Toyota Corolla (2012 – 2016) – fuse box diagram

Posted on 29 October 201522 July 2018 by admin

Toyota Corolla (2012 – 2016) – fuse box diagram

Year of production: 2012, 2013, 2014, 2015, 2016

Fuse box in engine compartment

Toyota Corolla mk11 - fuse box - engine compartment — Toyota Corolla mk11 – fuse box – engine compartment

Fuse		Ampere rating	Circuit
1	H-LP CLN	30	Headlight cleaner
2	RDI FAN	40	Electric cooling fan
3	ABS NO. 3^*1	30	Anti-lock brake system, vehicle stability control system
4	ABS NO. 1	50	Anti-lock brake system, vehicle stability control system
5	HTR	50	Air conditioning system
6	ALT	120 A^*1	RDI FAN, H-LP CLN, ABS NO. 1, ABS NO. 3, ABS NO. 2, HTR, HTR SUB NO. 1, HTR SUB NO. 2, HTR SUB NO. 3, STV HTR, ACC, CIG, METER, IGN, ECU-IG NO. 2, HTRIG, WIPER, WASHER, ECU-IG NO. 1, SEAT HTR, AM1, DOOR, STOP, FR DOOR, POWER, RR DOOR, RL DOOR, OBD, ACC-B, RR FOG, FR FOG, DEF, MIR HTR, TAIL, PANEL
6	ALT	140 A^*2
7	EPS	60	Electric power steering
8	GLOW*2	80	Engine glow system
9	P-SYSTEM^*1	30	No circuit
10	P/I	30	EFI MAIN, HORN, IG2
11	H-LP MAIN	50	H-LP LH LO, H-LP RH LO, H-LP LH HI, H-LP RH HI
12	AMT^*7	50	Multi-mode manual transmission
13	SPARE	10	Spare fuse
14	SPARE	30	Spare fuse
15	SPARE	20	Spare fuse
16	ECU-B3^*2	7,5	Multiport fuel injection system/ sequential multiport fuel injection system
17	ECU-B2	10	Multi-mode manual transmission, air conditioning system, smart entry & start system, power windows
18	ECU-B	10	Main body ECU, gauge and meters, vehicle stability control system, power door lock system, starting system, charging system
19	RAD NO. 1	15	Audio system
20	DOME	10	Interior lights, trunk light, vanity lights, smart entry & start system, wireless remote control, engine switch light
21	AM2 NO. 2	7,5	Main body ECU, multiport fuel injection system/sequential multiport fuel injection system, starting system
22	ALT-S	7,5	Charging system
23	TURN-HAZ	10	Turn signal lights
24	ETCS^*1	10	Multiport fuel injection system/ sequential multiport fuel injection system
25	AM2	30	Starting system, IG2 NO. 2
26	STRG LOCK	20	Steering lock system
27	IGT/INJ^*1	15	Multiport fuel injection system/ sequential multiport fuel injection system, starting system
28	EFI MAIN	20 A^*1	Multiport fuel injection system/ sequential multiport fuel injection system, EFI NO. 1, EFI NO. 2
28	EFI MAIN	30 A^*2
29	HORN	10	Horn
30	IG2	15	Multiport fuel injection system/ sequential multiport fuel injection system, starting system, IG2 NO. 2, IGN, METER
31	HTR SUB NO. 1	30 A^*5	Air conditioning system
31	HTR SUB NO. 1	50 A^*6	Air conditioning system
32	HTR SUB NO. 2	30	Air conditioning system
33	HTR SUB NO. 3	30	Air conditioning system
34	FR DEICER^*1	20	No circuit
35	ABS NO. 2	30	Anti-lock brake system, vehicle stability control system
36	STV HTR^*2	25	Power heater
37	WIP-S	7,5	Charging system
38	IG2 NO. 2	7,5	Starting system, AM2, AM2 NO. 2
39	EFI NO. 2	10	Multiport fuel injection system/ sequential multiport fuel injection system
40	EFI NO. 1	10	Multiport fuel injection system/ sequential multiport fuel injection system
41	H-LP RH HI	10	Right-hand headlight (high beam)
42	H-LP LH HI	10	Left-hand headlight (high beam)
43	H-LP RH LO	10 A^*3	Right-hand headlight (low beam)
43	H-LP RH LO	15 A^*4	Right-hand headlight (low beam)
44	H-LP LH LO	10 A^*3	Left-hand headlight (low beam)
44	H-LP LH LO	15 A^*4	Left-hand headlight (low beam)

*1: Vehicles with a gasoline engine

*2: Vehicles with a diesel engine

*3: Vehicles without discharge headlights (low beam)

*4: Vehicles with discharge headlights (low beam)

*5: Vehicles with a 495W PTC heater

*6: Vehicles with a 600W PTC heater

*7: Vehicles with a multi-mode manual transmission

Fuse box in instrument panel (type A)

Toyota Corolla mk11 - fuse box - instrument panel - type A — Toyota Corolla mk11 – fuse box – instrument panel – type A

Fuse		Ampere rating [A]	Circuit
1	TAIL	10	Front position lights, tail lights, license plate lights, rear fog light, front fog lights, manual headlight leveling dial, multiport fuel injection system/sequential multiport fuel injection system, instrument cluster lights
2	PANEL	7,5	Switch illumination, instrument cluster lights, main body ECU
3	FR DOOR	20	Power windows
4	RL DOOR	20	Power windows
5	RR DOOR	20	Power windows
6	SUNROOF	20	No circuit
7	CIG	15	Cigarette lighter
8	ACC	7,5	Outside rear view mirrors, audio system, main body ECU, smart entry & start system, rear view monitor system
9	MIR HTR	10	Outside rear view mirror defoggers, multiport fuel injection system/ sequential multiport fuel injection system
10	RR FOG	7,5	Rear fog light
11	IGN	7,5	Steering lock system, SRS airbag system, multi-mode manual transmission, multiport fuel injection system/sequential multiport fuel injection system, smart entry & start system, charging system, starting system
12	METER	7,5	Gauge and meters
13	SEAT HTR	15	Seat heaters
14	HTR-IG	10	Air conditioning system, rear window defogger, power heater
15	WIPER	25	Windshield wipers, rain sensor
16	WASHER	15	Windshield washer
17	ECU-IG NO. 1	10	Automatic headlight leveling system, main body ECU, electric power steering, electric cooling fan, shift lock control system, rain sensor, anti-lock brake system, vehicle stability control system, headlight cleaner
18	ECU-IG NO. 2	10	Back-up lights, charging system, auto anti-glare inside rear view mirror, rear window defogger, air conditioning system, emergency flashers, front passenger’s seat belt reminder light, rear view monitor system, multiport fuel injection system/sequential multiport fuel injection system
19	OBD	7,5	On-board diagnosis system
20	STOP	10	Stop lights, high mounted stoplight, anti-lock brake system, main body ECU, multiport fuel injection system/sequential multiport fuel injection system, multi-mode manual transmission, shift lock control system
21	DOOR	25	Power door lock system
22	ACC-B	25	CIG, ACC
23	FR FOG	15	Front fog lights
24	AM1	7,5	Starting system, shift lock control system, multiport fuel injection system/sequential multiport fuel injection system

Fuse box in instrument panel (type B)

Toyota Corolla mk11 - fuse box - instrument panel - type B — Toyota Corolla mk11 – fuse box – instrument panel – type B

Fuse		Ampere rating [A]	Circuit
1	POWER	30	Power windows
2	DEF	40	Rear window defogger, MIR HTR
3	PWR SEAT	30	No circuit

