system
20 – – –
Relay
R1 Main
R2 Headlights
R3 Starter

Engine Compartment Relay Box



No.
 Relay
R1 EFI Main
R2 Electric cooling fan (No.1)
R3 Horn
R4 Electric cooling fan (No.3)
R5 Magnetic clutch (A/C)
R6 Electric cooling fan (No.2)



Fusible Link Block

No.
 Fuse
 A
 Circuit
1 Main 80 “AM 2”, “HAZ-HORN”, “EFI”, “DOME”, “RADIO” and “ALT-S” fuses
2 ALT 100 Tail lights, “ABS”, “RADIO”, “HTR”, “AM 1”, “POWER”, “STOP” and “DEF” fuses
3 HTR 50 Air conditioning system

Passenger Compartment



  1. Fuse Box
  2. Relay Box
  3. ABS ECU
  4. Fuse Box No.2
  5. A/C Amplifier
  6. Door Lock Control Relay
  7. Cruise Control ECU
  8. Fuse Box No.3
  9. Airbag Sensor Assembly
  10. Shift Lock ECU
  11. Engine Control Modul



Passenger Compartment Fuse Box

No.
 Fuse
 A
 Circuit
1 TAIL 10 Tail lights, parking lights, license plate lights, interior lights
2 GAUGE 11 Gauges and meters, service reminder indicators (except discharge and open door warning lights), back-up lights, air conditioning system, power windows, rear window defogger, center differential lock system, electronically controlled automatic transmission system
3 TURN 7.5 Turn signal lights
4 CIG & RAD 15 Cigarette lighter, clock, car audio system, power rear view mirrors
5 DEF-I/UP 7.5 Multiport fuel injection system/sequential multiport fuel injection system
6 IGN 7.5 Multiport fuel injection system/sequential multiport fuel injection system, discharge warning light
7 ECU-IG 7.5 Anti-lock brake system, electronically controlled automatic transmission system
8 WIPER 20 Windshield wipers and washer, rear window wiper and washer
9 – – –
10 SRS 7.5 SRS airbag system
11 OBD 7.5 On-board diagnosis system
12 STOP 10 Stop lights

Passenger Compartment Relay Box

No.
 Relay
R1 Circuit Opening Relay
R2 –
R3 Turn Signal Flasher
R4 –

Passenger Compartment Fuse Box (No.2)



No.
 Fuse
 A
 Circuit
1 POWER 30 Power windows, power door lock system
2 DEF 30 Rear window defogger
3 AM1 40 “CIG & RAD”, “WIPER”, “GAUGE”, “ECU-IG”, “TURN”, “TAIL” and “PANEL” fuses
4 – – Noise Filter
Relay
R1 Defogger
R2 Power Main Relay
R3 Taillight
R4 Integration Relay



Passenger Compartment Fuse Box (No.3)



No.
 Fuse
 A
 Circuit
1 A/C 7.5 Air conditioning system
2 – – –
Relay
R1 Heater

Rear Wiper Relay



WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Toyota RAV4  (XA40; 2013 – 2018) -fuse box diagram

Posted on by admin

Toyota RAV4  (XA40; 2013 – 2018) -fuse box diagram

Year of production: 2013, 2014, 2015, 2016, 2017, 2018

Passenger Compartment

LHD

Toyota RAV4 (XA40) - fuse box diagram - passenger compartment (LHD)
Toyota RAV4 (XA40) – fuse box diagram – passenger compartment (LHD)

RHD

Toyota RAV4 (XA40) - fuse box diagram - passenger compartment (RHD)
Toyota RAV4 (XA40) – fuse box diagram – passenger compartment (RHD)
  1. LHD: Interior Light Relay (DOME CUT)
  2. Headlight Leveling ECU
  3. Fuse Box / Main Body ECU
  4. Steering Lock Actuator
  5. Power Steering ECU
  6. Relay Box
  7. Navigation ECU
  8. 4WD ECU
  9. Clearance Warning ECU
  10. Driving Support ECU
  11. Network Gateway ECU
  12. Windshield Wiper Relay
  13. Engine Stop and Start ECU
  14. Shift Lock Control ECU (Floor Shift Lever Sub-Assembly)
  15. Airbag Sensor Assembly
  16. Junction Connector
  17. A/C Amplifier
  18. Junction Connector
  19. RHD: Double Lock Door Control Relay

