Hyundai Centennial (2011 – 2012) – fuse box diagram

Posted on 12 August 2018 by admin

Hyundai Centennial (2011 – 2012) – fuse box diagram

Year of production: 2011, 2012

Instrument panel (Driver’s side fuse panel)

Description	Ampere rating [A]	Protected component
P/WDW(RH)	30	Rear Power Window Module RH, Passenger Power Window Module
P/WDW(LH)	30	Rear Power Window Module LH, Driver Power Window Module
CHASSIS UNIT	10	Steering Angle Sensor, Console Switch LH/RH, ECS Control Module, Pre-Safe Seat Belt LH/RH, Tire Pressure Monitoring Module
CRUISE SW	10	Multifunction Switch (Remocon), Crash Pad Switch, A/C Control Module, Alternator, Instrument Cluster, Rear Seat Warmer Module LH/RH, Rear CCS Control Module LH/RH, Driver/Passenger CCS Control Module (With CCS), Driver/Passenger Seat Warmer Module (W/O CCS), Center Facia Switch
ESCL SW	10	FOB Holder, Start Stop Button Switch
CLUSTER	10	Instrument Cluster
INTELLIGENT A/PEDAL	10	IAP ECU
KEY ILLUMINATION	10	Start Stop Button Switch, FOB Holder
P/DOOR(RL)	15	Rear Power Door Latch LH, Rear Door Window Curtain LH
IG KEY SUPPLY(IG1)	30	E/R Junction Box (Fuse : EHPS 10A, ECU(IG1) 10A, TCU 15A, ESP 10A, STOP LP 10A, AFLS 10A, INHIBITOR SW 10A, CRUISE 10A)
DR LOCK(LH)	10	Driver Door Module
P/DOOR(FL)	15	Front Door Mood Lamp LH, Driver Power Seat Switch, Driver Power Door Latch
A/BAG IND	10	Instrument Cluster (A/Bag IND.)
AFLS	10	Auto Head Lamp Leveling Device Sensor (W/O AFLS), Adaptive Front Lighting Module (With AFLS), Head Lamp LH/RH
PDM1	10	PDM
RDM	10	Data Link Connector, Rear Smart Outside Handle LH/RH, Rear Door Module LH/RH
SHIFT LOCK	10	SPORT Mode Switch
MODULE 2	10	Multifunction Switch, Tilt & Telescopic Module, Driver/Passenger Door Module, Power Trunk Lid Control Module, Electro Chromic Mirror, LDWS Camera, Front & Rear Parking Assist Control Module, EPB Control Module, Driver/Passenger IMS Control Module, E/R Junction Box (FAM)
MODULE 1	10	Multifunction Switch, Instrument Cluster (IND.), Power Trunk Lid Control Module, Driver/Passenger Door Module, Rear Curtain Module, E/R Junction Box (FAM), Front Smart Outside Handle LH/RH, Passenger IMS Control Module
P/HANDLE	15	Tilt & Telescopic Module
ECS	15	ECS Control Module
A/BAG	15	SRS Control Module
AUDIO(B+)	15	Audio, Front/Rear Monitor, AV Head Module, Rear Audio Switch, Media Module, Tunner Unit, MTS Unit
S/HEATER DRV	15	Driver CCS Control Module (With CCS), Driver Seat Warmer Module (With CCS)
P/TRUNK	30	Power Trunk Lid Control Module
F/LID	10	Fuel Filler Switch
AUDIO(IG1)	10	AV Head Module, Audio, Active Headrest Sensor Module, Camera Module, MTS Unit
A/CON(B+)	10	Auto Light Sensor & Security Indicator, RF Receiver, A/C Control Module, Analog Clock
I.O.D	30	Fuse : A/CON (B+) 10A, AUDIO (B+) 15A, BODY UNIT-1 10A
S/HEATER RL	15	Rear CCS Control Module LH (With CCS), Rear Seat Warmer Module LH (W/O CCS)
DR LOCK(RH)	15	Passenger Door Module
PDM 2	10	IPM,PDM
A/CON(IG1)	10	A/C Control Module
RF RECEIVER	10	Auto Light Sensor & Security Indicator, RF Receiver

Instrument panel (Passanger’s side fuse panel)

Description	Ampere rating [A]	Protected component
P/DOOR PASS	15	Passenger Power Door Latch, Passenser Power Seat Switch
PDM	25	PDM
ICE BOX	15	Rear Console Switch, Cool Box
HTD STRG	15	Steering Wheel Heated
S/HEATER PASS	15	Passenger CCS Control Module (With CCS), Passenger Seat Warmer Module (W/O CCS)
AUDIO(ACC)	10	Camera Module, Rear Audio Switch, Audio, Front Monitor, Media Module, AV Head Module, MTS Unit, RR MTS MIC
P/DOOR(RR)	15	Rear Power Door Latch RH, Rear Door Window Curtain RH
P/OUTLET(FR)	10	E/R Fuse & Relay Box(Front Power Outlet Relay), Front Room Lamp, Center Facia Switch
MODULE 2	10	Overhead Console Assembly (Sunroof Motor), Rain Sensor, Rear Curtain Module
P/SEAT PASS 1	20	Passenger IMS Control Module (With IMS), Passenger Power Seat Relay Box (W/O IMS)
S/ROOF	20	Overhead Console Assembly (Sunroof Motor)
MODULE 3	10	A/C Control Module, IPM, PDM, Key Lock Unit
P/OUTLET(RR)	15	Rear Accessory Socket
P/SEAT(RR)	20	Rear Power Seat Relay Box LH
MODULE 1	10	Instrument Cluster (MICOM), Rheostat, Driver/Passenger CCS Control Module, Passenger Receiver, Rear CCS Control Module LH/RH, PDM, IPM
A/CON(IG2)	10	Active Incar Sensor, Ionizer, A/C Control Module, Rear Console Switch, Console Vent Temperature Actuator & Switch
IG KEY SUPPLY	30	E/R Junction Box (Fuse : AQS 10A, WASHER 15A)
S/HEATER RR	15	Rear CCS Control Module RH (With CCS), Rear Seat Warmer Module RH (W/O CCS)
CONSOLE SW	10	Console Switch LH/RH, Massage Module, Vibrator Module
MIRROR	10	Outside Mirror LH/RH
LEG SUPPORT(RR)	15	Rear Power Seat Relay Box RH
RR CURTAIN MTR	10	Rear Curtain Module

Engine compartment fuse panel

Description	Ampere rating [A]	Protected component
ALT	200	Alternator
I/P POWER(LH)	60	I/P Junction Box LH
I/P POWER(RH)	60	I/P Junction Box RH
COOLING FAN	60	Cooling Fan Relay
EHPS	80	EHPS Motor
AIR ECS	40	ECS Compressor Relay
AMP-1	40	AV JBL AMP
AMP-2	30	AMP
PDM (ACC)	30	PDM (ACC) Relay
VDC/ESC1	30	VDC/ESP Control Module, Multipurpose Check Connector
VDC/ESC2	30	VDC/ESP Control Module, Multipurpose Check Connector
PDM (IGN1)	30	PDM (IGN1) Relay
PDM (IGN2)	30	PDM (IGN2) Relay
P/SEAT DRV	30	Driver Power Seat Relay Box, IMS Control Module, Driver Lumbar Support Switch
H/LP WASHER	20	Head Lamp Washer Relay
VACUUM PUMP	20	Brake Vacuum Pump Relay
P/OUTLET(FR)	25	ACC Socket Relay
TRUNK	10	Trunk Lid Relay
IMS	10	—
STOP LP	10	Stop Lamp Relay, Stop Lamp Switch, IPM
B/UP LP	10	Back Up Lamp Relay
ECU	30	Engine Control Relay
BLOWER	40	Blower Relay
IGN SW 2 (PRESAFETY PASS)	40	Ignition Switch (IG 2, START), Presafety Seat Belt Passenger
RR HTD	40	E/R Junction Box Fuse (AQS 10A, WASHER 15A)
IGN SW 1 (PRESAFETY DRV)	40	Ignition Switch (IG 1, ACC), Presafety Seat Belt Driver
A/CON	10	A/C Control Module
EPB-1	15	Electric Parking Brake Module
EPB-2	15	Electric Parking Brake Module
HORN	15	Horn Relay
IPM	10	IPM, Head Lamp (Low) Relay
AQS	10	AQS Sensor, Electronic Control Wiper Module, Blower Relay
DEICER	15	Heated Glass (FR) Relay
WASHER	15	Washer Relay
WIPER	30	Wiper Motor
HTD MIRR	10	A/C Control Module, Power Outside Mirror & Mirror Folding Motor LH/RH
TCU	15	TCM
AFLS	10	Head Lamp LH/RH
EHPS	10	EHPS Module
VDC/ESC	10	ESP Control Module, Multipurpose Check Connector
ECU(IG1)	10	ECM
IGN COIL	20	Ignition Coil #1,2,3,4,5,6
INJECTOR(B+)	15	Injector Drive Box
SENSOR 1	10	ECM, Mass Air Flow Sensor, Oxygen Sensor #1,2,3,4
SENSOR 2	10	Canister Purge Control Solenoid Valve, Variable Intake Manifold Valve, Oil Control Valve, ECM, Cooling Fan Relay, Immobilizer Module, Fuel Pump Resister
SENSOR 3	10	ECM, Injector #1~#6, Fuel Pump Relay
H/LP RH	15	Head Lamp RH
H/LP LH	15	Head Lamp LH
INJECTOR(IG1)	10	Injector Drive Box
CRUSIE	10	Smart Cruise Control Module
STOP LP	10	Stop Lamp Switch, Stop Lamp Relay, Generator,Vacuum Sw
ECU(B+)	15	ECM,TCM,Injector Drive Box
ROOM LP	10	Room Lamp Relay
F/PUMP	20	Fuel Pump Relay
START	30	Start Solenoid