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Toyota Aygo (AB10; 2012 – 2014) – fuse box diagram

Posted on 24 October 201522 July 2018 by admin

Toyota Aygo (AB10; 2012 – 2014) – fuse box diagram

Year of production: 2012, 2013, 2014

Fuse box in engine compartment (top side)

Toyota Aygo mk1 - fuse box - engine compartment (top side) — Toyota Aygo mk1 – fuse box – engine compartment (top side)

Fuse		Ampere rating [A]	Ciricuit
1	DRL	5	Daytime running lights
2	FOG FR	20	Front fog lights
3	H-LP LH	10	Left-hand headlights
4	H-LP RH	10	Right-hand headlights
5	STA	7,5	Multi-mode manual transmission, multiport fuel injection system/ sequential multiport fuel injection system
6	EFI NO.2	7,5	Multiport fuel injection system/ sequential multiport fuel injection system, multi-mode manual transmission
7	MET	5	Gauges and meters
8	SUB-LP	30	DRL, FOG FR fuses
9	ABS NO.2^*1	25	Anti-lock brake system
9	VSC NO.2^*2	30	Anti-lock brake system and vehicle stability control system
10	AM2	30	Starting system, IG1, IG2, STA fuses
11	HAZARD	10	Turn signal lights, emergency flashers, gauges and meters
12	H-LP MAIN	20	H-LP LH, H-LP RH fuses
13	DOME	15	Gauges and meters, interior light, audio system, tachometer
14	EFI	15	Electric cooling fan, multiport fuel injection system/sequential multiport fuel injection system
15	HORN	10	Horn
16	SPARE	7,5	Spare fuse
17	SPARE	10	Spare fuse
18	SPARE	15	Spare fuse
19	AMT	50	Multi-mode manual transmission
20	RADIATOR	30 A^*3	Electric cooling fan
20	RADIATOR	40 A^*3	Electric cooling fan
21	ABS^*1	40	Anti-lock brake system
	VSC^*2	50	Anti-lock brake system and vehicle stability control system
22	EMPS	50	Electric power steering system

*1: Vehicles without VSC system

*2: Vehicles with VSC system

*3: Replace the fuse with one of the same ampere rating as the original

Fuse box in engine compartment (back side)

Toyota Aygo mk1 - fuse box - engine compartment (back side) — Toyota Aygo mk1 – fuse box – engine compartment (back side)

Fuse		Ampere rating [A]	Circuit
1	ALTERNATR	120	Charging system, EMPS, ABS, VSC, RADIATOR, AM1, HTR, PWR, D/L, DEF, TAIL, STOP, OBD, ECU-B fuses

Fuse box in passeneger compartment (instrument panel – right side)

Toyota Aygo mk1 - fuse box - passeneger compartment - instrument panel (right side) — Toyota Aygo mk1 – fuse box – passeneger compartment – instrument panel (right side)

	Fuse	Ampere rating [A]	Circuits
1	STOP	10	Stop lights, high mounted stoplight, anti-lock brake system, multi-mode manual transmission
2	D/L	25	Power door lock system, wireless remote control system
3	DEF	20	Rear window defogger
4	TAIL	7,5	Daytime running light system, tail lights, license plate lights, position lights, headlight beam level control system, instrument panel lights
5	OBD	7,5	On-board diagnosis system
6	ECU-B	7,5	Multi-mode manual transmission, daytime running light system, vehicle stability control system, gauges and meters, rear fog light

Fuse box in passeneger compartment (instrument panel – right side)

Toyota Aygo mk1 - fuse box - passeneger compartment - instrument panel (light side) — Toyota Aygo mk1 – fuse box – passeneger compartment – instrument panel (light side)

	Fuse	Ampere rating [A]	Circuit
1	ECU-IG	7,5	Anti-lock brake system, vehicle stability control system, electric power steering system, electric cooling fan
2	BACK UP	10	Back-up lights, power door lock system, wireless remote control system, power windows, rear window defogger, tachometer, air conditioning system, heater system
3	WIP	20	Windshield wiper and washer, rear window wiper and washer
4	ACC	15	Power outlet, audio system
5	IG1	7,5	Windshield wiper and washer, rear window wiper and washer, anti-lock brake system, electric power steering system, electric cooling fan, back-up lights, power door lock system, wireless remote control system, power windows, rear window defogger, tachometer, air conditioning system, heater system
6	IG2	15	Multiport fuel injection system/ sequential multiport fuel injection system, SRS airbag system, gauges and meters, daytime running light system, multi-mode manual transmission
7	A/C	7,5	Air conditioning system, power heater

Fuse box in passeneger compartment (instrument panel – back side)

Toyota Aygo mk1 - fuse box - passeneger compartment - instrument panel (back side) — Toyota Aygo mk1 – fuse box – passeneger compartment – instrument panel (back side)

	Fuse	Ampere rating [A]	Circuits
1	AM1	40	ACC, WIP, ECU-IG, BACK UP fuses
2	PWR	30	Power windows
3	HTR	40	Heater system, air conditioning system, A/C fuse

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Toyota Avensis (from 2011)- fuse box diagram

Posted on 23 October 201521 July 2018 by admin

Toyota Avensis (from 2013) – fuse box (Europe version)

Year of production: 2011, 2012, 2013, 2014, 2015, 2016

Fuse box in engine compartment

Toyota Avensis mk3 FL - fuse box - engine compartment — Toyota Avensis mk3 FL – fuse box – engine compartment