Passenger Compartment Fuse Box

LHD

Toyota RAV4 (XA40) - fuse box diagram - passenger compartment fuse box (LHD)
Toyota RAV4 (XA40) – fuse box diagram – passenger compartment fuse box (LHD)

RHD

Toyota RAV4 (XA40) - fuse box diagram - passenger compartment fuse box (RHD)
Toyota RAV4 (XA40) – fuse box diagram – passenger compartment fuse box (RHD)
Toyota RAV4 (XA40) - fuse box diagram - passenger compartment fuse box (RHD)
Toyota RAV4 (XA40) – fuse box diagram – passenger compartment fuse box (RHD)
Toyota RAV4 (XA40) - fuse box diagram - passenger compartment fuse box
Toyota RAV4 (XA40) – fuse box diagram – passenger compartment fuse box



No.
 Fuse
 A
 Circuit
1 – –  –
2 STOP 7.5 Stop lights
3 S/ROOF 10 Moon roof
4 AM1 5 “IG1 NO.1”, “IG1 NO.2”, “IG1 NO.3”, “ACC” fuses
5 OBD 7.5 On-board diagnosis system
6 D/L NO.2 20 Before Oct. 2015: Power door lock system (side doors), main body ECU
7 FOG RR 7.5 Rear fog light
8 D/L BACK 10 Power door lock system (back door)
9 P/OUTLET NO.1 15 Power outlets
10 DOOR D 20 Driver’s door power window
11 DOOR R/R 20 Right-hand rear door power window
12 DOOR R/L 20 Left-hand rear door power window
13 WIP RR 15 Rear window wiper
14 WSH 15 Windshield washer, rear window washer
15 GAUGE 7.5 Back-up lights, Blind Spot Monitor system, inside rear view mirror
16 WIP FR 25 Windshield wipers
17 SFT LOCK-ACC 5 Shift lock system ECU
18 P/OUTLET NO.2 15 Power outlets
19 ACC 7.5 Power outlets, audio system, outside rear view mirrors, main body ECU, clock, electric current sensor
20 PANEL 7.5 VSC OFF switch, instrument cluster (indicators and warning lights), BSM main switch, all-wheel drive lock switch, windshield wiper de-icer switch, multiport fuel injection system/sequential multiport fuel injection system, intuitive parking assist ECU, seat heater switches, power outlets, power back door switches, air conditioning system switches, rear window defogger switch, audio system, cup holder light, steering switches, driver module switch
21 TAIL 10 Parking lights, tail lights, license plate lights, side marker lights, fog lights
22 D/L NO.2 20 From Oct. 2015: Power door lock system (side doors), main body ECU
23 EPS-IG 5 Electric power steering
24 ECU-IG NO.1 10 Dynamic Torque Control AWD system ECU, steering sensor, instrument cluster (indicators and warning lights), shift control switch
25 ECU-IG NO.2 5 Main body ECU, wireless remote control, shift lock system ECU, smart key system, moon roof ECU, audio system, power back door ECU, tire pressure warning system, LDA system, Blind Spot Monitor system
26 HTR-IG 7.5 Air conditioning system ECU, air conditioning system switches, rear window defogger switch
27 S-HTR LH 10 Before Oct. 2015: Left-hand seat heater
S/HTR F/L 10 From Oct. 2015: Left-hand seat heater
28 S-HTR RH 10 Before Oct. 2015: Right-hand seat heater
S/HTR F/R 10 From Oct. 2015: Right-hand seat heater
29 IGN 7.5 Fuel pump, multiport fuel injection system/sequential multiport fuel injection system, stop lights, steering lock system ECU
30 A/B 7.5 SRS airbag system ECU, front passenger occupant classification system ECU
31 METER 5 Gauges and meters
32 ECU-IG NO.3 7.5 Alternator, anti-lock brake system/vehicle stability control ECU, windshield wiper de-icer switch, stop lights, “FAN NO.1”, “FAN NO.2”, “FAN NO.3”, “HTR”, “PTC”, “DEF”, “DEICER” fuses



