Ford F-Series F-750 F750 (2015) – fuse box diagram

Posted on 25 August 201520 July 2018 by admin

Ford F-Series F-750 F750 (2015) – fuse box diagram

Power distribution box

Fuse or relay	Ampere rating [A]	Protected circuits
1	20	Upfitter switches (AUX 2 and AUX 4)/Trailer 12V socket pin
2	30	Power seat (driver)
3	30	Power seat (passenger)
4	15	Windshield washer relay, Washer pump motor
5	5	Brake warning switch (hydraulic brake vehicles only)
6	20	Upfitter switches (AUX 1 and AUX 3)
7	15	Brake pressure switches, ABS event relay
8	20	DEF (Urea) line heaters (diesel engine only)
9	20	Ignition switch, Starter cutoff
10	15	Air tank moisture removal valve
11	30	Electric trailer brake
12	20	Passenger compartment fuse box 5 and 21
13	15	Instrument cluster/Gateway module
14	20	Nitrogen oxide sensor (diesel engine only)
15	—	Not used
16	5	Bendix® Air ABS
17	—	Not used
18	10	Fuel transfer pump
19	15	Powertrain control module power 1 (gasoline engine only)
20	10	Powertrain control module power 2 (gasoline engine only)
21	20	Powertrain control module power 3 (gasoline engine only)
24	—	Not used
101	30	Bendix Air ABS relay (Air brake vehicles only)
101	30	Hydraulic brakes module (hydraulic brake vehicles only)
102	20	Ignition switch
103	20	Ignition switch, Passenger compartment fuse box fuses 19, 29 and 30
104	20	Power point
105	20	Power door lock switches
106	30	Main light switch, Multi-function switch
107	50	Passenger compartment fuse box fuses 1, 2, 3, 4, 12, 13, 14 and 15
108	40	Fuel heater (diesel engine only)
108	20	Fuel pump module (gasoline engine only)
109	40	Power window
110	30	Windshield wiper
111	30	Body builder relay, Parking lamps
112	40	Blower motor
113	30	Heated seats, Air-Ride seat
114	—	Not used
115	20	Ignition switch, Passenger compartment fuse box fuses 8, 9, 10 and 11
116	30	Left/Right turn relays, Back up lamp relay
117	20	Stop lamps
118	60	Hydraulic brake vehicles (trailer tow package only)
601	60	Trailer socket
602	60	Air brake trailer tow fuse block
201	—	Windshield washer relay
202	—	Wiper high/low relay
203	—	Wiper run/park relay
204	—	Windshield wiper relay
205	—	Body builder relay, right turn
206	—	Body builder relay, left turn
207	—	ABS event relay (hydraulic brake vehicles only)
208	—	Body builder relay, back up lamps relay
209	—	Auxiliary stop lamp relay
301	—	Fuel heater/Fuel transfer pump relay (diesel engine only)
301	—	Fuel pump module (gasoline engine only)
302	—	Body builder relay, parking lamps relay
303	—	Blower motor relay
304	—	DEF (Urea) line heaters relay (diesel engine only)
304	—	Powertrain control module power VPWR1 (gasoline engine only)

Individual maxi fuse holder in engine compartment
Fuse or relay	Ampere rating [A]	Protected circuits
9925	30	Hydraulic brakes pump motor 1

Passenger compartment fuse panel

Ford F-series F-650/F750 (2015) - fuse box - passenger compartment — Ford F-series F-650/F750 (2015) – fuse box – passenger compartment

The fuse box is located behind the passenger airbag cover. You can access it through the glove box

Fuse or relay	Ampere rating [A]	Protected circuits
1	20	Horn
2	15	Flasher relay
3	20	Power point
4	10	Data Link Connector (DLC), Engine diagnostic connector, Parking brake warning
5	15	Run relay
6	—	Not used
7	—	Not used
8	5	Radio, GEM
9	5	Power window relay
10	15	Heated mirrors
11	5	Wiper and washer systems
12	10	Transmission shift selector
13	20	Radio/SYNC®, Power mirrors
14	10	Interior lamp relay
15	10	Interior lamp relay
16	15	High beams, Indicator
17	—	Not used
18	5	Dimmer switch, Interior lighting
19	15	Engine control (diesel engine only)
20	5	Starting system
21	10	DRL resistor
22	15	Air horn, Air suspension dump, Two-speed axle, Driver-controlled locking differential
23	10	Flasher relay
24	15	Hydraulic brakes relay, Fuel heater relay (diesel engine only), Air dryer
25	10	Blower motor relay coil
26	10	Right-hand low beam headlight
27	—	Not used
28	10	Left-hand low beam headlight
29	10	Cluster, GEM
30	15	Allison electronic transmission
31	15	Mirror fold relay
Relay 1	—	Interior lamps
Relay 2	—	Not used
Relay 3	—	Horn
Relay 4	—	Not used
Relay 5	—	Not used

Relay center

The relay center is located along the passenger side A-pillar on the right side of the footwell.

Relay	Relay description
R1	Spring applied hydraulic release warning chime module or PCM power VPWR 2, 3 and 4
R2	A/C compressor clutch
R3	Power windows
R4	Flasher (standard/LED)
R5	Upfitter relay 1
R6	Upfitter relay 2
R7	Headlights
R8	Cummins starter lockout
R9	Upfitter relay 3
R10	Starter
R11	DCU (diesel engine only)
R12	Two–speed axle/Differential lock
R13	Door lock
R14	Air tank moisture valve
R15	DRL #1
R16	Heated mirrors
R17	Spare
R18	Upfitter relay 4
R19	Shift interlock/EPRNDL display
R20	Selective Catalyst Reduction (SCR) system (NOx) (diesel engine only)
R21	Run
R22	Door unlock
R23	ABS warning indicator
R24	DRL #2
R25	Park lights
R26	Spare

Trailer tow relays (if equipped)

Ford F-series F-650/F750 (2015) - trailer tow relays — Ford F-series F-650/F750 (2015) – trailer tow relays

Fuse or relay	Ampere rating [A]	Protected circuits
1	30*	Trailer tow ABS feed (non electric trailer brake vehicles only)
2	30*	Trailer tow park/marker lamps
3	30*	Trailer tow stop lamps
4	30*	Trailer tow turn/stop lamps (combined)
4	30*	Trailer tow turn lamps (separate)
5	—	Not used
R1	—	Trailer tow ABS relay (non electric trailer brake vehicles only)
R2	—	Trailer tow marker lamp relay
R3	—	Trailer tow stop lamp relay
R4	—	Trailer tow tail lamp relay
R5	—	Not used
R6	—	Not used
R7	—	Trailer tow left turn lamp relay
R8	—	Trailer tow right turn lamp relay
*Maxi fuse

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Ford F-Series F-650 F650 (2015) – fuse box diagram

