Audi 100 (1992) – fuse box diagram

Posted on 21 March 201927 March 2019 by admin

Audi 100 (1992) – fuse box diagram

Year of production: 1992, 1993, 1994

Instrument panel fuses box

Audi 100 - fuse box diagram - instrument panel — Audi 100 – fuse box diagram – instrument panel

№	A	Description
1	15	Rear fog lights
2	15	Emergency flash switch, anti-theft system (USA only)
3	25	Horns, brake lights switch
4	15	Luggage compartment, light, cigar lighter, interior lights
5	30	Not used
6	5	Tail lights, side marker light, RF
7	5	Tail lights, side marker light, LF
8	10	Headlight, hi-beam, right
9	10	Headlight, hi beam, left
10	10	Headlight, lo beam, right
11	10	Headlight, lo beam, left
12	15	Automatic transmission, backup lights, interior lights
13	15	Fuel pump
14	5	License plate lights, glove compartment light, engine compartment light, center console
15	25	Wipers/washer
16	30	Rear defogger
17	30	Fresh air fan, air conditioning
18	5	Power mirror switch
19	10	Central locking system, anti-theft system (USA only)
20	30	Heated seats
21	25	Fuel injection control unit, diagnostic
22	—	Open
23	—	Open
24	—	Open
25	—	Open
26	5	Speedometer, power mirrors
27	10	Ignition control unit
28	15	Fuel injection control unit, electronic engine cintrol
29	—	Open
30	5	Automatic transmission

№	Description
1	Rear fog light jumper plug
2	Rad. cooling fan relay 2nd stage
3	Rad. cooling fan relay after run control unit
4	Open
5	Load reduction relay
6	Open
7	Horn relay
8	Automatic transmission/anti-theft relay
9	Wash/wiper intermit, relay
10	Fuel pump relay, J17
11	Open

№	Description	Color
A	Air conditioning connector	Gray
B	Right front wiring harness connector	Black
C	Instrument panel connector	Blue
D	Left front wiring harness connector	Green
E	Left front wiring harness connector	Yellow
F	Instrument panel connector	Brown
G	Instrument panel connector	Red
H	Rear wiring harness connector	Black
I	Instrument panel connector	Red
J	Instrument panel connector	Yellow
K	—	—
L	Single connector (terminal 30) connector	Colorless
M	For optional equipment connector	Colorless
N	—	—
O	—	—
P	To fuse 26	—

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Skoda Fabia (2004 – 2005) – fuse box diagram

Posted on 12 March 201912 March 2019 by admin

Skoda Fabia (2004 – 2005) – fuse box diagram

Year of production: 2004, 2005

Engine Compartment Fuse Box

№	A	Protected Component
1	175	Dynamo
2	110	Interior
3	50	Power steering
4	40	Glow plugs
5	40	The radiator fan
6	40	ABS or TCS or ESP
7	25	ABS or TCS or ESP
8	30	The radiator fan
9	—	—
10	5	Central control unit
11	5	The air conditioning system
12	—	—
13	15	Engine Control Module (ECM), Electronic Throttle Control
14	—	—
15	—	—
16	—	—

Dash panel fuse box

Skoda Fabia - fuse box diagram - dash panel — Skoda Fabia – fuse box diagram – dash panel

№	A	Protected Component
1	5	Instrument cluster, ESP
2	10	Brake lights
3	5	Power supply for the diagnostics, air-conditioning system
4	10	Interior lighting
5	5	Door warning light
6	5	Lights and Visibility
7	5	Engine electronics, power-assisted steering
8	—	—
9	10	Lambda probe
10	5	S-contact a)
11	5	Electrically adjustable rear mirror b)
12	5	Ventilation system, air-conditioning system, Xenon headlight
13	10	Reversing light
14	10	Diesel engine control unit
15	10	Headlight cleaning system, window wiper
16	5	Instrument cluster
17	5	Petrol engine – control unit c)
18	5	Telephone
19	10	Automatic gearbox
20	5	Control unit for lamp failure
21	5	Heated windscreen washer nozzles
22	—	—
23	10	Right main beam
24	10	Engine electronics
25	5	Control unit for ABS, TCS
	10	Control unit for ESP
26	—	—
27	—	—
28	5	Cruise control, switch for the brake and clutch pedal
29	—	—
30	10	Main beam on the left and indicator light
31	10	Central locking system – door lock for the boot lid
32	10	Rear window wiper
33	5	Parking light on the right
34	5	Parking light on the left
35	10	Injector – petrol engine
36	5	Licence plate light
37	5	Rear fog light and indicator light
38	5	Heating of the external mirror
39	20	Rear window heater
40	20	Horn
41	20	Front window wiper
42	15	Cigarette lighter, power socket
43	20	Central control unit, selector lever lock for the automatic gearbox
44	15	Turn signals
45	20	Radio, navigation system
46	25	Electrical power window (at the front on the right)
47	—	—
48	30	Diesel engine – control unit, injector
49	15	Central locking system
50	15	Low beam on the right
51	15	Power socket in the luggage compartment
52	15	Ignition
53	25	Electrical power window (at the rear on the right)
54	15	Low beam on the left
55	—	—
56	20	Control unit – petrol engine
57	25	Towing device
58	25	Electrical power window (at the front on the left)
59	—	—
60	15	Horn for the anti-theft alarm system
61	15	Fuel pump – petrol engine
62	25	Electric sliding/tilting roof
63	15	Seat heaters
64	20	Headlight cleaning system
65	15	Fog lights
66	25	Electrical power window (at the rear on the left)
67	—	—
68	25	Fresh air blower
a) For power consumers, e.g. the radio, which can be operated with the ignition switched off as long as the ignition key is not withdrawn. b) For vehicles with an electrical power window system c) It is 15 amps for a vehicle with a 1.2 litre engine.

<br />

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Chevrolet Impala (2006 – 2013) – fuse box diagram

Posted on 10 March 2019 by admin

Chevrolet Impala (2006 – 2013) – fuse box diagram

Year of production: 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013

Engine Compartment Fuse Box

Chevrolet Impala - fuse bpx diagram - engine compartment — Chevrolet Impala – fuse bpx diagram – engine compartment