Toyota RAV4 (XA40) - fuse box diagram - passenger compartment fuse box
Toyota RAV4 (XA40) – fuse box diagram – passenger compartment fuse box
No.
 Fuse
 A
 Circuit
1 P/SEAT F/L 30
Left-hand power seat
2 PBD 30 Power back door
3 P/SEAT F/R 30
Right-hand power seat
4 P/W-MAIN 30 Front power windows, power window main switch



Passenger Compartment Relay Box

Toyota RAV4 (XA40) - fuse box diagram - passenger compartment relay box
Toyota RAV4 (XA40) – fuse box diagram – passenger compartment relay box

No.
 Relay
R1 LHD: Theft deterrent (S-HORN)
RHD: Interior lights (DOME CUT)
R2 Rear fog light (FOG RR)
Toyota RAV4 (XA40)
Toyota RAV4 (XA40)
  1. Sliding Roof Control ECU
  2. Door Control and Tire Pressure Monitoring System Receiver
    Tire Pressure Warning ECU and Receiver
  3. Door Control Receiver
  4. Telephone Transceiver
  5. Parking Assist ECU
  6. Blind Spot Monitor Sensor RH
  7. Multiplex Network Door ECU
  8. Blind Spot Monitor Sensor LH
  9. Fuel Pump Control ECU
  10. Junction Connector
  11. Stereo Component Amplifier



Engine Compartment

Toyota RAV4 (XA40) - fuse box diagram - engine compartment
Toyota RAV4 (XA40) – fuse box diagram – engine compartment
  1. Fuse Box
  2. ECM
  3. Glow Plug Controller
  4. Generator Control ECU
  5. From Oct. 2015: Cooling Fan ECU
  6. Headlight Cleaner Control Relay
  7. Transmission Control ECU
  8. Relay Box
  9. Injector Drive
  10. Continuously Variable Valve Lift Controller
  11. Brake Actuator
  12. Glow Plug Relay
  13. From Oct. 2015: Fuel Heater Relay

Engine Compartment Fuse Box (Type 1)

