Ford Crown Victoria (1979 – 1982) – fuse box diagram

Posted on 14 October 2019 by admin

Ford Crown Victoria (1979 – 1982) – fuse box diagram

Year of production: 1979, 1980, 1981, 1982

Fuse box diagram

№	A	Protected Component
1	5	Instrument illumination
2	10	Automatic light warning indicators and carburetor circuits
3	—	—
4	20	Horn and cigar lighter
5	25	Cigar lighters and tailgate window key switch
	30	Circuit Breaker: Door locks, tailgate window key switch, lighters and power seats
6	—	—
7	15	Courtesy lights, illuminated entry, clock and CB radio
8	15	License, tail, parking and coach lights
9	—	—
10	15	Radio, power antenna, CB radio and premium sound system
11	20	Air conditioning clutch, cornering lights, rear window de-icer, trunk release, speed control, police circuits, illuminated entry, power window safety relay (4-dr) and digital clock
12	8.25	Circuit Breaker: Windshield wipers/washers and intermittent wipers
13	15	Hazard and stop lights
14	15	Turn signal lights, back-up lights and trailer
15	30	Heater and air conditioning blower
16	—	—
17	25	Tailgate windows and instrument panel switch
	30	Circuit Breaker: Power windows
Circuit Breaker: Headlights – An 18 amp. C.B. is integral with headlight switch. Power Windows — A 20 amp. C.B. is located on the fuse panel on 2-door models, or at the starter relay on 4-door models. Fusible Links: A fusible link located at the wiring harness of the starter relay protects the followng circuits, heated rear window, trailer towing brakes and lights, and the air bag feed. In-Line Fuse: A 2 amp. in-line fuse is located on the visor to protect the lighted vanity mirror

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Ford LTD (1979 – 1982) – fuse box diagram

Posted on 14 October 2019 by admin

Ford LTD (1979 – 1982) – fuse box diagram

Year of production: 1979, 1980, 1981, 1982

Fuse box diagram

№	A	Protected Component
1	5	Instrument illumination
2	10	Automatic light warning indicators and carburetor circuits
3	—	—
4	20	Horn and cigar lighter
5	25	Cigar lighters and tailgate window key switch
	30	Circuit Breaker: Door locks, tailgate window key switch, lighters and power seats
6	—	—
7	15	Courtesy lights, illuminated entry, clock and CB radio
8	15	License, tail, parking and coach lights
9	—	—
10	15	Radio, power antenna, CB radio and premium sound system
11	20	Air conditioning clutch, cornering lights, rear window de-icer, trunk release, speed control, police circuits, illuminated entry, power window safety relay (4-dr) and digital clock
12	8.25	Circuit Breaker: Windshield wipers/washers and intermittent wipers
13	15	Hazard and stop lights
14	15	Turn signal lights, back-up lights and trailer
15	30	Heater and air conditioning blower
16	—	—
17	25	Tailgate windows and instrument panel switch
	30	Circuit Breaker: Power windows
Circuit Breaker: Headlights – An 18 amp. C.B. is integral with headlight switch. Power Windows — A 20 amp. C.B. is located on the fuse panel on 2-door models, or at the starter relay on 4-door models. Fusible Links: A fusible link located at the wiring harness of the starter relay protects the followng circuits, heated rear window, trailer towing brakes and lights, and the air bag feed. In-Line Fuse: A 2 amp. in-line fuse is located on the visor to protect the lighted vanity mirror

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Plymouth Reliant (1981 – 1984) – fuse box diagram

Posted on 14 October 2019 by admin

Plymouth Reliant (1981 – 1984) – fuse box diagram

Year of production: 1981, 1982, 1983, 1984

Fuse box diagram

№	A	Protected Component
1	20	Hazard warning flashers
2	5	Speed control and heated rear window relay
3	30	Air conditioning radiator tan motor
4	20	Heater blower motor
	30	Air conditioning blower motor
5	20	Parking, tail, side marker, license, cluster and clock intensity lights
6	20	Stop, dome, trunk, cargo and ignition switch lights. Headlight/key warning buzzer and time delay relay
7	20	Glove box light, horn, horn relay, cigar lighter and clock memory
8	30	Circuit Breaker: Power seat motors and power door lock solenoids
9	—	—
10	—	—
11	5	Brake warning, liftgate ajar, charge, oil, temperature and seat belt warning lights, voltage limiter and voltage monitor module
12	20	Door lock relay
13	3	Instrument cluster, air conditioning and heater control lights, ash tray, shift indicator, heated rear window, rear wiper/washer and radio control lights, clock display dimming
14	6	Circuit Breaker: Deck lid release, liftgate release, premium speaker system and rear wiper/washer
15	5	Radio and clock display
16	20	Back-up and turn signal lights, and air conditioning clutch
Circuit Breaker: Headlights — Circuit breaker integral with the headlight switch to protect the headlight circuit Windshield Wipers — Circuit breaker integral with the wiper switch to protect the circuit