№	A	Protected Component
1	10	Power Drop, Crank
2	15	except 3.6L: Fuel Pump and Sender Assembly
3	10	Body Control Module (BCM), Ignition Switch, Theft Deterrent Module (TDM)
4	10	Body Control Module (Interior Lamps)
5	10	Instrument Panel Cluster (IPC), HVAC Control Module, Inflatable Restraint Passenger Air Bag On/Off Indicator, Inflatable Restraint Sensing and Diagnostic Module (SDM)
6	10	Body Control Module (Back-Up Lamp, Center High Mount Stop Lamp)
7	15	Body Control Module (Interior Lamps, Panel Dimmer Switch)
8	2	Steering Wheel Controls
9	10	–
10	10	Data Link Connector (DLC), Remote Control Door Lock Receiver (RCDLR), Instrument Panel Cluster (IPC), HVAC Control Module
11	10	Vehicle Communication Interface Module (VCIM (OnStar))
12	–	–
13	15	Engine Control Module (ECM), Electronic Throttle Control
14	10	A/C Compressor Clutch
15	20	3.5L (LZE, LZ4), 3.9L (LZ9, LZG, LGD, LZG): Fuel Injectors
	20	5.3L (LS4): Fuel Injectors (1-3-5-7), Ignition Coils (1-3-5-7)
	15	3.6L (LFX): Fuel Injectors
16	15	Secondary Air Injection Pump Solenoid Relay
17	15	Engine Control Module (ECM), Transmission ControlModule (TCM)
18	10	Transmission
19	15	Heated Oxygen Sensors, Evaporative Emission (EVAP) Canister Purge Solenoid Valve
20	25	–
21	10	Engine Control Module (ECM), Ignition
22	20	3.5L (LZE, LZ4), 3.9L (LZ9, LZG, LGD, LZG): Ignition Control Module
	20	5.3L (LS4): Fuel Injectors (2-4-6-8), Ignition Coils (2-4-6-8)
	15	3.6L (LFX): Ignition Control Module
23	20	–
24	15	Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor, Valve Lifter Oil Manifold (VLOM) Assembly, Secondary Air Injection (AIR) Pump Relay (SS), Secondary Air Injection (AIR) Solenoid Relay (SS), A/C Compressor Clutch Relay, Cooling Fan Relay No.1, Cooling Fan Relay No.2, Cooling Fan Relay No.3
25	20	3.6L (LFX): Brake Booster Pump (Vacuum Pump)
26	25	Wiper
27	10	Heated Mirror
28	15	Right Spot Lamp
29	25	Accessory Power Outlets
30	10	Body Control Module (Regulated Voltage Control Sensor)
31	15	Body Control Module (Passenger Side Turn Signal Lamp)
32	10	Driver Side Parking Lamp (Marker, Park/Turn Signal Lamp, Tail Lamp, Tail/Stop and Turn Signal)
33	15	Left Spot Lamp
34	30	–
35	20	Radio
36	15	Body Control Module (Driver Side Turn Signal Lamp)
37	10	Passenger Side Parking Lamp (Marker, Park/Turn Signal Lamp, Tail Lamp, Tail/Stop and Turn Signal)
38	15	–
39	15	3.6L (LFX): Fuel System Control Module
40	10	Left Headlamp (Low Beam)
41	15	Headlamp Module
42	15	except 3.6L: Windshield Washer Fluid Pump
43	15	Daytime Running Lamps
44	10	Right Headlamp (Low Beam)
45	15	Daytime Running Lamps
46	15	Front Fog Lamps
47	10	Left Headlamp (High Beam)
48	15	3.6L (LFX): Windshield Washer Fluid Pump
49	15	Horn
50	10	Right Headlamp (High Beam)
51	30	Blower Motor Control Module
52	60	Passenger Compartment Fuse Box
53	60	Antilock Brake System (ABS) Motor
54	40	Starter
55	60	Secondary Air Injection Pump Relay
56	60	Antilock Brake System (ABS) Motor
57	40	Rear Window Defogger
58	60	Passenger Compartment Fuse Box
59	30	Cooling Fan Relay No.1
60	30	Cooling Fan Relay No.2, Cooling Fan Relay No.3
61	50	–
Relay
R1	except 3.6L: Fuel Pump
R1	3.6L (LFX): Brake Booster Pump (Vacuum Pump)
R2	A/C Compressor
R3	Starter
R4	Powertrain Control Module (PCM) / Engine Control Module (ECM)
R5	Rear Window Defogger
R6	–
R7	Cooling Fan (No.3)
R8	Cooling Fan (No.2)
R9	Cooling Fan (No.1)
Non-Serviceable
R10	Ignition
R11	Parking Lamps
R12	Wiper
R13	Wiper (High Speed)
R14	Headlamp (Low Beam)
R15	Daytime Running Lamps
R16	Headlamp (High Beam)
R17	Windshield Washer Fluid Pump
R18	Front Fog Lamps
R19	Horn

Passenger Compartment Fuse Box

Chevrolet Impala - fuse bpx diagram - passenger compartment — Chevrolet Impala – fuse bpx diagram – passenger compartment

№	A	Protected Component
1	10	’09 Automatic Transmission Shift Lock Control Solenoid (with Floor Shifter), Inside Rearview Mirror, Sunroof Motor
2	25	Audio Amplifier
3	10	Evaporative Emission (EVAP) Canister Vent Solenoid
4	10	’09 Rear Compartment Lid Release Actuator
5	20	Accessory Power Outlet – (Center Seat, Center Console 1, Center Console 2, Center Console Compartment)
6	10	Digital Radio Receiver
7	10	Inflatable Restraint Sensing and Diagnostic Module (SDM), Inflatable Restraint Front Passenger Presence System (PPS) Module
8	20	Heated Seat Control Module, Emergency Vehicle Rear Compartment Lid Lamps Relay
9	20	Sunroof Motor
10	2	Outside Rearview Mirror Switch
11	15	–
12	25	Door Locks
Circuit Breaker
CB1	25	Power Window
CB2	25	Power Seats
Relay
R2	Rear Compartment Lid Release Actuator
Non-Serviceable
R1	Accessory
R3	Power Door Lock (Lock)
R4	Driver Door Lock Actuator (Unlock)
R5	Power Door Lock (Unlock)

<br />

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Buick Lacrosse (2010 – 2016) – fuse box diagram

Posted on 10 March 201910 March 2019 by admin

Buick Lacrosse (2010 – 2016) – fuse box diagram

Year of production: 2010, 2011, 2012, 2013, 2014, 2015, 2016

Passenger Compartment Fuse Box

Buick LaCrosse - fuse box diagram - passenger compartment — Buick LaCrosse – fuse box diagram – passenger compartment

№	A	Protected Component
1	2	Steering Wheel Control Switch
2	15	Body Control Module (BCM)
3	15	Body Control Module (BCM)
4	15	Audio System
5	7.5	Vehicle Communications Interface Module (VCIM)
6	20	Accessory Power Outlet (Center Console 1)
7	20	Accessory Power Outlet (Center Console 2)
8	15	Body Control Module (BCM)
9	15	Body Control Module (BCM)
10	30	Body Control Module (BCM)
11	40	HVAC Control Module
12	25	Circuit Breaker: Passenger Seat
13	25	Circuit Breaker: Driver Seat, Seat Memory Control Module
14	7.5	Data Link Connector
15	10	Inflatable Restraint Sensing and Diagnostic Module (SDM)
16	10	Rear Compartment Lid Latch
17	10	HVAC Control Module
18	25	Audio System
19	10	Head Up Display (HUD), Info Display Module, Multimedia Player Interface Module, Radio/HVAC Control
20	5	Inflatable Restraint Passenger Presence System (PPS) Module
21	5	Instrument Panel Cluster (IPC)
22	2	Ignition Switch
23	15	Body Control Module (BCM)
24	15	Body Control Module (BCM)
25	–	–
26	30	Accessory AC/DC Power Control Module
Relay
R1	Accessory
R2	–
R3	Rear Compartment Lid Unlatch

Engine Compartment Fuse Box

Buick LaCrosse - fuse box diagram - engine compartment — Buick LaCrosse – fuse box diagram – engine compartment