Fuse		Ampere	Circuit
1	H-LP CLN	30	Headlight cleaner
2	RDI FAN	40	Electric cooling fan(s)
3	CDS FAN	30	Electric cooling fan(s)^*1
4	ABS NO.1	50	Anti-lock brake system, VSC
5	HTR	50	Air conditioning system
6	ALT	120 A^*2	RDI FAN, CDS FAN, H-LP CLN, PWR SEAT LH, FUEL OPN, ABS NO.1, ABS NO.2, FR DEICER, PSB, HTR, STV HTR, PWR OUTLET, HTR SUB NO.1, HTR SUB NO.2, HTR SUB NO.3, ECU-IG NO.2, HTR-IG, WIPER, RR WIPER, WASHER, ECU-IG NO.1, ECU-IG NO.3, SEAT HTR, AM1, DOOR, STOP, P FR DOOR, POWER, RR DOOR, RL DOOR, OBD, ACC-B, RR FOG, FR FOG, TI & TE, SHADE, PWR SEAT RH, DEF, TAIL, DRL
		140 A^*1
7	EPS	80	Electric power steering
8	GLOW^*1	80	Engine glow system
9	P-SYSTEM^*2	30	VALVEMATIC system
10	EFI MAIN^*1	50	Multiport fuel injection system/ sequential multiport fuel injection system, EFI NO.1, EFI NO.2
11	P/I	50	EFI MAIN, HORN, IG2, EDU
12	H-LP MAIN	50	H-LP LH LO, H-LP RH LO, H-LP LH HI, H-LP RH HI
13	E-PKB	30	Electric parking brake
14	SPARE	10	Spare fuse
15	SPARE	30	Spare fuse
16	SPARE	20	Spare fuse
17	AMP	30	Audio system
18	DOOR NO.2	25	Power door lock system
19	EFI MAIN NO.2^*1	7,5	Multiport fuel injection system/ sequential multiport fuel injection system
20	ECU-B2	10	Smart entry & start system, air conditioning system, power windows, power seat
21	ECU-B	10	Gauges and meters, main body ECU, steering sensor, wireless remote control, smart entry & start system, tilt and telescopic steering
22	RAD NO.1	15	Audio system
23	DOME	10	Trunk/luggage compartment light, vanity lights, front door courtesy lights, personal/interior lights, personal lights, foot lights
24	AM2 NO.2	7,5	Starting system
25	TURN-HAZ	10	Turn signal lights, emergency flashers
26	ETCS^*2	10	Electronic throttle control system
27	AM2	30	Starting system
28	STRG LOCK	20	Steering lock system
29	IGT/INJ^*2	15	Multiport fuel injection system/ sequential multiport fuel injection system, ignition system
29	EDU^*1	20	Multiport fuel injection system/ sequential multiport fuel injection system
30	EFI MAIN^*2	20	Multiport fuel injection system/ sequential multiport fuel injection system, EFI NO.1, EFI NO.2
30	FUEL OPN^*1	10	Fuel filler door opener
31	HORN	15	Horn
32	IG2	15	IGN, METER
33	HTR SUB NO.1	30	Air conditioning system
34	HTR SUB NO.2	30	Air conditioning system
35	HTR SUB NO.3	30	Air conditioning system
36	PWR SEAT LH	30	Power seat, lumber support
37	PWR OUTLET	15	Power outlet
38	PSB	30	Pre-crash seat belt
39	FUEL OPN^*2	10	Fuel filler door opener
40	FR DEICER	20	Windshield wiper de-icer
41	ABS NO.2	30	Anti-lock brake system, VSC
42	STV HTR^*1	25	Power heater
43	EFI NO.4^*1	30	Multiport fuel injection system/ sequential multiport fuel injection system, EFI NO.1, EFI NO.2
44	IG2 NO.2	7,5	Starting system
45	EFI NO.2	10	Air intake system, air flow meter, exhaust system
46	EFI NO.1	10	Multiport fuel injection system/ sequential multiport fuel injection system, air flow meter, exhaust system^*1
47	H-LP RH HI	10	Right-hand headlight (high beam)
48	H-LP LH HI	10	Left-hand headlight (high beam)
49	H-LP RH LO	15 ^*4	Right-hand headlight (low beam
49	H-LP RH LO	10^*5	Right-hand headlight (low beam
50	H-LP LH LO	15^*4	Left-hand headlight (low beam)
50	H-LP LH LO	10^*5	Left-hand headlight (low beam)
51	EFI NO.3^*3	7,5	Automatic transmission

*1: Vehicles with diesel engine

*2: Vehicles with gasoline engine

*3: Vehicles with diesel engine and automatic transmission

*4: Vehicles with discharge headlights

*5: Vehicles without discharge headlights

Fuse box under instrument panel (type A)

Toyota Avensis mk3 FL - fuse box - passenger compartment type A — Toyota Avensis mk3 FL – fuse box – passenger compartment type A

Fuse		Ampere rating [A]	Circuit
1	TAIL	10	Front position lights, tail lights, license plate lights, rear fog light, front fog lights, manual headlight leveling dial, instrument panel lights, air conditioning system switch, audio system, Multidrive or automatic transmission shift lever illumination, glove box light, airbag manual on-off system, emergency flashers, cigarette lighter, “AFS OFF” switch, speed limiter switch, electric parking brake switch, steering switch, VSC OFF switch, Toyota parking assist-sensor switch, “LKA” switch, seat heater switch, “SPORT” switch, outside rear view mirror switches, fuel filler door opener switch
2	ECU-IG NO.3	10	Toyota parking assist-sensor, AFS, windshield wiper de-icer, electric parking brake, pre-crash seat belt, paddle shift switch, tilt & telescopic steering, electric power steering
3	P FR DOOR	20	Power windows (passenger side)
4	RL DOOR	20	Power windows (rear left)
5	RR DOOR	20	Power windows (rear right)
6	SHADE	20	Panoramic roof shade^*1
7	CIG	15	Cigarette lighter
8	ACC	7,5	Outside rear view mirrors, shift lock system, audio system, main body ECU, power outlet
9	MIR HTR	10	Outside rear view mirror defoggers
10	TI & TE	30	Tilt & telescopic steering
11	RR FOG	7,5	Rear fog light
12	IGN	7,5	Steering lock system, SRS airbag system, multiport fuel injection system/sequential multiport fuel injection system, automatic transmission^*2, starting system
13	METER	7,5	Gauges and meters
14	SEAT HTR	15	Seat heaters
15	HTR-IG	10	Air conditioning system
16	WIPER	30	Windshield wipers, rain sensing windshield wipers
17	RR WIPER	15	Rear window wiper^*1
18	WASHER	15	Windshield washers, rear window washer^*1
19	ECU-IG NO.1	10	Main body ECU, smart entry & start system, electric cooling fan(s), shift lock system, panoramic roof shade^*1, auto anti-glare inside rear view mirror, anti-lock brake system, steering sensor, yaw rate & G sensor, VSC, headlight cleaner, precrash safety system, LKA, driver support system
20	ECU-IG NO.2	10	Back-up lights, charging system, emergency flashers, rear window defogger, “PASSENGER AIRBAG” indicator, air conditioning system, AFS, rear view monitor, Toyota parking assist-sensor
21	OBD	7,5	On-board diagnosis system
22	STOP	10	Stop lights, high mounted stoplight, anti-lock brake system, VSC, multiport fuel injection system/ sequential multiport fuel injection system, automatic transmission^*2, shift lock system, starting system
23	DOOR	25	Power door lock system
24	ACC-B	25	CIG, ACC
25	DRL	7,5	Daytime running light system
26	FR FOG	15	Front fog lights
27	AM1	7,5	Starting system, ACC, CIG, ECU-IG NO.2, HTR-IG, WIPER, RR WIPER, WASHER, ECU-IG NO.1, ECU-IG NO.3, SEAT HTR

*1: Wagon only

*2: Vehicles with diesel engine and automatic transmission

Fuse box under the instrument panel (type B)

Toyota Avensis mk3 FL - fuse box - passenger compartment type B — Toyota Avensis mk3 FL – fuse box – passenger compartment type B

Fuse		Ampere rating [A]	Circuit
1	POWER	30	Power windows (driver side)
2	DEF	40	Rear window defogger, MIR HTR
3	PWR SEAT RH	30	Power seat, lumber support
4	WIPER NO.2^*1	7,5	Charging system, driver support system ECU
5	WIPER NO.2^*1	7,5	Charging system, driver support system ECU

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Toyota Auris Hybrid mk2 (from 2013) – fuse box diagram

Posted on 20 October 201521 July 2018 by admin

Toyota Auris Hybrid mk2 (from 2013) – fuse box diagram

Year of production: 2013, 2014, 2015, 2016

Fuse box in engine compartment

Toyota Auris mk2 - fuse box - engine compartment - (hybrid model) — Toyota Auris mk2 – fuse box – engine compartment – (hybrid model)