Posted on 25 August 201520 July 2018 by admin

Ford F-Series F-650 F650 (2015) – fuse box diagram

Power distribution box

Fuse or relay	Ampere rating [A]	Protected circuits
1	20	Upfitter switches (AUX 2 and AUX 4)/Trailer 12V socket pin
2	30	Power seat (driver)
3	30	Power seat (passenger)
4	15	Windshield washer relay, Washer pump motor
5	5	Brake warning switch (hydraulic brake vehicles only)
6	20	Upfitter switches (AUX 1 and AUX 3)
7	15	Brake pressure switches, ABS event relay
8	20	DEF (Urea) line heaters (diesel engine only)
9	20	Ignition switch, Starter cutoff
10	15	Air tank moisture removal valve
11	30	Electric trailer brake
12	20	Passenger compartment fuse box 5 and 21
13	15	Instrument cluster/Gateway module
14	20	Nitrogen oxide sensor (diesel engine only)
15	—	Not used
16	5	Bendix® Air ABS
17	—	Not used
18	10	Fuel transfer pump
19	15	Powertrain control module power 1 (gasoline engine only)
20	10	Powertrain control module power 2 (gasoline engine only)
21	20	Powertrain control module power 3 (gasoline engine only)
24	—	Not used
101	30	Bendix Air ABS relay (Air brake vehicles only)
101	30	Hydraulic brakes module (hydraulic brake vehicles only)
102	20	Ignition switch
103	20	Ignition switch, Passenger compartment fuse box fuses 19, 29 and 30
104	20	Power point
105	20	Power door lock switches
106	30	Main light switch, Multi-function switch
107	50	Passenger compartment fuse box fuses 1, 2, 3, 4, 12, 13, 14 and 15
108	40	Fuel heater (diesel engine only)
108	20	Fuel pump module (gasoline engine only)
109	40	Power window
110	30	Windshield wiper
111	30	Body builder relay, Parking lamps
112	40	Blower motor
113	30	Heated seats, Air-Ride seat
114	—	Not used
115	20	Ignition switch, Passenger compartment fuse box fuses 8, 9, 10 and 11
116	30	Left/Right turn relays, Back up lamp relay
117	20	Stop lamps
118	60	Hydraulic brake vehicles (trailer tow package only)
601	60	Trailer socket
602	60	Air brake trailer tow fuse block
201	—	Windshield washer relay
202	—	Wiper high/low relay
203	—	Wiper run/park relay
204	—	Windshield wiper relay
205	—	Body builder relay, right turn
206	—	Body builder relay, left turn
207	—	ABS event relay (hydraulic brake vehicles only)
208	—	Body builder relay, back up lamps relay
209	—	Auxiliary stop lamp relay
301	—	Fuel heater/Fuel transfer pump relay (diesel engine only)
301	—	Fuel pump module (gasoline engine only)
302	—	Body builder relay, parking lamps relay
303	—	Blower motor relay
304	—	DEF (Urea) line heaters relay (diesel engine only)
304	—	Powertrain control module power VPWR1 (gasoline engine only)

Individual maxi fuse holder in engine compartment
Fuse or relay	Ampere rating [A]	Protected circuits
9925	30	Hydraulic brakes pump motor 1

Passenger compartment fuse panel

The fuse box is located behind the passenger airbag cover. You can access it through the glove box

Fuse or relay	Ampere rating [A]	Protected circuits
1	20	Horn
2	15	Flasher relay
3	20	Power point
4	10	Data Link Connector (DLC), Engine diagnostic connector, Parking brake warning
5	15	Run relay
6	—	Not used
7	—	Not used
8	5	Radio, GEM
9	5	Power window relay
10	15	Heated mirrors
11	5	Wiper and washer systems
12	10	Transmission shift selector
13	20	Radio/SYNC®, Power mirrors
14	10	Interior lamp relay
15	10	Interior lamp relay
16	15	High beams, Indicator
17	—	Not used
18	5	Dimmer switch, Interior lighting
19	15	Engine control (diesel engine only)
20	5	Starting system
21	10	DRL resistor
22	15	Air horn, Air suspension dump, Two-speed axle, Driver-controlled locking differential
23	10	Flasher relay
24	15	Hydraulic brakes relay, Fuel heater relay (diesel engine only), Air dryer
25	10	Blower motor relay coil
26	10	Right-hand low beam headlight
27	—	Not used
28	10	Left-hand low beam headlight
29	10	Cluster, GEM
30	15	Allison electronic transmission
31	15	Mirror fold relay
Relay 1	—	Interior lamps
Relay 2	—	Not used
Relay 3	—	Horn
Relay 4	—	Not used
Relay 5	—	Not used

Relay center

The relay center is located along the passenger side A-pillar on the right side of the footwell.

Relay	Relay description
R1	Spring applied hydraulic release warning chime module or PCM power VPWR 2, 3 and 4
R2	A/C compressor clutch
R3	Power windows
R4	Flasher (standard/LED)
R5	Upfitter relay 1
R6	Upfitter relay 2
R7	Headlights
R8	Cummins starter lockout
R9	Upfitter relay 3
R10	Starter
R11	DCU (diesel engine only)
R12	Two–speed axle/Differential lock
R13	Door lock
R14	Air tank moisture valve
R15	DRL #1
R16	Heated mirrors
R17	Spare
R18	Upfitter relay 4
R19	Shift interlock/EPRNDL display
R20	Selective Catalyst Reduction (SCR) system (NOx) (diesel engine only)
R21	Run
R22	Door unlock
R23	ABS warning indicator
R24	DRL #2
R25	Park lights
R26	Spare

Trailer tow relays (if equipped)

Fuse or relay	Ampere rating [A]	Protected circuits
1	30*	Trailer tow ABS feed (non electric trailer brake vehicles only)
2	30*	Trailer tow park/marker lamps
3	30*	Trailer tow stop lamps
4	30*	Trailer tow turn/stop lamps (combined)
4	30*	Trailer tow turn lamps (separate)
5	—	Not used
R1	—	Trailer tow ABS relay (non electric trailer brake vehicles only)
R2	—	Trailer tow marker lamp relay
R3	—	Trailer tow stop lamp relay
R4	—	Trailer tow tail lamp relay
R5	—	Not used
R6	—	Not used
R7	—	Trailer tow left turn lamp relay
R8	—	Trailer tow right turn lamp relay
*Maxi fuse

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Ford F-53 F53 Commercial Stripped Chassis (2015) – fuse box diagram

Posted on 25 August 201520 July 2018 by admin

Ford F-53 Commercial Stripped Chassis (2015) – fuse box diagram

Power distribution box

Locate the power distribution box in the engine compartment. It has high-current fuses that protect your vehicle’s main electrical systems from overloads.

Fuse or relay	Ampere rating [A]	Protected components
1	5*	Power brake assist module – Hydromax
2	10*	Air conditioning compressor clutch
3	20*	Air conditioning clutch relay coil. Catalyst monitor sensor. Engine heated exhaust gas oxygen sensor #11 and #21. Mass air flow sensor with intake air temperature. Vapor management valve
4	5*	Powertrain control module memory. Powertrain control module relay coil
5	20*	Powertrain control module power
6	20*	Instrument panel dimmer module. Instrument panel fuse #41. Park lamp feeds. Trailer tow running lamp relay coil
7	20*	Ignition coils. Radio capacitors
8	30*	Hydromax – Anti-lock brake system module
9	10*	Powertrain control module. Starter ground relay coil. Starter main relay coil
10	20*	Daytime running lamps
11	20*	Fuel pump relay coil. Powertrain control module power
12	25*	Instrument panel – backup lamp feed. Trailer tow back-up lamps feed
13	30**	Trailer tow electric brake controller feed
14	60**	Instrument panel battery feed (fuse #9, 15, 21). Lighting primary fuse
15	20**	Trailer tow park lamps
16	60**	Anti-lock brake system module – Hydromax
16	40**	Anti-lock brake system module – Hydroboost
17	20**	Horn feed
18	20**	Backup lamp feed. Tow/haul switch. Transmission control indicator light
19	—	Not used
20	30**	Powertrain control module relay coil. Powertrain control module relay (Power distribution box fuses # 3, 5, 7, 18)
21	20**	Fuel injectors. Fuel pump motor
22	20**	Cigar lighter feed. Diagnostic tool connector
23	40**	Blower motor feed
24	50**	Instrument panel battery feed (fuses #4, 10, 16, 22)
25	40**	Ignition switch feed (Instrument panel fuses #1, 5, 7, 11, 13, 14, 17, 19, 23; Power distribution box fuses #9, 11)
26	40**	Ignition switch feed (Instrument panel fuses #5, 11, 17, 23, 26, 38)
27	30**	Multi-function switch (headlamps)
28	30**	Starter solenoid
29	60**	Power brake assist motor – Hydromax
	40**	Anti-lock brake system module – Hydroboost
R1	—	Air conditioning clutch relay
R2	—	Fuel pump relay
R3	—	Horn relay
R4	—	Starter relay
R5	—	Blower motor relay
R6	—	Powertrain control module relay
Diode 1	—	Fuel pump diode
Diode 2	—	Air conditioning clutch diode
Mini fuses. *Maxi fuses.