№	A	Protected Component
1	15	Transmission Control Solenoid Valve Assembly
2	5	Engine Control Module (ECM)
3	10	’14: A/C Compressor Clutch
4	–	–
5	5	Engine Control Module (ECM)
6	30	Windshield Wiper Motor
7	–	–
8	15	3.0L (LF1), 3.6L (LLT, LFX): Ignition Coils, Engine Control Module (ECM)
9	15	3.0L (LF1), 3.6L (LLT, LFX), 2.4L (LUK): Ignition Coils, Engine Control Module (ECM)
10	20	Engine Control Module (ECM)
11	10	3.0L (LF1), 3.6L (LLT, LFX): Heated Oxygen Sensors
11	10	3.6L (LFX): Heated Oxygen Sensors, Mass Air Flow (MAF) Sensor/Intake Air Temperature (IAT) Sensor, Fuel Composition Sensor
12	30	Starter Motor
13	7.5	Fuel Pump Flow Control Module, Transmission Control Solenoid Valve Assembly
14	5	2.4L (LUK – Hybrid): Heater Coolant Pump
15	10	2.4L (LUK – Hybrid): Starter/Generator Control Module
16	7.5	3.6L (LLT): Mass Air Flow (MAF) Sensor/Intake Air Temperature (IAT) Sensor
17	5	Inflatable Restraint Sensing and Diagnostic Module (SDM)
18	–	–
19	–	–
20	–	–
21	30	Window Switch (Left Rear/Right Rear)
22	30	Sunroof Control Module, Sunroof Sunshade Motor Module
23	10	Power Steering Control Module
23	7.5	2.4L (LUK – Hybrid): Hybrid/EV Battery Pack
24	30	“14: Window Switch (Left Front/Right Front)
25	–	–
26	60	ABS
27	30	Parking Brake Control Module
28	40	Rear Window Defogger
29	15	Seat Lumbar Adjuster Switch – Driver
30	15	2.4L (LUK -Hybrid): Hybrid/EV Battery Pack Cooling Fan
31	–	–
32	15	Body Control Module (BCM)
33	25	Heated Seat Control Module
33	25	Memory Seat Module
34	25	ABS
35	30	Audio Amplifier
36	10	Adaptive Forward Lighting (AFL)
37	10	Right Headlamp (High Beam), High Beam Solenoid Actuator (Right)
38	10	Left Headlamp (High Beam), High Beam Solenoid Actuator (Left)
39	–	–
40	–	–
41	20	Brake Booster Pump Motor
42	30	Cooling Fan Motor (Right)
43	–	–
44	30	2.4L (LUK -Hybrid): Transmission Fluid Pump
45	30	Cooling Fan Motor (Left)
46	10	Cooling Fan Low Speed Relay, Cooling Fan Left High Speed Relay
47	10	2.4L (LAF), 3.0L (LF1), 2.4L (LUK): Heated Oxygen Sensors, Mass Air Flow (MAF) Sensor/Intake Air Temperature (IAT) Sensor
	10	3.6L (LLT): Camshaft Position (CMP) Actuators
	10	3.6L (LFX): Heated Oxygen Sensor, Multifunction Intake Air Sensor, Evaporative Emission Purge Solenoid Valves
48	15	Front Fog Lamps
49	15	Right Headlamp (Low Beam)
50	15	Left Headlamp (Low Beam)
51	15	Horn
52	5	Instrument Panel Cluster (IPC)
53	10	Air Quality Sensor, Brake Booster Vacuum Switch, Inside Rearview Mirror, Rearview Camera, Active Grille Air Shutter Actuator
54	5	HVAC Control Module
55	7.5	Outside Rearview Mirror Switch, Window Switch (Driver/Passenger Side), Garage Door Opener
56	15	Windshield Washer Fluid Pump
57	–	–
58	–	–
59	50	Secondary Air Injection Pump
60	7.5	Heated Mirror
61	–	–
62	10	Evaporative Emission (EVAP) Canister Vent Solenoid Valve
63	–	–
64	5	Headlamp Control Module
65	–	–
66	15	Secondary Air Injection Pressure Sensor
67	20	Fuel Pump Flow Control Module
68	–	–
69	5	Body Control Module (BCM)
70	5	Side Object Sensor (Left/Right), Rear Parking Assist Control Module
71	–	–
Relay
R1	Air Conditioning Compressor Clutch
R2	Starter
R3	–
R4	Front Wiper (Speed Control)
R5	Front Wiper (On/Off)
R6	2.4L (LUK -Hybrid): Heater Coolant Pump
R7	Engine Control Module (ECM)
R8	–
R9	Cooling Fan Right (High Speed)
R10	Cooling Fan (Low Speed)
R11	2.4L (LUK -Hybrid): Transmission Fluid Pump
R12	–
R13	Cooling Fan Left (High Speed)
R14	Low Beam
R15	Ignition
R16	Secondary Air Injection Pump
R17	Rear Window Defogger
Relay (Non-Serviceable)
R18	Horn
R19	Windshield Washer Pump
R20	Front Fog Lamp
R21	High Beam
R22	Door Locks
R23	2.4L (LUK – Hybrid): Starter/Generator Control Module

Fusible Link Block

Buick LaCrosse - fuse box diagram - fuseible link block — Buick LaCrosse – fuse box diagram – fuseible link block

No.	A	Circuit Protected
1	100	Fuse Block (Instrument Panel)
2	100	Fuse Block (Instrument Panel)
3	100	Fuse Block (Rear Left)
4	100	Fuse Block (Rear Left)
5	250	Fuse Block (Underhood)
6	300	Starter Motor

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Honda Accord (1998 – 2003) – fuse box diagram

Posted on 7 March 20197 March 2019 by admin

Honda Accord (1998 – 2003) – fuse box diagram

Year of production: 1998, 1999, 2000, 2001, 2002, 2003

Engine compartment

The under-hood fuse box is located in the back of the engine compartment on the passenger’s side.

Fuse name	[A]	Description
R1	—	Headlamp relay – RH
R2	—	Headlamp relay – LH
R3	—	Horn relay
R4	—	Heater blower relay
R5	—	–
R6	—	AC condenser blower motor relay
R7	—	Engine coolant blower motor relay
R8	—	AC compressor clutch relay
F41	100	Battery
F42	50	Ignition switch
F43	20	Headlamp high beam warning lamp, headlamp washers, RH headlamp
F44	7,5	Headlamp high beam relay (with daytime running lamps)
F45	20	Headlamp adjustment (with gas discharge headlamps), headlamp high beam warning lamp, LH headlamp
F46	15	Datalink connector (DLC), engine management
F47	15	Alarm system horn, anti-lock brake system (ABS), cruise control, engine management, horn, ignition key interlock solenoid (AT), ignition switch illumination, stop lamps
F48	20	Anti-lock brake system (ABS)
F49	10	Indicators/hazard warning amps
F50	40	Anti-lock brake system (ABS)
F51	40	Fuse box/relay plate-fascia 2/Power Window Motor
F52	30	Fuse box/relay plate-fascia 2
F53	30	Heated rear window
F54	40	Fuse box/relay plate-fascia 2
F55	30	Fuse box/relay plate-fascia 2
F56	40	Heater blower motor
F57	20	Engine coolant blower motor
F58	20	AC compressor clutch, AC condenser blower motor
F59	15	Daytime running lamps, instrument illumination, licence plate lamps, side/tail lamps
F60	—	–
F61	—	–
F62	—	–

Passenger compartment fuse panel

The interior fuse boxes are located on each side of the dashboard. To open an interior fuse box, open the car door.

Driver’s side

Honda Accord - fuse box - interior compartment box — Honda Accord – fuse box – interior compartment box

Number	[A]	Description
1	—	Indicator relay/hazard warning lamps relay
2	—	Reversing lamp/s relay
3	—	Starter motor relay
4	—	Multifunction control module 1
F1	15	Airbag, engine management
F2	10	Airbag
F3	7,5	AC condenser blower motor, engine coolant blower motor, heater/air conditioning (AC)
F4	7,5	Electric door mirrors, heated seats
F5	10	Anti-lock brake system (ABS)
F5	7,5	IG2 Day Light
F6	15	Alternator, engine management, engine mounting control solenoid, cruise control
F7	7,5	Headlamp adjustment, sunroof, multifunction control module 1, rear screen wash/wipe system
F8	7,5	Navigation system, transmission park position inter lock solenoid, multifunction control module 1 (AT), ACC
F9	7,5	Central locking, clock, instrument panel, multifunction control module 1, reversing lamps (MT)
F10	7,5	Indicators/hazard warning amps, Turn Signals
F11	7,5	Ignition coil
F12	30	Multifunction control module1, windscreen wipers
F13	7,5	Engine management (except 1,6)