Fuse		Ampere rating [A]	Circuit
1	SPARE	20	Spare fuse
2	EFI NO. 2	10	Multiport fuel injection system/sequential multiport fuel injection system
3	EFI NO. 1	10	Multiport fuel injection system/sequential multiport fuel injection system
4	EFI-B	5	Multiport fuel injection system/sequential multiport fuel injection system
5	SPARE	30	Spare fuse
6	SPARE	10	Spare fuse
7	PTC HIR NO.2	30	Air conditioning system
8	PTC HIR NO.3	20	Air conditioning system
9	PTC HIR NO.1	30	Air conditioning system
10	ENG W/PMP	30	Cooling system
11	DRL	10	Daytime running lights
12	HTR	50	Air conditioning system
13	H-LP CLN	30	Headlight cleaner
14	DEF	30	Rear window defogger, outside rear view mirror defoggers
15	CDS FAN	30	Electric cooling fan(s)
16	RDI	40	Electric cooling fan(s)
17	DC/DC	125	Hybrid system
18	AM2	7,5	Starting system
19	P-CON MTR	30	P position control system, transmission
20	P-CON MAIN	7,5	P position control system, p position switch
21	DC/DC-S	5	Hybrid system
22	ETCS	10	Electronic throttle control system
23	ECU-B NO.2	10	Air conditioning system, power windows, smart entry & start system, out side rear view mirrors, gauge and meters
24	TURN&HAZ	10	Gauge and meters, turn signal lights
25	AMP	15	Audio system
26	ECU-B NO.3	5	Electric power steering
27	IGCT-MAIN	30	IGCT NO.2, INV W/PMP, PCU, PM-IGCT
28	P/I	50	HORN, BATT FAN, IG2, EFI MAIN
29	ABS-MTR NO.2	40	Electronically controlled brake system
30	ABS-MTR NO.1	40	Electronically controlled brake system
31	H-LP-MAIN	30	H-LP RH-LO, H-LP LH-LO, H-LP-RH-HI, H-LP-LH-HI
32	ABS NO.1	30	Electronically controlled brake system
33	ABS NO.2	7.5 A	Electronically controlled brake system
34	D/C CUT	30	DOME, ECU-B NO.1, RADIO
35	EPS	80	Electric power steering
36	H-LP RH-HI	7,5	Right-hand headlight (high beam)
37	H-LP LH-HI	7,5	Left-hand headlight (high beam), gauge and meters
38	H-LP RH-LO	10 A^*1	Right-hand headlight (low beam)
38	H-LP RH-LO	15 A^*2	Right-hand headlight (low beam)
39	H-LP LH-LO	10 A^*1	Left-hand headlight (low beam), manual headlight leveling dial
39	H-LP LH-LO	15 A*2	Left-hand headlight (low beam)
40	PM-IGCT	10	Hybrid system
41	PCU	10	Hybrid system
42	INV W/PMP	10	Cooling system
43	IGTC NO.2	10	Hybrid system, P position control system
44	ECU-B NO.1	10	Main body ECU, smart entry & start system, clock, electronically controlled brake system, power door lock system, tire pressure warning system
45	RADIO	20	Audio system
46	DOME	7,5	Interior lights, vanity lights, luggage compartment light, main body ECU
47	MIR-HTR	10	Multiport fuel injection system/sequential multiport fuel injection system, outside rear view mirror defoggers
48	BATT FAN	10	Multiport fuel injection system/sequential multiport fuel injection system, cooling fan
49	IG2	15	Multiport fuel injection system/sequential multiport fuel injection system, gauge and meters, SRS airbag system
50	HORN	10	Horn
51	EFI-MAIN	25	Multiport fuel injection system/sequential multiport fuel injection system, EFI NO.1, EFI NO.2, fuel pump, EFI-B

*1 – Vehicles without discharge headlights (low beam)

*2 – Vehicles with discharge headlights (low beam)

Fuse box in passeneger compartment – type A (under the instrument panel)

Toyota Auris mk2 - fuse box - passenger compartment - type A - (hybrid model) — Toyota Auris mk2 – fuse box – passenger compartment – type A – (hybrid model)

Fuse		Ampere rating [A]	Circuit
1	P/OUTLET	15	Power outlet (luggage compartment)
2	OBD	7,5	On-board diagnosis system
3	STOP	7,5	Stop lights, high mounted stoplight, electronically controlled brake system, power management system
4	FOG RR	7,5	Rear fog light, gauge and meters
5	D/L NO.3	20	Power door lock system
6	S/ROOF	20	Panoramic roof shade
7	FOG FR	7,5	Front fog lights, gauge and meters
8	AM1	5	IG1 RLY, ACC RLY
9	D/L NO.2	10	Back door lock system, power door lock system
10	DOOR NO.2	20	Power windows
11	DOOR R/R	20	Power windows
12	DOOR R/R	20	Power windows
13	WASHER	15	Windshield washer
14	WIPER NO.2	25	Windshield wipers
15	WIPER RR	15	Rear window wiper
16	WIPER NO.1	25	Windshield wipers
17	CIG	15	Power outlet
18	ACC	7,5	Outside rear view mirrors, audio system, main body ECU, clock, power outlet
19	SFT LOCK-ACC	5	—
20	TAIL	10	Front position lights, tail lights, license plate lights, front fog lights, rear fog light
21	PANEL	7,5	Switch illumination, instrument cluster lights, glove box light, main body ECU
22	WIPER-S	5	—
23	ECU-IG NO.1	7,5	Electric cooling fan, AFS, electronically controlled brake system
24	ECU-IG NO.2	7,5	Back-up lights, multiport fuel injection system/sequential multiport fuel injection system, audio system, AFS, Toyota parking assist-sensor
25	ECU-IG NO.3	7,5	Inside rear view mirror, headlight cleaner, audio system, AFS, panoramic roof shade, windshield washer, tire pressure warning system
26	HTR-IG	7,5	Air conditioning system, rear window defogger, seat heaters
27	ECU-IG NO.4	7,5	Main body ECU, front passenger seat belt reminder light, airbag manual on-off system, outside rear view mirrors, Toyota parking assist-sensor
28	ECU-IG NO.5	5	Electric power steering
29	IGN	7,5	Smart entry & start system, stop lights, electronically controlled brake system, power management system
30	S/HTR	15	Seat heaters
31	METER	5	Gauge and meters
32	A/BAG	7,5	SRS airbag system

Fuse box in passeneger compartment – type B (under the instrument panel)

Toyota Auris mk1 - fuse box - passenger compartment type B (hybrid model) — Toyota Auris mk1 – fuse box – passenger compartment type B (hybrid model)

Fuse		Ampere rating [A]	Circuit
1	P/SEAT	30	Power seat
2	DOOR NO.1	30	Power windows

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Toyota Auris mk2 (from 2012) – fuse box diagram (diesel engine)

Posted on 13 October 201521 July 2018 by admin

Toyota Auris mk2 (from 2012) – fuse box diagram (diesiel engine)

Year of production: 2012, 2013, 2014, 2015, 2016

Fuse box in engine compartment

Toyota Auris mk2 - fuse box - engine compartment (diesel engine) — Toyota Auris mk2 – fuse box – engine compartment (diesel engine)