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Hyundai Centennial (2010) – fuse box diagram

Posted on 12 August 2018 by admin

Hyundai Centennial (2010) – fuse box diagram

Year of production: 2010

Instrument panel (Driver’s side fuse panel)

Description	Ampere rating [A]	Protected component
P/WDW(RH)	30	Rear Power Window Module RH, Passenger Power Window Module
P/WDW(LH)	30	Rear Power Window Module LH, Driver Power Window Module
CHASSIS UNIT	10	Steering Angle Sensor, Console Switch LH/RH, ECS Control Module, Pre-Safe Seat Belt LH/RH, Tire Pressure Monitoring Module
CRUISE SW	10	Multifunction Switch (Remocon), Crash Pad Switch, A/C Control Module, Alternator, Instrument Cluster, Rear Seat Warmer Module LH/RH, Rear CCS Control Module LH/RH, Driver/Passenger CCS Control Module (With CCS), Driver/Passenger Seat Warmer Module (W/O CCS), Center Facia Switch
ESCL SW	10	FOB Holder, Start Stop Button Switch
CLUSTER	10	Instrument Cluster
A/CON(IG1)	10	A/C Control Module, FOB Holder
KEY ILLUMINATION	10	Start Stop Button Switch, FOB Holder
P/DOOR(RL)	15	Rear Power Door Latch LH, Rear Door Window Curtain LH
IG KEY SUPPLY(IG1)	30	E/R Junction Box (Fuse : EHPS 10A, ECU(IG1) 10A, TCU 15A, ESP 10A, STOP LP 10A, AFLS 10A, INHIBITOR SW 10A, CRUISE 10A)
DR LOCK(LH)	10	Driver Door Module
P/DOOR(FL)	15	Front Door Mood Lamp LH, Driver Power Seat Switch, Driver Power Door Latch
A/BAG IND	10	Instrument Cluster (A/Bag IND.)
AFLS	10	Auto Head Lamp Leveling Device Sensor (W/O AFLS), Adaptive Front Lighting Module (With AFLS), Head Lamp LH/RH
ESCL-1	10	PDM
RR DOOR MDL	10	Data Link Connector, Rear Smart Outside Handle LH/RH, Rear Door Module LH/RH
RR CURTAIN MTR	10	Rear Curtain Module
BODY UNIT-2	10	Multifunction Switch, Tilt & Telescopic Module, Driver/Passenger Door Module, Power Trunk Lid Control Module, Electro Chromic Mirror, LDWS Camera, Front & Rear Parking Assist Control Module, EPB Control Module, Driver/Passenger IMS Control Module, E/R Junction Box (FAM)
BODY UNIT-1	10	Multifunction Switch, Instrument Cluster (IND.), Power Trunk Lid Control Module, Driver/Passenger Door Module, Rear Curtain Module, E/R Junction Box (FAM), Front Smart Outside Handle LH/RH, Passenger IMS Control Module
P/HANDLE	15	Tilt & Telescopic Module
ECS	15	ECS Control Module
A/BAG	15	SRS Control Module
AUDIO(B+)	15	Audio, Front/Rear Monitor, AV Head Module, Rear Audio Switch, Media Module, Tunner Unit, MTS Unit
S/HTD ECU(FL)	15	Driver CCS Control Module (With CCS), Driver Seat Warmer Module (With CCS)
P/TRUNK	30	Power Trunk Lid Control Module
F/LID OPEN	10	Fuel Filler Switch
AUDIO(IG1)	10	AV Head Module, Audio, Active Headrest Sensor Module, Camera Module, MTS Unit
A/CON(B+)	10	Auto Light Sensor & Security Indicator, RF Receiver, A/C Control Module, Analog Clock
P/CONN	30	Fuse : A/CON (B+) 10A, AUDIO (B+) 15A, BODY UNIT-1 10A
S/HTD ECU(RL)	15	Rear CCS Control Module LH (With CCS), Rear Seat Warmer Module LH (W/O CCS)
DR LOCK(RH)	15	Passenger Door Module
ESCL-2	10	IPM,PDM
A/CON(IG1)	10	A/C Control Module

Instrument panel (Passanger’s side fuse panel)

Description	Ampere rating [A]	Protected component
P/DOOR(FR)	15	Passenger Power Door Latch
ESCL	25	PDM
ICE BOX	15	Rear Console Switch, Cool Box
HTD STRG	15	Steering Wheel Heated
S/HTD ECU(FR)	15	Passenger CCS Control Module (With CCS), Passenger Seat Warmer Module (W/O CCS)
AUDIO(ACC)	10	Camera Module, Rear Audio Switch, Audio, Front Monitor, Media Module, AV Head Module, MTS Unit, RR MTS MIC
H/REST(FR)	10	Passenger Power Seat Switch
P/DOOR(RR)	15	Rear Power Door Latch RH, Rear Door Window Curtain RH
P/OUTLET(FR)	10	E/R Fuse & Relay Box(Front Power Outlet Relay)
ECM	10	Overhead Console Assembly (Sunroof Motor), Rain Sensor, Rear Curtain Module
P/SEAT(FR)	20	Passenger IMS Control Module (With IMS), Passenger Power Seat Relay Box (W/O IMS)
S/ROOF	20	Overhead Console Assembly (Sunroof Motor)
A/CON(ACC)	10	A/C Control Module, IPM, PDM, Center Facia Switch
P/OUTLET(RR)	15	Rear Accessory Socket
P/SEAT(RR)	20	Rear Power Seat Relay Box LH
BODY UNIT	10	Instrument Cluster (MICOM), Rheostat, Driver/Passenger CCS Control Module, Passenger Receiver, Rear CCS Control Module LH/RH, PDM, IPM
A/CON(IG2)	10	Active Incar Sensor, Ionizer, A/C Control Module, Rear Console Switch, Console Vent Temperature Actuator & Switch
IG KEY SUPPLY(IG2)	30	E/R Junction Box (Fuse : AQS 10A, WASHER 15A)
S/HTD ECU(RR)	15	Rear CCS Control Module RH (With CCS), Rear Seat Warmer Module RH (W/O CCS)
TPMS	10	Tire Pressure Monitoring Module, Electro Chromic Mirror
CONSOLE SW	10	Console Switch LH/RH, Massage Module, Vibrator Module
MIRROR	10	Outside Mirror LH/RH
LEG SUPPORT(RR)	15	Rear Power Seat Relay Box RH