Passenger’s side

Identifying fuse box type No 1

Number	[A]	Description
1	30 A	Moonroof
2	20 A	Driver Power Seat Recline
3	20 A	Assistant Power Seat Recline
4	20 A	Driver Power Seat Slide
5	20 A	Assistant Power Seat Slide
6	10 A	Daytime Running Light*
7	20 A	Rear Left Power Window
8	20 A	Front Right Power Window
9	20 A	Radio, Cigarette Lighter
10	10 A	Small Lights
11	7.5 A	Interior Light, Courtesy Lights
12	20 A	Power Door Locks
13	7.5 A	Clock
14	7.5 A	ABS Motor Check
15	20 A	Front Left Power Window
16	20 A	Rear Right Power Window
R1	—	AC diode
R2	—	Heated rear window relay
R3	—	Cigarette lighter relay
R4	—	Electric windows relay
R5	—	Multifunction control module 2

Identifying fuse box type No 2

Number	[A]	Description
1	—	A diode
2	—	Heated rear window relay
3	—	Cigarette lighter relay
4	—	Electric windows relay
5	—	Multifunction control module2
F1	20	Electric windows
F2	20	Electric seats
F3	30	Headlamp washers
F4	20	Electric seats
F5	20	Fog lamps, multifunction control module2
F6	7,5	1,6 Engine control module(ECM)
F7	20	Electric window motor, rear left
F8	20	Electric window motor, front right
F9	15	Audio system, cigarette lighter
F10	20	Audio unit output amplifier
F11	7,5	Electric aerial, interior lamps
F12	20	Central locking, multifunction control module 2
F13	7,5	Engine control module(ECM), clock, heater/air-conditioning (AC), immobilizer warning lamp, multifunction control module2, navigation system
F14	20	Heated seats
F15	30	Sunroof
F16	20	Electric window motor, rear right

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Hyundai Nexo (2018 – 2019) – fuse box diagram

Posted on 6 January 201916 July 2019 by admin

Hyundai Nexo (2018 – 2019) – fuse box diagram

Year of production: 2018, 2019

Instrument panel

Fuse name	[A]	Protected component
MEMORY1	10	Power Tail Gate Module, A/C Control Module, A/C Control Panel
MODULE1	10	ICM Relay Box (Outside Mirror Folding/Unfolding Relay), A/V & Navigation Head Unit (Hazard Lamp Switch), Shift Selection Switch (SBW), Auto Light & Photo Sensor, Driver/Passenger Power Outside Mirror, Instrument Cluster
TAIL GATE OPEN	10	Tail Gate Relay
P/WINDOW RH	25	Power Window RH Relay
P/WINDOW LH	25	Power Window LH Relay, Driver Safety Window Module
P/SEAT DRV	25	Driver Seat Manual Switch
MODULE4	7,5	IBU, Remote Control Smart Parking Assist Unit, VESS Unit, Electronic Parking Brake Switch, Lane Keeping Assist Unit(Line), Blind-Spot Collision Warning Unit LH/RH, Crash Pad Switch, PE Room Junction Block (Multipurpose Check Connector
MODULE8	7,5	Data Link Connector, Crash Pad Switch, Electro Chromic Mirror
S/HEATER RR	20	Rear Seat Heater
HEATED MIRROR	10	Driver/Passenger Power Outside Mirror, A/C Control Panel
S/HEATER FRT	20	Front Air Ventilation/Seat Heater Seat Control Module
AMP	25	AMP
MULTI MEDIA	15	A/V & Navigation Head Unit, Center Fascia Switch Panel
MODULE5	10	Front Air Ventilation/Seat Heater Seat Control Module, AMP, A/V & Navigation Head Unit, A/C Control Panel, PTC Heater, A/C Control Module, Electro Chromic Mirror, Rear Seat Heater
WIPER (RR)	15	ICM Relay Box (Rear Wiper Relay), Rear Wiper Motor
DOOR LOCK	20	Door Lock Relay, Door Unlock Relay, ICM Relay Box (Two Turn Door Unlock Relay)
IBU1	15	IBU
BRAKE SWITCH	10	IBU, Stop Lamp Switch
P/SEAT PASS	25	Passenger Seat Manual Switch
A/C	7,5	A/C Control Module, Incar Temperature Sensor, A/C Control Panel, Cluster Ionizer, A/C Compressor, PE Room Junction Block (Blower Relay)
AIR BAG2	10	SRS Control Module
WASHER	15	Multifunction Switch
MDPS	7,5	MDPS Unit
MODULE7	7,5	Front Air Ventilation/Seat Heater Seat Control Module, AC Inverter, Rear Seat Heater, Surround View Monitor Unit, Rear Power Outlet
SUNROOF2	20	Sunroof Unit
SUNROOF1	20	Sunroof Unit
CLUSTER	7,5	Instrument Cluster
MODULE3	7,5	SCU, Shift Selection Switch (SBW), IDC, VPD Sensor, Stop Lamp Switch, HMU, BMS Control Module
START	7,5	FCU, IBU
IBU2	7,5	IBU
A/BAG IND	7,5	Instrument Cluster, A/C Control Panel
MODULE6	7,5	IBU
MODULE2	10	BMS Control Module, Wireless Charger, USB Charger LH/RH, A/V & Navigation Head Unit, Center Fascia Switch Panel, AMP, Surround View Monitor Unit, Power Outside Mirror Switch, IBU
AIR BAG1	15	SRS Control Module, Passenger Occupant Detection Sensor

Fuel cell power module compartment fuse panel

Hyundai Nexo - fuse box diagram - engine compartment — Hyundai Nexo – fuse box diagram – engine compartment

Type	Fuse name	[A]	Circuit protected
MULTI FUSE-1	B+2	60	ICU Junction Block (IPS Control Module, IPS1)
	B+3	60	ICU Junction Block (IPS Control Module)
	COOLING PE PUMP	40	PE Room Coolant Pump (CPP)
	EPB2	40	Electronic Brake Control Module
	IG2	40	PE Room Junction Block (IG2 Relay)
	EPB1	40	Electronic Brake Control Module, PE Room Junction Block (Multipurpose Check Connector)
	B+4	60	ICU Junction Block (Fuse – SUNROOF1, SUNROOF2, AMP, P/SEAT DRV, P/SEAT PASS, S/HEATER FRT, P/WINDOW LH, P/WINDOW RH, TAIL GATE OPEN)
	IMEB	80	Electronic Brake Control Module
MULTI FUSE-2	BLOWER	50	PE Room Junction Block (Blower Relay)
MULTI FUSE-2	MDPS	80	MDPS Unit
FUSE	HVJB LV	15	HV Junction Block
	RCU	15	Driver / Passenger Auto Flush Door Handle Module, Rear Auto Flush Door Handle Module LH/RH
	FUEL DOOR OPEN	7,5	ICM Relay Box (Fuel Filler Door Relay)
	E-SHIFTER	40	PE Room Junction Block (E-Shifter Relay)
	INVERTER	30	AC Inverter
	REAR HEATED	40	PE Room Junction Block (Rear Heated Relay)
	B+1	50	ICU Junction Block ((Fuse – MODULE1, AIR BAG2, MODULE8, S/HEATER RR, DOOR LOCK, IBU1, BRAKE SWITCH), Leak Current Autocut Relay)
	POWER TAIL GATE	30	Power Tail Gate Module
	WIPER FRT	30	Front Wiper Motor
	COOLING STACK PUMP	10	Stack Coolant Pump (CSP)
	INVERTER LV	7,5	Inverter
	BHDC	7,5	IDC
	HMU1	10	HMU
	BATTERY MANAGEMENT	10	BMS Control Module
	FUEL CELL CONTROL UNIT	15	FCU
	BMS FAN	15	PE Room Junction Block (BMS FAN Relay)

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Hyundai Elantra (2019) – fuse box diagram