Fuse		Ampere rating [A]	Circuit
1	ALT	140	Charging system
2	EPS	80	Electric power steering
3	H-LP-MAIN	30	H-LP RH-LO, H-LP LH-LO, H-LP RH-HI, H-LP LH-HI
4	ST	30	Starting system
5	EFI-MAIN NO.2^*1	20	Multiport fuel injection system/sequential multiport fuel injection system
5	ECU-B NO.4^*2	10
6	IG2	15	Gauge and meters, multiport fuel injection system/sequential multiport fuel injection system, SRS airbag system
7	TURN&HAZ	10	Gauge and meters, turn signal lights
8	EDU^*1	20	Multiport fuel injection system/sequential multiport fuel injection system
9	ICS/ALT-S	5	Charging system
10	EFI-MAIN	30	Multiport fuel injection system/sequential multiport fuel injection system, EFI NO.1, EFI NO.2
11	HORN	10	Horn
12	D/C CUT	30	DOME, ECU-B No.1, RADIO
13	AM2	7,5	Multiport fuel injection system/sequential multiport fuel injection system, starting system, IG2, multi-mode manual transmission, Stop & Start system
14	ECU-B NO.3	5	Electric power steering
15	ECU-B NO.2	10	Air conditioning system, power windows, smart entry & start system, out side rear view mirrors, gauge and meters, multimode manual transmission
16	SPARE	30	Spare fuse
17	HTR	50	Air conditioning system
18	ABS NO.1	50	ABS, VSC
19	DEF	30	Rear window defogger, outside rear view mirror defoggers
20	RDI	40	Electric cooling fan
21	ABS NO.2	30	ABS, VSC
22	DRL	10	Daytime running lights
23	RADIO	20	Audio system
24	DOME	7,5	Interior lights, vanity lights, luggage compartment light, main body ECU
25	ECU-B NO.1	10	Wireless remote control, main body ECU, smart entry & start system, clock, VSC, power door lock system, tire pressure warning system
26	SPARE	20	Spare fuse
27	EFI NO.2^*2	10	Multiport fuel injection system/sequential multiport fuel injection system
28	EFI NO.1	10	Multiport fuel injection system/sequential multiport fuel injection system
29	MIR-HTR	10	Multiport fuel injection system/sequential multiport fuel injection system, outside rear view mirror defoggers
30	SPARE	10	Spare fuse
31	H-LP RH-LO	10 ^*3	Right-hand headlight (low beam)
31	H-LP RH-LO	15 ^*4	Right-hand headlight (low beam)
32	H-LP LH-LO	10 ^*3	Left-hand headlight (low beam), manual headlight leveling dial
32	H-LP LH-LO	15 ^*4	Left-hand headlight (low beam)
33	H-LP RH-HI	7,5	Right-hand headlight (high beam)
34	H-LP LH-HI	7,5	Left-hand headlight (high beam), gauge and meters
35	GLOW	80	Engine glow system
36	BBC ^*5	40	Stop & Start system
36	AMT ^*6	50	Multi-mode manual transmission
37	STRG LOCK	20	Steering lock system
38	AMP	15	Audio system
39	CDN FAN	30	Electric cooling fan(s)
40	H-LP CLN	30	Headlight cleaner
41	PTC HIR NO.1	50	Air conditioning system
42	PTC HIR NO.2	30	Air conditioning system
43	STV HTR	25	Power heater
44	S-HORN	10	—
45	PTC HIR NO.3	30	Air conditioning system

*1 – Vehicles with 1AD-FTV engine

*2 – Vehicles with 1ND-TV engine

*3 – Vehicles without discharge headlights (low beam)

*4 – Vehicles with discharge headlights (low beam)

*5 – Vehicles without multi-mode manual transmission

*6 – Vehicles with multi-mode manual transmission

Fuse box in passeneger compartment – type A (under the instrument panel)

Toyota Auris mk2 - fuse box - passenger compartment type A - gasoline engine — Toyota Auris mk2 – fuse box – passenger compartment type A – gasoline engine

Fuse		Ampere rating [A]	Circuit
1	P/OUTLET	15	Power outlet (luggage compartment)
2	OBD	7,5	On-board diagnosis system
3	STOP	7,5	Stop lights, multiport fuel injection system/sequential multiport fuel injection system, high mounted stoplight, ABS, VSC, shift lock control system, multimode manual transmission
4	FOG RR	7,5	Rear fog light, gauge and meters
5	D/L NO.3	20	Power door lock system
6	S/ROOF	20	Panoramic roof shade
7	FOG FR	7,5	Front fog lights, gauge and meters
8	AM1	5	IG1 RLY, ACC RLY
9	D/L NO.2	10	Back door lock system, power door lock system
10	DOOR NO.2	20	Power windows
11	DOOR R/R	20	Power windows
12	DOOR R/R	20	Power windows
13	WASHER	15	Windshield washer
14	WIPER NO.2	25	Windshield wipers
15	WIPER RR	15	Rear window wiper
16	WIPER NO.1	25	Windshield wipers
17	CIG	15	Power outlet
18	ACC	7,5	Outside rear view mirrors, audio system, main body ECU, clock, charging system, power outlet, Stop & Start system
19	SFT LOCK-ACC	5	Shift lock control system
20	TAIL	10	Front position lights, tail lights, license plate lights, front fog lights, rear fog light
21	PANEL	7,5	Switch illumination, instrument cluster lights, glove box light, main body ECU
22	WIPER-S	5	Charging system
23	ECU-IG NO.1	7,5	Electric cooling fan, AFS, charging system, ABS, VSC
24	ECU-IG NO.2	7,5	Back-up lights, multiport fuel injection system/sequential multiport fuel injection system, audio system, AFS, Toyota parking assist-sensor
25	ECU-IG NO.3	7,5	Multiport fuel injection system/sequential multiport fuel injection system, inside rear view mirror, shift lock control system, panoramic roof shade, headlight cleaner, audio system, AFS, windshield wipers, tire pressure warning system, cruise control system
26	HTR-IG	7,5	Air conditioning system, rear window defogger, power heater, Stop & Start system
27	ECU-IG NO.4	7,5	Front passenger seat belt reminder light, airbag manual on-off system, outside rear view mirrors, main body ECU, Toyota parking assist-sensor
28	ECU-IG NO.5	5	Electric power steering, Stop & Start system
29	IGN	7,5	Smart entry & start system, multiport fuel injection system/sequential multiport fuel injection system, steering lock system, multi-mode manual transmission
30	S/HTR	15	Seat heaters
31	METER	5	Gauge and meters, Stop & Stat system
32	A/BAG	7,5	SRS airbag system

Fuse box in passeneger compartment – type B (under the instrument panel)

Toyota Auris mk2 - fuse box - passenger compartment - type B - gasoline engine — Toyota Auris mk2 – fuse box – passenger compartment – type B – gasoline engine

Fuse		Ampere rating [A]	Circuit
1	P/SEAT	30	Power seat
2	DOOR NO.1	30	Power windows

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Toyota Auris (from 2012) – fuse box diagram (gasoline engine)

Posted on 12 October 201521 July 2018 by admin

Toyota Auris (from 2012)- fuse box diagram (gasoline engine)

Year of production: 2012, 2013, 2014, 2015, 2016

Fuse box in engine compartment

Toyota Auris mk2 - fuse box - engine compartment - gasoline engine — Toyota Auris mk2 – fuse box – engine compartment – gasoline engine