Engine compartment fuse panel

Description	Ampere rating [A]	Protected component
ALT	200	Alternator
I/P POWER(LH)	60	I/P Junction Box LH
I/P POWER(RH)	60	I/P Junction Box RH
COOLING FAN	60	Cooling Fan Relay
EHPS	80	EHPS Motor
ECS	40	ECS Compressor Relay
AMP-1	40	AV JBL AMP
AMP-2	30	AMP
ESCL(ACC)	30	ESCL (ACC) Relay
ESP-1	30	ESP Control Module, Multipurpose Check Connector
ESP-2	30	ESP Control Module
ESCL(IGN1)	30	ESCL (IGN1) Relay
ESCL(IGN2)	30	ESCL (IGN2) Relay
P/SEAT(FR-LH)	30	Driver Lumbar Support Valve, Driver IMS Control Module, Driver Lumbar Support Switch
H/LP WASHER	20	Head Lamp Washer Relay
P/OUTLET(FR)	25	Front Power Outlet Relay, Cigar Lighter
TRUNK OPEN	10	Trunk Lid Open Relay
IMS	10	IMS Relay
STOP LP	10	Stop Lamp Relay, Stop Lamp Switch, IPM, ESP Control Module, High Mounting Stop Lamp
B/UP LP-1 (G8BA)	10	Back Up Lamp Relay
B/UP LP-2 (G8BA)	10	Rear Combination Lamp LH/RH, Electro Chromic Mirror, Rear Curtain Module, Audio, AV Head Module
WIPER	30	Electronic Control Wiper Module
FAM POWER-2	40	FAM
FAM POWER-1	40	FAM
START	30	Start Relay
WASHER	15	Washer Relay
AQS	10	AQS Sensor, Blower Relay, Electronic Control Wiper Module
HTD GLASS(FR)	15	HTD Glass(FR) Relay
IPM	10	IPM, H/LP(Low) Relay
HORN	15	Horn Relay
EPB-1	15	EPB Control Module
EPB-2	15	EPB Control Module
A/CON	10	A/C Control Module
BLOWER MOTOR	40	Blower Relay
PRESAFETY(LH)	40	Pre-Safe Seat Belt LH
HTD GLASS(RR)	40	HTD Glass(RR) Relay
PRESAFETY(RH)	40	Pre-Safe Seat Belt RH
ECU(IG1)	10	ECM
ESP	10	ESP Control Module, E/R Fuse & Relay Box (Multipurpose Check Connector)
EHPS	10	EHPS Module
AFLS	10	Head Lamp LH/RH
TCU	15	TCM
MIRROR HTD	10	A/C Control Module, Power Outside Mirror LH/RH
FUEL PUMP	20	Fuel Pump Relay
ROOM LP	10	Room LP Relay
ECU(B+)	10	ECM, TCM
STOP LP	10	Stop Lamp Switch, Alternator (G6DA), E/R Fuse & Relay Box (Stop Lamp Relay)
CRUISE	10	Smart Cruise Control Module
INHIBITOR SW	15	Alternator (G8BA), Transmission Range Switch (G6DA)
H/LP(LO-LH)	15	Head Lamp LH
H/LP(LO-RH)	15	Head Lamp RH
ENG SNSR-3	15	ECM (G6DA), Injector #1~ 6 (G6DA), Fuel Pump Relay, Injector #1~ 8 (G8BA)
ENG SNSR-2	10	Canister Purge Control Solenoid Valve, Oil Control Valve #1~4, Variable Intake Manifold Valve, E/R Fuse & Relay Box (Cooling Fan Relay), ECM, Mass Air Flow Sensor (G8BA)
ENG SNSR-1	10	Mass Air Flow Sensor (G6DA), Oxygen Sensor #1 ~ 4, ECM, Camshaft Position Sensor (G8BA)
IGN COIL-2	15	Condenser #1, Condenser #2(G6DA), Ignition Coil #1/3/5, Ignition Coil #7(G8BA)
IGN COIL-1	15	Ignition Coil #2/4/6, Ignition Coil #8 (G8BA), Condenser #2 (G8BA)
ECU	30	Engine Control Relay

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Hyundai Elantra GT (2018) – fuse box diagram

Posted on 12 August 2018 by admin

Hyundai Elantra GT (2018) – fuse box diagram

Year of production: 2018

Instrument panel

Fuse Name	Fuse Rating	Protected Component
MODULE 5	7.5A	Crash Pad Switch, Electro Chromic Mirror, A/V & Navigation Head Unit, A/C Control Module, A/T Shift Lever Indicator, Console Switch LH, Head Lamp Leveling Device LH/RH, Front Seat Warmer Control Module, Front Air Ventilation Seat Control Module
MODULE 3	7.5A	BCM, Sport Mode Switch
SUNROOF 1	20A	Panorama Sunroof
TAIIGATE OPEN	10A	Tail Gate Relay
P/WDW (LH)	25A	Power Window LH Relay, Driver/Passenger Safety Window Module
MULTIMEDIA	15A	A/V & Navigation Head Unit
P/WDW (RH)	25A	Power Window RH Relay
P/SEAT DRV	25A	Driver Seat Manual Switch
MODULE 4	7.5A	Lane Keeping Assist Module, Blind Spot Detection Radar LH/RH, Stop Lamp Switch, Electric Parking Brake Switch, Autonomous Emergency Braking Module
SMART KEY 2	7.5A	Smart Key Control Module, Immobilizer Module
SUNROOF 2	20A	Panorama Sunroof
INTERIOR LAMP	7.5A	Wireless Charger, Vanity Lamp LH/RH, Room Lamp, Overhead Console Lamp, Personal Lamp LH/RH
MEMORY 2	7.5A	BCM
MEMORY 1	10A	A/C Control Module, Instrument Cluster, Auto Light & Photo Sensor, Electro Chromic Mirror, ICM Relay Box (Outside Mirror Folding/Unfolding Relay)
AMP	30A	AMP
MODULE 6	7.5A	Smart Key Control Module, BCM
MDPS	7.5A	MDPS Unit
MODULE 1	7.5A	Hazard Switch, Center Door Lock Switch, Ignition Key Interlock Switch, Driver/Passenger Smart Key Outside Handle, Data Link Connector
MODULE 7	7.5A	Front Seat Warmer Control Module, Front Air Ventilation Seat Control Module
A/BAG IND	7.5A	Instrument Cluster, Center Door Lock Switch
BRAKE SWITCH	7.5A	Smart Key Control Module, Stop Lamp Switch
START	7.5A	Without Smart Key : Ignition Key Switch With Smart Key : Smart Key Control Module
CLUSTER	7.5A	Instrument Cluster
DR LOCK	20A	Door Lock/Unlock Relay, ICM Relay Box (T/Turn Unlock Relay)
AEB	10A	Autonomous Emergency Braking Module
S/HEATER	20A	Front Seat Warmer Control Module, Front Air Ventilation Seat Control Module
A/CON	7.5A	A/C Control Module, Cluster Ionizer, E/R Junction Block (Blower Relay)
SMART KEY 1	15A	Smart Key Control Module, Immobilizer Module
A/BAG	15A	SRS Control Module
IG1	25A	PCB Block (ABS3, ECU5, SENSOR4, TCU2)
MODULE 2	10A	Wireless Charger, Smart Key Control Module, BCM, A/V & Navigation Head Unit, Power Outside Mirror Switch, E/R Junction Block (Power Outlet Relay), AMP
WASHER	15A	Multifunction Switch
WIPER (LO/HI)	10A	ECM/PCM, BCM
WIPER (RR)	15A	Rear Wiper Relay, Rear Wiper Motor
HEATED MIRROR	10A	Driver/Passenger Power Outside Mirror, A/C Control Module, ECM/PCM
POWER OUTLET	20A	Rear Power Outlet #2
HEATED STEERING	15A	BCM

Engine compartment fuse panel

Hyundai Elantra GT - fuse box diagram - engine compartment — Hyundai Elantra GT – fuse box diagram – engine compartment