Posted on 6 January 201916 July 2019 by admin

Hyundai Elantra (2019) – fuse box diagram

Year of production: 2019

Instrument panel

Fuse name	[A]	Protected component
HEATED MIRROR	10	Driver/Passenger Power Outside Mirror, A/C Control Module
WIPER 2	10	PCM, BCM
P/WINDOW RH	25	Power Window RH Relay
P/WINDOW LH	25	Power Window LH Relay, Driver Safety Power Window Module
CLUSTER	10	CLUSTER
DR LOCK	20	Door Lock/Unlock Relay, E/R Junction Block (Two Turn Unlock Relay)
MEMORY 1	10	Driver/Passenger Door Module, Driver IMS Module, A/C Control Module, Instrument Cluster, Electro Chromic Mirror, Data Link Connector, Blind Spot Detection Radar LH/RH, Digital Clock
S/HEATER RR	15	Rear Seat Warmer Control Module
TRUNK	10	Trunk Relay
INTERIOR LAMP	10	Room Lamp, Front Vanity Lamp LH/RH, Overhead Console Lamp, Ignition Key ILL. & Door Warning Switch, Trunk Room Lamp
A/BAG IND	7,5	Instrument Cluster, A/C Control Module
MULTI MEDIA	15	CD Player, Audio, A/V & Navigation Head Unit
MEMORY 2	7,5	—
AMP	25	AMP
P/SEAT DRV	30	Driver Seat Manual Switch, Driver IMS Module
MDPS	7,5	MDPS Unit
MODULE 1	7,5	Key Interlock, Driver/Passenger Smart Key Outside Handle, Driver/Passenger Door Module, BCM, Driver/Passenger Outside Mirror Switch/Motor
SUNROOF	20	Sunroof Moto
SPARE 1	10	—
S/HEATER FRT	20	Front Seat Warmer Control Module
MODULE 7	7,5	Front Seat Warmer Control Module, Rear Seat Warmer Control Module, Sunroof Motor, BCM
PDM 3	7,5	Smart Key Control Module, Immobilizer Module
BRAKE SWITCH	7,5	Stop Lamp Switch, Smart Key Control Module
PDM 2	7,5	Smart Key Control Module, Immobilizer Module
START	7,5	W/O Smart Key : Transmission Range Switch, Ignition Lock Switch With Smart Key :Transmission Range Switch, PCM
A/C	7,5	Ionizer, A/C Control Module, E/R Junction Block (A/Con Relay, Blower Relay), Gasoline PTC Relay
AIR BAG	15	SRS Control Module, Passenger Occupant Detection Sensor
MODULE 3	10	Stop Lamp Switch, BCM, Sport Mode Switch, Driver/Passenger Door Module
IG1	25	PCB Block (Fuse : ABS3, ECU5, TCU2)
PDM 1	15	Smart Key Control Module
HEATED STEERING	15	BCM
MODULE 6	7,5	BCM, Smart Key Control Module
MODULE 5	10	Crash Pad Switch, Electro Chromic Mirror, A/T Shift Lever Indicator, A/V & Navigation Head Unit, Audio, A/C Control Module, Console Switch LH/RH, Head Lamp Leveling Device LH/RH, Front Seat Warmer Control Module, Rear Seat Warmer Control Module, Driver IMS Module
FCA	10	FCA Module
A/CON 2	10	E/R Junction Block (Blower Relay), Blower Motor, Blower Resistor, A/C Control Module
WIPER 1	25	Wiper Motor, PCB Block (Front Wiper (Low) Relay
WASHER	15	Multifunction Switch
MODULE 4	10	Lane keeping Assist System, Parking Assist Buzzer, BCM
SPARE 2	10	—
MODULE 2	10	E/R Junction Block (Power Outlet Relay), USB Charging Connector, Smart Key Control Module, BCM, Audio, A/V & Navigation Head Unit, CD Player, Power Outside Mirror Switch, AMP, Driver Door Module, Digital Clock, Console Switch

Engine compartment

Fuse name		[A]	Protected component
MULTI FUSE-1	MAIN	180	Fuse : ABS1, ABS2, POWER OUTLET
MULTI FUSE-1	MDPS	80	MDPS Unit
MULTI FUSE-2	B+5	60	PCB Block (Fuse : ECU3, ECU4, HORN, A/C COMP, ENGINE CONTROL RELAY)
	B+2	60	Smart Junction Block (Fuse : S/HEATER FRT, ARISU
	B+3	60	Smart Junction Block (Fuse : ARISU, IPS)
	B+4	50	Smart Junction Block (Fuse : S/HEATER RR, P/WINDOW LH, P/WINDOW RH, TRUNK, SUNROOF, AMP, P/SEAT DRV)
	COOLING FAN 1	60	—
	REAR HEATED	50	Rear Heated Relay
	BLOWER	40	Blower Relay
	IG1	40	Ignition Switch, E/R Junction Block (PDM #2, #3 (ACC/IG1) Relay)
	IG2	40	Ignition Switch, E/R Junction Block (PDM #4 (IG2) Relay, START Relay)
FUSE	B/UP LAMP	10	Electro Chromic Mirror, Rear Combination Lamp (IN) LH/RH, Smart Junction Block (IPS Control Module)
	POWER OUTLET 3	20	Cigarette Lighter
	POWER OUTLET 2	20	Front Power Outlet
	H/LAMP HI	10	BI-FUNC H/LP RLY (coil)
	TCU 1	15	—
	VACUUM PUMP 1	20	—
	A/CON	10	A/Con Relay
	COOLING FAN 2	40	Cooling Fan 1/2 Relay
	B+1	40	Smart Junction Block (Leak Current Autocut Device, Fuse : BRAKE SWITCH, MODULE 1, DR LOCK, PDM 1, PDM 2)
	DCT1	40	—
	DCT2	40	—
	S/FUEL PUPMP	15	—
	ABS1	40	ESC Module, Multipurpose Check Connector
	ABS2	30	ESC Module, Multipurpose Check Connector
	POWER OUTLET 1	40	Power Outlet Relay

Fuse name	[A]	Protected component
ECU 5	10	PCM
VACUUM PUMP	15	—
SPARE	20	—
ABS 3	10	ESC Module, Multipurpose Check Connector
TCU 2	15	Transmission Range Switch, E/R Junction Block (Fuse : B/UP LAMP
ECU 4	15	PCM
ECU 3	15	PCM
FUEL PUMP	20	Fuel Pump Relay
SENAOR 2	10	Canister Close Valve, Purge Control Solenoid Valve, Variable Intake Solenoid Valve, E/R Junction Block (Cooling Fan 1/2 Relay)
ECU2	10	—
ECU1	20	PCM
INJECTOR	15	Injector #1/#2/#3/#4
SENSOR 1	15	Oxygen Sensor (UP/DOWN)
IGN COIL	20	Ignition Coil #1/#2/#3/#4
SENSOR 3	10	Fuel Pump Relay
HORN	20	Horn Relay

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Hyundai Accent (2018 – 2019) – fuse box diagram