Fuse		Ampere rating [A]	Circuit
1	ALT	120	Charging system
2	RPS	80	Electric power steering
3	VLVMATIC*1	30	Multiport fuel injection system/sequential multiport fuel injection system
4	4 H-LP-MAIN	30	H-LP RH-LO, H-LP LH-LO, H-LP RH-HI, H-LP LH-HI
5	ST	30	Starting system
6	INJ/EFI-B*1	15	Multiport fuel injection system/sequential multiport fuel injection system
7	IG2	15	Gauge and meters, multiport fuel injection system/sequential multiport fuel injection system, SRS airbag system
8	TURN&HAZ	10	Gauge and meters, turn signal lights
9	ETCS	10	Electronic throttle control system
10	ICS/ALT-S	5	Charging system
11	EFI-MAIN	25 ^*1	Multiport fuel injection system/sequential multiport fuel injection system, EFI NO.1, EFI NO.2, fuel pump
11	EFI-MAIN	20 ^*2
12	HORN	10	Horn
13	D/C CUT	30	DOME, ECU-B No.1, RADIO
14	AM2	7,5	Multiport fuel injection system/sequential multiport fuel injection system, starting system, IG2, Stop & Start system
15	ECU-B NO.3	5	Electric power steering
16	ECU-B NO.2	10	Air conditioning system, power windows, smart entry & start system, outside rear view mirrors, gauge and meters
17	SPARE	30	Spare fuse
18	HTR	50	Air conditioning system
19	ABS NO.1	50	ABS, VSC
20	DEF	30	Rear window defogger, outside rear view mirror defoggers
21	RDI	40	Electric cooling fan
22	ABS NO.2	30	ABS, VSC
23	DRL	10	Daytime running lights
24	RADIO	20	Audio system
25	DOME	7,5	Interior lights, vanity lights, luggage compartment light, main body ECU
26	ECU-B NO.1	10	Wireless remote control, main body ECU, smart entry & start system, clock, VSC, power door lock system, tire pressure warning system
27	SPARE	20	Spare fuse
28	EFI NO.2	10	Multiport fuel injection system/sequential multiport fuel injection system
29	EFI NO.1	10	Multiport fuel injection system/sequential multiport fuel injection system, Stop & Start system
30	MIR-HTR	10	Multiport fuel injection system/sequential multiport fuel injection system, outside rear view mirror defoggers
31	SPARE	10	Spare fuse
32	H-LP RH-LO	10 ^*3	Right-hand headlight (low beam)
32	H-LP RH-LO	15 ^*4	Right-hand headlight (low beam)
33	H-LP LH-LO	10 ^*3	Left-hand headlight (low beam), manual headlight leveling dial
33	H-LP LH-LO	15 ^*4	Left-hand headlight (low beam)
34	H-LP RH-HI	7,5	Right-hand headlight (high beam)
35	H-LP LH-HI	7,5	Left-hand headlight (high beam), gauge and meters
36	BBC ^*2	40	Stop & Start system
37	STRG LOCK	20	Steering lock system
38	AMP	15	Audio system
39	H-LP CLN	30	Headlight cleaner
40	PTC HIR NO.1	10 ^*5	Air conditioning system
40	PTC HIR NO.1	50 ^*6	Air conditioning system
41	PTC HIR NO.2	30	Air conditioning system
42	S-HORN	10	S-HORN
43	PTC HIR NO.3	30	Air conditioning system

*1 – Vehicles with 1ZR-FAE engine

*2 – Vehicles with 1NR-FE engine

*3 – Vehicles without discharge headlights (low beam)

*4 – Vehicles with discharge headlights (low beam)

*5 – Vehicles without PTC 600W heater

*6 – Vehicles with PTC 600W heater

Fuse box in passeneger compartment – type A (under the instrument panel)

Fuse		Ampere rating [A]	Circuit
1	P/OUTLET	15	Power outlet (luggage compartment)
2	OBD	7,5	On-board diagnosis system
3	STOP	7,5	Stop lights, multiport fuel injection system/sequential multiport fuel injection system, high mounted stoplight, ABS, VSC, shift lock control system
4	FOG RR	7,5	Rear fog light, gauge and meters
5	D/L NO.3	20	Power door lock system
6	S/ROOF	20	Panoramic roof shade
7	FOG FR	7,5	Front fog lights, gauge and meters
8	AM1	5	IG1 RLY, ACC RLY
9	D/L NO.2	10	Back door lock system, power door lock system
10	DOOR NO.2	20	Power windows
11	DOOR R/R	20	Power windows
12	DOOR R/R	20	Power windows
13	WASHER	15	Windshield washer
14	WIPER NO.2	25	Windshield wipers
15	WIPER RR	15	Rear window wiper
16	WIPER NO.1	25	Windshield wipers
17	CIG	15	Power outlet
18	ACC	7,5	Outside rear view mirrors, audio system, main body ECU, clock, charging system, power outlet, Stop & Start system, audio system
19	SFT LOCK-ACC	5	Shift lock control system
20	TAIL	10	Front position lights, tail lights, license plate lights, front fog lights, rear fog light
21	PANEL	7,5	Switch illumination, instrument cluster lights, glove box light, main body ECU
22	WIPER-S	5	Charging system
23	ECU-IG NO.1	7,5	Electric cooling fan, AFS, charging system, ABS, VSC
24	ECU-IG NO.2	7,5	Back-up lights, multiport fuel injection system/sequential multiport fuel injection system, audio system, AFS, Toyota parking assist-sensor
25	ECU-IG NO.3	7,5	Multiport fuel injection system/sequential multiport fuel injection system, inside rear view mirror, shift lock control system, headlight cleaner, audio system, AFS, panoramic roof shade, windshield washer, tire pressure warning system
26	HTR-IG	7,5	Air conditioning system, rear window defogger, Stop & Start system
27	ECU-IG NO.4	7,5	Main body ECU, front passenger seat belt reminder light, airbag manual on-off system, outside rear view mirrors, Toyota parking assist-sensor
28	ECU-IG NO.5	5	Electric power steering, Stop & Start system
29	IGN	7,5	Smart entry & start system, multiport fuel injection system/sequential multiport fuel injection system, steering lock system
30	S/HTR	15	Seat heaters
31	METER	5	Gauge and meters, Stop & Stat system
32	A/BAG	7,5	SRS airbag system

Fuse box in passeneger compartment – type B (under the instrument panel)

Fuse		Ampere rating [A]	Circuit
1	P/SEAT	30	Power seat
2	DOOR NO.1	30	Power windows

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Toyota Auris (2006 – 2012) – fuse box diagram

Posted on 11 October 201521 July 2018 by admin

Toyota Auris (2006 – 2012) – fuse box diagram

Year of production: 2006, 2007, 2008, 2009, 2010, 2011, 2012

Fuse box in engine compartment

Toyota Auris mk1 - fuse box - engine compartment — Toyota Auris mk1 – fuse box – engine compartment