UPS Power distribution box 1

Fuse or relay	Ampere rating [A]	Protected components
R1	Relay	Powertrain control module
R2	Relay	Daytime running lamps
R3	Relay	Starter motor
R4	Relay	Blower motor
R5	Relay	Horn
R6	Relay	Fuel pump
R7	Relay	Starter ground
R8	Relay	Trailer tow parking lamps
R9	Relay	Back-up lamps
R10	Relay	Not used
R11	Relay	Not used
R12	Relay	Air conditioning
M1-1	10	Hydromax brake on/off relay
M1-2	—	Not used
M1-3	—	Not used
M1-4	—	Not used

UPS Power distribution box 2

Fuse or relay	Ampere rating [A]	Protected components
M1	25*	Back-up lamps
M2	20*	Daytime running lamps
M3	30*	4–channel anti-lock brake system module (Hydromax)
M4	20*	Powertrain control module run/start. Fuel pump relay coil
M5	10*	Starter relay coil
M6	20*	Vehicle power 4
M7	5*	Hydromax motor monitor
M8	20*	Vehicle power 2
M9	20*	Vehicle power 1
M10	10*	Air conditioning
M11	5*	Powertrain control module relay keep alive power
M12	20*	Parking lamps
D1	Diode	One-touch start
D2	Diode	Fuel pump
D3	Diode	Air conditioning
R2-1	—	Not used
J1	30**	Powertrain control module vehicle power
J2	20**	Fuel pump
J3	20**	Cigar lighter power point. Diagnostic connector
J4	40**	Blower motor
J5	30**	Headlamps
J6	40**	Ignition switch feeds
J7	40**	Ignition switch feeds
J8	50**	Instrument panel fuse box
J9	30**	Starter motor solenoid
J10	40**	3–channel anti-lock brake system modul
J10	60**	4–channel anti-lock brake system module (Hydromax)
J11	30**	Trailer tow electronic brake
J12	60**	Lighting
J13	20**	Vehicle power 3
J14	20**	Horn
J15	20**	3–channel anti-lock brake system module
J15	60**	4–channel anti-lock brake system module
J16	20**	Trailer tow parking lamps
^Mini fuse. ^*J-case fuse.

Diode and relay module

Locate the module box with the power distribution box in from of the radiator.

Relay location	Protected components
1	One-touch integrated start (ATO diode)
2	Not used
3	Not used
4	Daytime running lamps power relay
5	Hydromax – brake on/off signal isolating relay
6	Reverse lamps relay
7	Starter ground relay
8	Trailer tow parking lamps relay

Fuse holder module

Locate the fuse holder next to the diode and relay module.

Fuse	Ampere rating [A]	Protected components
1	10	Hydromax – brake on/off signal

Passenger compartment fuse panel

Ford F-series F53 Motorhome chassis (2015) - Fuse panel passeneger compartment — Ford F-series F53 Motorhome chassis (2015) – Fuse panel passeneger compartment

Locate this fuse panel below and to the left of the steering wheel near the brake pedal. Remove the panel cover to access the fuses.

Fuse or relay	Ampere rating [A]	Protected components
1	20	Body builder battery (+12V) feed
2	20	Flasher run
3	15	Left turn
4	15	Blower relay coil
5	15	Right turn
6	10	ABS run
7	10	Body builder headlamp
8	5	Daytime running lamps
9	10	Body builder headlamp
10	—	Not used
11	10	Cluster battery (+12V) #1
12	5	UPS BTSI
13	10	Cluster battery (+12V) #2
14	10	Switch illumination
15	20	Body builder battery (+12V) feed
16	—	Not used
17	20	Trailer tow run
18	10	Body builder run
19	10	Brake lamp feed
20	10	Body builder run
21	10	R/S
22	30	Wiper module battery (+12V)
23	10	Reverse lamps
24	5	Body builder radio
25	10	Trailer tow reverse lamps
26	10	Cluster R/S
27	20	Daytime running lamps
Relay 1	—	Daytime running lamps. Parking brake
Relay 2	—	Daytime running lamps on/off
Relay 3	—	Right-hand direction indicator
Relay 4	—	Trailer tow right-hand direction indicator
Relay 5	—	Left-hand direction indicator
Relay 6	—	Trailer tow left-hand direction indicator
Relay 7	—	Not used
Relay 8	—	Not used
Relay 9	—	Not used
Diode 1	—	Not used
Diode 2	—	Not used
Diode 3	—	Not used

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Ford F-Series F-550 F550 (2015) – fuse box diagram