Toyota RAV4 (XA40) - fuse box diagram - engine compartment fuse box (type 1)
Toyota RAV4 (XA40) – fuse box diagram – engine compartment fuse box (type 1)
No. Fuse
 A
 Circuit
1 EFI-MAIN NO.1 20 2AR-FE: Multiport fuel injection system/sequential multiport fuel injection system, “EFI NO.1”, “EFI NO.2” fuses
25 3ZR-FE, 3ZR-FAE: Multiport fuel injection system/sequential multiport fuel injection system, “EFI NO.1”, “EFI NO.2” fuses
30 Diesel: Multiport fuel injection system/sequential multiport fuel injection system, automatic transmission ECU, “EFI NO.3” fuses
2 TOWING-B 30 Trailer
3 STRG LOCK 10 Steering lock ECU
4 ECU-B NO.2 10 Air conditioning system ECU, gauges and meters, smart entry & start system, overhead module
5 TURN&HAZ 10 Gauges and meters
6 EFI-MAIN NO.2 20 2AR-FE: Air flow sensor, fuel pump, rear O2 sensor
Diesel: “EFI NO.1”, “EFI NO.2” fuses
15 3ZR-FE, 3ZR-FAE: Multiport fuel injection system/sequential multiport fuel injection system
7.5 From Oct. 2015:
2WW: Multiport fuel injection system/sequential multiport fuel injection system
7 ST NO.2 20 Before Oct. 2015: Starting system
D/L NO.1 30 From Oct. 2015: Back door opener, combination meter, double locking, entry & start system, front fog light, front wiper and washer, headlight, immobiliser system, interior light, power back door, power window, rear fog light, seat belt warning, SRS, starting, steering lock, theft deterrent, tire pressure warning system, wireless door lock control
8 ST 30 Starting system
ST NO.1 30 Before Oct. 2015:
3ZR-FAE From Apr. 2015: Starting system
9 AMP 30 Before Oct. 2015: Audio system
AMP/BBC NO.3 30 From Oct. 2015: Audio system
10 ETCS 10 Multiport fuel injection system/sequential multiport fuel injection system
FUEL PMP 30 From Oct. 2015:
2WW: Fuel pump
11 S-HORN 10 Before Oct. 2015: Theft deterrent
BBC NO.2 30 From Oct. 2015:
without Telematics System: Stop & Start system ECU
MAYDAY 7.5 From Oct. 2015:
with Telematics System: Mayday system
12 IG2 15 Multiport fuel injection system/sequential multiport fuel injection system, “METER”, “IGN”, “A/B” fuses
13 AM2 7.5 Starting system, “IG2” fuse
14 ALT-S/ICS 7.5 Electric current sensor, alternator
15 HORN 10 Horn
16 EDU 25 Diesel: Multiport fuel injection system/sequential multiport fuel injection system
ST NO.2 20 From Oct. 2015:
3ZR-FAE: Starting system
S-HORN 10 From Oct. 2015:
with Security Horn: Theft deterrent
17 D/C CUT 30 “DOME”, “ECU-B NO.1”, “RADIO” fuses
18 WIPER-S 5 Windshield wiper switch, electric current sensor, multiport fuel injection system/sequential multiport fuel injection system
19 EFI NO.1 10 3ZR-FE: Air flow meter, purge control VSV, ACIS VSV, rear O2 sensor, multiport fuel injection system/sequential multiport fuel injection system
3ZR-FAE: Multiport fuel injection system/sequential multiport fuel injection system
2AR-FE: Air flow meter, purge control VSV, ACIS VSV
1AD-FTV: Oil switching valve, EDU, ADD FUEL VLV, EGR cooler bypass VSV, clutch upper switch, Stop & Start system ECU, glow control unit, air flow meter
2AD-FTV, 2AD-FHV: EDU, ADD FUEL VLV, EGR cooler bypass VSV, clutch upper switch, air flow meter, VNT E-VRV
7.5 From Oct. 2015:
2WW: Multiport fuel injection system/sequential multiport fuel injection system
20 EFI NO.2 10 3ZR-FAE: Air flow sensor, Air flow meter, purge control VSV, ACIS VSV, rear O2 sensor, Stop & Start system ECU
2AR-FE: Multiport fuel injection system/sequential multiport fuel injection system, key off pump module