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Dodge Aries (1981 – 1984) – fuse box diagram

Posted on 14 October 2019 by admin

Dodge Aries (1981 – 1984) – fuse box diagram

Year of production: 1981, 1982, 1983, 1984

Fuse box diagram

№	A	Protected Component
1	20	Hazard warning flashers
2	5	Speed control and heated rear window relay
3	30	Air conditioning radiator tan motor
4	20	Heater blower motor
	30	Air conditioning blower motor
5	20	Parking, tail, side marker, license, cluster and clock intensity lights
6	20	Stop, dome, trunk, cargo and ignition switch lights. Headlight/key warning buzzer and time delay relay
7	20	Glove box light, horn, horn relay, cigar lighter and clock memory
8	30	Circuit Breaker: Power seat motors and power door lock solenoids
9	—	—
10	—	—
11	5	Brake warning, liftgate ajar, charge, oil, temperature and seat belt warning lights, voltage limiter and voltage monitor module
12	20	Door lock relay
13	3	Instrument cluster, air conditioning and heater control lights, ash tray, shift indicator, heated rear window, rear wiper/washer and radio control lights, clock display dimming
14	6	Circuit Breaker: Deck lid release, liftgate release, premium speaker system and rear wiper/washer
15	5	Radio and clock display
16	20	Back-up and turn signal lights, and air conditioning clutch
Circuit Breaker: Headlights — Circuit breaker integral with the headlight switch to protect the headlight circuit Windshield Wipers — Circuit breaker integral with the wiper switch to protect the circuit

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Dodge Diplomat (1977 – 1981) – fuse box diagram

Posted on 14 October 201914 October 2019 by admin

Dodge Diplomat (1977 – 1981) – fuse box diagram

Year of production: 1977, 1978, 1979, 1980, 1981

Fuse box diagram

№	A	Protected Component
1	20	Hazard warning lights
2	20	Speed control, heated rear window and cornering lights
3	30	Circuit Breaker: Power windows and moon roof
4	20	Heater and air conditioning blower motor
	30	Automatic temperature control and heater blower motor
5	20	Cluster, parking, tail, license, side marker lights, map, dome, trunk and opera lights, search tune radio and cassette lights
6	20	Map, glove box, door ajar, courtesy, vanity, reading and stop lights, seat belt, key and headlight warning buzzer, ignition delay relay, power door lock relay, chimes and illuminated entry
7	20	Horn, horn relay, stop lights, clock feed, search tune radio memory, glove box light, power antenna and cigar lighter
8	30	Circuit Breaker: Power door locks and power seats
9	—	—
10	—	—
11	5	Brake warning, oil pressure, door ajar, seat belt lights, seat belt buzzer, gauges, voltage limiter, tailgate and low washer fluid light
12	—	—
13	3	Cluster, parking brake, radio, digital clock, heated rear window, air conditioning or ATC heater control, cigar lighter and ash tray lights, search tune and CB radio display dimming
14	6	Circuit Breaker: Rear wiper/washer, liftgate relay and deck lid release solenoid
15	5	Power antenna controller, radio and digital clock display
16	20	Back-up and turn signal lights, idle stop solenoid and air conditioning clutch
Circuit Breaker: Headlights — Circuit breaker integral with the headlight switch to protect the headlight circuit Windshield Wipers — Circuit breaker integral with the wiper switch to protect the circuit Vanity Mirror — 1.5 amp. breaker located on the visor to protect the mirror circuit Power Sun Roof — 15 amp. breaker located in the left side cowl to protect the roof system

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Chrysler LeBaron (1977 – 1981) – fuse box diagram