Posted on 25 August 201519 July 2018 by admin

Ford F-Series F-550 F550 (2015) – fuse box diagram

Power distribution box

Fuse or relay	Ampere rating [A]	Protected components
1	Relay	Blower motor
2	—	Not used
3	Relay	Urea heaters (diesel engine)
4	—	Not used
5	Relay	Heated mirrors Rear window defroster
6	—	Not used
7	50*	Heated mirrors Rear window defroster
8	30*	Passenger seat
9	30*	Driver seat
10	40*	Trailer tow
11	—	Not used
12	30*	Driver smart window motor
13	—	Not used
14	—	Not used
15	Diode	Fuel pump (diesel engine)
16	—	Not used
17	15**	Heated mirror
18	—	Not used
19	—	Not used
20	—	Not used
21	—	Not used
22	30*	Trailer tow electric brake
23	40*	Blower motor
24	—	Not used
25	30*	Wipers
26	30*	Trailer tow park lamps
27	25*	Urea heaters (diesel engine)
28	—	Buss bar
29	Relay	Trailer tow park lamps
30	Relay	A/C clutch
31	Relay	Wipers
32	—	Not used
33	15**	Vehicle power 1
34	15**	Vehicle power 2 (diesel engine)
34	20**	Vehicle power 2 (gas engine)
35	10**	Vehicle power 3
36	15**	Vehicle power 4 (diesel engine)
36	20**	Vehicle power 4 (gas engine)
37	10**	Vehicle power 5 (diesel engine)
38	Relay	Electronic control module (diesel engine) Powertrain control module (gas engine)
39	10**	4×4 hub lock
40	15*	4×4 electronic lock
41	—	Not used
42	20**	Rear heated seats
43	—	Not used
44	—	Not used
45	10**	Run/start relay coil
46	10**	Transmission control module keep-alive power (diesel engine)
47	10**	A/C clutch feed
48	Relay	Run/start
49	10**	Rearview camera system
50	10**	Blower motor relay coil
51	—	Not used
52	10**	Electronic control module Powertrain control module, Transmission control module run/start
53	10**	4×4 module
54	10**	Anti-lock brake system run/start
55	10**	Rear window defroster coil
56	20**	Passenger compartment fuse panel run/start feed
57	Relay	Fuel pump
58	—	Not used
59	—	Not used
60	—	Not used
61	—	Not used
62	—	Not used
63	—	Not used
64	—	Not used
65	—	Not used
66	20**	Fuel pump
67	—	Not used
68	10**	Fuel pump relay coil
69	—	Not used
70	10**	Trailer tow backup lamp
71	10**	Canister vent (gas engine)
72	10**	Electronic control module relay coil feed keep-alive power Powertrain control module
73	—	Not used
74	—	Not used
75	—	Not used
76	Relay	Trailer tow backup lamp
77	—	Not used
78	—	Not used
79	—	Not used
80	—	Not used
81	—	Not used
82	20*	Auxiliary power point #2
83	20*	Auxiliary power point #1
84	30*	4×4 shift motor
85	30*	Heated/cooled seats
86	25*	Anti-lock brake system coil feed
87	20*	Auxiliary power point #5
88	20*	Auxiliary power point #6
89	40*	Starter motor
90	25	Trailer tow battery charge
91	—	Not used
92	20*	Auxiliary power point #4
93	20*	Auxiliary power point #3
94	25*	Auxiliary switch #1
95	25*	Auxiliary switch #2
96	50*	Anti-lock brake system pump
97	40*	Inverter
98	—	Not used
99	40*	Instrument panel power inverte
100	—	Not used
101	Relay	Starter
102	—	Not used
103	—	Not used
104	—	Not used
105	—	Not used
106	—	Not used
107	—	Not used
Cartridge fuses *Mini fuses

Passenger compartment fuse panel

Ford F-series F-250 (2015) - fuse box - passenger compartment — Ford F-series F-550 (2015) – fuse box – passenger compartment

Fuse or relay	Ampere rating [A]	Protected components
1	30	Not used (spare)
2	15	Auxiliary switch relay #4
3	30	Passenger smart window motor
4	10	Hood lamp Interior lights
5	20	Moonroof
6	5	Driver seat module
7	7,5	Driver lumbar motor Driver seat switch
8	10	Power mirror switch
9	10	Auxiliary switch relay #3
10	10	Customer access feed Run/accessory relay
11	10	Instrument cluster
12	15	Interior lighting Lighted running board lamps
13	15	Right turn signals and brake lamps
14	15	Left turn signals and brake lamps
15	15	Backup lamps, Trailer tow backup relay High-mounted stop lamps Reverse signal interior mirror
16	10	Right low beam headlamp
17	10	Left low beam headlamp
18	10	Brake shift interlock Keypad illumination Passive anti-theft transceiver Powertrain control module
19	20	Amplifier Subwoofer
20	20	Power door locks
21	10	Brake on/off switch
22	20	Horn
23	15	Not used (spare)
24	15	Diagnostic connector Electronic finish panel Power fold mirror relay Remote keyless entry Steering wheel control module
25	15	Not used (spare)
26	5	Steering wheel control module
27	20	Not used (spare)
28	15	Ignition switch
29	20	GPS module Radio SYNC
30	15	Parking lamp relay Trailer tow parking lamp relay
31	5	Customer access Trailer brake controller (brake signal)
32	15	Auto dimming mirror Driver and passenger door lock switch illumination Driver and passenger smart window motor Moonroof motor Passenger window switch Power inverter Rear heated seat switch illumination Telescoping mirror switch
33	10	Restraint control module
34	10	Heated steering wheel module Rear heated seats module
35	5	Reverse park aid module Select shift switch Trailer brake control module
36	10	Fuel tank select switch
37	10	Positive temperature coefficient heater
38	10	AM/FM base radio
39	15	High beam headlamps
40	10	Parking lamps (in mirrors) Roof marker lamps
41	7,5	Passenger airbag deactivation indicator
42	5	Not used (spare)
43	10	Wiper relay
44	10	Auxiliary switches
45	5	Not used (spare)
46	10	Climate control
47	15	Fog lamps Fog lamp indicator (in switch)
48	30A Circuit breaker	Power rear sliding window switch Power windows switch Moonroof switch
49	Relay	Delayed accessory

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Ford F-53 F53 Motorhome Chassis (2015) – fuse box diagram

Posted on 23 August 201519 July 2018 by admin

Ford F-53 F53 Motorhome Chassis (2015) – fuse box diagram

Power distribution box

Locate the power distribution box in the engine compartment. It has high-current fuses that protect your vehicle’s main electrical systems from overloads.

Fuse or relay	Ampere rating [A]	Protected components
1	5*	Power brake assist module – Hydromax
2	10*	Air conditioning compressor clutch
3	20*	Air conditioning clutch relay coil. Catalyst monitor sensor. Engine heated exhaust gas oxygen sensor #11 and #21. Mass air flow sensor with intake air temperature. Vapor management valve
4	5*	Powertrain control module memory. Powertrain control module relay coil
5	20*	Powertrain control module power
6	20*	Instrument panel dimmer module. Instrument panel fuse #41. Park lamp feeds. Trailer tow running lamp relay coil
7	20*	Ignition coils. Radio capacitors
8	30*	Hydromax – Anti-lock brake system module
9	10*	Powertrain control module. Starter ground relay coil. Starter main relay coil
10	20*	Daytime running lamps
11	20*	Fuel pump relay coil. Powertrain control module power
12	25*	Instrument panel – backup lamp feed. Trailer tow back-up lamps feed
13	30**	Trailer tow electric brake controller feed
14	60**	Instrument panel battery feed (fuse #9, 15, 21). Lighting primary fuse
15	20**	Trailer tow park lamps
16	60**	Anti-lock brake system module – Hydromax
16	40**	Anti-lock brake system module – Hydroboost
17	20**	Horn feed
18	20**	Backup lamp feed. Tow/haul switch. Transmission control indicator light
19	—	Not used
20	30**	Powertrain control module relay coil. Powertrain control module relay (Power distribution box fuses # 3, 5, 7, 18)
21	20**	Fuel injectors. Fuel pump motor
22	20**	Cigar lighter feed. Diagnostic tool connector
23	40**	Blower motor feed
24	50**	Instrument panel battery feed (fuses #4, 10, 16, 22)
25	40**	Ignition switch feed (Instrument panel fuses #1, 5, 7, 11, 13, 14, 17, 19, 23; Power distribution box fuses #9, 11)
26	40**	Ignition switch feed (Instrument panel fuses #5, 11, 17, 23, 26, 38)
27	30**	Multi-function switch (headlamps)
28	30**	Starter solenoid
29	60**	Power brake assist motor – Hydromax
	40**	Anti-lock brake system module – Hydroboost
R1	—	Air conditioning clutch relay
R2	—	Fuel pump relay
R3	—	Horn relay
R4	—	Starter relay
R5	—	Blower motor relay
R6	—	Powertrain control module relay
Diode 1	—	Fuel pump diode
Diode 2	—	Air conditioning clutch diode
Mini fuses. *Maxi fuses.