3ZR-FE, 2AD-FTV, 2AD-FHV: Air flow sensor
15 From Oct. 2015:
2WW: Multiport fuel injection system/sequential multiport fuel injection system
21 H-LP LH-HI 10 Left-hand headlight (high beam), headlight high beam indicator
22 H-LP RH-HI 10 Right-hand headlight (high beam)
23 EFI NO.3 7.5 Multiport fuel injection system/sequential multiport fuel injection system, automatic transmission ECU
20 From Oct. 2015:
2WW: Multiport fuel injection system/sequential multiport fuel injection system
24 – –  –
25 – –  –
26 RADIO 20 Audio system
27 ECU-B NO.1 10 Wireless remote control, steering sensor, main body ECU, door lock ECU, clock, power back door ECU, tire pressure warning system
28 DOME 10 Engine switch light, interior lights, vanity lights, luggage compartment light, personal lights
29 H-LP LH-LO 10 Before Oct. 2015:
Halogen: Left-hand headlight (low beam), manual headlight leveling dial, headlight leveling system
From Oct. 2015: Left-hand headlight (low beam), manual headlight leveling dial, headlight leveling system
15 Before Oct. 2015:
HID: Left-hand headlight (low beam), manual headlight leveling dial, headlight leveling system
30 H-LP RH-LO 10 Before Oct. 2015:
Halogen: Right-hand headlight (low beam)
From Oct. 2015: Right-hand headlight (low beam)
15 Before Oct. 2015:
HID: Right-hand headlight (low beam)
31 – –  –
32 – –  –
33 – –  –
34 – –  –
35 FUEL HTR 50 From Oct. 2015:
2WW: Fuel heater
36 BBC 40 Stop & Start system ECU
37 VLVMATIC 30 VALVEMATIC system
EFI MAIN 50 From Oct. 2015:
2WW: ABS, auto LSDcruise control, downhill assist control, dynamic radar cruise control, engine control, hill-start assist control, panoramic view monitor system, stop & start system, TRC, VSC
38 ABS NO.2 30 Vehicle stability control, anti-lock brake system
39 ABS NO.2 50 Vehicle stability control, anti-lock brake system
40 H-LP-MAIN 50 “H-LP RH-LO”, “H-LP LH-LO”, “H-LP RH-HI”, “H-LP LH-HI” fuses
41 GLOW 80 Glow control unit
42 EPS 80 Electric power steering
43 ALT 120 Before Oct. 2015:
Gasoline: “STOP”, “S/ROOF”, “AM1”, “OBD”, “D/L NO.2”, “FOG RR”, “D/L BACK”, “P/OUTLET NO.1”, “DOOR D”, “DOOR R/R”, “DOOR R/L”, “WIP RR”, “WSH”, “GAUGE”, “WIP FR”, “SFT LOCK-ACC”, “P/OUTLET NO.2”, “ACC”, “PANEL”, “TAIL”, “D/L NO.2”, “EPS-IG”, “ECU-IG NO.1”, “ECU-IG NO.2”, “HTR-IG”, “S-HTR LH”, “S-HTR RH”, “IGN”, “A/B”, “METER”, “ECU-IG NO.3” fuses
140 Before Oct. 2015:
Diesel, 3ZR-FAE From Apr. 2015: ↓
From Oct. 2015:
Except 2WW: “ABS NO.1”, “ABS NO.2”, “RDI FAN”, “FAN NO.1”, “S/HTR R/L”, “DEICER”, “FOG FR”, “S/HTR R/R”, “CDS FAN”, “FAN NO.2”, “HTR”, “STV HTR”, “TOWING-ALT”, “HWD NO.1”, “HWD NO.2”, “H-LP CLN”, “DRL”, “PTC HTR NO.1”, “PTC HTR NO.2”, “PTC HTR NO.3”, “DEF”, “NOISE FILTER”, “STOP”, “S/ROOF”, “AM1”, “OBD”, “D/L NO.2”, “FOG RR”, “D/L BACK”, “P/OUTLET NO.1”, “DOOR D”, “DOOR R/R”, “DOOR R/L”, “WIP RR”, “WSH”, “GAUGE”, “WIP FR”, “SFT LOCK-ACC”, “P/OUTLET NO.2”, “ACC”, “PANEL”, “TAIL”, “D/L NO.2”, “EPS-IG”, “ECU-IG NO.1”, “ECU-IG NO.2”, “HTR-IG”, “S-HTR LH”, “S-HTR RH”, “IGN”, “A/B”, “METER”, “ECU-IG NO.3” fuses
Relay
R1 Engine control unit (EFI-MAIN NO.2)
R2 Ignition (IG2)
R3 Diesel: Engine control unit (EDU)
Gasoline: Fuel pump (C/OPN)
2WW: Fuel pump (FUEL PMP)
R4 Before Oct. 2015: Headlight (H-LP)
From Oct. 2015: Dimmer
R5 Engine control unit (EFI-MAIN NO.1)
R6 Before Oct. 2015: Dimmer
From Oct. 2015:
Except 2AR-FE: Headlight (H-LP)
2AR-FE: Headlight / daytime running light (H-LP/DRL)