Posted on 14 October 2019 by admin

Chrysler LeBaron (1977 – 1981) – fuse box diagram

Year of production: 1977, 1978, 1979, 1980, 1981

Fuse box diagram

№	A	Protected Component
1	20	Hazard warning lights
2	20	Speed control, heated rear window and cornering lights
3	30	Circuit Breaker: Power windows and moon roof
4	20	Heater and air conditioning blower motor
	30	Automatic temperature control and heater blower motor
5	20	Cluster, parking, tail, license, side marker lights, map, dome, trunk and opera lights, search tune radio and cassette lights
6	20	Map, glove box, door ajar, courtesy, vanity, reading and stop lights, seat belt, key and headlight warning buzzer, ignition delay relay, power door lock relay, chimes and illuminated entry
7	20	Horn, horn relay, stop lights, clock feed, search tune radio memory, glove box light, power antenna and cigar lighter
8	30	Circuit Breaker: Power door locks and power seats
9	—	—
10	—	—
11	5	Brake warning, oil pressure, door ajar, seat belt lights, seat belt buzzer, gauges, voltage limiter, tailgate and low washer fluid light
12	—	—
13	3	Cluster, parking brake, radio, digital clock, heated rear window, air conditioning or ATC heater control, cigar lighter and ash tray lights, search tune and CB radio display dimming
14	6	Circuit Breaker: Rear wiper/washer, liftgate relay and deck lid release solenoid
15	5	Power antenna controller, radio and digital clock display
16	20	Back-up and turn signal lights, idle stop solenoid and air conditioning clutch
Circuit Breaker: Headlights — Circuit breaker integral with the headlight switch to protect the headlight circuit Windshield Wipers — Circuit breaker integral with the wiper switch to protect the circuit Vanity Mirror — 1.5 amp. breaker located on the visor to protect the mirror circuit Power Sun Roof — 15 amp. breaker located in the left side cowl to protect the roof system

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Dodge St. Regis (1979 – 1981) – fuse box diagram

Posted on 14 October 2019 by admin

Dodge St. Regis (1979 – 1981) – fuse box diagram

Year of production: 1979, 1980, 1981

Fuse box diagram

№	A	Protected Component
1	20	Hazard lights
2	20	Circuit Breaker: Passenger side power seat motors
3	30	Circuit Breaker: Power window motors, power sun roof motor and illuminated entry sense
4	30	Air conditioning and heater blower motor, heated rear window relay and deck lid release solenoid
5	20	Parking, side marker, tail, license opera, clock and radio display lights
6	20	Horn, horn relay, power antenna, cigar lighter, glove box light
7	20	Horn, horn relay, cigar lighter, power antenna and glove box light, stop lights, clock feed and radio memory
8	30	Circuit Breaker: Power seats and door locks
9	20	Spot light for fleet vehicles
10	20	Spot light for fleet vehicles
11	5	Brake warning, oil pressure, low fuel light, voltage limiter, fuel and temperature gauges, radio capacitor, fleet oil gauge, seat belt and door ajar lights, chimes and speed control
12	20	Under panel light, door courtesy lights, reading light, cigar lighter, door lock relay and illuminated entry
13	4	Cluster, radio, air conditioning and heater lights, cigar lighter, ash tray light, hood and parking brake lights, heated rear window lights and digital clock display control
14	20	Power amplifier
15	5	Radio, power antenna control, electronic clock display
16	20	Turn signal, back-up and cornering lights, air conditioning clutch and slow idle solenoid
Circuit Breaker: Headlights — Circuit breaker integral with the headlight switch to protect the headlight circuit Windshield Wipers — Circuit breaker integral with the wiper switch to protect the circuit Concealed Headlight Doors — 5 amp. breaker in the relay to protect the system Vanity Mirror — 1.5 amp. breaker located on the visor to protect the mirror circuit. Power Sun Roof — 15 amp. breaker located in the left side cowl to protect the roof system

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Plymouth Gran Fury (1979 – 1981) – fuse box diagram

Posted on 14 October 2019 by admin

Plymouth Gran Fury (1979 – 1981) – fuse box diagram

Year of production: 1979, 1980, 1981

Fuse box diagram

№	A	Protected Component
1	20	Hazard lights
2	20	Circuit Breaker: Passenger side power seat motors
3	30	Circuit Breaker: Power window motors, power sun roof motor and illuminated entry sense
4	30	Air conditioning and heater blower motor, heated rear window relay and deck lid release solenoid
5	20	Parking, side marker, tail, license opera, clock and radio display lights
6	20	Horn, horn relay, power antenna, cigar lighter, glove box light
7	20	Horn, horn relay, cigar lighter, power antenna and glove box light, stop lights, clock feed and radio memory
8	30	Circuit Breaker: Power seats and door locks
9	20	Spot light for fleet vehicles
10	20	Spot light for fleet vehicles
11	5	Brake warning, oil pressure, low fuel light, voltage limiter, fuel and temperature gauges, radio capacitor, fleet oil gauge, seat belt and door ajar lights, chimes and speed control
12	20	Under panel light, door courtesy lights, reading light, cigar lighter, door lock relay and illuminated entry
13	4	Cluster, radio, air conditioning and heater lights, cigar lighter, ash tray light, hood and parking brake lights, heated rear window lights and digital clock display control
14	20	Power amplifier
15	5	Radio, power antenna control, electronic clock display
16	20	Turn signal, back-up and cornering lights, air conditioning clutch and slow idle solenoid
Circuit Breaker: Headlights — Circuit breaker integral with the headlight switch to protect the headlight circuit Windshield Wipers — Circuit breaker integral with the wiper switch to protect the circuit Concealed Headlight Doors — 5 amp. breaker in the relay to protect the system Vanity Mirror — 1.5 amp. breaker located on the visor to protect the mirror circuit. Power Sun Roof — 15 amp. breaker located in the left side cowl to protect the roof system