UPS Power distribution box 1

Fuse or relay	Ampere rating [A]	Protected components
R1	Relay	Powertrain control module
R2	Relay	Daytime running lamps
R3	Relay	Starter motor
R4	Relay	Blower motor
R5	Relay	Horn
R6	Relay	Fuel pump
R7	Relay	Starter ground
R8	Relay	Trailer tow parking lamps
R9	Relay	Back-up lamps
R10	Relay	Not used
R11	Relay	Not used
R12	Relay	Air conditioning
M1-1	10	Hydromax brake on/off relay
M1-2	—	Not used
M1-3	—	Not used
M1-4	—	Not used

UPS Power distribution box 2

Fuse or relay	Ampere rating [A]	Protected components
M1	25*	Back-up lamps
M2	20*	Daytime running lamps
M3	30*	4–channel anti-lock brake system module (Hydromax)
M4	20*	Powertrain control module run/start. Fuel pump relay coil
M5	10*	Starter relay coil
M6	20*	Vehicle power 4
M7	5*	Hydromax motor monitor
M8	20*	Vehicle power 2
M9	20*	Vehicle power 1
M10	10*	Air conditioning
M11	5*	Powertrain control module relay keep alive power
M12	20*	Parking lamps
D1	Diode	One-touch start
D2	Diode	Fuel pump
D3	Diode	Air conditioning
R2-1	—	Not used
J1	30**	Powertrain control module vehicle power
J2	20**	Fuel pump
J3	20**	Cigar lighter power point. Diagnostic connector
J4	40**	Blower motor
J5	30**	Headlamps
J6	40**	Ignition switch feeds
J7	40**	Ignition switch feeds
J8	50**	Instrument panel fuse box
J9	30**	Starter motor solenoid
J10	40**	3–channel anti-lock brake system modul
J10	60**	4–channel anti-lock brake system module (Hydromax)
J11	30**	Trailer tow electronic brake
J12	60**	Lighting
J13	20**	Vehicle power 3
J14	20**	Horn
J15	20**	3–channel anti-lock brake system module
J15	60**	4–channel anti-lock brake system module
J16	20**	Trailer tow parking lamps
^Mini fuse. ^*J-case fuse.

Diode and relay module

Locate the module box with the power distribution box in from of the radiator.

Relay location	Protected components
1	One-touch integrated start (ATO diode)
2	Not used
3	Not used
4	Daytime running lamps power relay
5	Hydromax – brake on/off signal isolating relay
6	Reverse lamps relay
7	Starter ground relay
8	Trailer tow parking lamps relay

Fuse holder module

Locate the fuse holder next to the diode and relay module.

Fuse	Ampere rating [A]	Protected components
1	10	Hydromax – brake on/off signal

Passenger compartment fuse panel

Locate this fuse panel below and to the left of the steering wheel near the brake pedal. Remove the panel cover to access the fuses.

Fuse or relay	Ampere rating [A]	Protected components
1	20	Body builder battery (+12V) feed
2	20	Flasher run
3	15	Left turn
4	15	Blower relay coil
5	15	Right turn
6	10	ABS run
7	10	Body builder headlamp
8	5	Daytime running lamps
9	10	Body builder headlamp
10	—	Not used
11	10	Cluster battery (+12V) #1
12	5	UPS BTSI
13	10	Cluster battery (+12V) #2
14	10	Switch illumination
15	20	Body builder battery (+12V) feed
16	—	Not used
17	20	Trailer tow run
18	10	Body builder run
19	10	Brake lamp feed
20	10	Body builder run
21	10	R/S
22	30	Wiper module battery (+12V)
23	10	Reverse lamps
24	5	Body builder radio
25	10	Trailer tow reverse lamps
26	10	Cluster R/S
27	20	Daytime running lamps
Relay 1	—	Daytime running lamps. Parking brake
Relay 2	—	Daytime running lamps on/off
Relay 3	—	Right-hand direction indicator
Relay 4	—	Trailer tow right-hand direction indicator
Relay 5	—	Left-hand direction indicator
Relay 6	—	Trailer tow left-hand direction indicator
Relay 7	—	Not used
Relay 8	—	Not used
Relay 9	—	Not used
Diode 1	—	Not used
Diode 2	—	Not used
Diode 3	—	Not used

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Ford F-Series F-450 F450 (2015) – fuse box diagram

Posted on 23 August 201519 July 2018 by admin

Ford F-Series F-450 F450 (2015) – fuse box diagram

Power distribution box

Fuse or relay	Ampere rating [A]	Protected components
1	Relay	Blower motor
2	—	Not used
3	Relay	Urea heaters (diesel engine)
4	—	Not used
5	Relay	Heated mirrors Rear window defroster
6	—	Not used
7	50*	Heated mirrors Rear window defroster
8	30*	Passenger seat
9	30*	Driver seat
10	40*	Trailer tow
11	—	Not used
12	30*	Driver smart window motor
13	—	Not used
14	—	Not used
15	Diode	Fuel pump (diesel engine)
16	—	Not used
17	15**	Heated mirror
18	—	Not used
19	—	Not used
20	—	Not used
21	—	Not used
22	30*	Trailer tow electric brake
23	40*	Blower motor
24	—	Not used
25	30*	Wipers
26	30*	Trailer tow park lamps
27	25*	Urea heaters (diesel engine)
28	—	Buss bar
29	Relay	Trailer tow park lamps
30	Relay	A/C clutch
31	Relay	Wipers
32	—	Not used
33	15**	Vehicle power 1
34	15**	Vehicle power 2 (diesel engine)
34	20**	Vehicle power 2 (gas engine)
35	10**	Vehicle power 3
36	15**	Vehicle power 4 (diesel engine)
36	20**	Vehicle power 4 (gas engine)
37	10**	Vehicle power 5 (diesel engine)
38	Relay	Electronic control module (diesel engine) Powertrain control module (gas engine)
39	10**	4×4 hub lock
40	15*	4×4 electronic lock
41	—	Not used
42	20**	Rear heated seats
43	—	Not used
44	—	Not used
45	10**	Run/start relay coil
46	10**	Transmission control module keep-alive power (diesel engine)
47	10**	A/C clutch feed
48	Relay	Run/start
49	10**	Rearview camera system
50	10**	Blower motor relay coil
51	—	Not used
52	10**	Electronic control module Powertrain control module, Transmission control module run/start
53	10**	4×4 module
54	10**	Anti-lock brake system run/start
55	10**	Rear window defroster coil
56	20**	Passenger compartment fuse panel run/start feed
57	Relay	Fuel pump
58	—	Not used
59	—	Not used
60	—	Not used
61	—	Not used
62	—	Not used
63	—	Not used
64	—	Not used
65	—	Not used
66	20**	Fuel pump
67	—	Not used
68	10**	Fuel pump relay coil
69	—	Not used
70	10**	Trailer tow backup lamp
71	10**	Canister vent (gas engine)
72	10**	Electronic control module relay coil feed keep-alive power Powertrain control module
73	—	Not used
74	—	Not used
75	—	Not used
76	Relay	Trailer tow backup lamp
77	—	Not used
78	—	Not used
79	—	Not used
80	—	Not used
81	—	Not used
82	20*	Auxiliary power point #2
83	20*	Auxiliary power point #1
84	30*	4×4 shift motor
85	30*	Heated/cooled seats
86	25*	Anti-lock brake system coil feed
87	20*	Auxiliary power point #5
88	20*	Auxiliary power point #6
89	40*	Starter motor
90	25	Trailer tow battery charge
91	—	Not used
92	20*	Auxiliary power point #4
93	20*	Auxiliary power point #3
94	25*	Auxiliary switch #1
95	25*	Auxiliary switch #2
96	50*	Anti-lock brake system pump
97	40*	Inverter
98	—	Not used
99	40*	Instrument panel power inverte
100	—	Not used
101	Relay	Starter
102	—	Not used
103	—	Not used
104	—	Not used
105	—	Not used
106	—	Not used
107	—	Not used
Cartridge fuses *Mini fuses