Fuse Name	Fuse Rating	Protected Component
MAIN	150A	E/R Junction Block (Fuse – ABS1, ABS2, B/Alarm, Power Outlet – !)
MDPS 1	80A	MDPS Unit, Battery
B+5	60A	PCB Block (Fuse – ECU4, ECU3, Horn, Wiper, Engine Control Relay)
B+2	60A	IGPM (Fuse – S/Heater, IPSO, IPS1, IPS2)
B+3	60A	IGPM (IPS3, IPS4, IPS5, IPS6, IPS7, IPS8)
B+4	60A	IGPM (Fuse – AMP, P/WDW LH, P/WDW RH, Tail Gate Open, Sunroofl, Sunroof2, P/Seat (DRV))
COOLING FAN 1	60A	E/R Junction Block (Cooling Fan1 Relay)
REAR HEATED	40A	E/R Junction Block (Rear Heated Relay)
BLOWER	40A	E/R Junction Block (Blower Relay)
IG1	40A	Ignition Switch, E/R Junction Block (ACC Relay, IG1 Relay)
IG2	40A	Ignition Switch, E/R Junction Block (IG2 Relay)
PTC HEATER 1	50A	PTC Heaterl
POWER OUTLET 3	20A	Rear Power Outlet 1
POWER OUTLET 2	20A	Front Power Outlet
TCU1	15A	TCM
VACUUM PUMP	20A	Vacuum Pump
FUEL PUMP	20A	E/R Junction Block (Fuel Pump Relay)
COOLING FAN 2	40A	E/R Juntion Block (Cooling Fan2 Relay, Cooling Fan3 Relay)
B+1	40A	IGPM (Fuse – Door Lock, Smart Key1, Module*!, Brake Switch, Reak Current Autocut Device)
DOT 1	40A	TCM
DOT 2	40A	TCM
B/ALARM HORN	10A	ICM Relay Box (Burglar Alarm Horn Relay)
ABS 1	40A	Multipurpose Check Connector, ESC Control Module
ABS 2	30A	Multipurpose Check Connector, ESC Control Module
POWER OUTLET 1	40A	E/R Junction Block (Power Outlet Relay)
B/UP LAMP	10A	Back-Up Lamp Switch
GAMMA 1.6LT-GDI
SENS0R2	10A	Waste Gate Valve, Purge Control Solenoid Valve, Oil Control Valve #1/#2, RCV Control Solenoid Valve, E/R Junction Block (Cooling Fan2 Relay, Cooling Fan1 Relay)
ECU2	10A	ECM
ECU1	20A	ECM
SENS0R1	15A	Oxygen Sensor (Up), Oxygen Sensor (Down)
IGN COIL	20A	Ignition Coil #1/#2/#3/#4
ECU3	15A	ECM
ECU5	10A	ECM
SENSOR4	15A	Vaccum Pump
ABS3	10A	ESC Control Module, Multipurpose Check Connector, Clutch Master Cylinder
TCU2	15A	E/R Junction Block (Fuse – B/Up Lamp), Transaxle Range Switch, TCM
SENSOR3	10A	E/R Junction Block (Fuel Pump Relay)
ECU4	15A	ECM
WIPER	25A	Wiper Relay
HORN	15A	Horn Relay
NU 2.0L GDI
SENS0R2	10A	Purge Control Solenoid Valve, Oil Control Valve #1/#2, Variable Intake Solenoid Valve, E/R Junction Block (Cooling Fan2 Relay, Cooling Fan3 Relay)
ECU2	10A	ECM/PCM
ECU1	20A	ECM/PCM
SENS0R1	15A	Oxygen Sensor (Up), Oxygen Sensor (Down)
IGN COIL	20A	Ignition Coil #1/#2/#3/#4, Condenser
ECU3	15A	ECM/PCM
ECU5	10A	ECM/PCM
ABS3	10A	ABS/ESC Control Module, Multipurpose Check Connector
ABS3	15A	E/R Junction Block (Fuse – B/Up Lamp), Transaxle Range Switch, TCM
SENSOR3	10A	E/R Junction Block (Fuel Pump Relay)
WIPER	25A	Wiper Relay
HORN	15A	Horn Relay

Battery terminal cover

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Hyundai Elantra GT (2016 – 2017) – fuse box diagram

Posted on 12 August 2018 by admin

Hyundai Elantra GT (2016 – 2017) – fuse box diagram

Year of production: 2016, 2017

Instrument panel

Description	Fuse rating	Protected component
C/LIGHTER	20A	Console Cigar Light, Rear Power Outlet
1 MODULE	7.5A	Sport Mode Switch
4 MODULE	7.5A	A/ C Control Module, Head Lamp Leveling Device Actuator LH/RH, Fuel Filter Warning Sensor(D4FD), Rear Parking Assist System
3 MODULE	7.5A	Instrument Cluster, BCM, Tire Pressure Monitoring Module, Audio, Driver/Passenger Seat Warmer Module, ATM shift lever Ind
POWER OUTLET FRT	15A	Front Power Outlet
HTD MIRR	10A	Driver/Passenger Power Outside Mirror, A/C Control Module, ECU
WIPER FRT	25A	ICM Relay Box (Rain Sensor Relay), Multifunction Switch, E/R Fuse & Relay Box (RLY. 7) Front Wiper Motor
A/CON	7.5A	A/C Control Module, E/R Fuse & Relay Box (RLY. 4)
P/WDW LH	25A	P/WDW LH Relay, Driver Safety Power Window Module (LHD)
T/GATE OPEN	10A	Tail Gate, Rear Camera Open Actuator
P/SEAT DRV	30A	Driver Manual Switch
2 MODULE	7.5A	ICM Relay Box, Rear Camera Module, Electro Chromic Mirror
WIPER RR	15A	Rear Wiper Relay, Rear Wiper Motor, Multifunction Switch
STOP LAMP	15A	Stop Lamp Switch
P/WDW RH	25A	P/WDW RH Relay, Driver Safety Power Window Module (RHD)
2 PDM	7.5A	Smart Key Control Module, Start/Stop Button Switch, Ultrasonic Instruction Protection Sensor
5 MODULE	7.5A	EMS BOX (Head Lamp Washer Relay), Ionizer Unit, Panorama Sunroof, DSL BOX (PTC Relay), E/R Fuse & Relay BOX(RLY.), Driver/Passenger Seat Warmer Module
IG1	20A	E/R Fuse & Relay Box (Fuse – F)
6 MODULE	10A	Outside Mirror Switch, Audio, Navigation Head Unit, Digital Clock
MDPS	7.5A	EPS Control Module
DR LOCK	20A	Door Lock/Unlock Relay, ICM Relay BOX (Dead Lock Relay), Driver/Passenger Door Lock Actuator, Fuel filler actuator, Door Lock Actuator LH/RH
INTERIOR LAMP	10A	Vanity Lamp LH/RH, Overhead Console Lamp, Room Lamp, Luggage Lamp, DR Warning Switch
MULTI MEDIA	15A	Audio, Navigation Head Unit
A/BAG	15A	SRS Control Module
1 MEMORY	7.5A	Instrument Cluster
A/BAG IND	7.5A	Instrument Cluster
3 PDM	7.5A	Smart Key Control Module, Ultrasonic instrusion Protection Sensor
2 MEMORY	10A	Outside Mirror Switch, Tire Pressure Monitoring Module, BCM, Auto Light & Photo Sensor, OBD, Digital Clock, A/C Control Module
1 PDM	25A	Smart Key Control Module
START	7.5A	W/O Button Start: E/R Fuse & Relay Box (RLY.) Ignition Lock Switch, Transaxle Range Switch With Button Start: ECM/PCM, Transaxle Range Switch
SUNROOF	20A	Panorama Sunroof
BCM	7.5A	BCM, Smart Key Control Module
A/CON SWITCH	7.5A	A/C Control Module
7 MODULE	7.5A	BCM, Smart Key Control Module
FOG LAMP RR	10A	Rear Fog Lamp
PUDDLE LAMP	10A	Driver/Passenger Power Outside Mirror