Fuse		Ampere ratin [A]	Circuit
1	H-LP CLN	30	Headlight cleaner
2	RDI FAN	40	Electric cooling fan(s)
3	CDS FAN*7	30	Electric cooling fan(s)
4	ABS NO. 1	50	Anti-lock brake system, vehicle stability control system
5	HTR	50	Air conditioning system
6	ALT	120^1 140^2	Charging system, RDI FAN, CDS FAN7, H-LP CLN, ABS NO. 1, ABS NO. 31, ABS NO. 22, HTR, HTR SUB NO. 1, HTR SUB NO. 2, HTR SUB NO. 3, STV HTR2, ACC, CIG, ECU-IG NO. 2, HTR-IG, WIPER, RR WIPER, WASHER, ECU-IG NO. 1, SEAT HTR, AM1, DOOR, STOP, FR DOOR, POWER, RR DOOR, RL DOOR, OBD, ACC-B, RR FOG, FR FOG, SUNROOF, DEF, MIR HTR, TAIL, PANEL
7	EPS	60	Electric power steering
8	GLOW^*2	80	Engine glow system
9	P-SYSTEM^*1	30	Multiport fuel injection system/ sequential multiport fuel injection system
10	P/I	50	EFI MAIN, HORN, IG2, EDU
11	H-LP MAIN	50	H-LP LH-LO, H-LP RH LO, H-LP LH-HI, H-LP, RH-HI
12	AMT^*1,6	50	Multi-mode manual transmission
12	BBC^*5	40	Stop & Start system
13	SPARE	10	Spare fuse
14	SPARE	30	Spare fuse
15	SPARE	20	Spare fuse
16	ECU-B3	7,5	Multiport fuel injection system/ sequential multiport fuel injection system
17	ECU-B2	10	Multi-mode manual transmission, air conditioning system, smart entry & start system, charging system, power windows
18	ECU-B	10	Main body ECU, power windows, gauge and meters, power door lock system, vehicle stability control system, Stop & Start system, charging system
19	RAD NO. 1	15	Audio system, “touch screen”
20	DOME	10	Interior lights, luggage compartment light, vanity lights, smart entry & start system, wireless remote control, engine switch light
21	AM2 NO. 2	7,5	Main body ECU, Stop & Start system
22	ALT-S	7,5	Charging system
23	TURN-HAZ	10	Turn signal lights
24	ETCS^*1	10	Electronic throttle control system
25	AM2	30	Starting system, smart entry & start system, IG2 NO. 2
26	A/F^*7	20	Exhaust system
27	STRG LOCK	20	Steering lock system
28	IGN/INJ^*1	15	Multiport fuel injection system/ sequential multiport fuel injection system, starting system
29	EDU*7	20	Multiport fuel injection system/ sequential multiport fuel injection system
30	EFI MAIN	20*1	Multiport fuel injection system/ sequential multiport fuel injection system, Stop & Start system, EFI NO. 1, EFI NO. 2
30	EFI MAIN	30^*2
31	HORN	10	Horn
32	IG2	15	Multiport fuel injection system/ sequential multiport fuel injection system, starting system, smart entry & start system, IGN, METER
33	HTR SUB NO. 1	30^*8	Air conditioning system
33	HTR SUB NO. 1	50^*9	Air conditioning system
34	HTR SUB NO. 2	30	Air conditioning system
35	HTR SUB NO. 3	30	Air conditioning system
36	STV HTR^*2	25	Anti-lock brake system, vehicle stability control system
37	WIP-S^*6	7,5	Power heater
38	IG2 NO. 2	7,5	Charging system
39	EFI NO. 2	10	Starting system, smart entry & start system
40	EFI NO. 2	10	Multiport fuel injection system/ sequential multiport fuel injection system
41	EFI NO. 1	10	Multiport fuel injection system/ sequential multiport fuel injection system
42	H-LP RH HI	10	Right-hand headlight (high beam)
43	H-LP LH HI	10	Left-hand headlight (high beam)
44	H-LP RH LO	10^*3	Right-hand headlight (low beam)
44	H-LP RH LO	15^*4	Right-hand headlight (low beam)
44	H-LP LH LO	10^*3	Left-hand headlight (low beam)
44	H-LP LH LO	15^*4	Left-hand headlight (low beam)

^*1 – Vehicles with a gasoline engine

^*2 – Vehicles with a diesel engine

^*3 – Vehicles without discharge headlights (low beam)

^*4 – Vehicles with discharge headlights (low beam)

^*5 – Vehicles with 1NR-FE engine (with a Stop & Start system)

^*6 – Vehicles with 1ND-TV engine

^*7 – Vehicles with 1AD-FTV or 2AD-FHV engine

^*8 – Vehicles without PTC 600W heater

^*9 – Vehicles with PTC 600W heater

Fuse box in passeneger compartment (type A)

Toyota Auris mk1 - fuse box - passenger compartment type A — Toyota Auris mk1 – fuse box – passenger compartment type A

Fuse		Ampere rating [A]	Circuit
1	TAIL	10	Front position lights, tail lights, license plate lights, rear fog light, front fog lights, manual headlight leveling dial, multiport fuel injection system/sequential multiport fuel injection system, instrument cluster lights
2	PANEL	7,5	Switch illumination, instrument cluster lights, glove box light, steering switches, main body ECU
3	ECU-IG NO. 1^*1	10	Automatic headlight leveling system, main body ECU, electric power steering, electric cooling fan(s), shift lock control system, rain sensor, anti-lock brake system, vehicle stability control system, audio system, “touch screen”, multiport fuel injection system/sequential multiport fuel injection system, headlight cleaner, smart entry & start system, Stop & Start system
4	FR DOOR	20	Power windows
5	RL DOOR	20	Power windows
6	RR DOOR	20	Power windows
7	SUNROOF	20	Electric moon roof
8	CIG	15	Cigarette lighter, power outlet
9	ACC	7,5	Outside rear view mirrors, audio system, “touch screen”, shift lock control system, main body ECU, smart entry & start system, Stop & Start system
10	MIR HTR	10	Outside rear view mirror defoggers, multiport fuel injection system/ sequential multiport fuel injection system
11	RR FOG	7,5	Rear fog light
12	ING	7,5	Steering lock system, SRS airbag system, multi-mode manual transmission, multiport fuel injection system/sequential multiport fuel injection system, smart entry & start system, Stop & Start system
13	METER	7,5	Gauge and meters, Stop & Start system
14	SEAT HTR	15	Seat heaters
15	HTR-IG	10	Air conditioning system, rear window defogger, power heater
16	WIPER	25	Windshield wipers, rain sensor
17	RR WIPER	15	Rear window wiper
18	WASHER	15	Windshield washer
19	ECU-IG NO. 1^*2	10	Automatic headlight leveling system, main body ECU, electric power steering, electric cooling fan(s), shift lock control system, rain sensor, anti-lock brake system, vehicle stability control system, audio system, “touch screen”, multiport fuel injection system/sequential multiport fuel injection system, headlight cleaner, smart entry & start system
20	ECU-IG NO. 2	10	Back-up lights, charging system, auto anti-glare inside rear view mirror, rear view monitor system, electric moon roof, rear window defogger, air conditioning system, turn signal lights, emergency flashers, front passenger’s seat belt reminder light, Stop & Start system, Toyota parking assist-sensor
21	OBD	7,5	On-board diagnosis system
22	STOP	10	Stop lights, high mounted stoplight, anti-lock brake system, vehicle stability control system, main body ECU, multiport fuel injection system/sequential multiport fuel injection system, multi-mode manual transmission
23	DOOR	25	Power door lock system
24	ACC-B	25	CIG, ACC
26	FR FOG	15	Front fog lights
27	AM1	7,5	Starting system, multiport fuel injection system/sequential multiport fuel injection system, ACC, CIG

^*1 – Vehicles with a Stop & Start system

^*2 – Vehicles without a Stop & Start system

^*3 – Vehicles without a smart entry & start system

Fuse box in passeneger compartment (under instrument panel) type B

Toyota Auris mk1 - fuse box - passenger compartment type B — Toyota Auris mk1 – fuse box – passenger compartment type B

Fuse		Ampere rating [A]	Circuit
1	POWER	30	Power windows
2	DEF	30	Rear window defogger, MIR HTR

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Volkswagen Golf and GTI (1989) – fuse box (Mexican production)

Posted on 8 October 201521 July 2018 by admin

VW Golf and GTI (1989) – fuse box (Mexican production)

Volkswagen Golf and GTI - fuse box (mexican production ) — Volkswagen Golf and GTI – fuse box (mexican production )