Passenger compartment fuse panel

Fuse or relay	Ampere rating [A]	Protected components
1	30	Not used (spare)
2	15	Auxiliary switch relay #4
3	30	Passenger smart window motor
4	10	Hood lamp Interior lights
5	20	Moonroof
6	5	Driver seat module
7	7,5	Driver lumbar motor Driver seat switch
8	10	Power mirror switch
9	10	Auxiliary switch relay #3
10	10	Customer access feed Run/accessory relay
11	10	Instrument cluster
12	15	Interior lighting Lighted running board lamps
13	15	Right turn signals and brake lamps
14	15	Left turn signals and brake lamps
15	15	Backup lamps, Trailer tow backup relay High-mounted stop lamps Reverse signal interior mirror
16	10	Right low beam headlamp
17	10	Left low beam headlamp
18	10	Brake shift interlock Keypad illumination Passive anti-theft transceiver Powertrain control module
19	20	Amplifier Subwoofer
20	20	Power door locks
21	10	Brake on/off switch
22	20	Horn
23	15	Not used (spare)
24	15	Diagnostic connector Electronic finish panel Power fold mirror relay Remote keyless entry Steering wheel control module
25	15	Not used (spare)
26	5	Steering wheel control module
27	20	Not used (spare)
28	15	Ignition switch
29	20	GPS module Radio SYNC
30	15	Parking lamp relay Trailer tow parking lamp relay
31	5	Customer access Trailer brake controller (brake signal)
32	15	Auto dimming mirror Driver and passenger door lock switch illumination Driver and passenger smart window motor Moonroof motor Passenger window switch Power inverter Rear heated seat switch illumination Telescoping mirror switch
33	10	Restraint control module
34	10	Heated steering wheel module Rear heated seats module
35	5	Reverse park aid module Select shift switch Trailer brake control module
36	10	Fuel tank select switch
37	10	Positive temperature coefficient heater
38	10	AM/FM base radio
39	15	High beam headlamps
40	10	Parking lamps (in mirrors) Roof marker lamps
41	7,5	Passenger airbag deactivation indicator
42	5	Not used (spare)
43	10	Wiper relay
44	10	Auxiliary switches
45	5	Not used (spare)
46	10	Climate control
47	15	Fog lamps Fog lamp indicator (in switch)
48	30A Circuit breaker	Power rear sliding window switch Power windows switch Moonroof switch
49	Relay	Delayed accessory

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Ford F-Series F-350 F350 (2015) – fuse box diagram

Posted on 23 August 201519 July 2018 by admin

Ford F-Series F-350 F350 (2015) – fuse box diagram

Power distribution box

Fuse or relay	Ampere rating [A]	Protected components
1	Relay	Blower motor
2	—	Not used
3	Relay	Urea heaters (diesel engine)
4	—	Not used
5	Relay	Heated mirrors Rear window defroster
6	—	Not used
7	50*	Heated mirrors Rear window defroster
8	30*	Passenger seat
9	30*	Driver seat
10	40*	Trailer tow
11	—	Not used
12	30*	Driver smart window motor
13	—	Not used
14	—	Not used
15	Diode	Fuel pump (diesel engine)
16	—	Not used
17	15**	Heated mirror
18	—	Not used
19	—	Not used
20	—	Not used
21	—	Not used
22	30*	Trailer tow electric brake
23	40*	Blower motor
24	—	Not used
25	30*	Wipers
26	30*	Trailer tow park lamps
27	25*	Urea heaters (diesel engine)
28	—	Buss bar
29	Relay	Trailer tow park lamps
30	Relay	A/C clutch
31	Relay	Wipers
32	—	Not used
33	15**	Vehicle power 1
34	15**	Vehicle power 2 (diesel engine)
34	20**	Vehicle power 2 (gas engine)
35	10**	Vehicle power 3
36	15**	Vehicle power 4 (diesel engine)
36	20**	Vehicle power 4 (gas engine)
37	10**	Vehicle power 5 (diesel engine)
38	Relay	Electronic control module (diesel engine) Powertrain control module (gas engine)
39	10**	4×4 hub lock
40	15*	4×4 electronic lock
41	—	Not used
42	20**	Rear heated seats
43	—	Not used
44	—	Not used
45	10**	Run/start relay coil
46	10**	Transmission control module keep-alive power (diesel engine)
47	10**	A/C clutch feed
48	Relay	Run/start
49	10**	Rearview camera system
50	10**	Blower motor relay coil
51	—	Not used
52	10**	Electronic control module Powertrain control module, Transmission control module run/start
53	10**	4×4 module
54	10**	Anti-lock brake system run/start
55	10**	Rear window defroster coil
56	20**	Passenger compartment fuse panel run/start feed
57	Relay	Fuel pump
58	—	Not used
59	—	Not used
60	—	Not used
61	—	Not used
62	—	Not used
63	—	Not used
64	—	Not used
65	—	Not used
66	20**	Fuel pump
67	—	Not used
68	10**	Fuel pump relay coil
69	—	Not used
70	10**	Trailer tow backup lamp
71	10**	Canister vent (gas engine)
72	10**	Electronic control module relay coil feed keep-alive power Powertrain control module
73	—	Not used
74	—	Not used
75	—	Not used
76	Relay	Trailer tow backup lamp
77	—	Not used
78	—	Not used
79	—	Not used
80	—	Not used
81	—	Not used
82	20*	Auxiliary power point #2
83	20*	Auxiliary power point #1
84	30*	4×4 shift motor
85	30*	Heated/cooled seats
86	25*	Anti-lock brake system coil feed
87	20*	Auxiliary power point #5
88	20*	Auxiliary power point #6
89	40*	Starter motor
90	25	Trailer tow battery charge
91	—	Not used
92	20*	Auxiliary power point #4
93	20*	Auxiliary power point #3
94	25*	Auxiliary switch #1
95	25*	Auxiliary switch #2
96	50*	Anti-lock brake system pump
97	40*	Inverter
98	—	Not used
99	40*	Instrument panel power inverte
100	—	Not used
101	Relay	Starter
102	—	Not used
103	—	Not used
104	—	Not used
105	—	Not used
106	—	Not used
107	—	Not used
Cartridge fuses *Mini fuses