Engine compartment fuse panel

Description	Fuse rating	Protected component
MULTI FUSE
MDPS	80A	EPS Control Module
1B+	60A	I/P Junction Box (IPS 0 (4CH), IPS 1 (4CH), IPS 2 (2CH), Fuse – F13/F14/F19/F20/F21 /F26/ F36)
1 ABS	40A	ESC Control Module, Multipurpose Check Connector
BLOWER	40A	RLY. 4 (Blower Relay)
2B+	60A	I/P Junction Box (IPS 3 (4CH), IPS 4 (4CH), Fuse – F2/F7/F9/F15)
GSLPTC HEATER	60A	RLY. 12 (GASOLINE PTC Relay)
FUSE
COOLING FAN	40A	RLY 1 (C/FAN LO Relay), RLY 2 (C/FAN HI Relay)
2 ABS	20A	ESC Control Module, Multipurpose Check Connector
IG2	40A	RLY 9 (Start Relay), Ignition Switch (W/O Button Start), RLY 6 (PDM 4 (IG2) Relay, With Button Start)
IG1	40A	W/O Button Start: Ignition Switch, With Button Start: RLY 8 (PDM 2 (ACC) Relay)/RLY. 10 (PDM 3 (IG1) Relay
DEICER	15A	ICM Relay Box (Front Deicer Relay)
3B+	50A	I/P Junction Box (Leak Current Autocut Device, Fuse – F18/F25/F30/F34/F38)
BRAKE SWITCH	10A	Smart Key Control Module, Stop Signal Relay
S/HEATER FRT	20A	Driver/Passenger Seat Warmer Module
WIPER	10A	PCM/ECM
HORN	15A	RLY. 5 (Horn Relay), ICM Relay Box (B/A Horn Relay)
1 TCU	15A	A/T – TCM (D4FD), Transaxle Range Switch
6 ECU	15A	RLY. 9 (D4FD, Start Relay), ECM/PCM
3 ABS	10A	ESC Control Module, Multipurpose Check Connector
3 ECU	10A	ECM/PCM, Air Flow Sensor, Stop Lamp Switch
B/UP LAMP	10A	M/T – Back-Up Lamp Switch, A/T – Rear Combination Lamp (IN) LH/RH, Rear Curtain Module, Navigation Head Unit, Electro Chromic Mirror, IPS Control Module
1 ECU	20A	G4FD/D4FD : ECM G4NA/G4NC : PCM (A IT), ECM (M/T)
IGN COIL	20A	G4NA : Ignition Coil #1/#2/#3/#4, Condenser
2 SENSOR	10A	G4FD : Oxygen Sensor (UP/DOWN), Variable Intake Solenoid Valve, Purge Control Solenoid Valve G4NA/G4NC : Oxygen Sensor (UP/DOWN), Variable Intake Solenoid Valve, Purge Control Solenoid Valve D4FD : Camshaft Position Sensor, EGR Cooling Bypass Solenoid Valve, Diesel Box (Glow Relay)
1 SENSOR	10A	G4FD : Oil Control Valve #1/ #2, Oil Level Sensor, E/R Fuse & Relay Box (RLY. 1) G4NA/G4NC : Oil Control Valve #1/ #2, Camshaft Position Sensor (Intake/Exhaust), E/R Fuse & Relay Box (RLY. 1) D4FD : E/R Fuse & Relay Box (RLY 1), Diesel Box (PTC Heater Relay#1), Lambda Sensor, VGT Control Solenoid Valve
2 ECU	10A	G4FD : ECM G4NA : Fuel Pump Relay G4NC : Fuel Pump Relay, PCM (A/T), ECM (M/T) D4FD : Oil Level Sensor, Fuel Pressure Regulating Valve
INJECTOR	10A	G4NA – Injector #1/#2/#3/#4
4 ECU	15A	G4NA/G4NC : PCM (ATT), ECM (M/T)
FUEL PUMP	20A	EMS Box (Fuel Pump Relay)
A/CON	30A	EMS Box (Air Conditioner)
EMS	40A	EMS Box

Assignment of the relay

Description	Protected component	Type
1 COOLING FAN	C/FAN LO RELAY	PLUG MICRO
2 COOLING FAN	C/FAN HI RELAY	PLUG MICRO
BLOWER	BLOWER RELAY	PLUG MICRO
HORN	HORN RELAY	PLUG MICRO
4 PDM (IG2)	PDM 4 (IG2) RELAY	PLUG MICRO
WIPER	FRONT WIPER RELAY	PLUG MICRO
1 PDM (ACC)	PDM 1 (ACC) RELAY	PLUG MICRO
START 1	START RELAY	PLUG MICRO
3 PDM (IG1)	PDM 3 (IG1) RELAY	PLUG MICRO
REAR HEATED	RR HTD RELAY	PLUG MICRO
GSL PTC HEATER	PTC Heater/Fuel Filter	PLUG MINI

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Hyundai Elantra (2017 – 2018) – fuse box diagram

Posted on 12 August 2018 by admin

Hyundai Elantra (2017 – 2018) – fuse box diagram

Year of production: 2017, 2018

Instrument panel (Driver’s side fuse panel)

Hyundai Elantra - fuse box diagram - instrument panel — Hyundai Elantra – fuse box diagram – instrument panel

Fuse name	Symbol	A	Protected component
SPARE2		10	Spare
CLUSTER		10	Instrument Cluster
A/BAG IND		7,5	Instrument Cluster, A/C Control Module
MDPS1		7,5	MDPS Unit
MODULE7		7,5	Front Seat Warmer Control Module, Front Air Ventilation, Seat Control Module, Rear Seat Warmer Control Module, Sunroof Motor, Electro Chromic Mirror
A/CON1		7,5	E/R Junction Block (RLY.12, RLY. 1B, RLY. 13B), Ionizer, A/C Control Module
HTD STRG		15	BCM
WIPER1		25	Wiper Motor, PCM Block (Front Wiper (Low) Relay)
HTD MIRR		10	Driver Power Outside Mirror, Passenger Power Outside Mirror, A/C Control Module
DR LOCK		20	Door Lock Relay, Door Unlock Relay
MULTI MEDIA		15	DC-DC Converter, Audio A/V&Navigation Head Unit MTH E-Call Module
MODULE1		7,5	Driver/Passenger Smart Key Outside Handle, Driver Door Module, Passenger Door Module
BUTTON START3		7,5	Immobilizer Module, Smart Key Control Module
A/BAG		15	SRS Control Module
MODULE6		7,5	Smart Key Control Module, BCM
WASHER		15	Multifunction Switch
WIPER2		10	BCM, ECM/PCM
MEMORY1		10	Driver/Passenger Door Module, Driver IMS Module, BCM, Data Link Connector, Digital Clock, Rain Sensor, A/C Control Module, Instrument Cluster, ICM Relay Box (Outside Mirror Folding/Unfolding Relay)
MEMORY2		7,5	—
SUNROOF		20	Sunroof Motor
BRAKE SWITCH		7,5	Stop Lamp Switch, Smart Key Control Module
MODULE3		10	Stop Lamp Switch, BCM, Sport Mode Switch, Driver Door Module, Passenger Door Module
SPARE3		15	Spare
SPARE5		25	Spare
S/HEATER REAR		25	Rear Seat Warmer Control Module
AMP		25	DC-DC Converter, AMP
SPARE4		20	Spare
BUTTON START2		7,5	Smart Key Control Module, Immobilizer Module
AEB	AEB	10	—
MODULE4		10	Parking Assist Buzzer, Blind Spot Detection Radar LH/RH
P/WDW RH		25	Power Window RH Relay Driver Safety Power Window Module (RHD)
TRUNK		10	Trunk Relay, Trunk Lid Latch
P/SEAT DRV		30	Driver Seat Manual Switch, Driver Seat Manual Switch, Driver lms Module
S/HEATER FRONT		20	Front Seat Warmer Control Module, Front Air Ventilation Seat Control Module
START		7,5	Burglar Alarm Relay, Transmission Range Switch, Ignition Lock & Clutch Switch, Smart Key Control Module, ECM/PCM, E/R Junction Block (RLY.4)
BUTTON START1		15	Smart Key Control Module
A/CON2		10	E/R Junction Block (RLY.12), Blower Motor, B;pwer Resistor, A/C Control Module
SPARE1		20	Spare
P/WDW LH		25	Power Window LH Relay Driver Safety Power Window Module (LHD)
INTERIOR LAMP		10	Ignition Key ILL. & Door Warning Switch, Trunk Room Lamp, Front Vanity Lamp, LH/RH Room Lamp, Overhead Console Lamp
MODULE2		10	Digital Clock, USB Charging Connector, MTS E-Call Module, Smart Key Control Module, BCM, Audio, A/V & Navigation Head Unit, Power Outside Mirror Switch, DC-DC Converter, AMP, E/R Junction Block (RLY.14)

Engine compartment fuse panel

Hyundai Elantra - fuse box diagram - engine compartment — Hyundai Elantra – fuse box diagram – engine compartment