Fuses

Fuse	Description	Ampere rating
1	Radiator fan	30
2	Brake lights	10
3	Cigarette lighter, radio, clock, interior lights, central locking	10
4	Emergency flashers	15
5	Fuel pump	15
6	Open	—
7	Taillights, side marker lights, left	10
8	Taillights, side marker lights, right	10
9	High beam, right, high beam indicator	10
10	High beam, left	10
11	Windshield wiper/washer	15
12	Heated seats, electric mirrors	15
13	Rear window defogger, heated rear view mirrors, rear wiper	15
14	Fresh air blower, glove box light	20
15	Backup lights, shift console light	10
16	Horn	15
17	Knock sensor control unit	10
18	Horn relay, coolant level and temperature warning light	10
19	Turn signals, brake warning light	10
20	License plate lights	10
21	Low beam, left	10
22	Low beam, right	10

Relays

Relays	Description
1	Open
2	Fuel pump or glow plug
3	Seat belt warning system
4	Open
5	A/C
6	Dual horn
7	Open
8	Load reduction
9	Open
10	Intermittent wipers
11	Rear wiper/washer
12	Emergency flasher
13	Power window
14	Open
15	Open
16	Idle stabilizer
17	A/C thermofuse
18	Coolant level indicator
19	Power window
20	Heated seat
21	Heated seat
22	Open
23	Power window fuse
24	Open

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Volkswagen 1986-1988 Golf and GTI models, and 1989 Golf and GTI models produced in the U.S – fuse box

Posted on 7 October 201521 July 2018 by admin

VW 1986-1988 Golf and GTI models, and 1989 Golf and GTI models produced in the U.S – fuse box

Relays panel

Volkswagen 1986-1988 Golf and GTI models, and 1989 Golf and GTI models produced in the U.S - relay box — Volkswagen 1986-1988 Golf and GTI models, and 1989 Golf and GTI models produced in the U.S – relay box

Relays	Golf, Golf GL	Golf diesel	Golf GT, GTI
1	Intermittent wiper	Intermittent wiper	Intermittent wiper
2	Upshift indicator (1986-1987)	Upshift indicator (1986-1987)	Upshift indicator (1986-1987)
2	Open (1988, 1989)	Open (1988, 1989)	Open (1988, 1989)
3	Low speed radiator cooling fan (with A/C)	Low speed radiator cooling fan (with A/C)	Low speed radiator cooling fan (with A/C)
4	Horns	Low coolant level	Horns, or Open
5	Rear wiper	Rear wiper	Rear wiper
6	Fuel pump	Glow plugs	Fuel pump
7	Turn signals, flashers	Turn signals, flashers	Turn signals, flashers
8	Load reduction	Load reduction	Load reduction
9	Idle speed control (1986, 1987)	Horns	Horns (except 1988, 1989 Golf GT)
9	Power supply (1988, 1989)	Horns	Power supply (1988, 1989 Golf GT)
10	A/C high blower (1986)	A/C high blower (1986, 1987)	A/C high blower (1986-1987 except 16-valve)
	Fuel injection (1987)	A/C cutout (1988, 1989)
	Passive restraint (1988, 1989)	A/C cutout (1988, 1989)
11	Seat belt interlock	Seat belt interlock	Seat belt interlock
12	Bridge	Bridge	Open (1986-1987)
12	Bridge	Bridge	Open (1986-1987)
13	Radiator cooling fan after-run	Open	Radiator cooling fan after-run
14	Oxygen sensor relay (1987)	A/C cutout (1986, 1987)	Low coolant indicator (1988, 1989 Golf GT)
	Low coolant relay (1987)	Passive restraint (1988, 1989)	Open (except 1988, 1989 Golf GT)
	Open (1988, 1989)	Passive restraint (1988, 1989)	Open (except 1988, 1989 Golf GT)

Fuse panel

Volkswagen 1986-1988 Golf and GTI models, and 1989 Golf and GTI models produced in the U.S - fuse box — Volkswagen 1986-1988 Golf and GTI models, and 1989 Golf and GTI models produced in the U.S – fuse box

Fuse	Description	Ampere rating [A]
1	Dome light, luggage light, glove box light, clock, Multi-function indicator memory	15
2	Taillights, parking lights, sidemarker lights, license plate lights	15
3	Rear window wiper	10
4	Rear window defogger	20
5	Windshield wiper/washer	15
6	Instrument panel lights	5
7	Headlights, low beam	10
8	Headlights, high beam	15
9	Brake lights, hazard warning lights	20
10	Fuel pump (gasoline engines)	20
10	Open (diesel engines)	—
11	Horn, glove box light	15
12	Heater (without A/C)	20
12	Heater (with A/C)	30
13	Back-up lights, turn signal lamps, emergency flasher switch	10
14	Relays: (interlock, upshift, OXS, low coolant, glow plug, radiator after-run)	10
15	Radiator cooling fan after-run (1988, 1989 except GTI)	30
15	Open (1986-1987)
16	Open	—
17	Cigar lighter, A/C clutch, radiator cooling fan (low speed), central locking, diesel vacuum pump	25
18	ACC connector or radio	—
18	Radiator cooling fan after-run (1987 except 16-valve)	30
19	Open	—
20	ACC connector, cruise control	5
21	Senders, gauges, warning lamps	5
22	Throttle switches and idle stabilizer valve (GTI)	10
22	OXS relay (1986-1987 CIS and 1988, 1989 except GTI)	15

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Volkswagen Golf and GTI models (1985) – fuse box (EU version)

Posted on 7 October 201521 July 2018 by admin

VW Golf and GTI models (1985) – fuse box (EU version)

1985 Golf and GTI models relay panel

Volkswagen Golf and GTI - (1985) - relay box — Volkswagen Golf and GTI models- (1985) – relay box

Relay	Golf	GTI	Golf diesel
1	Intermittent wiper	Intermittent wiper	Intermittent wiper
2	Upshift indicator	Upshift indicator	Upshift indicator
3	Horns	Low speed radiator cooling fan (with A/C)	Open
4	Low speed radiator cooling fan (with A/C)	Open	Low coolant level
5	Open	Open	A/C cutout
6	Fuel pump	Fuel pump	Glow plugs
7	Turn signals, emergency flashers	Turn signals, emergency flashers	Turn signals, emergency flashers
8	Load reduction	Load reduction	Load reduction
9	Idle speed control	Horns	Horns
10	A/C high blower	A/C high blower	Low speed radiator cooling (A/C only)
11	Seat belt interlock	Seat belt warning	Seat belt warning
12	See #11	Open	Open
13	Rear wiper	Rear wiper	Rear wiper
14	—	—	Glow plug fuse

1985 Golf and GTI models fuse panel

Volkswagen Golf and GTI - (1985) - fuse box — Volkswagen Golf and GTI models – (1985) – fuse box

Fuse	Description	Ampere rating [A]
1	Dome light, luggage light, glove box light,clock, Multi-function indicator memory	15
2	Taillights, parking lights, sidemarker lights,license plate lights	15
3	Rear window wiper	10
4	Rear window defogger, horn	20
5	Windshield wiper/washer	15
6	Instrument panel lights	5
7	Headlights, low beam	10
8	Headlights, high beam	15
9	Brake lights, hazard warning lights	20
10	Fuel pump (gasoline engines)	20
10	Open (diesel engines)	—
11	Open	—
12	Heater	20
13	Back-up lights, turn signal lamps, emergency flasher switch	10
14	Relays: (interlock, upshift, OXS,low coolant, glow plug, radiator after-run)	10
15	Open	—
16	Open	—
17	Cigar lighter, A/C clutch, radiator cooling fan (low speed), central locking, diesel vacuum pump	25
18	ACC connector	—
19	Open	—
20	ACC connector, cruise control	5
21	Senders, gauges, warning lamps	5
22	Fuel injection (gasoline engines)	15
22	Open (diesel engines)	—

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