Passenger compartment fuse panel

Fuse or relay	Ampere rating [A]	Protected components
1	30	Not used (spare)
2	15	Auxiliary switch relay #4
3	30	Passenger smart window motor
4	10	Hood lamp Interior lights
5	20	Moonroof
6	5	Driver seat module
7	7,5	Driver lumbar motor Driver seat switch
8	10	Power mirror switch
9	10	Auxiliary switch relay #3
10	10	Customer access feed Run/accessory relay
11	10	Instrument cluster
12	15	Interior lighting Lighted running board lamps
13	15	Right turn signals and brake lamps
14	15	Left turn signals and brake lamps
15	15	Backup lamps, Trailer tow backup relay High-mounted stop lamps Reverse signal interior mirror
16	10	Right low beam headlamp
17	10	Left low beam headlamp
18	10	Brake shift interlock Keypad illumination Passive anti-theft transceiver Powertrain control module
19	20	Amplifier Subwoofer
20	20	Power door locks
21	10	Brake on/off switch
22	20	Horn
23	15	Not used (spare)
24	15	Diagnostic connector Electronic finish panel Power fold mirror relay Remote keyless entry Steering wheel control module
25	15	Not used (spare)
26	5	Steering wheel control module
27	20	Not used (spare)
28	15	Ignition switch
29	20	GPS module Radio SYNC
30	15	Parking lamp relay Trailer tow parking lamp relay
31	5	Customer access Trailer brake controller (brake signal)
32	15	Auto dimming mirror Driver and passenger door lock switch illumination Driver and passenger smart window motor Moonroof motor Passenger window switch Power inverter Rear heated seat switch illumination Telescoping mirror switch
33	10	Restraint control module
34	10	Heated steering wheel module Rear heated seats module
35	5	Reverse park aid module Select shift switch Trailer brake control module
36	10	Fuel tank select switch
37	10	Positive temperature coefficient heater
38	10	AM/FM base radio
39	15	High beam headlamps
40	10	Parking lamps (in mirrors) Roof marker lamps
41	7,5	Passenger airbag deactivation indicator
42	5	Not used (spare)
43	10	Wiper relay
44	10	Auxiliary switches
45	5	Not used (spare)
46	10	Climate control
47	15	Fog lamps Fog lamp indicator (in switch)
48	30A Circuit breaker	Power rear sliding window switch Power windows switch Moonroof switch
49	Relay	Delayed accessory

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Ford F-Series F-250 F250 (2015) – fuse box diagram

Posted on 22 August 201519 July 2018 by admin

Ford F-Series F-250 F250 (2015) – fuse b0x diagram

Power distribution box

Fuse or relay	Ampere rating [A]	Protected components
1	Relay	Blower motor
2	—	Not used
3	Relay	Urea heaters (diesel engine)
4	—	Not used
5	Relay	Heated mirrors Rear window defroster
6	—	Not used
7	50*	Heated mirrors Rear window defroster
8	30*	Passenger seat
9	30*	Driver seat
10	10*	Trailer tow
11	—	Not used
12	30*	Driver smart window motor
13	—	Not used
14	—	Not used
15	Diode	Fuel pump (diesel engine)
16	—	Not used
17	15**	Heated mirror
18	—	Not used
19	—	Not used
20	—	Not used
21	—	Not used
22	30*	Trailer tow electric brake
23	40*	Blower motor
24	—	Not used
25	30*	Wipers
26	30*	Trailer tow park lamps
27	25*	Urea heaters (diesel engine)
28	—	Buss bar
29	Relay	Trailer tow park lamps
30	Relay	A/C clutch
31	Relay	Wipers
32	—	Not used
33	15**	Vehicle power 1
34	15**	Vehicle power 2 (diesel engine)
34	20**	Vehicle power 2 (gas engine)
35	10**	Vehicle power 3
36	15**	Vehicle power 4 (diesel engine)
36	20**	Vehicle power 4 (gas engine)
37	10**	Vehicle power 5 (diesel engine)
38	Relay	Electronic control module (diesel engine) Powertrain control module (gas engine)
39	10**	4×4 hub lock
40	15*	4×4 electronic lock
41	—	Not used
42	20**	Rear heated seats
43	—	Not used
44	—	Not used
45	10**	Run/start relay coil
46	10**	Transmission control module keep-alive power (diesel engine)
47	10**	A/C clutch feed
48	Relay	Run/start
49	10**	Rearview camera system
50	10**	Blower motor relay coil
51	—	Not used
52	10**	Electronic control module Powertrain control module, Transmission control module run/start
53	10**	4×4 module
54	10**	Anti-lock brake system run/start
55	10**	Rear window defroster coil
56	20**	Passenger compartment fuse panel run/start feed
57	Relay	Fuel pump
58	—	Not used
59	—	Not used
60	—	Not used
61	—	Not used
62	—	Not used
63	—	Not used
64	—	Not used
65	—	Not used
66	20**	Fuel pump
67	—	Not used
68	10**	Fuel pump relay coil
69	—	Not used
70	10**	Trailer tow backup lamp
71	10**	Canister vent (gas engine)
72	10**	Electronic control module relay coil feed keep-alive power Powertrain control module
73	—	Not used
74	—	Not used
75	—	Not used
76	Relay	Trailer tow backup lamp
77	—	Not used
78	—	Not used
79	—	Not used
80	—	Not used
81	—	Not used
82	20*	Auxiliary power point #2
83	20*	Auxiliary power point #1
84	30*	4×4 shift motor
85	30*	Heated/cooled seats
86	25*	Anti-lock brake system coil feed
87	20*	Auxiliary power point #5
88	20*	Auxiliary power point #6
89	40*	Starter motor
90	25	Trailer tow battery charge
91	—	Not used
92	20*	Auxiliary power point #4
93	20*	Auxiliary power point #3
94	25*	Auxiliary switch #1
95	25*	Auxiliary switch #2
96	50*	Anti-lock brake system pump
97	40*	Inverter
98	—	Not used
99	40*	Instrument panel power inverte
100	—	Not used
101	Relay	Starter
102	—	Not used
103	—	Not used
104	—	Not used
105	—	Not used
106	—	Not used
107	—	Not used
Cartridge fuses *Mini fuses

Passenger compartment fuse panel

Fuse or relay	Ampere rating [A]	Protected components
1	30	Not used (spare)
2	15	Auxiliary switch relay #4
3	30	Passenger smart window motor
4	10	Hood lamp Interior lights
5	20	Moonroof
6	5	Driver seat module
7	7,5	Driver lumbar motor Driver seat switch
8	10	Power mirror switch
9	10	Auxiliary switch relay #3
10	10	Customer access feed Run/accessory relay
11	10	Instrument cluster
12	15	Interior lighting Lighted running board lamps
13	15	Right turn signals and brake lamps
14	15	Left turn signals and brake lamps
15	15	Backup lamps, Trailer tow backup relay High-mounted stop lamps Reverse signal interior mirror
16	10	Right low beam headlamp
17	10	Left low beam headlamp
18	10	Brake shift interlock Keypad illumination Passive anti-theft transceiver Powertrain control module
19	20	Amplifier Subwoofer
20	20	Power door locks
21	10	Brake on/off switch
22	20	Horn
23	15	Not used (spare)
24	15	Diagnostic connector Electronic finish panel Power fold mirror relay Remote keyless entry Steering wheel control module
25	15	Not used (spare)
26	5	Steering wheel control module
27	20	Not used (spare)
28	15	Ignition switch
29	20	GPS module Radio SYNC
30	15	Parking lamp relay Trailer tow parking lamp relay
31	5	Customer access Trailer brake controller (brake signal)
32	15	Auto dimming mirror Driver and passenger door lock switch illumination Driver and passenger smart window motor Moonroof motor Passenger window switch Power inverter Rear heated seat switch illumination Telescoping mirror switch
33	10	Restraint control module
34	10	Heated steering wheel module Rear heated seats module
35	5	Reverse park aid module Select shift switch Trailer brake control module
36	10	Fuel tank select switch
37	10	Positive temperature coefficient heater
38	10	AM/FM base radio
39	15	High beam headlamps
40	10	Parking lamps (in mirrors) Roof marker lamps
41	7,5	Passenger airbag deactivation indicator
42	5	Not used (spare)
43	10	Wiper relay
44	10	Auxiliary switches
45	5	Not used (spare)
46	10	Climate control
47	15	Fog lamps Fog lamp indicator (in switch)
48	30A Circuit breaker	Power rear sliding window switch Power windows switch Moonroof switch
49	Relay	Delayed accessory