Fuse name	Symbol	A	Protected component
MAIN		150	Fuse: F28, F29, F30, F31, F34
MDPS		80	MDPS Unit
BATT5		60	PCB Block (Fuse: F8, F14, F15, F16, Engine Control Relay)
BATT2		60	Smart Junction Block (Fuse: F36, ARISU)
BATT3		60	Smart Junction Block (Fuse: ARISU, IPS)
BATT4		50	Smart Junction Block (Fuse: F20, F26, F27, F33, F34, F35, F41)
COOLING FAN1		50	RLY.9, RLY.2 (DSL)
RR HTD		50	RLY.10
BLOWER		40	RLY.12
IG1		40	Ignition Switch, E/R Junction Block (RLY.3, RLY8)
IG2		40	Ignition Switch, E/R Junction Block (RLY.6)
PTC HEATER1		50	RLY.11B
PTC HEATER2		50	RLY.1B
PTC HEATER3		50	RLY.13B
FUEL HEATER		40	RLY.5B
B/UP LAMP		10	Electro Chromic Mirror, Rear Combination Lamp (IN) LH/RH, Audio, MTS E-Call Module, Smart Junction Block (IPS Control Module)
POWER OUTLET3		20	Cigarette Lighter
POWER OUTLET2		20	Power Outlet
HEAD LAMP HI		20	RLY.13A
TCU1		15	TCM
VACUUM PUMP1		20	—
A/CON		10	—
COOLING FAN2		40	RLY.9, RLY.2 (GSL)
BATT1		40	Smart Junction Block (LEAK CURRENT AUTCUT DEVICE, Fuse: F10, F12, F21, F29, F38)
DCT1		40	TCM
DCT2		40	TCM
B/ALARM HORN		10	RLY.7
ABS1		40	ABS Control Module, ESC Control Module, Multipurpose Check Connector
ABS2		30	ABS Control Module, ESC Control Module, Multipurpose Check Connector
POWER		40	RLY.14

Engine compartment main fuse panel – PCB (Gamma 1.6 MPI)

Fuse name	Symbol	A	Protected component
SNSR2		10	Purge Control Solenoid Valve, Variable Intake Solenoid Valve, E/R Junction Block (RLY.2, RLY.9)
ECU2		15	—
ECU1		10	ECM/PCM
INJ		15	INJECTOR #1-#4
SNSR1		15	Oxygen Sensor (Up), Oxygen Sensor (Down)
IGN		15	Ignition Coil #1-#4, Condenser
SNSR3		20	Fuel Pump Relay, Oil Control Valve #1, Oil Control Valve #2
HORN		10	Horn Relay
ECU5		10	ECM/PCM
SNSR4		20	—
ABS3		15	ABS/ESC Control Module, Multipurpose Check Connector
TCU2		15	Vehicle Speed Sensor, Transmission Range Switch, E/R Junction Block (Fuse: F17)
ECU4		20	ECM/PCM
ECU3		10	ECM/PCM
F/PUMP		20	Fuel Pump Relay

Engine compartment main fuse panel – PCB Block (Nu 2.0 MPI)

Fuse name	Symbol	A	Protected component
SNSR2		10	Purge Control Solenoid Valve, Variable Intake Solenoid Valve, E/R Junction Block (RLY.2, RLY.9)
ECU2		15	PCM
ECU1		10
INJ		15	INJECTOR #1-#4
SNSR1		15	Oxygen Sensor (Up), Oxygen Sensor (Down)
IGN		15	Ignition Coil #1-#4, Condenser
SNSR3		20	Fuel Pump Relay, Oil Control Valve #1, Oil Control Valve #2
HORN		10	Horn Relay
ECU5		10	ECM/PCM
SNSR4		20	—
ABS3		15	ABS/ESC Control Module, Multipurpose Check Connector
TCU2		15	Vehicle Speed Sensor, Transmission Range Switch, E/R Junction Block (Fuse: F17)
ECU4		20	PCM
ECU3		10	PCM
F/PUMP		20	Fuel Pump Relay

Engine compartment main fuse panel – PCB Block (UII 1.6 TCI)

Fuse name	Symbol	A	Protected component
SNSR2		10	Purge Control Solenoid Valve, Variable Intake Solenoid Valve, E/R Junction Block (RLY.2, RLY.9)
ECU2		15	—
ECU1		10	ECM
INJ		15
SNSR1		15	Lambda Sensor #1, Lambda Sensor #2
IGN		15	—
SNSR3		20	Fuel Pump Relay, Air Flow Sensor, Camshaft Position Sensor, Oil Control Valve
HORN		10	Horn Relay
ECU5		10	ECM
SNSR4		20	Fuel Filter Warning Sensor, Glow Relay Unit
ABS3		15	ABS/ESC Control Module, Multipurpose Check Connector
TCU2		15	TCM, Transmission Range Switch
ECU4		20	—
ECU3		10	PCM
F/PUMP		20	Fuel Pump Relay

Assignment of the relay

Symbol	Relay NO.	Protected component	Type
	RLY.1B	PTC HEATER #2 Relay	MICRO
	RLY.2	COOLING FAN2 Relay	MICRO
	RLY.3	PDM #3 (IG1) Relay	MICRO
	RLY.4	START #1 Relay	MICRO
	RLY.5A	SUB FUEL PUMP Relay	MICRO
	RLY.5B	FUEL HEATER Relay (D4FB)	MICRO
	RLY.6	PDM #4 (IG2) Relay	MICRO
	RLY.7	B/ALARM HORN Relay	MICRO
	RLY.8	PDM #2 (ACC) Relay	MICRO
	RLY.9	COOLING FAN1 Relay	MINI
	RLY.10	REAR HEATED Relay	MINI
	RLY.11	A/C Relay	MICRO
	RLY.11B	PTC HEATER #1 Realy (D4FB)	MICRO
	RLY.12	BLOWER Relay	MICRO
	RLY.13A	H/LAMP HI Relay	MICRO
	RLY.13B	PTC HEATER #3 Relay (D4FB)	MICRO
	RLY.14	POWER OUTLET Relay (D4FB)	MICRO

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Subaru WRX (2018) – fuse box diagram

Posted on 11 August 2018 by admin

Subaru WRX (2018) – fuse box diagram

Year of production: 2018

Instrument panel

Fuse	A	Circuit
1	20	R.FOG TRAIL
2	7.5	METER IG
3	15	DOOR LOCK
4	10	IG2
5	—	—
6	7.5	MIR
7	15	UNIT+B
8	7.5	STOP
9	7.5	WIPER DEICE
10	7.5	D-OP+B
11	7.5	TURN IG
12	15	UNIT IG1
13	20	12V PLUG
14	10	TAIL CLEARANCE
15	10	BKUP+B
16	7.5	ILM
17	15	SEAT HTR
18	10	LAMP IG
19	—	—
20	10	CIGAR
21	10	START
22	7.5	A/C IG
23	—	—
24	10	AUDIO NAVI
25	15	SRS AIR BAG
26	7.5	IG1
27	15	BLOWER
28	15	BLOWER
29	15	F.FOG
30	—	—
31	7.5	ACC
32	7.5	STR LOCK
33	7.5	UNIT IG2

Engine compartment (STI)

Fuse	A	Circuit
A		Main fuse
1	30	ABS SOL
2	25	MAIN FAN
3	25	SUB FAN
4	—	—
5	25	AUDIO AMP
6	30	H/L LO
7	15	H/L HI
8	20	BACK UP
9	15	HORN
10	25	R.DEF
11	15	FUEL PI, P
12	10	(Transmission control unit)
13	7.5	EGI+B
14	15	HAZARD
15	15	LIGHTING
16	7.5	ALT-S
17	—	—
18	20	INJ
19	15	H/L LO RH
20	15	H/L LO LH
21	10	AIR CUT
22	7.5	(Telematics)

Engine compartment (expect STI)

Fuse	A	Circuit
A		Main fuse
1	30	ABS SOL
2	25	MAIN FAN
3	25	SUB FAN
4	—	—
5	25	AUDIO AMP
6	30	H/L LO
7	15	H/L HI
8	20	BACK UP
9	15	HORN
10	25	R.DEF
11	15	FUEL PI, P
12	10	(Transmission control unit)
13	7.5	EGI+B
14	15	HAZARD
15	15	LIGHTING
16	7.5	ALT-S
17	—	—
18	20	INJ
19	15	H/L LO RH
20	15	H/L LO LH

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Subaru WRX (2015 – 2017) – fuse box diagram