Posted on 6 January 201916 July 2019 by admin

Hyundai Accent (2018 – 2019) – fuse box diagram

Year of production: 2018, 2019

Instrument panel

Fuse name	[A]	Circuit protected
DOOR LOCK	20	I/P Junction Block (Tail Gate Unlock Relay, Door Lock/Unlock Relay, Two Turn Unlock Relay)
POWER OUTLET	20	Power Outlet
SAFETY P/WINDOW	25	Driver Safety Power Window Module
STOP LAMP	15	I/P Junction Block(Stop Signal Electronic Module)
T/SIGNAL LAMP	15	BCM, SLM
C/LIGHTER	20	Cigarette Lighter
HEATED MIRROR	10	Driver Power Outside Mirror, Passenger Power Outside Mirror, A/C Control Module
DRL	10	BCM
P/WINDOW RH	25	Power Window Main Switch, Passenger Power Window Switch
S/HEATER	20	Front Seat Warmer Control Module
SPARE1	10	—
START	7,5	With Smart Key : ECM/PCM, E/R Junction Block(Start Relay), Smart Key Control Module, Transaxle Range Switch, Ignition Lock & Clutch Switch W/O Smart Key : Burglar Alarm Relay, Transaxle Range Switch, Ignition Lock & Clutch Switch
TAIL LAMP RH	7,5	Head Lamp RH, Rear Combination Lamp (OUT) RH, License Lamp RH, Rear Combination Lamp (IN) RH, ILL (+)
MODULE2	10	FCA Module, Crash Pad Switch
TCU	15	E/R Junction Block(Fuse – B/UP LAMP), A/T Shift Lever, Transaxle Range Switch, Stop Lamp Switch
P/WINDOW LH	25	Power Window Main Switch
SPARE2	25	—
FOG LAMP REAR	10	—
HEATED STEERING	15	Clock Spring
TAIL LAMP LH	7,5	Head Lamp LH, License Lamp LH, Rear Combination Lamp (OUT) LH, Rear Combination Lamp (IN) LH
MODULE3	7,5	Front Seat Warmer Control Module, Audio, Electro Chromic Mirror, A/C Control Module, Clock Spring, A/T Shift Lever Indicator
ABS3	7,5	E/R Junction Block(Multipurpose Check Connector), ESC Module
BRAKE SWITCH	10	Smart Key Control Module, Stop Lamp Switch
BCM	10	BCM
FOG LAMP FRONT	15	I/P Junction Block(Front Fog Lamp Relay)
A/C1	7,5	E/R Junction Block(Blower Relay), A/C Control Module
MODULE5	10	Sunroof Motor, Front Seat Warmer Control Module
MODULE7	10	TPMS Unit
ECU	10	ECM/PCM, Immobilizer Module, Smart Key Control Module
SUNROOF	15	Sunroof Motor
IMMO.	10	Immobilizer Module
MODULE6	10	Key Solenoid
SPARE4	10	—
MODULE4	7,5	SLM, BCM, Smart Key Control Module
SPARE5	10	—
AIR BAG	10	SRS Control Module, Occupant Detection Sensor
MODULE1	7,5	BCM, SLM, Key Interlock
SMART KEY	25	Smart Key Control Module
A/C2	7,5	—
WIPER RR	15	Multifunction Switch, Rear Wiper Motor, Rear Wiper Relay
WIPER FRT	25	Multifunction Switch, Front Wiper Motor, E/R Junction Block(Wiper Lo Relay)
ACC	10	I/P Junction Block(Power Outlet Relay), BCM, SLM, Audio, Key Interlock Power Outside Mirror Switch, Smart Key Control Module, USB Charging Connecto
SPARE3	20	—
A/BAG IND	7,5	Instrument Cluster, A/C Control Module
CLUSTER	7,5	Instrument Cluster
MDPS2	7,5	MDPS Unit
AUDIO	20	Audio
ROOM LP	10	I/P Junction Block(Room Lamp Relay), Overhead Console Lamp , A/C Control Module, SLM, BCM, Auto Light & Photo Sensor, TPMS Unit ,Instrument Cluster, Data Link Connector, Room Lamp, Trunk Room Lamp, Electro Chromic Mirror

Engine compartment

Type	Relay NO.	Relay name
MICRO	AC	A/C Relay
	E81	Start Relay
	E82	Blower Relay
	E83	Fuel Pump Relay
	E84	Cooling Fan1 Relay
	E85	Wiper HI Relay
	E86	Wiper LO Relay
	E87	H/Lamp HI Relay
	E88	Head Lamp Relay
	E89	Cooling Fan2 Relay
	E90	Horn Relay
	E91	B/Alarm Horn Relay
MINI	E93	Horn Relay

Engine compartment (Battery terminal cover)

Fuse name	[A]	Circuit protected
MDPS	80	MDPS Unit
ALT	150	E/R Junction Block (Fuse – ABS1, ABS2, BLOWER, REAR HEATED)
REAR HEATED	40	I/P Junction Block (Rear Defogger Relay)
ABS1	40	ESC Module, Multipurpose Check Connector
ABS2	40	ESC Module
BLOWER	40	E/R Junction Block (Blower Relay)
WIPER	10	Front Wiper Motor, Multifunction Switch, E/R Junction Block (Wiper LO Relay)
ECU4	15	ECM/PCM
SENSOR1	10	Oil Control Valve #1/#2, E/R Junction Block (Cooling Fan1/2 Relay), Oxygen Sensor (Up), Oxygen Sensor (Down), Variable Intake Solenoid Valve, Sub Relay Block (A/C Relay) Purge Control Solenoid Valve, Canister Close Valve
ECU2	15	ECM/PCM
ECU3	20	ECM/PCM
HEAD LAMP RH	10	Head Lamp RH
HEAD LAMP LH	10	Head Lamp LH
IGN COIL	20	Ignition Coil #1~#4, Condenser
ECU5	15	ECM/PCM, E/R Junction Block (Fuel Pump Relay)
B/UP LAMP	10	Back-Up Lamp Switch
B+1	40	I/P Junction Block (Fuse – DRL, FOGLAMP FRONT, STOP LAMP, MODULE6, Power Connector (AUDIO, ROOM LAMP))
B+2	50	I/P Junction Block (Fuse – IMMO, SMART KEY1, BRAKE SWITCH, BCM, SAFETY P/WINDOW, S/HEATER, SUNROOF, Power Window Relay)
IG2	40	Ignition Switch, PDM Relay Box (IG2 Relay), E/R Junction Block (Start Relay)
COOLING FAN	40	E/R Junction Block (Cooling Fan1/2 Relay)
ECU1	30	E/R Junction Block (Fuse – ECU3, ECU4, Main Relay)
B/ALARM HORN	10	B/Alarm Horn Relay
HEAD LAMP	20	E/R Junction Block (Head Lamp Relay)
H/LAMP HI	20	W/O DRL : E/R Junction Block (H/Lamp HI Relay) With DRL : SLM, BCM
FUEL PUMP	20	E/R Junction Block (Fuel Pump Relay)
HORN	10	E/R Junction Block (Horn Relay)
A/C	10	Sub Relay Block (A/C Relay)
AMS	10	Battery Sensor
B+3	40	I/P Junction Block (Fuse – T/SIGNAL LAMP, DOOR LOCK, Tail Lamp Relay)
IG1	40	Ignition Switch, PDM Relay Box (IG1 Relay, ACC Relay)
POWER OUTLET	40	I/P Junction Block (Power Outlet Relay)

Engine compartment (Battery terminal cover)

Hyundai Accent - fuse box diagram - engine compartment (ABS — Hyundai Accent – fuse box diagram – engine compartment (ABS)

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Cadillac Commercial Chassis (1995) – fuse box diagram