Engine Compartment Fuse Box (Type 2)

Toyota RAV4 (XA40) - fuse box diagram - engine compartment fuse box (type 2)
Toyota RAV4 (XA40) – fuse box diagram – engine compartment fuse box (type 2)
No. Fuse
 A
 Circuit
1 RADIO 20 Audio system
2 ECU-B NO.1 10 Wireless remote control, steering sensor, main body ECU, clock, power back door ECU, tire pressure warning system, driving position memory ECU
3 DOME 10 Engine switch light, interior lights, vanity lights, luggage compartment light, personal lights
4 – –  –
5 DEICER 20 Windshield wiper de-icer
6 – –  –
7 FOG FR 7.5 Fog lights, fog light indicator
8 AMP 30 Audio system
9 ST 30 Starting system
10 EFI-MAIN NO.1 20 Multiport fuel injection system/sequential multiport fuel injection system, “EFI NO.1”, “EFI NO.2” fuses
11 – –  –
12 IG2 15 Multiport fuel injection system/sequential multiport fuel injection system, “METER”, “IGN”, “A/B” fuses
13 TURN&HAZ 10 Gauges and meters
14 AM2 7.5 Starting system, “IG2” fuse
15 ECU-B NO.2 10 Air conditioning system ECU, gauges and meters, front passenger occupant classification system ECU, smart key system
16 STRG LOCK 10 Steering lock ECU
17 D/C CUT 30 “DOME”, “ECU-B NO.1”, “RADIO” fuses
18 HORN 10 Horn
19 ETCS 10 Multiport fuel injection system/sequential multiport fuel injection system
20 EFI-MAIN NO.2 20 Air flow sensor, fuel pump, rear O2 sensor
21 ALT-S/ICS 7.5 Electric current sensor
22 MIR HTR 10 Outside rear view mirror defoggers, multiport fuel injection system/sequential multiport fuel injection system
23 EFI NO.1 10 Air flow meter, purge control VSV, ACIS VSV
24 EFI NO.2 10 Multiport fuel injection system/sequential multiport fuel injection system, key off pump module
25 H-LP LH-HI 10 Left-hand headlight (high beam), headlight high beam indicator
26 H-LP RH-HI 10 Right-hand headlight (high beam)
27 – –  –
28 H-LP LH-LO 10 Left-hand headlight (low beam)
29 H-LP RH-LO 10 Right-hand headlight (low beam)
30 CDS FAN 30 Electric cooling fans
31 HTR 50 Air conditioning system
32 H-LP-MAIN 50 Daytime running lights, “H-LP RH-LO”, “H-LP LH-LO”, “H-LP RH-HI”, “H-LP LH-HI” fuses
33 PTC HTR NO.2 30 PTC heater
34 PTC HTR NO.1 30 PTC heater
35 DEF 30 Rear window defogger, “MIR HTR” fuse
36 ABS NO.2 30 Vehicle stability control
37 RDI FAN 30 Electric cooling fans
38 ABS NO.1 50 Vehicle stability control
39 EPS 80 Electric power steering
40 ALT 120 “ABS NO.1”, “ABS NO.2”, “PTC HTR NO.1”, “PTC HTR NO.2”, “DEICER”, “HTR”, “RDI FAN”, “CDS FAN”, “FOG FR”, “DEF” fuses
41 WIPER-S 5 Windshield wiper switch, electric current sensor
42 SPARE 10 Spare fuse
43 SPARE 20 Spare fuse
44 SPARE 30 Spare fuse
Relay
R1 Engine control unit (EFI-MAIN NO.2)
R2 Ignition (IG2)
R3 Fuel pump (C/OPN)
R4 Short Pin
R5 Headlight (H-LP)
R6 Engine control unit (EFI-MAIN NO.1)
R7 Rear window defogger (DEF)
M1 Daytime running lights module

Engine Compartment Relay Box (Type 1)

Toyota RAV4 (XA40) - fuse box diagram - engine compartment relay box (type 1)
Toyota RAV4 (XA40) – fuse box diagram – engine compartment relay box (type 1)
Toyota RAV4 (XA40) - fuse box diagram - engine compartment relay box (type 1)
Toyota RAV4 (XA40) – fuse box diagram – engine compartment relay box (type 1)