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Chrysler Newport (1979 – 1981) – fuse box diagram

Posted on 14 October 201914 October 2019 by admin

Chrysler Newport (1979 – 1981) – fuse box diagram

Year of production: 1979, 1980, 1981

Fuse box diagram

№	A	Protected Component
1	20	Hazard lights
2	20	Circuit Breaker: Passenger side power seat motors
3	30	Circuit Breaker: Power window motors, power sun roof motor and illuminated entry sense
4	30	Air conditioning and heater blower motor, heated rear window relay and deck lid release solenoid
5	20	Parking, side marker, tail, license opera, clock and radio display lights
6	20	Horn, horn relay, power antenna, cigar lighter, glove box light
7	20	Horn, horn relay, cigar lighter, power antenna and glove box light, stop lights, clock feed and radio memory
8	30	Circuit Breaker: Power seats and door locks
9	20	Spot light for fleet vehicles
10	20	Spot light for fleet vehicles
11	5	Brake warning, oil pressure, low fuel light, voltage limiter, fuel and temperature gauges, radio capacitor, fleet oil gauge, seat belt and door ajar lights, chimes and speed control
12	20	Under panel light, door courtesy lights, reading light, cigar lighter, door lock relay and illuminated entry
13	4	Cluster, radio, air conditioning and heater lights, cigar lighter, ash tray light, hood and parking brake lights, heated rear window lights and digital clock display control
14	20	Power amplifier
15	5	Radio, power antenna control, electronic clock display
16	20	Turn signal, back-up and cornering lights, air conditioning clutch and slow idle solenoid
Circuit Breaker: Headlights — Circuit breaker integral with the headlight switch to protect the headlight circuit Windshield Wipers — Circuit breaker integral with the wiper switch to protect the circuit Concealed Headlight Doors — 5 amp. breaker in the relay to protect the system Vanity Mirror — 1.5 amp. breaker located on the visor to protect the mirror circuit. Power Sun Roof — 15 amp. breaker located in the left side cowl to protect the roof system

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Chrysler New Yorker (1979 – 1981) – fuse box diagram

Posted on 14 October 2019 by admin

Chrysler New Yorker (1979 – 1981) – fuse box diagram

Year of production: 1979, 1980, 1981

Fuse box diagram

№	A	Protected Component
1	20	Hazard lights
2	20	Circuit Breaker: Passenger side power seat motors
3	30	Circuit Breaker: Power window motors, power sun roof motor and illuminated entry sense
4	30	Air conditioning and heater blower motor, heated rear window relay and deck lid release solenoid
5	20	Parking, side marker, tail, license opera, clock and radio display lights
6	20	Horn, horn relay, power antenna, cigar lighter, glove box light
7	20	Horn, horn relay, cigar lighter, power antenna and glove box light, stop lights, clock feed and radio memory
8	30	Circuit Breaker: Power seats and door locks
9	20	Spot light for fleet vehicles
10	20	Spot light for fleet vehicles
11	5	Brake warning, oil pressure, low fuel light, voltage limiter, fuel and temperature gauges, radio capacitor, fleet oil gauge, seat belt and door ajar lights, chimes and speed control
12	20	Under panel light, door courtesy lights, reading light, cigar lighter, door lock relay and illuminated entry
13	4	Cluster, radio, air conditioning and heater lights, cigar lighter, ash tray light, hood and parking brake lights, heated rear window lights and digital clock display control
14	20	Power amplifier
15	5	Radio, power antenna control, electronic clock display
16	20	Turn signal, back-up and cornering lights, air conditioning clutch and slow idle solenoid
Circuit Breaker: Headlights — Circuit breaker integral with the headlight switch to protect the headlight circuit Windshield Wipers — Circuit breaker integral with the wiper switch to protect the circuit Concealed Headlight Doors — 5 amp. breaker in the relay to protect the system Vanity Mirror — 1.5 amp. breaker located on the visor to protect the mirror circuit. Power Sun Roof — 15 amp. breaker located in the left side cowl to protect the roof system

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