Posted on 11 August 2018 by admin

Subaru WRX (2015 – 2017) – fuse box diagram

Year of production: 2015, 2016, 2017

Instrument panel

Fuse	A	Circuit
1	20	(Not available)
2	7.5	Combination meter
3	15	Door locking
4	10	Front wiper deicer relay
5	—	—
6	7.5	Remote control rear view mirrors, Seat heater relay
7	10	Combination meter, Integrated unit
8	7.5	Stop light
9	7.5	Front wiper deicer
10	7.5	Power supply (battery)
11	7.5	Turn signal unit
12	15	Transmission control unit, Engine control unit, Integrated unit
13	20	Accessory power outlet (center console)
14	10	Parking light, Tail light, Rear combination light
15	10	Trunk light, Keyless unit
16	7.5	Illumination
17	15	Seat heaters
18	10	Backup light
19	–	Daytime running lights
20	10	Accessory power outlet (instrument panel)
21	7.5	Starter relay
22	10	Air conditioner, Rear window defogger relay coil
23	—	—
24	10	Audio unit, Navigation system (if equipped)
25	15	SRS airbag system
26	7.5	Power window relay, Radiator main fan relay
27	15	Blower fan
28	15	Blower fan
29	10	Fog light
30	—	—
31	7.5	Auto air conditioner unit, Integrated unit
32	7.5	Clutch switch, Steering lock control unit
33	7.5	Vehicle Dynamics Control unit

Engine compartment (STI)

Fuse	A	Circuit
A		Main fuse
1	30	ABS unit, Vehicle Dynamics Control unit
2	25	Main fan (cooling fan)
3	25	Sub fan (cooling fan)
4	—	—
5	25	Audio
6	30	Headlight (low beam)
7	15	Headlight (high beam)
8	20	Back-up
9	15	Horn
10	25	Rear window defogger, Mirror heater
11	15	Fuel pump
12	10	Transmission control unit
13	7.5	Engine control unit
14	15	Turn and hazard warning flasher
15	15	Tail and illumination relay
16	7.5	Alternator
17	—	—
18	20	Injection
19	15	Headlight (low beam -right hand)
20	15	Headlight (low beam -left hand)
21	10	Secondary air combination valve

Engine compartment (expect STI)

Fuse	A	Circuit
A		Main fuse
1	30	ABS unit, Vehicle Dynamics Control unit
2	25	Main fan (cooling fan)
3	25	Sub fan (cooling fan)
4	—	—
5	25	Audio
6	30	Headlight (low beam)
7	15	Headlight (high beam)
8	20	Back-up
9	15	Horn
10	25	Rear window defogger, Mirror heater
11	15	Fuel pump
12	20	Transmission control unit
13	7.5	Engine control unit
14	15	Turn and hazard warning flasher
15	15	Tail and illumination re lay
16	7.5	Alternator
17	—
18	20	Injection
19	15	Headlight (low beam -right hand)
20	15	Headlight (low beam -left hand)

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Subaru Crosstrek (2018) – fuse box diagram

Posted on 11 August 2018 by admin

Subaru Crosstrek (2018) – fuse box diagram

Year of production: 2018

Instrument panel

Fuse	A	Circuit
1	—	—
2	20	CIGAR SEAT/H
3	7.5	IG A-1
4	15	AUDIO NAVI
5	15	IG B-2
6	—	—
7	15	12V SOCKET
8	15	A/C IG
9	7.5	ACC
10	7.5	IG B-1
11	—	—
12	Empty
13	7.5A	IG A-3
14	7.5A	UNIT +B
15	7.5A	METER IG
16	Empty
17	7.5A	MIRROR
18	7.5A	LAMP IG
19	10A	IG A-2
20	10A	SRS AIR BAG
21	Empty
22	15	STRG/H
23	10	DRL
24	—	—
25	—	—
26	10	BACK UP
27	—	—
28	20	TRAIL R.FOG
29	—	—
30	—	—
31	—	—
32	7.5	ILLUMI
33	7.5	KEY SWA
34	—	—
35	—	—
36	7.5	KEY SW B
37	7.5	STOP
38	7.5	EYE SIGHT

Engine compartment

Fuse	A	Circuit
1	7.5	HORN 2
2	7.5	HORN 1
3	15	H/L LO RH
4	15	H/L LO LH
5	7.5	ACTGS
6	10	H/L HI RH
7	10	H/L HI LH
8	10	TAIL
9	10	ODS
10	7.5	OBD
11	7.5	PU B/UP
12	30	JB-B
13	15	HAZARD
14	20	FUEL
15	7.5	D-OP+B
16	10	MB-B
17	15	D/L
18	10	DCM
19	20	TCU
20	7.5	CVT SSR
21	15	IG COIL
22	10	AVCS
23	10	E/G2
24	—	—
25	—	—
26	20	O2 HTR
27	15	E/G1
28	—	—
29	30	BACKUP
30	25	R. DEF
31	20	AUDIO
32	30	VDC SOL
33	25	MAIN FAN
34	25	SUB FAN
35	10	DEICER
36	15	F. FOG
37	15	BLOWER
38	15	BLOWER
39	—
40	30	F. WIPER
41	15	F. WASH
42	15	R. WIPER
43	—	—
44	—	—

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Subaru Crosstrek (2011 – 2015) – fuse box diagram

Posted on 11 August 2018 by admin

Subaru Crosstrek (2011 – 2015) – fuse box diagram

Year of production: 2011, 2012, 2013, 2014, 2015

Instrument panel

Subaru Crosstrek - fuse box - passenger compartment — Subaru Crosstrek – fuse box – passenger compartment

Fuse panel	Fuse rating	Circuit
1	20A	Trailer hitch connector
2	Empty
3	15A	Door locking
4	10A	Front wiper deicer relay
5	10A	Combination meter, Clock
6	7.5A	Remote control rear view mirrors, Seat heater relay
7	15A	Combination meter, Integrated unit
8	15A	Stop light
9	15A	Front wiper deicer
10	7.5A	Power supply (battery)
11	7.5A	Turn signal unit
12	15A	Transmission control unit, Engine control unit, Integrated unit
13	20A	Accessory power outlet (center console), AC 110V (If installed)
14	15A	Parking light, Tail light, Rear combination light
15	10A	Luggage light, Clock
16	7.5A	Illumination
17	15A	Seat heaters
18	10A	Backup light
19	7.5A	(Spare)
20	10A	Accessory power outlet (instrument panel)
21	7.5A	Starter relay
22	10A	Air conditioner, Rear window defogger relay coil
23	Empty
24	10A	Audio unit, Clock
25	15A	SRS airbag system
26	7.5A	Power window relay, Radiator main fan relay
27	15A	Blower fan
28	15A	Blower fan
29	15A	Fog light
30	Empty
31	7.5A	Auto air conditioner unit, Integrated unit
32	7.5A	Clutch switch, Steering lock control unit
33	7.5A	Vehicle Dynamics Control unit

Engine compartment

Fuse	A	Circuit
1	30	ABS unit, Vehicle Dynamics Control unit
2	25	Main fan (cooling fan)
3	25	Sub fan (cooling fan)
4	—	—
5	—	—
6	30	Headlight (low beam)
7	15	Headlight (high beam)
8	20	Back-up
9	15	Horn
10	25	Rear window defogger, Mirror heater
11	15	Fuel pump
12	20	Automatic transmission control unit
13	7.5	Engine control unit
14	15	Turn and hazard warning flasher
15	15	Tail and illumination relay
16	7.5	Alternator
17	—	—
18	—	—
19	15	Headlight (low beam -right hand)
20	15	Headlight (low beam -left hand)

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Mercury Mountaineer (1997 – 2001) – fuse box diagram

Posted on 11 August 2018 by admin

Mercury Mountaineer (1997 – 2001) – fuse box diagram

Year of production: 1997, 1998, 1999, 2000, 2001

Passenger compartment fuse panel

Mercury Mountaineer First Generation - fuse box - passenger compartment — Mercury Mountaineer First Generation – fuse box – passenger compartment