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Ford F-Series F-150 F150 (from 2014) – fuse box diagram

Posted on 21 August 201519 July 2018 by admin

Ford F-Series XIII F-150 F150 (from 2014) – fuse box diagram

Year of production: 2014, 2015, 2016

Power distribution box

Fuse or relay	Amepre rating [A]	Protected components
1	—	Not used
2	—	Not used
3	—	Not used
4	—	Telescoping side-view mirror
5	40*	Rear window defroster
6	—	Not used
7	—	Not used
8	—	Telescoping side-view mirror
9	—	Not used
10	—	Not used
11	60*	Automatic brake system motor
12	50*	Body control module 1
13	60*	Body control module 2
14	20**	Amplifier
15	25**	4×4
16	15**	Spot light module
17	15**	Heated seat
18	10**	Steering-column lock
19	10**	Power seats
20	15**	Snow plow, rear heated seats
21A	—	Not used
21B	—	Not used
22	30*	Windshield wiper motor
23	15*	Rain sensor
24	25*	Series fan feed
25	—	Not used
26	30*	Driver seat motors
27	30*	Passenger power seat
28	30*	Climate controlled seat
29	—	Not used
30	—	Air conditioner clutch relay
31	—	Not used
32	—	Not used
33	50*	Electric fan 3
34	25*	Trailer tow park lamps
35	20*	Trailer tow stop-turn relay fuse
36	25**	Trailer tow lamps module
37	50**	Electric fan 1
38	10**	Alt A sensor
39	10**	Integrated wheel end solenoid
40	15**	E-locker
41	10**	Telescoping mirror
42	30**	Transmission fluid pump
43	25**	Horn
44	10**	Air conditioner clutch
45	10**	Powertrain control module relay coil
46	10**	Wiper relay coil
47	—	Not used
48	—	Not used
49	30*	Trailer brake control module
50	30*	Power running boards
51	—	Fuel pump relay
52	—	Not used
53	—	Not used
54	30	Voltage quality module, body-control-module voltage-qualitymodule feed
55	40*	Body control module RP2 feed
56	20*	Fuel pump
57	30*	Right-hand EPB actuator
58	30*	Left-hand EPB actuator
59	30*	Starter
60	40*	Blower motor
61	30*	Brake control module, automatic brake system valves
62	—	Power seat relay
63	15**	Heated mirrors
64	—	Not used
65	—	Starter relay
66	—	Powertrain control module relay
67	—	Windshield wiper relay
68	—	Blower motor relay
69	—	Power sliding back window relay
70	—	Electric fan 1 relay
71	—	Not used
72	25*	4×4
73	—	Not used
74	30*	PDRG motor
75	—	Horn relay
76	—	Not used
77	—	Steering column lock relay
78	—	Not used
79	—	Trailer tow parking lamp relay
80	—	Rear window defroster relay
81	—	Not used
82	—	PDRG close relay
83	—	Not used
84	—	Not used
85	—	Not used
86	—	Not used
87	10*	Trailer tow backup lamps
88	—	Not used
89	20*	Cigar lighter power point 1
90	20*	Power point 2
91	20*	Power point 3
92	20*	Power point 4
93	25**	GTDI vehicle power 1
93	10**	PFI vehicle power 1
94	—	Not used
95	25**	Vehicle power 2
96	—	Not used
97	10**	Vehicle power 2
98	—	Not used
99	20**	Vehicle power 4 (PFI)
99	15**	Vehicle power 4 (GTDI)
100	—	Not used
101	—	Not used
102	—	Snow plow relay
103	—	Not used
104	—	Electic fan 3 relay
105	10**	Power steering
106	—	Not used
107	10**	Anti-lock brakes
108	—	Not used
109	10**	Powertrain control module
110	10**	4×4 run/start, adaptive cruise control
111	10**	Transmission pump run-start
112	—	Not used
113	7,5**	Left hand blind spot information system, rear view camera, front view camera, voltage quality module
114	—	Electric fan 2 relay
115	—	Not used
116	—	Not used
Cartridge fuses*Mini fuses

Passenger compartment fuse panel

Ford F-series F-150 (2015) - fuse box - passenger compartment — Ford F-series XIII F-150 (from 2014) – fuse box – passenger compartment

Fuse or relay	Ampere rating [A]	Protected components
1	10	Demand lamp relay, power seats relay, glove box, vanity lamps, overhead console, dome, courtesy, map lamps
2	7,5	Memory module logic, memory seat switches, lumbar motor
3	20	Driver door lock motor
4	5	Trailer brake control
5	20	Not used
6	10	Not used
7	10	Not used
8	10	Not used
9	10	Not used
10	5	Not used (spare)
11	5	Combined sensor module
12	7,5	Climate head module, smart datalink converter
13	7,5	Cluster, SCCM
14	10	Brake
15	10	Smart datalink converter
16	15	Tailgate release
17	5	HUD
18	5	Ignition switch and passive-entry passivestart start stop switch, key inhibit solenoid
19	7,5	Tow haul (O/D) cancel for floor or column shifter
20	7,5	Not used
21	5	HUD, in car temperature with humidity sensor
22	5	EPB, power seat
23	10	PDRG switch, inverter, driver side window, moonroof
24	20	Central lock/unlock
25	30	Driver door control module
26	30	Passenger door control module
27	30	Vista roof, moonroof
28	20	Not used
29	30	Not used
30	30	Not used
31	15	Not used
32	10	Multi-function display, global position system, sync 1, sync 2, radio frequency receiver
33	20	Radio
34	30	Run-start relay
35	5	Restraints module
36	15	360 camera module, heated steering wheel module, rear-view mirror, rear heated seats
37	15	Power distribution box run-start relay
38	30A Circuit breaker	Rear window switches and motors

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Ford Explorer (from 2010) – bulb specification chart

Posted on 20 August 201519 July 2018 by admin

Ford Explorer (from 2010) – bulb specification chart

Year of production: 2010, 2011, 2012, 2013, 2014, 2015, 2016

Function	Number of bulbs	Trade number
Low/high beam headlamp	2	HB3
HID headlamp	2	D3S
Front park/turn lamp	2	3457K
Sidemarker	2	W5W
Tail lamp	n/a	LED
Backup lamp	2	W21W
Rear turn lamp	2	WY21W (amber)
Stop lamp	n/a	LED
High-mount stop lamps	n/a	LED
Rear license plate lamp	1	W5W
Front fog lamp	2	H11
Interior front map lamps	2	168 (T10)
Second row dome/courtesy lamp	2	168 (T10)
Second row dome/map lamp	n/a	LED
Third row cargo lamp	n/a	LED
Rear cargo lamp	1	578
Visor vanity lamp – Slideon rail system (SOR)	2	A6224PF
All replacement bulbs are clear in color, except where noted.

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