Posted on 1 January 201912 March 2019 by admin

Cadillac Commercial Chassis (1995) – fuse box diagram

Year of production: 1995

Underhood (U/H) electrical center

Cadillac Commercial Chassis – fuse box diagram – engine compartment

Maxi Fuse	Name	Description
1	BODY 1	60 amp power to PWR ST Circuit Breaker, #3 30 amp. RR DEFG Circuit Breaker, #4 30 amp. I/P Fuse Block, #36 TRK PDWN 15 amp. #31 HAZARD LTS 20 amp, #39 PWR LUMB 20 amp, #40-HTD SEAT 20 amp #44 STOP LTS 20 amp, #45 PWR LK 20 amp
2	BODY 2	50 amp power to I/P Fuse Block #21 RAP BAT 25 amp. #22 HVAC MDL 25 amp, #26 ELC SENS 20 amp. #27 D/INT LTS 15 amp. #28 F’RT CIG 10 amp, #29 RRCIG 20 amp. #30 EBTCM 25 amp. #33-HVAC BAT 10 amp, #34-CCM BAT 10 amp. #35 PWR MIR 10 amp, #2 Circuit Breaker RAP RLY 30 amp.
3	IGN 1	60 amp power to I/P Concealed Fuse 5 amp, I/P Fuse Block, #6 T/SIG 15 amp, #7 EBTCM/TPS 10 amp, #8 RAP WPR 25 amp, #9 RADIO 10 amp, #10 WIPER 25 amp, #11 I/P INDC 10 amp, #12 ELC IGN 1 10 amp, #13 CHIME 10 amp, #14 CCMIGNI 10 amp, #15 AIR BAG 15 amp, #24 STARTER 10 AMP, U/H Electrical Cente, #15 PCM/IGN 10 amp, #16 I 10 amp, #17 EMissions 10 AMP, #18 INJ 2 10 AMP
4	—	—
5**	ABS/TCS	40 amp power to ABS/TC Brake Pressure Modulator Valve (BPMV)
6**	ABS/TCS	20 amp power to ABS/TC Brake Pressure Modulator Valve (BPMV)
7	SCNDRY CLG FAN	40 amp power to Secondary Engine Cooling Fan Relay
8	PRIMARY CLG FAN	40 amp power to Primary Engine Cooling Fan Relay
9	LEVEL CONTROL	30 amp power to Automatic Level Control (ALC) Air Compressor
10	ENGINE	30 amp power to U/H Electrical Center, #13 PCM/FUEL PUMP 15 amp #14 AIR PUMP 20 amp
11	HEADLIGHTS/HORNS	50 amp power to I/P Flue Block Circuit Breaker, #5 HDLT’S 20 amp, Fuse #31 PARK LTS 20 amp, #32 HORN 25 amp
12	—	—

Mini Fuse	Name	Description
13	PCM/FUEL PUMP	15 amp power to Fuel Pump Relay, Fuel Pump/Engine Oil Pressure Indicator Switch, Powertrain Control Module (PCM)
14	AIR PUMP	20 amp power to Secondary Air Injection (AIR) Pump Relay
15	PCM/IGN	10 amp power to Powertrain Control Module (PCM), Electronic Transmission Ignition Coil, Electronic Brake Control Module
16	INJ 1	10 amp power to fuel Injectors Cylinders 1-4, 6-7
17	EMISSIONS	15 amp power to Exhaust Gas Recirculation (EGA), Vacuum Control Signal Solenoid Valve, Secondary Air Injection (AIR) Pump Relay (coil), Mass Air Flow (MAF) sensor, Bank 1 (left) Heated Oxygen Sensor (H02S), Bank 2 (right) Heated Oxygen Sensor (H02S), Evaporative Emission (EVAP) Canister Purge Solenoid Valve
18	INJ 2	10 amp power to fuel Injectors Cylinders 2-3, 5-8

Relay	Name	Description
A	A/C COMP RELAY	A/C Compressor Relay
B	AIR PUMP RELAY	Secondary Air lnjection (AIR) Pump Relay

Instrument panel

Fuse	Name	Description
1	—	—
2	—	—
3	—	—
4	—	—
5	—	—
6	—	—
7	—	—
8	RAP WPR	Component Center (RAP Wiper) Relay
9	RADIO	Radio Receiver
10	WIPER	Windshield Wiper/Washer Switch
11	LP/NDC	Inflatable Restraint Diagnostic Energy reserve (with sensor) Module, Instrument Panel Cluster
12	T/SIG	Park/Neutral Positive and Backup Lamp Switch, Turn Signal Lamp
13	CHIME	Warning Alarm, Cruise Control Release Switch, Inside Rearview Mirror (DDB), Rear Window Defogger Relay, Catalytic Converter Temperature Alarm Module (UD6, Japan only), Park/Neutral Position and Backup Lamp Switch, Autmatic Level Control Sensor
14	CCM IGN 1	Central Control Module (CCM)
15	AIR BAG	Inflatable Restraint Diagnostic Energy Reserve (with sensor) Module (SDM)
16	GEN	Generator, Secondary Electrical Engine Cooling Fan Relay
17	MEM SEAT	Driver’s Seat Adjuster Memory Module, Heated Driver Seat Control Module, Heated Passenger Seat Control Module
18	CCM IGN 3	Central Control Module (CCM), Remote Control Door Lock Receiver and Theft Deterrent Module, Cruise Control Module Cruise Control Switch
19	RAP PWR	Accessory Time Delay Cut-off (RAP Power) Relay
20	A/C COMP	A/C Compressor Relay, Primary Engine Cooling Fan Relay
21	RAP BATT	Component Center (RAP Wiper) Relay
22	HVAC MDL	Blower Motor Control Module
23	TRK REL	Rear Compartment Lid Release Switch
24	STARTER	Theft Deterrent Relay, Inflatable Restraint Diagnostic Energy Reserve (with sensor) Module (SDM)
25	HVAC IGN	Instrument Cluster Heater-A/C Control, Vacuum/Electric Solenoid, Electric Actuator
26	ELC SENS	Automatic level Control Sensor, Rear Compartment Courtesy Lamp
27	D/INT LTS	Component Center (DIL) Relay
28	FRT CIG	Front Cigar Lighter
29	RR CIG	Rear Cigar Lighters
30	EBTCM	Electronic Brake and Traction Control Module (EBTCM)
31	PARK LTS	Park Lamp Relay
32	HORN	Horn Relay
33	HVAC BAT	Warning Alarm, Heater A/C Control, Headlamp Switch, Radio Receiver
34	CCM BAT	Central Control Module (CCM)
35	PWR MIR	Door Lock Switch, Outside Rearview Mirrors, Ignition Key Disable Relay Assembly
36	TRK PDWN	Rear Compartment Lidl Pull-Down Actuator
37	HAZARD LTS	Hazard Lamp Flasher
38	STOP LTS	Stoplamp Switch
39	PWR LUMB	Door Lock Relay
40	HTD SEAT	Heated Driver’s Seat Control Module, Heated Passenger Seat Control Module
41	CORNR LTS	Instrument Cluster, Radio Control, Cornering Lamps, Turn Signal Switch, Front Park Lamps
42	I/P DIM LTS	Headlamp Switch, Interior Lamps, Dimming
43	TAIL LTS	Rear Taillamps, Rear Side Marker Lamps, License lamp
44	MIR DEFG	Outside Rearview Mirror Defogger
45	—	—

Circuit Breaker	Name	Description
1	PWR RECL	Lumbar, Power Antenna
2	RAP RLY	Accessory Time Delay Cut-off (RAP Power) Relay
3	PWR SEAT	Driver’s Power Seat Switch, Passenger Power Seat Adjuster Switch, Driver’s Seat Adjuster Memory Module, Driver’s Seat Recline Switch, Passenger Seat Recline Switch
4	RR DEFG	Rear Defogger Relay
5	HDLTS	Headlamp Relay, Daytime Running Lamps (DRL) Module

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Cadillac Commercial Chassis (1994) – fuse box diagram