No.	A	Protected components
1	7.5	Power Mirror Switch, Power Antenna, Memory Seat (’00-’01)
2	7.5	’98-’01: Blower Motor Relay, Air Bag Diagnostic Monitor, Passive Deactivation (PAD) Module (’98)
2	7.5	’97: High-mount Brakelamp
3	7.5	’98-’01: Left Stop/Turn Trailer Tow Connector
3	15	’97: Parking Lamps
4	10	Left Headlamp
5	10	Data Link Connector (DLC)
6	7.5	’99-’01: Rear Blower Motor (Without EATC)
6	7.5	’97-’98: Air Bag System, Blower Relay, Passive Deactivation (PAD) Module (’98)
7	7.5	’98-’01: Right Stop/Turn Trailer Tow Connector
7	7.5	’97: Illumination switches
8	10	Right Headlamp, Foglamp Relay, Daytime Running Lamps (DRL) Module (’98)
9	7.5	’98-’01: Brake Pedal Position Switch
9	10	’97: Autolamps
10	7.5	’98-’01: Speed Control/Amplifier Assembly, Generic Electronic Module (GEM), Shift Lock Actuator, Blend Door Actuator, A/C – Heater Assembly, Flasher, Overhead Console (’99-’01), Load Leveling Module (’99-’01), Brake Pressure Switch (’98), Main Light Switch (’98), RABS Resistor (’98), A/C – Heater Assembly
10	7.5	’97: Rear Blower, Speed Control, Generic Electronic Module (GEM), Brake Interlock, Overhead Console
11	7.5	Instrument Cluster, Main Light Switch (’98), RABS Resistor (’98)
12	7.5	’98-’01: Washer Pump Relay, Rear Washer Pump Relay
12	10	’97: Liftgate Wiper/Washer, Front Washer
13	20	’98-’01: Brake Pedal Position Switch, Brake Pressure Switch
13	15	’97: Brake on/off Switch
14	10	’98-’01: 4 Wheel Anti-Lock Brake System (4WABS) Module, 4WABS Main Relay
	10	’97: Anti-Lock Brake System
	20	’98: Rear Anti-Lock Brake System (RABS) Module
15	7.5	Instrument Cluster, Air Bag System (’97)
16	30	Windshield Wiper Motor (’98-’01), Wiper Hi-Lo Relay (’98-’01), Wiper Run/Park Relay
17	25	’98-’01: Cigar Lighter
17	15	’97: Cigar Lighter
18	25	’99-’01: Drivers Unlock Relay, All Unlock Relay, All Lock Relay, Power Seats
	15	’97: A/C System
	15	’98: Drivers Unlock Relay, All Unlock Relay, All Lock Relay
19	25	’98-’01: PCM Power Diode
19	25	’97: Ignition Coil, PCM System
20	7.5	RAP Module (’98-’01), Generic Electronic Module (GEM), Radio, Cellular Phone (’99-’01), Power Antenna (’97), Anti-theft (’97)
21	15	Flasher (Hazard)
22	20	Auxiliary Power Socket
22	10	Turn Signals
23	—	’99-’01: Not Used
	10	’97: Rear Wiper System
	15	’98: Turn Signals
24	7.5	’99-’01: Clutch Pedal Position (CPP) Switch, Starter Interrupt Relay, Anti-Theft
	10	’97: Anti-theft Relay
	—	’98: Not Used
25	7.5	Generic Electronic Module (GEM), Instrument Cluster, Securi-Lock (’99-’01)
26	10	’98-’01: Battery Saver Relay, Electronic Shift Relay, Interior Lamp Relay, Electronic Shift Control Module, Power Window Relay (’98), Shift Control Module (’98), Transmission Control (’98)
26	10	’97: 4R70W Overdrive, Daytime Running Lamps (DRL) System, Backup Lamps, Rear Defroster Relay
27	15	’99-’01: Daytime Running Lamps (DRL), Backup Lamps Switch, DTR Sensor
	10	’97: Underhood Lamp, Map Lights, Glove Box Lamp, Overhead Lamp, Visor Lamps, Accessory Delay, Dimmer Switch Illumination
	15	’98: Switch, Daytime Running Lamps (DRL), Backup Lamps Switch, DTR Sensor, Instrument Illumination Dimming Module, Dome/Map Lamp, GEM, Electric Shift, Interior Lights, Glove Box Lamp and Switch
28	7.5	Generic Electronic Module (GEM), Radio (’98-’01), Memoiy Seat (’99-’01)
29	25	’00-’01: Radio
	10	’97: Audio System
	15	’98: Radio
	10	’99: Radio
30	15	’98-’01: Park Lamp/Trailer Tow Relay
30	—	’97: Not Used
31	—	’98-’01: Not Used
31	7.5	’97: Rear Blower Motor Relay
32	10	’99-’01: Heated Mirror
	7.5	’97: Heated Rear Window
	10	’98: Rear Blower
33	15	Headlamps, Daytime Running Lamps (DRL) Module, Instrument Cluster
34	7.5	’98-’01: Rear Integrated Control Parrel, CD
34	7.5	’97: Luxury Audio System
35	7.5	’99-’01: Rear Blower Motor (With EATC)
	—	’97: Not Used
	10	’98: RABS Test Connector
36	7.5	’98-’01: EATC Memory (’99-’01), CD, Rear Integrated Control Panel, Memory Seat, Message Center
36	—	’97: Not Used

Engine Compartment Fuse Box (’97)

Mercury Mountaineer - fuse box diagram - engine compartment — Mercury Mountaineer – fuse box diagram – engine compartment

No.	A	Fused component
Maxi fuses
1	30	Rear window defrost
2	30	PCM power relay
3	20	Fuel system, anti-theft system
4	20	Headlamps
5	30	ABS system
6	30	ABS system
7	20	Trailer park LP and trailer stop LP
8	30	Battery saver relay and headlamp relay
9	50	Blower motor
10	30	Power locks, power windows and power
11	20	PCM memory and
12	50	Air ride control relay
13	60	Instrument panel fuse
14	60	Ignition
Mini fuses
1	30	JBL system
2	15	Rear wiper system
3	30	Power point
4	20	4WD system
5	15	Air suspension system
6	15	Alternator system
7	10	Air bag system
8	15	DRL/Fog lamps/Off-road lamps
9	—	Not used
10	—	Not used
11	20	HEGO system
Relay
1	Wiper run relay
2	Horn relay
3	Wiper HI/LO relay
4	WOT A/C relay
5	PCM power relay
6	Fuel pump relay
Diode
1	ABS diode
2	PCM diode

Engine Compartment Fuse Box (’98-’01)

No.	A	Protected components
Maxi Fuses
1	60	’99-’01: I/P Fuse Panel fuses 1,9, and 13
1	50	’98: I/P Fuse Panel
2	40	Blower Motor Relay
3	50	4 Wheel Anti-Lock Brake System (4WABS) Module
4	30	’99-’01: Power Moon Roof, Accessory Relay Delay (’01), Power Windows (’99-’00), Power Seat (’99-’00)
4	20	’98: Mainlight Switch, Instrument Cluster
5	50	Ignition Switch, Starter Relay
6	20	Transfer Case Relay
7	—	Not Used
8	20	Air Suspension (Automatic Ride Control ARC Switch Off/On Switch)
9	40	Air Suspension (Automatic Ride Control Relay)
10	30	PCM Power Relay
Mini Fuses
1	10	A/C Relay
2	30	’99-’01: Heated Seats
2	20	’98: Auxiliary Power Point
3	30	’99-’01: Heated Backlight
3	—	’98: Not Used
4	15	Fog Lamps and Daytime Running Lamps
5	—	’99-’01: Not Used
5	10	’98: Air Bag Diagnostic Monitor
6	10	Powertrain Control Module
7	30	4 Wheel Anti-Lock System (4WABS) Module
8	15	’99-’01: Rear Wiper Motor
8	30	’98: PCM Relay
9	20	Fuel Pump Relay and RAP Module
10	15	Horn Relay
11	15	Parklamps Relay and Mainlight Switch
12	30	Mainlight Switch and Multifunction Switch
13	15	Heated Oxygen Sensor, EGR Vacuum Regulator, EVR Solenoid, Camshaft Position (CMP) Sensor, Canister Vent Solenoid, A4LD Automatic Transmission (’98)
14	30	Generator/Voltage Regulator
15	—	Not Used
Relay
1	Wiper Park
2	A/C
3	Wiper High/Low
4	PCM Power
5	Fuel Pump
6	Starter
7	Horn
8	’99-’01: Rear Wiper Down
8	’98: Washer Pump
9	Blower Motor
10	’99-’01: Rear Wiper Up
10	’98: Fog Lamp
Diode / Resistor
1	’99-’01: Not Used
1	’98: Resistor: Fuse 7
1	’00-’01: Daytime Running Lamps Diode
	’98: Anti-Lock Brakes Indicator Diode
	’99: Not Used
2	Electronic Engine Controls Diode

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market