No. Fuse
 A
 Circuit
1 DRL 5 Daytime running lights
2 TOWING-ALT 30 Trailer
3 FOG FR 7.5 Front fog lights, front fog light indicator
4 NOISE FILTER 10 Noise filter
5 STV HTR 25 Power heater
6 S/HTR R/R 10 From Oct. 2015: Seat heater (rear passenger’s seat)
7 DEICER 20 Windshield wiper de-icer
S/HTR R/L 10 From Oct. 2015: Seat heater (rear passenger’s seat)
8 CDS FAN NO.2 5 From Oct. 2015:
Diesel: Electric cooling fans
9 – –  –
10 RDI FAN NO.2 5 From Oct. 2015:
Diesel: Electric cooling fans
11 – –  –
12 – –  –
13 MIR HTR 10 Outside rear view mirror defoggers, multiport fuel injection system/sequential multiport fuel injection system
14 – –  –
15 – –  –
16 – –  –
17 PTC HTR NO.1 50 600W, 840W: PTC heater
30 330W: PTC heater
18 PTC HTR NO.2 50 840W: PTC heater
30 330W: PTC heater
19 PTC HTR NO.3 50 840W: PTC heater
30 330W: PTC heater
20 CDS FAN 30 Electric cooling fans
40 From Oct. 2015:
2WW: Electric cooling fans
FAN NO.2 50 From Oct. 2015 Diesel:
with Trailer Towing: Electric cooling fans
21 RDI FAN 30 Electric cooling fans
40 From Oct. 2015:
2WW: Electric cooling fans
FAN NO.1 50 From Oct. 2015 Diesel:
with Trailer Towing: Electric cooling fans
22 HTR 50 Air conditioning system
23 DEF 30 Rear window defogger, “MIR HTR” fuse
24 HWD NO.2 50 Heated windshield defroster
25 H-LP CLN 30 Headlight cleaner
26 HWD NO.1 50 Heated windshield defroster
Relay
R1 Electric cooling fan (FAN NO.2)
R2 Front fog lights (FOG FR)
R3 Horn
R4 Heater (HTR)
R5 Daytime running lights (DRL)
R6 Electric cooling fan (FAN NO.3)
R7 Electric cooling fan (FAN NO.1)
R8 Rear window defogger (DEF)
R9 PTC heater (PTC HTR NO.1)
R10 PTC heater (PTC HTR NO.2)
Heated windshield defroster (HWD NO.1)
R11 PTC heater (PTC HTR NO.3)
Heated windshield defroster (HWD NO.2)
R12 Stop lights (STOP LP)
R13 Starter (ST), (ST NO.1)
R14 Heated windshield defroster (DEICER)
Heated steering wheel (STRG HTR)
Heated windshield defroster / heated steering wheel (DEICER/STRG HTR)
A
R15 From Oct. 2015:
with Trailer towing + Diesel: Electric cooling fans (FAN NO.1)
Rear seat heater (S/HTR R/L)
R16 From Oct. 2015: Rear seat heater (S/HTR R/R)
B
R17 From Oct. 2015:
with Trailer towing + Diesel: Electric cooling fans (FAN NO.2)
Washer nozzle heater (WSH NZL HTR)
R18 Starter (ST NO.2)
C
R19 330W: PTC heater (PTC HTR NO.1)
600W: PTC heater (PTC HTR NO.3)
R20 PTC heater (PTC HTR NO.2)

Engine Compartment Relay Box (Type 2)

Toyota RAV4 (XA40) - fuse box diagram - engine compartment relay box (type 1)
Toyota RAV4 (XA40) – fuse box diagram – engine compartment relay box (type 1)
No.
 Relay
R1 Front fog lights (FOG FR)
R2 Air conditioner compressor clutch (MG/CLT)
R3 PTC heater (PTC HTR NO.2)
R4  –
R5 Horn
R6 Electric cooling fan (FAN NO.2)
R7 PTC heater (PTC HTR NO.1)
R8 Electric cooling fan (FAN NO.3)
R9 Starter (ST)
R10 Electric cooling fan (FAN NO.1)

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