Posted on 1 January 201912 March 2019 by admin

Cadillac Commercial Chassis (1994) – fuse box diagram

Year of production: 1994

Underhood (U/H) electrical center

Maxi fuse	Name	Description
1	BODY 1	60 amp power to PWR SEAT Circuit Breaker #3 30 amp, I/P Fuse Block, #36·TRK PDWN 15amp, #37·HAZRD LTS 20 amp, #39 PWR LUMB 20 amp, #40 HTD SEAT 20 amp, RR DHG Circuit Breaker #4 30 amp, #44-STOP LTS 20 amp, #45-PWRLK 20 amp
2	BODY 2	50 amp power to I/P fuse Block #21-RAP BAT 25 amp, #22 HVAC MDL 25 amp, #26 ELC SENS 20 amp, #27 D/INT LTS 15 amp, #28 FRT CIG 10 amp, #29 RRClG 20 amp, #30 EBTCM 25 amp, #33 HVAC BAT 10 amp, #34 CCM BAT 10 amp, #35 PWR MIR 10 amp, #2 Circuit Breaker RAP RLY 30 amp.
3	IGN1	50 amp power to I/P Concealed Fuse 5 amp, I/P Fuse Block; #6 T/SIG 15 amp, #7 EBTCM/TPS 10 amp, #8 RAP WPR 25 amp, #9 RADIO 10 amp, #10 WIPER 25 amp, #11 I/P INDC 10 amp, #12 ELC IGN 1 10 amp, #13 CHIME 10 amp, #14 CCMIGN1 10 amp, #15 AIR BAG 15 amp, #24 STARTER U/H Electrical Center, #15 PCM/IGN 10 amp, #16 INJ 1 10 amp, #19 RAP PWR 30 amp, #20 A/C COMP 10 amp, #25 HVAC IGN 10 anlp
4	IGN3	40 amp power to I/P Fuse Block; #16-G£N 10 amp, #17 MEM Seat 1O amp, #18 CCM IGN 3 10 amp, #19 RAP PWR 30 amp, #20 A/C COMP 10 amp, #25 HVACIGN 10 amp
5**	ABS/TC	60 amp power to ABS/TC Brake Pressure Modulator Valve (BPMV)
6	—	—
7	SCNDRV CLG FAN	40 amp pawer to Secondary Engine Cooling fan Motor Control Relay
8	PRIMARY CLG FAN	40 amp power to Primary engine Cooling Fan Motor Control Relay
9	LEVEL CONTROL	10 amp power to Automatic Level Control Air Compressor
10	ENGINE	30 amp power to U/H Electrical Center; #13 PCM/Fuel Pump 15 amp, #14-Air Pump 20 amp
11	HEADLIGHTS/HORNS	50 amp power to I/P Fuse Block Circuit Breaker #5 HDLTS 20 amp, Fuse #31 Park LTS 20 amp, #32-Horn 25 amp
12	—	—
** DELETE WITH V4F/V4U (LIMO)

Mini Fuse	Name	Description
13	PCM/FUEL PUMP	15 amp power to Fuel Pump Relay, Fuel Pump/Engine Oil Pressure Indicator Switch, Powertrain Control Module (PCM)
14	AIR PUMP	20 amp power to Secondary Air Injeection (AIR) Pump Relay
15	PCM/IGN	10 amp power to Powertrain Control Module (PCM), Electronic Transmission Ignition Coil
16	INJ1	10 amp power to fuel Injectors Cylinders 1-4, 6-7
17	EMISSIONS	10 amp power to Exhaust Gas Recirculation (EGA), Vacuum Control Signal Solenoid Valve, Secondary Air Injection (AIR) Pump Relay (coil), Mass Air Flow (MAF) sensor, Bank 1 (left) Heated Oxygen Sensor (H02S), Bank 2 (right) Heated Oxygen Sensor (H02S), Evaporative Emission (EVAP) Canister Purge Solenoid Valve
18	INJ2	10 amp power to fuel Injectors Cylinders 2-3, 5-8

Relay	Name	Description
A	A/C COMP RELAY	A/C Compressor Relay
B	AIR PUMP RELAY	Secondary Air lnjection (AIR) Pump Relay

Instrument panel

Fuse	Name	Description
1	MIR DEFG	Outside Rearview Mirror Defogger
2	—	—
3	—	—
4	—	—
5	—	—
6	T/SIG	Park/Neutral Position and Back-up Lamp switch, Turn Signal Lamp flasher
7**	EBTCM/TPS	Electronic Brake and Traction Control Module (EBTCM), Throttle Position(TP) Sensor Interface Module
8	RAP WPR	Component Center (RAP Wiper) Relay
9	RADIO	Radio Receiver
10	WIPER	Windshield Wiper/Washer Switch
11	LP/NDC	Inflatable Restrain Diagnostic Energy reserve (with sensor) Module, Instrument Panel Cluster
12	ELC IGN 1	Automatic Level Control Sensor
13	CHIME	Warning Alarm, Cruise Control Release Switch, Inside Rearview Mirror (DDB), Rear Window Defogger Relay, Catalytic Converter Temperature Alarm (Japan only)
14	CCM IGN 1	Central Control Module (CCM)
15	AIR BAG	Inflatable Restraint Diagnostic Energy Reserve (with sensor) Module (SDM)
16	GEN	Engine Electrical Generator, Secondary Electrical Engine Cooling Fan Relay
17	MEM SEAT	Driver’s Seat Adjuster Memory Module, Heated Driver Seat Control Module, Heated Passenger Seat Control Module
18	CCM IGN 3	Central Control Module (CCM), Remote Control Door Lock Receiver and Theft Deterrent Module
19	RAP PWR	Accessory Time Delay Cut-off (RAP Power) Relay
20	A/C COMP	A/C Compressor Relay, Primary Electrical Engine Cooling Dan Relay
21	RAP BATT	Component Center (RAP Wiper) Relay
22	HVAC MDL	Blower Motor Control Module
23	TRK REL	Rear Compartment Lid Release Switch
24	STARTER	Theft Deterrent Relay, Inflatable Restraint Diagnostic Energy Reserve (with sensor) Module (SDM)
25	HVAC IGN	Instrument Panel Gauge Cluster, Blower Motor Control Module
26	ELC SENS	Automatic level Control Sensor, Rear Compartment Courtesy Lamp
27	D/INT LTS	Component Center (DIL) Relay
28	FRT CIG	Front Cigar Lighter
29	RR CIG	Rear Cigar Lighters
30	EBTCM	Electronic Brake and Traction Control Module (EBTCM)
31	PARK LTS	Forward Lamp Wiring Harness Relay
32	HORN	Horn Relay
33	HVAC BAT	Warning Alarm, Heater A/C Control, Instrument Cluster, Engine Oil Level Indicator Control Module, Headlamp Switch, Radio Receiver
34	CCM BAT	Central Control Module (CCM)
35	PWR MIR	Door Lock Switch, Outside Rearview Mirrors, Power Seatback, lumbar Control
36	TRK PDWN	Rear Compartment Lidl Pull-Down Unit
37	HAZARD LTS	Hazard Lamp Flasher
38	—	—
39	PWR LUMB	Power Sear Pneumatic Control Module, Radio Power Antenna Relay
40	HTD SEAT	Heated Driver’s Seat Control Module, Heated Passenger Seat Control Module
41	CORNR LTS	Instrument Cluster, Radio Control, Cornering Lamps, Turn Signal Switch, Front Park Lamps
42	I/P DIM LTS	Headlamp Switch, Interior Lamps, Dimming
43	TAIL LTS	Rear Taillamps, Rear Side Marker Lamps, License lamp
44	STOP LTS	Stoplamp Switch
45	PWR LK	Door Lock Relay
** DELETE WITH V4F/V4U (LIMO)

Name	Description
—	—
RAP RLY	Accessory Time Delay Cut-off (RAP Power) Relay
PWR SEAT	Driver’s Power Seat Switch, Passenger Power Seat Switch, Driver’s Power Seat Memory Module
RR DEFG	Rear Defogger Relay
HDLTS	Headlamp Relay, Daytime Running Lamps (DRL) Module

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
